| Application | Specifications |
|---|
| Compressor Type | Nippondenso 10PA20 10-Cyl. |
| Compressor Belt Tension | (1) |
| Compressor Oil Capacity (2) | 4.1 ozs. |
| Refrigerant (R-134a) Capacity | 31.7-35.3 ozs. |
| System Operating Pressures (3) |
| High Side | 199-228 psi (14-16 kg/cm 2 ) |
| Low Side | 21-36 psi (1.5-2.5 kg/cm 2 ) |
| (1) Belt tension is maintained automatically. (2) Use ND-OIL 8 (Part No. 38899-PR7-003). (3) Specification is with ambient temperature at 86-95°F 30-35°C) and engine speed at 1500 RPM. |
| (1) | Belt tension is maintained automatically. |
| (2) | Use ND-OIL 8 (Part No. 38899-PR7-003). |
| (3) | Specification is with ambient temperature at 86-95°F 30-35°C) and engine speed at 1500 RPM. |
A/C-HEATER SYSTEMS SPECIFICATIONS
DESCRIPTION
An Electronic Control Unit (ECU), located within the A/C-heater control panel, automatically controls all air conditioning and heating functions. Manual controls allow the driver to select air distribution mode and desired temperature. In addition to normal A/C system components, the system includes various motors, controls, and sensors. (Scheme 1) The system has self-diagnostic capabilities.
Scheme 1
