PRECAUTION
Note. When disconnecting the cable from the negative (-) battery terminal, initialize the following system after the cable is reconnected.
| System Name | See procedure |
|---|---|
| Front power seat control system (w/ Memory) | INITIALIZATION |
| Meter gauge system | CALIBRATION |
SYSTEM NAME CHART
| CAUTION | When there are problems with contact points of terminals and improper part installation, the installation / removal of the suspected part may return the system to normal or may only temporarily return the system to normal. To determine the malfunctioning area, use DTCs, freeze frame data and other data to help determine conditions at the time of the malfunction. Write down the data before disconnecting connectors or installing / removing parts. The vehicle stability control system may be affected by malfunctions in other systems. Check for DTCs in other systems and, if present, troubleshoot those DTCs first. Unless specified, the ignition switch must be OFF when installing / removing the brake actuator and the vehicle stability control system's connectors. After the brake actuator or a vehicle stability control system connector has been removed and reinstalled, be sure to check for DTCs. Also, perform the test mode inspection to make sure the part is functioning normally. After replacing the yaw rate sensor and / or the skid control ECU, make sure to perform the yaw rate sensor and deceleration sensor zero point calibration. Since the CAN communication line has its own length and route, it cannot be repaired temporarily with a bypass wire, etc. |
Identifying Vehicle Stability Control System Parts Location (1 Of 2). Scheme 148
Identifying Vehicle Stability Control System Parts Location (2 Of 2). Scheme 149
Vehicle Stability Control System - System Diagram (1 Of 2). Scheme 150
Vehicle Stability Control System - System Diagram (2 Of 2). Scheme 151
FREEZE FRAME DATA
- FREEZE FRAME DATA HINT: When a DTC is detected or the ABS operates, the skid control ECU stores the current vehicle (sensor) state as freeze frame data. The skid control ECU stores the number of times (maximum: 31) the ignition switch has been turned from OFF to ON since the last time the ABS was activated. However, if the vehicle is stopped, the vehicle is driven at 7 km/h (4.3 mph) or less, or a DTC is detected, the ECU will not count the next time the ignition switch is turned from OFF to ON. Freeze frame data at the time the ABS operates: The skid control ECU stores data or updates stored data when the ABS operates. This data is erased when the ECU stores data at the time a DTC is detected. Freeze frame data at the time a DTC is detected: When the ECU stores data at the time a DTC is detected, the data will not be updated until the data is cleared. Connect the intelligent tester (with CAN VIM) to the DLC3. Turn the ignition switch ON. From the display on the tester, select Freeze Frame Data. FREEZE FRAME DATA Intelligent Tester Display Measurement Item Reference Value VEHICLE SPD Wheel speed sensor reading Speed indicated on speedometer STOP LIGHT SW Stop light switch signal Stop light switch ON: ON Stop light switch OFF: OFF #IGON Number of operations of ignition switch ON after memorizing freeze frame data 0 to 31 MAS CYL PRESS 1 Master cylinder pressure sensor output voltage Release brake pedal: 0.3 to 0.9 V Depress brake pedal: 3.2 to 4.5 V MAS PRESS GRADE Master cylinder pressure sensor changing declivity -30 to 200 MPa/s SYSTEM Operate system ABS activated: ABS BA activated: BA VSC (TRAC) operate: VSC (TRC) No system activated: No SYS Fail-safe mode activated: FAIL SF YAW RATE Yaw rate angle sensor output value -70 to 70 STEERING ANG Steering sensor output value Left turn: Increase Right turn: Drop THROTTLE Throttle position sensor output value Release accelerator pedal: Approx. 0° Depress accelerator pedal: Approx. 90° G (RIGHT & LEFT) Right and left G -1.5 to 1.5 G (BACK & FORTH) Back and forth G -1.5 to 1.5 SHIFT POSITION Shift lever position P: P* R: R N: N* D: D TRAC/VSC OFF M TRAC/VSC Off Mode Normal mode TRAC OFF mode VSC OFF mode HINT: *: The A/C switch is OFF and all accessory switches are OFF.
FAIL-SAFE CHART
- FAIL-SAFE OPERATION FAIL-SAFE CHART Malfunction Result ABS system Prohibit ABS, BA, TRAC and VSC control BA system Prohibit ABS, BA, TRAC and VSC control EBD system Prohibit EBD, ABS, BA, TRAC and VSC control TRAC system Prohibit TRAC and VSC control VSC system Prohibit TRAC and VSC control HINT: A malfunction in either the ABS or BA system will result in an identical fail-safe operation, with ABS, BA, EBD, TRAC and VSC system control prohibited. If a control is prohibited due to a malfunction during its operation, the control will be cut off gradually so that vehicle stability will not change suddenly.
