PRECAUTION [03/2012 - 07/2012]
- NOTICE FOR INITIALIZATION WARNING: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. System Name See Procedure Parking Assist Monitor System Refer to «INITIALIZATION [03/2012 - 07/2012]»(ref-602551-S24591545042014030500000) Back Door Closer System Power Back Door System
PRECAUTION [07/2012 - ]
- NOTICE FOR INITIALIZATION WARNING: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. System Name See Procedure Parking Assist Monitor System Refer to «INITIALIZATION [07/2012 - ]»(ref-602551-S38908041872014030500000) Back Door Closer System Power Back Door System
Scheme 71
Scheme 72
Scheme 73
![Scheme 73: SYSTEM DIAGRAM [03/2012 - ]](https://i.diagnostdata.com/repair/14/1486e3993d0a5ccbef06df140af8296d3b69e5649b2ca6317c305ea8c6958761.webp)
| Sender | Receiver | Signal | Line |
|---|---|---|---|
| ECM | Main Body ECU (Multiplex Network Body ECU) | Transmission information Shift position P signal | CAN |
| Outer Mirror Control ECU Assembly (Driver Side) | Main Body ECU (Multiplex Network Body ECU) | M1 switch signal M2 switch signal M3 switch signal SET switch signal | CAN |
| Main Body ECU (Multiplex Network Body ECU) | Position Control ECU and Switch Assembly | Shift position P signal Engine switch signal Parking brake switch signal Vehicle speed signal Transmission information Driver's position buzzer request Driver seat return and away position data Driver seat position request Driver position data | CAN |
| Certification ECU (Smart Key ECU Assembly) | Main Body ECU (Multiplex Network Body ECU) | Smart memory call replay request Key identification No 1 to No. 7 acquisition condition | CAN |
| Position Control ECU and Switch Assembly | Main Body ECU (Multiplex Network Body ECU) | State signal of driver seat State signal of driver position buzzer Driver's seat belt buckle switch status | CAN |
| Park / Neutral Position Switch Assembly | ECM | Shift position P signal | Local communication |
| Front Door Courtesy Light Switch Assembly | Main Body ECU (Multiplex Network Body ECU) | Front door courtesy light switch assembly signal | Local communication |
| Seat Memory Switch | Outer Mirror Control ECU Assembly (Driver Side) | M1 switch signal M2 switch signal M3 switch signal SET switch signal | Local communication |
| Front seat inner belt assembly LH | Position Control ECU and Switch Assembly | Driver seat buckle switch signal | Local communication |
COMMUNICATION TABLE
CUSTOMIZE PARAMETERS [03/2012 - ]
- CUSTOMIZING FUNCTION WITH TECHSTREAM (REFERENCE) HINT: When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Utility / Customize Setting. Select the setting by referring to the table below. MAIN BODY Tester Display Default Content Setting Seat Move Distance Standard Allows customizing of the seat movement distance for the power easy access system. OFF / Little / Standard
- CUSTOMIZING FUNCTION WITH MULTI-DISPLAY HINT: The items in the table below can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current setting before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. Customizing with the multi-display Turn the engine switch on (IG). Enter the following menus: Menu / Setup / Vehicle / Vehicle Settings / Vehicle Customization / Other Vehicle Settings Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Driver's Seat Easy Exit Full Allows customizing of the seat movement distance for the power easy access system. Full / Partial / Off Front power seat switch (driver side)
- CUSTOMIZING FUNCTION WITH COMBINATION METER ASSEMBLY HINT: Press the UP/DOWN switch on the steering pad switch assembly when changing an item selection. Press the ENTER switch on the steering pad switch assembly when selecting an item. Turn the engine switch on (IG). Press and hold the MENU switch on the steering pad switch assembly. Select the setting by referring to the table below Display Default Content Setting Relevant ECU DRIVER'S SEAT EASY EXIT FULL Allows customizing of the seat movement distance for the power easy access system. FULL / PARTIAL / OFF Front power seat switch (driver side) Press the ENTER switch on the steering pad switch assembly. The setting completion screen will be displayed. Return to the item selection screen.
