DESCRIPTION

The radio receiver sends sound signals to the stereo component amplifier.

Only Sound Of Radio, Cassette Tape Or CD Cannot Be Heard - Wiring Diagram. Scheme 1

Scheme 2

Scheme 3

1. CHECK RADIO RECEIVER ASSEMBLY Check the voltage of the receiver. (Scheme 2): Identifying Radio Receiver Assembly Connector Terminals Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Terminal Connection Condition Specified Condition R3-8 (R+) - R3-20 (GND) Audio system is sounding Waveform synchronized with sound is output R3-18 (R-) - R3-20 (GND) Audio system Is sounding Waveform synchronized with sound is output R3-9 (L+) - R3-20 (GND) Audio system is sounding Waveform synchronized with sound is output R3-19 (L-) - R3-20 (GND) Audio system is sounding Waveform synchronized with sound is output NG: REPLACE RADIO RECEIVER ASSEMBLY OK: Go to next step
2. CHECK WIRE HARNESS (RADIO RECEIVER - STEREO COMPONENT AMPLIFIER) Disconnect the R3 receiver connector. (Scheme 3): Identifying R3 Receiver Connector Terminals Disconnect the S23 amplifier connector. Measure the resistance of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Terminal Connection Condition Specified Condition S23-11 (R+) - R3-8 (R+) Audio system is sounding Waveform synchronized with sound is output S23-23 (R-) - R3-18 (R-) Audio system is sounding Waveform synchronized with sound is output S23-12 (L+) - R3-9 (L+) Audio system is sounding Waveform synchronized with sound is output S23-24 (L-) - R3-19 (L-) Audio system Is sounding Waveform synchronized with sound is output NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: REPLACE STEREO COMPONENT AMPLIFIER ASSEMBLY

The radio receiver panel illuminates when the light control switch is set to the TAIL or HEAD position.

Illumination - Wiring Diagram. Scheme 4

Scheme 5

Scheme 6

1. INSPECT NIGHTTIME ILLUMINATION Turn on the light switch and check the nighttime illuminations of the vehicle interior. Result: RESULT CHART Result Proceed to Only radio receiver nighttime illumination does not activate A No nighttime illumination at all B B: GO TO «COMBINATION METER»(ref-283180-S32187046362008041900000) A: Go to next step
2. CHECK DRIVER SIDE JUNCTION BLOCK (PANEL2 VOLTAGE) Removed the 2E junction block connector. (Scheme 5): Identifying 2E Junction Block Connector Terminals Measure the voltage of the wire harness side connector. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition PANEL2 (2E-5) - Body ground 10 to 14 V NG: REPLACE DRIVER SIDE JUNCTION BLOCK OK: Go to next step
3. CHECK WIRE HARNESS (RADIO RECEIVER - DRIVER SIDE JUNCTION BLOCK AND BODY GROUND) Disconnect the R3 receiver connector. (Scheme 6): Identifying R3 Receiver Connector Terminals Measure the voltage and resistance of the wire harness side connector. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition ILL+ (R3-2) - Body ground Light control switch OFF Below 1 V ILL+ (R3-2) - Body ground Light control switch TAIL or HEAD 10 to 14 V Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition ILL- (R3-12) - Body ground Below 1 ohms NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

The stereo component amplifier sends sound signals to the speakers.

Speaker - Wiring Diagram. Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. CHECK SPEAKER Result: RESULT CHART Result Proceed to All speakers do not sound A A speaker does not sound B B: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE B: Go to next step
2. CHECK SPEAKER Result: RESULT CHART Result Proceed to Front No. 1 speaker does not sound A Front No. 2 speaker does not sound B Stereo component speaker does not sound C Rear speaker does not sound D Rear No. 2 speaker does not sound E B: Go to step 4 C: Go to step 6 D: Go to step 8 E: Go to step 10 A: Go to next step
3. INSPECT FRONT NO. 1 SPEAKER ASSEMBLY Check that malfunction disappears when the speaker is replaced with a normal one. OK: Malfunction disappears. HINT: Connect all connectors to speakers. If the right front or left front speaker is suspected to be malfunctioning, inspect by interchanging the right front and left front speaker. NG: REPLACE STEREO COMPONENT AMPLIFIER ASSEMBLY OK: END
4. CHECK WIRE HARNESS (STEREO COMPONENT AMPLIFIER - FRONT NO. 2 SPEAKER) Disconnect the S23 amplifier connector. (Scheme 8): Identifying S23 Amplifier Connector Terminals Disconnect the D15 or D16 speaker connector. Measure the resistance of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition S23-1 (TFR+) - D16-1 Below 1 ohms S23-14 (TFR-) - D16-2 Below 1 ohms S23-2 (TFL+) - D15-1 Below 1 ohms S23-15 (TFL-) - D15-2 Below 1 ohms S23-1 (TFR+) - Body ground 10 kohms or higher S23-14 (TFR-) - Body ground 10 kohms or higher S23-2 (TFL+) - Body ground 10 kohms or higher S23-15 (TFL-) - Body ground 10 kohms or higher NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
5. INSPECT FRONT NO. 2 SPEAKER ASSEMBLY Disconnect the D15 or D16 speaker connector. (Scheme 9): Identifying D15 Or D16 Speaker Connector Terminals Measure the resistance of the speaker. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 1 - 2 Approx. 5.4 ohms NG: REPLACE FRONT NO. 2 SPEAKER ASSEMBLY OK: REPLACE STEREO COMPONENT AMPLIFIER ASSEMBLY
6. CHECK WIRE HARNESS (STEREO COMPONENT AMPLIFIER - STEREO COMPONENT SPEAKER) Disconnect the S22 amplifier connector. (Scheme 10): Identifying S22 Amplifier Connector Terminals Disconnect the W4 or W5 speaker connector. Measure the resistance of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition S22-1 (FR+) - W5-1 Below 1 ohms S22-8 (FR-) - W5-2 Below 1 ohms S22-2 (FL+) - W4-1 Below 1 ohms S22-9 (FL-) - W4-2 Below 1 ohms S22-1 (FR+) - Body ground 10 kohms or higher S22-8 (FR-) - Body ground 10 kohms or higher S22-2 (FL+) - Body ground 10 kohms or higher S22-9 (FL-) - Body ground 10 kohms or higher NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
7. INSPECT STEREO COMPONENT SPEAKER ASSEMBLY Disconnect the W4 or W5 speaker connector. (Scheme 11): Identifying W4 Or W5 Speaker Connector Terminals Measure the resistance of the speaker. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 1 - 2 Approx. 8 ohms NG: REPLACE STEREO COMPONENT SPEAKER ASSEMBLY OK: REPLACE STEREO COMPONENT AMPLIFIER ASSEMBLY
8. CHECK WIRE HARNESS (STEREO COMPONENT AMPLIFIER - REAR SPEAKER) Disconnect the S22 amplifier connector. (Scheme 12): Identifying S22 Amplifier Connector Terminals Disconnect the R10 or R11 speaker connector. Measure the resistance of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition S22-3 (RR+) - R11-1 Below 1 ohms S22-10 (RR-) - R11-2 Below 1 ohms S22-4 (RL+) - R10-1 Below 1 ohms S22-11 (RL-) - R10-2 Below 1 ohms S22-3 (RR+) - Body ground 10 kohms or higher S22-10 (RR-) - Body ground 10 kohms or higher S22-4 (RL+) - Body ground 10 kohms or higher S22-11 (RL-) - Body ground 10 kohms or higher NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
9. INSPECT STEREO COMPONENT SPEAKER ASSEMBLY Disconnect the R10 or R11 speaker connector. (Scheme 13): Identifying R10 Or R11 Speaker Connector Terminals Measure the resistance of the speaker. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 1 - 2 Approx. 8 ohms NG: REPLACE REAR SPEAKER ASSEMBLY OK: REPLACE STEREO COMPONENT AMPLIFIER ASSEMBLY
10. CHECK WIRE HARNESS (STEREO COMPONENT AMPLIFIER - REAR NO. 2 SPEAKER ASSEMBLY) Disconnect the S22 amplifier connector. (Scheme 14): Identifying S22 Amplifier Connector Terminals Disconnect the W6 speaker connector. Measure the resistance of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition S22-6 (WF-) - W6-1 Below 1 ohms S22-5 (WF+) - W6-2 Below 1 ohms S22-6 (WF-) - Body ground 10 kohms or higher S22-5 (WF+) - Body ground 10 kohms or higher NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
11. INSPECT REAR NO. 2 SPEAKER ASSEMBLY Disconnect the W6 speaker connector. (Scheme 15): Identifying W6 Speaker Connector Terminals Measure the resistance of the speaker. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition 1 - 2 Approx. 8 ohms NG: REPLACE REAR NO. 2 SPEAKER ASSEMBLY OK: REPLACE STEREO COMPONENT AMPLIFIER ASSEMBLY

The radio receiver sends sound signals to the stereo component amplifier. The amplifier then amplifies the signal, and the amplified signal is sent to the speakers.

If this circuit is open or shorted, no sound will come out of the speakers even if the amplifier and speakers are functioning properly.

Amp Sound Signal Circuit Between Radio Receiver Assembly And Stereo Component Tuner - Wiring Diagram. Scheme 16

Scheme 17

1. CHECK WIRE HARNESS (RADIO RECEIVER - STEREO COMPONENT AMPLIFIER) Disconnect the R3 receiver connector. (Scheme 17): Identifying R3 Receiver Connector Terminals Disconnect the S23 amplifier connector. Measure the resistance of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition R3-8 (R+) - S23-11 (R+) Below 1 ohms R3-9 (L+) - S23-12 (L+) Below 1 ohms R3-18 (R-) - S23-23 (R-) Below 1 ohms R3-19 (L-) - S23-24 (L-) Below 1 ohms R3-8 (R+) or S23-11 (R+) - Body ground 10 kohms or higher R3-9 (L+) or S23-12 (L+) - Body ground 10 kohms or higher R3-18 (R-) or S23-23 (R-) - Body ground 10 kohms or higher R3-19 (L-) or S23-24 (L-) - Body ground 10 kohms or higher NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

Mute signals are sent to the stereo component amplifier to mute noises that occur when muting the sound source. If the navigation system is available, the mute signal also mutes CD audio, etc. when the navigation system's voice guidance is on.

If the circuit is open: 1) noise will occur when the sound source is changed, and 2) if the navigation system is available, CD audio, etc. will not mute while the voice guidance is on.

If the circuit is shorted: 1) even if the amplifier is functioning properly, no sounds or only barely audible sounds will be output.

Mute Signal Circuit Between Radio Receiver And Stereo Component Amplifier - Wiring Diagram. Scheme 18

Scheme 19

Scheme 20

1. CHECK WIRE HARNESS (RADIO RECEIVER - STEREO COMPONENT AMPLIFIER) Disconnect the R3 receiver connector. Disconnect the S23 amplifier connector. (Scheme 19): Identifying S23 Amplifier Connector Terminals Measure the resistance of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition R3-7 (MUTE) - S23-21 (MUTE) Below 1 ohms R3-7 (MUTE) or S23-21 (MUTE) -Body ground 10 kohms or higher NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
2. CHECK STEREO COMPONENT AMPLIFIER ASSEMBLY (MUTE VOLTAGE) (Scheme 20): Identifying Stereo Component Amplifier Assembly Connector Terminals Measure the voltage of the amplifier. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition S23-21 (MUTE) - Body ground Turn ignition switch to ACC. Audio system is playing Above 3.5 V S23-21 (MUTE) - Body ground Turn ignition switch ACC. Audio system mode is Changing Below 1 V NG: REPLACE STEREO COMPONENT AMPLIFIER ASSEMBLY OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

AVC-LAN - Wiring Diagram. Scheme 21

Scheme 22

Scheme 23

Scheme 24

1. INSPECT RADIO RECEIVER ASSEMBLY Disconnect the R3 receiver connector. (Scheme 22): Identifying R3 Receiver Connector Terminals Measure the resistance of the receiver. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition R3-5 (TX+) - R3-15 (TX-) 60 to 80 ohms NG: REPLACE RADIO RECEIVER ASSEMBLY OK: Go to next step
2. CHECK WIRE HARNESS (RADIO RECEIVER - STEREO COMPONENT AMPLIFIER) Disconnect the R3 receiver connector. (Scheme 23): Identifying R3 Receiver Connector Terminals Disconnect the S23 amplifier connector. Measure the resistance of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition R3-5 (TX+) - S23-6 (TDX+) Below 1 ohms R3-15 (TX-) - S23-19 (TDX-) Below 1 ohms R3-5 (TX+) - Body ground 10 kohms or higher R3-15 (TX-) - Body ground 10 kohms or higher NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
3. INSPECT STEREO COMPONENT AMPLIFIER ASSEMBLY Temporarily replace the amplifier with a new or normally functioning amplifier. Turn the ignition switch to ACC and check that the amplifier is functioning properly by operating the radio receiver switches. OK: Amplifier can be operated by radio receiver switches. OK: END NG: Go to next step
4. INSPECT RADIO RECEIVER ASSEMBLY Temporarily replace the radio receiver with a new or normally functioning radio receiver. Turn the ignition switch to ACC and check that the radio receiver switches are functioning properly. OK: Radio receiver switches are functioning properly. OK: END NG: Go to next step
5. CHECK WIRE HARNESS (RADIO RECEIVER - GATEWAY ECU) Disconnect the R1 receiver connector. Disconnect the G3 ECU connector. (Scheme 24): Identifying G3 ECU Connector Terminals Measure the resistance of the wire harness side connector. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition R1-3 (TXS+) - G3-6 (GTX+) Below 1 ohms R1-6 (TXS-) - G3-21 (GTX-) Below 1 ohms R1-3 (TXS+) - Body ground 10 kohms or higher R1-6 (TXS-) - Body ground 10 kohms or higher NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

The stereo component amplifier's Auto Sound Levelizer (ASL) adjusts the audio volume in accordance with vehicle noise. For example, when vehicle noise increases, the ASL automatically increases the audio's volume.

In a standard system, the ASL uses speed signals from the combination meter and a microphone to determine audio volume.

In a Mark Levinson system, the ASL uses speed signals from the combination meter to determine audio volume.

Speed Signal - Wiring Diagram. Scheme 25

Scheme 26

Scheme 27

1. CHECK WIRE HARNESS (STEREO COMPONENT AMPLIFIER - COMBINATION METER) Disconnect the S23 amplifier connector. Disconnect the C8 meter connector. (Scheme 26): Identifying C8 Meter Connector Terminals Measure the resistance of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition S23-13 (SPD) - C8-21 (+S) Below 1 ohms S23-13 (SPD) - Body ground 10 kohms or higher NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
2. CHECK COMBINATION METER ASSEMBLY (+S VOLTAGE) (Scheme 27): Identifying Combination Meter Assembly Connector Terminals Jack up either of the rear wheels. Move the shift lever to N. Measure the voltage of the meter connectors. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition C8-21 (+S) - Body ground Ignition switch ON and turn rear wheel Voltage is pulsed NG: GO TO METER / GAUGE SYSTEM (See «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-283180-S42151122152008041900000) ) NG: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit provides power to the audio door control switch.

Door Control Switch - Wiring Diagram. Scheme 28

Scheme 29

Scheme 30

1. CHECK WIRE HARNESS (RADIO RECEIVER - AUDIO DOOR CONTROL SWITCH) Disconnect the R1 receiver connector. (Scheme 29): Identifying R1 Receiver Connector Terminals Disconnect the A25 switch connector. Measure the resistance of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition R1-2 (DOS1) - A25-8 Below 1 ohms R1-2 (DOS1) - Body ground 10 kohms or higher NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
2. CHECK WIRE HARNESS (AUDIO DOOR CONTROL SWITCH - BATTERY AND BODY GROUND) Disconnect A25 connector. (Scheme 30): Identifying A25 Connector Terminals Measure the resistance and voltage of the wire harness side connector. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition A25-6 (GND) - Body ground Below 1 ohms Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition A25-10 (+B) - Body ground Always 10 to 14 V A25-4 (ACC) - Body ground Ignition switch ACC 10 to 14 V NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
3. REPLACE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY LOWER CENTER (AUDIO DOOR CONTROL SWITCH) After replacing the instrument cluster finish panel lower center (audio door control switch), check that the audio door can be opened and closed by using the audio door control switch. OK: Audio door can be opened and closed with switch. NG: REPLACE RADIO RECEIVER ASSEMBLY OK: END

This circuit provides power to the radio receiver.

Radio Receiver Power Source - Wiring Diagram. Scheme 31

Scheme 32

1. INSPECT FUSE (RADIO NO. 1, RADIO NO. 2, AM1) Remove the RADIO NO. 1 fuse from the engine room No. 1 relay block. Remove the RADIO NO. 2 fuse from the passenger side junction block. Remove the AM1 fuse from the driver side junction block. Measure the resistance of the fuses. Standard resistance: Below 1 ohms NG: REPLACE FUSE OK: Go to next step
2. CHECK WIRE HARNESS (RADIO RECEIVER - BATTERY AND BODY GROUND) Disconnect the R3 receiver connector. (Scheme 32): Identifying R3 Receiver Connector Terminals Measure the voltage and resistance of the wire harness side connector. Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition R3-1 (+B) - Body ground Always 10 to 14 V R3-11 (ACC) - Body ground Ignition switch ACC 10 to 14 V Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition R3-20 (GND) - Body ground Below 1 ohms NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit provides power to the stereo component amplifier.

Stereo Component Amplifier Power Source - Wiring Diagram. Scheme 33

Scheme 34

1. INSPECT FUSE (RADIO NO. 1, RADIO NO. 2, AM1) Remove the RADIO NO. 1 fuse from the engine room No. 1 relay block. Remove the RADIO NO. 2 fuse from the passenger side junction block. Remove the AM1 fuse from the driver side junction block. Measure the resistance of the fuses. Standard resistance: Below 1 ohms NG: REPLACE FUSE OK: Go to next step
2. CHECK WIRE HARNESS (STEREO COMPONENT AMPLIFIER - BATTERY AND BODY GROUND) Disconnect the S22 and S23 amplifier connectors. (Scheme 34): Identifying S22 And S23 Amplifier Connectors Terminals Measure the resistance and voltage of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Specified Condition S22-13 (GND) - Body ground Below 1 ohms S22-12 (E) - Body ground Below 1 ohms Standard voltage TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition S22-7 (+B) - Body ground Always 10 to 14 V S22-16 (+B) - Body ground Always 10 to 14 V S23-20 (ACC) - Body ground Ignition switch ACC 10 to 14 V NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

Identifying Radio Receiver Components (1 Of 2). Scheme 35

Identifying Radio Receiver Components (2 Of 2). Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. SET RADIO RECEIVER ASSEMBLY TO SHIPMENT MODE Take out all CDs. NOTE: If CD(s) cannot be taken out, do not attempt to take it out forcibly. Send the unit to a repair shop. While simultaneously pressing the "SEEK UP" and "DISK" switches, turn the ignition switch to ACC. (Scheme 37): Identifying Seek Up And Disk Switches HINT: The CD indicator light blinks during mode setting and it remains lit after the setting is completed. (Scheme 38): Identifying CD Indicator Light Blinks When the mode setting is completed, "SHIPMENT' appears on the display. Turn the ignition switch OFF.
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
3. REMOVE REAR CONSOLE UPPER PANEL GARNISH (See «REMOVAL»(ref-283177-S12462467572008041900000) )
4. REMOVE UPPER CONSOLE PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-283177-S12462467572008041900000) )
5. REMOVE AIR CONDITIONING CONTROL ASSEMBLY (See «REMOVAL»(ref-283177-S12462467572008041900000) )
6. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY LOWER CENTER Remove the 4 bolts and panel. Disconnect the connector. (Scheme 39): Locating Bolts And Panel
7. CONFIRM RADIO RECEIVER ASSEMBLY SHIPMENT MODE SETTING Look at the backside of the radio receiver and check that red sections can be seen through the holes near the "SHIP" marks. NOTE: If red sections cannot be seen, perform the shipment mode setting again. (Scheme 40): Locating Ship Marks
8. REMOVE RADIO RECEIVER ASSEMBLY Remove the 4 screws and 3 panel retainers. Remove the 4 bolts. Press the 2 claws shown in the illustration to detach them and remove the panel. NOTE: Do not forcibly press the claw as it may break. (Scheme 41): Identifying Panel Retainers And Screws Remove the 2 screws and No. 1 bracket. Remove the 2 screws and No. 2 bracket. (Scheme 42): Locating No. 1, 2 Bracket And Screws

Scheme 43

Scheme 44

Scheme 45

1. INSTALL RADIO RECEIVER ASSEMBLY Install the No. 1 bracket with the 2 screws. Install the No. 2 bracket with the 2 screws. (Scheme 43): Locating No. 1, 2 Bracket And Screws Attach the 2 claws to install the panel. Install the 4 bolts. Install the 3 panel retainers with the 4 screws. (Scheme 44): Identifying Panel Retainers And Screws
2. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY LOWER CENTER Connect the connector. Install the panel with the 4 bolts. NOTE: If the connector is connected with the battery connected, the system will start initialization. Vibration during initialization may cause problems in the radio receiver. (Scheme 45): Locating Bolts And Panel
3. INSTALL AIR CONDITIONING CONTROL ASSEMBLY (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
4. INSTALL UPPER CONSOLE PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
5. INSTALL REAR CONSOLE UPPER PANEL GARNISH (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
8. CHECK SRS WARNING LIGHT (See «INSTALLATION»(ref-283183-S18299305412008041900000) )

Identifying Multi-Display (W/ Navigation System) Components. Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE AIR CONDITIONING CONTROL ASSEMBLY (See «REMOVAL»(ref-283177-S12462467572008041900000) )
3. REMOVE INSTRUMENT PANEL SAFETY PAD GARNISH SUB-ASSEMBLY (See «REMOVAL»(ref-283177-S12462467572008041900000) )
4. REMOVE NO. 2 INSTRUMENT PANEL GARNISH SUB-ASSEMBLY (See «REMOVAL»(ref-283177-S12462467572008041900000) )
5. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY CENTER Remove the 2 bolts and 2 screws. Disconnect the connector. Then remove the multi-display (with panel) and clip. (Scheme 47): Locating Instrument Cluster Finish Panel Bolts And Screws
6. REMOVE MULTI-DISPLAY (CENTER DISPLAY) Remove the 4 screws on the both sides of the instrument panel finish upper panel. (Scheme 48): Locating Instrument Panel Finish Upper Panel Screws Remove the 6 screws and instrument panel finish panel No. 1 retainer. (Scheme 49): Locating Instrument Panel Finish Panel No. 1 Retainer And Screws Remove the 5 screws and instrument panel finish panel No. 2 retainer. Remove the instrument cluster finish center lower panel. (Scheme 50): Locating Instrument Panel Finish Panel No. 2 And Screws Remove the 2 screws. (Scheme 51): Locating Screws Remove the 2 screws and wiring harness clamp. Disconnect the 4 connectors, then remove the clamp. Remove the multi-display. (Scheme 52): Identifying Wiring Harness Clamp And Screws

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

1. INSTALL MULTI-DISPLAY (CENTER DISPLAY) Install the multi-display. Connect the 4 connectors and install the clamp. Install the harness clamp with the 2 screws. (Scheme 53): Identifying Wiring Harness Clamp And Screws Install the 2 screws. (Scheme 54): Locating Screws Install the No. 2 retainer with the 5 screws. (Scheme 55): Locating Instrument Panel Finish Panel No. 2 And Screws Install the No. 1 retainer with the 6 screws. (Scheme 56): Locating Instrument Panel Finish Panel No. 1 Retainer And Screws Install the instrument panel finish upper panel with the 4 screws to the both sides. (Scheme 57): Locating Instrument Panel Finish Upper Panel Screws
2. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY CENTER Connect the connector and detach the clip. Install the panel with the 2 bolts and 2 screws. (Scheme 58): Locating Instrument Cluster Finish Panel Bolts And Screws
3. INSTALL NO. 2 INSTRUMENT PANEL GARNISH SUB-ASSEMBLY (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
4. INSTALL INSTRUMENT PANEL SAFETY PAD GARNISH SUB-ASSEMBLY (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
5. INSTALL AIR CONDITIONING CONTROL ASSEMBLY (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
8. CHECK SRS WARNING LIGHT (See «INSTALLATION»(ref-283183-S35791853952008041900000) )

Identifying Stereo Component Amplifier Components (1 Of 3). Scheme 59

Identifying Stereo Component Amplifier Components (2 Of 3). Scheme 60

Identifying Stereo Component Amplifier Components (3 Of 3). Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-283191-S33402229792008041900000) )
3. REMOVE LUGGAGE COMPARTMENT FLOOR MAT
4. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH (See «REMOVAL»(ref-283191-S33402229792008041900000) )
5. REMOVE LUGGAGE COMPARTMENT TRIM COVER RH (See «REMOVAL»(ref-283191-S33402229792008041900000) )
6. REMOVE SPARE WHEEL COVER ASSEMBLY
7. REMOVE TOOL BOX COVER (See «REMOVAL»(ref-283191-S33402229792008041900000) )
8. REMOVE LUGGAGE COMPARTMENT TRIM COVER SUB-ASSEMBLY REAR (See «REMOVAL»(ref-283191-S33402229792008041900000) )
9. REMOVE TONNEAU COVER ASSEMBLY (See «REMOVAL»(ref-283191-S33402229792008041900000) )
10. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «REMOVAL»(ref-283191-S33402229792008041900000) )
11. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (See «REMOVAL»(ref-283191-S33402229792008041900000) )
12. REMOVE LUGGAGE COMPARTMENT TRAY BRACKET FRONT (See «INSTALLATION»(ref-283194-S13658024082008041900000) )
13. REMOVE STEREO COMPONENT AMPLIFIER ASSEMBLY w/o Mark Levinson Sound System: Remove the 2 bolts and nut. Disconnect the 2 connectors, then remove the amplifier. (Scheme 62): Locating Stereo Component Amplifier Bolts And Nut w/ Mark Levinson Sound System: Remove the 2 bolts and nut. Disconnect the 2 connectors, then remove the amplifier. (Scheme 63): Locating Stereo Component Amplifier Bolts And Nut
14. REMOVE NO. 1 AMPLIFIER BRACKET Remove the 2 screws and bracket. (Scheme 64): Locating No. 1 Amplifier Bracket And Screws
15. REMOVE NO. 2 AMPLIFIER BRACKET Remove the 2 screws and bracket. (Scheme 65): Locating No. 2 Amplifier Bracket And Screws

Scheme 66

Scheme 67

Scheme 68

Scheme 69

1. INSTALL NO. 2 AMPLIFIER BRACKET Install the bracket with the 2 screws. (Scheme 66): Locating No. 2 Amplifier Bracket And Screws
2. INSTALL NO. 1 AMPLIFIER BRACKET Install the bracket with the 2 screws. (Scheme 67): Locating No. 1 Amplifier Bracket And Screws
3. INSTALL STEREO COMPONENT AMPLIFIER ASSEMBLY w/ Mark Levinson Sound System: Connect the 2 connectors. Install the amplifier with the 2 bolts and nut. (Scheme 68): Locating Stereo Component Amplifier Bolts And Nut w/o Mark Levinson Sound System: Connect the 2 connectors. Install the amplifier with the 2 bolts and nut. (Scheme 69): Locating Stereo Component Amplifier Bolts And Nut
4. INSTALL LUGGAGE COMPARTMENT TRAY BRACKET FRONT (See «INSTALLATION»(ref-283194-S13658024082008041900000) )
5. INSTALL LUGGAGE COMPARTMENT TRIM COVER FRONT (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
6. INSTALL LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
7. INSTALL TONNEAU COVER ASSEMBLY (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
8. INSTALL LUGGAGE COMPARTMENT TRIM COVER SUB-ASSEMBLY REAR (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
9. INSTALL TOOL BOX COVER (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
10. INSTALL SPARE WHEEL COVER ASSEMBLY
11. INSTALL LUGGAGE COMPARTMENT TRIM COVER LH (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
12. INSTALL LUGGAGE COMPARTMENT TRIM COVER RH (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
13. INSTALL LUGGAGE COMPARTMENT FLOOR MAT
14. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
15. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
16. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Identifying Radio Antenna Cord Components With Torque Specifications (1 Of 8). Scheme 70

Identifying Radio Antenna Cord Components With Torque Specification (2 Of 8). Scheme 71

Identifying Radio Antenna Cord Components (3 Of 8). Scheme 72

Identifying Radio Antenna Cord Components With Torque Specifications (4 Of 8). Scheme 73

Identifying Radio Antenna Cord Components (5 Of 8). Scheme 74

Identifying Radio Antenna Cord Components (6 Of 8). Scheme 75

Identifying Radio Antenna Cord Components (7 Of 8). Scheme 76

Identifying Radio Antenna Cord Components (8 Of 8). Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

1. SET RADIO RECEIVER ASSEMBLY TO SHIPMENT MODE (See «REMOVAL»(ref-283181-S27203737922008041900000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
3. INSPECT CENTER FRONT WHEEL
4. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY Remove the instrument panel safety pad (see «REMOVAL»(ref-283177-S12462467572008041900000) ).
5. REMOVE FRONT WIPER ARM RH (See «REMOVAL»(ref-283192-S32739372242008041900000) )
6. REMOVE FRONT WIPER ARM LH (See «REMOVAL»(ref-283192-S32739372242008041900000) )
7. REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY (See «REMOVAL»(ref-283192-S32739372242008041900000) )
8. REMOVE WINDSHIELD WIPER LINK ASSEMBLY (See «REMOVAL»(ref-283192-S32739372242008041900000) )
9. REMOVE ANTENNA CORD SUB-ASSEMBLY Disconnect the connector. (Scheme 78): Identifying Antenna Cord Sub-Assembly Connector Remove the 3 clamps. (Scheme 79): Identifying Antenna Cord Sub-Assembly Clamps Remove the 2 nuts and antenna cord. (Scheme 80): Locating Antenna Cord Nuts
10. REMOVE CONSOLE UPPER PANEL GARNISH REAR (See «REMOVAL»(ref-283177-S12462467572008041900000) )
11. REMOVE UPPER CONSOLE PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-283177-S12462467572008041900000) )
12. REMOVE AIR CONDITIONING CONTROL ASSEMBLY (See «REMOVAL»(ref-283177-S12462467572008041900000) )
13. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY LOWER CENTER (See «REMOVAL»(ref-283181-S27203737922008041900000) )
14. REMOVE CONSOLE BOX CARPET
15. REMOVE NO. 3 BOX PANEL (See «REMOVAL»(ref-283177-S12462467572008041900000) )
16. REMOVE CONSOLE BOX ASSEMBLY (See «REMOVAL»(ref-283177-S12462467572008041900000) )
17. REMOVE REAR SEAT CUSHION ASSEMBLY (See «REMOVAL»(ref-283167-S15523135892008041900000) )
18. REMOVE REAR SEAT HEADREST PLATE COVER (See «REMOVAL»(ref-283167-S15523135892008041900000) )
19. REMOVE WIND DEFLECTOR BOARD ASSEMBLY (See «REMOVAL»(ref-283167-S15523135892008041900000) )
20. REMOVE REAR SEAT HEADREST PLATE (See «REMOVAL»(ref-283167-S15523135892008041900000) )
21. REMOVE REAR SEAT HEADREST ASSEMBLY (See «REMOVAL»(ref-283167-S15523135892008041900000) )
22. REMOVE REAR SEATBACK ASSEMBLY (See «DISASSEMBLY»(ref-283167-S05554962582008041900000) )
23. REMOVE TONNEAU COVER STOPPER SUB-ASSEMBLY RH (See «REMOVAL»(ref-283191-S33402229792008041900000) )
24. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-283191-S33402229792008041900000) )
25. REMOVE LUGGAGE COMPARTMENT FLOOR MAT
26. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH (See «REMOVAL»(ref-283191-S33402229792008041900000) )
27. REMOVE LUGGAGE COMPARTMENT TRIM COVER RH (See «REMOVAL»(ref-283191-S33402229792008041900000) )
28. REMOVE SPARE WHEEL COVER ASSEMBLY
29. REMOVE TOOL BOX COVER (See «REMOVAL»(ref-283191-S33402229792008041900000) )
30. REMOVE LUGGAGE COMPARTMENT TRIM COVER SUB-ASSEMBLY REAR (See «REMOVAL»(ref-283191-S33402229792008041900000) )
31. REMOVE TONNEAU COVER ASSEMBLY (See «REMOVAL»(ref-283191-S33402229792008041900000) )
32. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «REMOVAL»(ref-283191-S33402229792008041900000) )
33. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (See «REMOVAL»(ref-283191-S33402229792008041900000) )
34. REMOVE LUGGAGE COMPARTMENT TRIM COVER SIDE RH (See «DISASSEMBLY»(ref-283191-S28213072792008041900000) )
35. REMOVE NO. 3 ANTENNA CORD SUB-ASSEMBLY w/ Navigation System: Disconnect the 4 connectors. Remove the bolt. Remove the 14 clamps and antenna cord. (Scheme 81): Identifying Antenna Cord Clamps w/o Navigation System: Disconnect the 2 connectors. Remove the bolt. Remove the 13 clamps and antenna cord. (Scheme 82): Identifying Antenna Cord Clamps

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

1. INSTALL NO. 3 ANTENNA CORD SUB-ASSEMBLY w/o Navigation System: Install the antenna cord and 13 clamps. Install the bolt. Connect the 2 connectors. (Scheme 83): Identifying Antenna Cord And Clamps w/ Navigation System: Install the antenna cord and 14 clamps. Install the bolt. Connect the 4 connectors. (Scheme 84): Identifying Antenna Cord Clamps
2. INSTALL LUGGAGE COMPARTMENT TRIM COVER SIDE RH (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
3. INSTALL LUGGAGE COMPARTMENT TRIM COVER FRONT (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
4. INSTALL LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
5. INSTALL TONNEAU COVER ASSEMBLY (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
6. INSTALL LUGGAGE COMPARTMENT TRIM COVER SUB-ASSEMBLY REAR (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
7. INSTALL TOOL BOX COVER (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
8. INSTALL SPARE WHEEL COVER ASSEMBLY
9. INSTALL LUGGAGE COMPARTMENT TRIM COVER LH (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
10. INSTALL LUGGAGE COMPARTMENT TRIM COVER RH (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
11. INSTALL LUGGAGE COMPARTMENT FLOOR MAT
12. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
13. INSTALL TONNEAU COVER STOPPER SUB-ASSEMBLY RH (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
14. INSTALL REAR SEATBACK ASSEMBLY (See «DISASSEMBLY»(ref-283167-S05554962582008041900000) )
15. INSTALL REAR SEAT HEADREST ASSEMBLY (See «INSTALLATION»(ref-283167-S11653705542008041900000) )
16. INSTALL REAR SEAT HEADREST PLATE (See «INSTALLATION»(ref-283167-S11653705542008041900000) )
17. INSTALL WIND DEFLECTOR BOARD ASSEMBLY (See «INSTALLATION»(ref-283167-S11653705542008041900000) )
18. INSTALL REAR SEAT HEADREST PLATE COVER (See «INSTALLATION»(ref-283167-S11653705542008041900000) )
19. INSTALL REAR SEAT CUSHION ASSEMBLY (See «INSTALLATION»(ref-283167-S11653705542008041900000) )
20. INSTALL CONSOLE BOX ASSEMBLY (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
21. INSTALL NO. 3 BOX PANEL (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
22. INSTALL CONSOLE BOX CARPET
23. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY LOWER CENTER (See «INSTALLATION»(ref-283181-S42153828682008041900000) )
24. INSTALL AIR CONDITIONING CONTROL ASSEMBLY (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
25. INSTALL UPPER CONSOLE PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
26. INSTALL REAR CONSOLE UPPER PANEL GARNISH (See «INSTALLATION»(ref-283177-S14297446472008041900000) )
27. INSTALL ANTENNA CORD SUB-ASSEMBLY Install the antenna cord with the 2 nuts. (Scheme 85): Locating Antenna Cord Nuts Install the 3 clamps. (Scheme 86): Identifying Clamps Connect the connector. (Scheme 87): Identifying Antenna Cord Sub-Assembly Connector
28. INSTALL WINDSHIELD WIPER LINK ASSEMBLY (See «INSTALLATION»(ref-283192-S03382038922008041900000) )
29. INSTALL COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY
30. INSTALL FRONT WIPER ARM LH (See «INSTALLATION»(ref-283192-S03382038922008041900000) )
31. INSTALL FRONT WIPER ARM RH (See «INSTALLATION»(ref-283192-S03382038922008041900000) )
32. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY Install the instrument panel safety pad (see «INSTALLATION»(ref-283177-S14297446472008041900000) ).
33. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
34. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Identifying Radio Antenna Holder Components (1 Of 3). Scheme 88

Identifying Radio Antenna Holder Components (2 Of 3). Scheme 89

Identifying Radio Antenna Holder Components (3 Of 3). Scheme 90

Scheme 91

Scheme 92

1. CONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE TONNEAU COVER STOPPER SUB-ASSEMBLY RH (See «REMOVAL»(ref-283191-S33402229792008041900000) )
3. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-283191-S33402229792008041900000)
4. REMOVE LUGGAGE COMPARTMENT FLOOR MAT
5. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH (See «REMOVAL»(ref-283191-S33402229792008041900000) )
6. REMOVE LUGGAGE COMPARTMENT TRIM COVER RH (See «REMOVAL»(ref-283191-S33402229792008041900000) )
7. REMOVE SPARE WHEEL COVER ASSEMBLY
8. REMOVE TOOL BOX COVER (See «REMOVAL»(ref-283191-S33402229792008041900000) )
9. REMOVE LUGGAGE COMPARTMENT TRIM COVER SUB-ASSEMBLY REAR (See «REMOVAL»(ref-283191-S33402229792008041900000) )
10. REMOVE TONNEAU COVER ASSEMBLY (See «REMOVAL»(ref-283191-S33402229792008041900000) )
11. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «REMOVAL»(ref-283191-S33402229792008041900000) )
12. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (See «REMOVAL»(ref-283191-S33402229792008041900000) )
13. REMOVE LUGGAGE COMPARTMENT TRIM COVER SIDE RH (See «DISASSEMBLY»(ref-283191-S28213072792008041900000) )
14. REMOVE WITH HOLDER ANTENNA ASSEMBLY Remove the nut and antenna ornament. (Scheme 91): Identifying Antenna Ornament Nut Disconnect the connector and cord plug from the antenna. Remove the nut and antenna. (Scheme 92): Identifying Antenna And Nut

Scheme 93

Scheme 94

1. INSTALL WITH HOLDER ANTENNA ASSEMBLY Install the antenna with the nut. Connect the connector and plug to the antenna. (Scheme 93): Identifying Antenna And Nut Install the antenna ornament with the nut. (Scheme 94): Identifying Antenna Ornament Nut
2. INSTALL LUGGAGE COMPARTMENT TRIM COVER SIDE RH (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
3. INSTALL LUGGAGE COMPARTMENT TRIM COVER FRONT (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
4. INSTALL LUGGAGE COMPARTMENT TRIM COVER INNER LOWER (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
5. INSTALL TONNEAU COVER ASSEMBLY (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
6. INSTALL LUGGAGE COMPARTMENT TRIM COVER SUB-ASSEMBLY REAR (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
7. INSTALL TOOL BOX COVER (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
8. INSTALL SPARE WHEEL COVER ASSEMBLY
9. INSTALL LUGGAGE COMPARTMENT TRIM COVER LH (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
10. INSTALL LUGGAGE COMPARTMENT TRIM COVER RH (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
11. INSTALL LUGGAGE COMPARTMENT FLOOR MAT
12. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
13. INSTALL TONNEAU COVER STOPPER SUB-ASSEMBLY RH (See «INSTALLATION»(ref-283191-S32248558452008041900000) )
14. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
15. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-283168-S15934672912008041900000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
