Charging System (Service Information): Removal & Installation Lexus RX III рестайлинг

REMOVAL [07/2012 - ]

1. PRECAUTION NOTE: After turning the engine switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to «PRECAUTION [03/2012 - ]»(ref-602551-S11461672722014030500000) .
2. REMOVE RADIATOR ASSEMBLY WITH FAN SHROUD AND FAN MOTOR HINT: Refer to «REMOVAL [07/2012 - ]»(ref-602691-S10594216172014030500000) .
3. REMOVE V-RIBBED BELT HINT: Refer to «REMOVAL [07/2012 - ]»(ref-602689-S01251316472014030500000) .
4. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL [07/2012 - ] - Step 34»(ref-602689-S23172420682014030500000)
5. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Refer to «PRECAUTION [07/2012 - ]»(ref-602724-S13282392072014030500000) . NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [07/2012 - ]»(ref-602551-S38908041872014030500000) .
6. REMOVE GENERATOR ASSEMBLY Turn back the terminal cap. Remove the nut and disconnect the wire harness from terminal B. Disconnect the generator connector from the generator assembly. Disconnect the connector from the compressor and magnetic clutch. Disconnect the wire harness clamps. Remove the bolt, nut and generator bracket from the cylinder block. Disconnect the wire harness clamp and remove the generator bracket. Remove the 2 bolts. Remove the bolt and the wire harness clamp stay.

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. REMOVE GENERATOR REAR END COVER Remove the 3 nuts and generator rear end cover.
2. REMOVE TERMINAL INSULATOR Remove the terminal insulator from the generator coil assembly.
3. REMOVE GENERATOR BRUSH HOLDER ASSEMBLY Remove the 2 screws and generator brush holder assembly from the generator coil assembly.
4. REMOVE GENERATOR COIL ASSEMBLY Remove the 4 bolts. Using SST, remove the generator coil assembly. TEXT IN ILLUSTRATION *1 Turn *2 Hold SST: 09950-40011 09951-04020 09952-04010 09953-04020 09954-04010 09955-04071 09957-04010 09958-04011 Remove the generator washer.
5. REMOVE GENERATOR CLUTCH PULLEY Using a screwdriver, puncture the center of the generator pulley cap and pry it off. NOTE: Do not reuse the generator pulley cap. Mount the generator drive end frame in a vise tightly. Confirm SST (A) and (B) shown in the illustration. TEXT IN ILLUSTRATION *1 SST (A) *2 SST (B) SST: 09820-63021 Place the rotor shaft end into SST (A). TEXT IN ILLUSTRATION *1 Rotor Shaft *2 SST (A) Fit SST (B) to the clutch pulley. TEXT IN ILLUSTRATION *1 Clutch Pulley *2 SST (B) *3 SST (A) Loosen the pulley by turning SST (B) in the direction shown in the illustration. NOTE: Check that the drive end frame is secured in the vise tightly. Hold SST (A) tightly during the operation. TEXT IN ILLUSTRATION *1 SST (B) *2 SST (A) Remove SST from the generator assembly. Remove the clutch pulley from the rotor shaft.
6. REMOVE GENERATOR ROTOR ASSEMBLY Remove the generator rotor assembly.

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

1. INSPECT GENERATOR CLUTCH PULLEY Hold the center of the pulley, and confirm that the outer ring turns counterclockwise and does not turn clockwise. TEXT IN ILLUSTRATION *1 Free *2 Lock If the result is not as specified, replace the clutch pulley.
2. INSPECT GENERATOR DRIVE END FRAME BEARING Check that the bearing is not rough or worn. OK The bearing rotates smoothly. If the bearing does not rotate smoothly, replace the bearing.
3. INSPECT GENERATOR BRUSH HOLDER ASSEMBLY Using a vernier caliper, measure the length of the exposed brushes. TEXT IN ILLUSTRATION *1 Length Standard exposed length 9.5 to 11.5 mm (0.375 to 0.452 in.) Minimum exposed length 4.5 mm (0.178 in.) If the exposed length is less than the minimum, replace the brush holder assembly.
4. INSPECT GENERATOR ROTOR ASSEMBLY Check that the generator rotor bearing is not rough or worn. If necessary, replace the generator rotor assembly. Check the generator rotor for an open circuit. TEXT IN ILLUSTRATION *1 Slip Ring *2 Ohmmeter Using an ohmmeter, measure the resistance between the slip rings. Standard Resistance Condition Specified Condition Approx. 20°C (68°F) 1.5 to 1.9 ohms If the result is not as specified, replace the generator rotor assembly. Check the rotor for a short to ground. TEXT IN ILLUSTRATION *1 Slip Ring *2 Rotor *3 Ohmmeter Using an ohmmeter, measure the resistance between the slip ring and rotor. Standard Resistance Tester Connection Specified Condition Slip ring - Rotor 1 Mohms or higher If the result is not as specified, replace the generator rotor assembly. Using a vernier caliper, measure the slip ring diameter. TEXT IN ILLUSTRATION *1 Diameter Standard diameter 14.2 to 14.4 mm (0.560 to 0.566 in.) Minimum diameter 14.0 mm (0.552 in.) If the diameter is less than the minimum, replace the generator rotor assembly.

Scheme 47

Scheme 48

Scheme 49

Scheme 50

1. REPLACE GENERATOR DRIVE END FRAME BEARING Remove the 4 screws and retainer plate from the generator drive end frame. Using SST and a hammer, tap out the generator drive end frame bearing from the generator drive end frame. SST: 09950-60010 09951-00250 SST: 09950-70010 09951-07100 Using SST and a press, press in a new generator drive end frame bearing. SST: 09950-60010 09951-00470 SST: 09950-70010 09951-07100 Fit the tabs on the retainer plate into the cutouts on the generator drive end frame to install the retainer plate. TEXT IN ILLUSTRATION *1 Tab *2 Cutout Install the 4 screws. Torque: 2.3 N*m (23 kgf*cm, 20 in.*lbf)

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

1. INSTALL GENERATOR ROTOR ASSEMBLY Place the generator drive end frame on the clutch pulley. Install the generator rotor assembly to the generator drive end frame.
2. INSTALL GENERATOR CLUTCH PULLEY Temporarily install the clutch pulley onto the rotor shaft. Mount the generator drive end frame in a vise tightly. Confirm SST (A) and (B) shown in the illustration. TEXT IN ILLUSTRATION *1 SST (A) *2 SST (B) SST: 09820-63021 Place the rotor shaft end into SST (A). TEXT IN ILLUSTRATION *1 Rotor Shaft *2 SST (A) Fit SST (B) to the clutch pulley. TEXT IN ILLUSTRATION *1 Clutch Pulley *2 SST (B) *3 SST (A) Tighten the pulley by turning SST (B) in the direction shown in the illustration. TEXT IN ILLUSTRATION *1 SST (B) *2 SST (A) *3 Fulcrum Length: 400 mm without SST Torque: 80 N*m (816 kgf*cm, 59 ft.*lbf) with SST Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf) NOTE: The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 400 mm (1.312 ft.). This torque value is effective when SST is parallel to the torque wrench. Check that the drive end frame is secured in the vise tightly. Hold SST (A) tightly during the operation. Remove SST from the generator assembly. Check that the clutch pulley rotates smoothly. Install a new generator pulley cap to the clutch pulley.
3. INSTALL GENERATOR COIL ASSEMBLY Place a new generator washer on the generator rotor. Using a deep socket wrench (21 mm) and a press, slowly press in the generator coil assembly. TEXT IN ILLUSTRATION *1 Deep Socket Wrench (21 mm) Install the 4 bolts. Torque: 5.8 N*m (59 kgf*cm, 51 in.*lbf)
4. INSTALL GENERATOR BRUSH HOLDER ASSEMBLY While pushing the 2 brushes into the generator brush holder assembly, insert a 1.0 mm (0.039 in.) diameter pin into the brush holder hole. TEXT IN ILLUSTRATION *1 Pin Install the brush holder assembly to the generator coil with the 2 screws. TEXT IN ILLUSTRATION *1 Pin Torque: 1.8 N*m (18 kgf*cm, 16 in.*lbf) Pull out the pin from the generator brush holder.
5. INSTALL TERMINAL INSULATOR Install the terminal insulator to the generator coil. NOTE: Pay attention to the installation direction of the terminal insulator.
6. INSTALL GENERATOR REAR END COVER Install the generator rear end cover to the generator coil with the 3 nuts. Torque: 4.6 N*m (47 kgf*cm, 41 in.*lbf)

Scheme 58

1. INSTALL GENERATOR ASSEMBLY Install the wire harness clamp stay with the bolt. Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf) Install the 2 bolts. Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf) Connect the wire harness clamp. Install the generator assembly and generator bracket with the bolt and nut. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) Connect the generator connector to the generator assembly. Install the generator wire with the nut. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf) Install the terminal cap. Connect the wire harness clamps. Connect the magnetic clutch connector to the compressor and magnetic clutch.
2. INSTALL V-RIBBED BELT HINT: Refer to «INSTALLATION [03/2012 - 07/2012]»(ref-602689-S38725693222014030500000) .
3. INSTALL RADIATOR ASSEMBLY WITH FAN SHROUD AND FAN MOTOR HINT: Refer to «INSTALLATION [03/2012 - 07/2012]»(ref-602691-S11045437542014030500000) .
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [03/2012 - 07/2012]»(ref-602551-S24591545042014030500000) .
5. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 108»(ref-602689-S39902766612014030500000)

INSTALLATION [07/2012 - ]

1. INSTALL GENERATOR ASSEMBLY Install the wire harness clamp stay with the bolt. Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf) Install the 2 bolts. Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf) Connect the wire harness clamp. Install the generator assembly and generator bracket with the bolt and nut. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) Connect the generator connector to the generator assembly. Install the generator wire with the nut. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf) Install the terminal cap. Connect the wire harness clamps. Connect the magnetic clutch connector to the compressor and magnetic clutch.
2. INSTALL V-RIBBED BELT HINT: Refer to «INSTALLATION [07/2012 - ]»(ref-602689-S34970785562014030500000) .
3. INSTALL RADIATOR ASSEMBLY WITH FAN SHROUD AND FAN MOTOR HINT: Refer to «INSTALLATION [07/2012 - ]»(ref-602691-S38924193342014030500000) .
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [07/2012 - ]»(ref-602551-S38908041872014030500000) .
5. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION [07/2012 - ] - Step 113»(ref-602689-S30369469832014030500000)
