Seat Belt Warning (Diagnostics): Other Lexus RX III

Warning System 5 illustrations ~2134 words

PRECAUTION

Note. When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. System Name See Procedure Parking Assist Monitor System Refer to INITIALIZATION Side Monitor System (w/ Parking Assist Monitor System) Back Door Closer System Power Back Door System

  1. PRECAUTION WHEN USING TECHSTREAM When using the Techstream to troubleshoot the power door lock control system: Connect the Techstream to the DLC3 while the engine switch is off, and turn a door courtesy light switch on and off at 1.5-second intervals until communication between the Techstream and vehicle begins.

Note. When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. System Name See Procedure Parking Assist Monitor System Refer to INITIALIZATION Side Monitor System (w/ Parking Assist Monitor System) Back Door Closer System Power Back Door System

  1. PRECAUTION WHEN USING TECHSTREAM When using the Techstream to troubleshoot the power door lock control system: Connect the Techstream to the DLC3 while the engine switch is off, and turn a door courtesy light switch on and off at 1.5-second intervals until communication between the Techstream and vehicle begins.

Scheme 155

Scheme 155: ILLUSTRATION
Scheme 155: ILLUSTRATION

Scheme 156

Scheme 156: ILLUSTRATION
Scheme 156: ILLUSTRATION

Scheme 157

Scheme 157: ILLUSTRATION
Scheme 157: ILLUSTRATION

Scheme 158

Scheme 158: SYSTEM DIAGRAM
Scheme 158: SYSTEM DIAGRAM

Scheme 159

Scheme 159
Scheme 159
  1. w/ Occupant Classification System COMMUNICATION TABLE Sender Receiver Signal Communication Method Center airbag sensor assembly Combination meter assembly Front seat inner belt buckle switch signal (for driver side) Front seat inner belt buckle switch signal (for front passenger side) Occupant detection signal CAN
  2. w/o Occupant Classification System COMMUNICATION TABLE Sender Receiver Signal Communication Method Center airbag sensor assembly Combination meter assembly Front seat inner belt buckle switch signal (for driver side) CAN

CUSTOMIZE PARAMETERS

  1. CUSTOMIZE FUNCTION WITH TECHSTREAM NOTE: Be sure to record the current settings before customizing. These buzzers should be ON for safe driving. Perform this procedure only if it is necessary to set the buzzer OFF (disabled). HINT: The following items can be customized using the Techstream. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Combination Meter / Utility / Customize Setting. Select the setting by referring to the table below. COMBINATION METER Tester Display Default Content Setting Driver Side Seatbelt Warning Buzzer ON Function to sound the seat belt warning buzzer ON/OFF Front Passenger Side Seatbelt Warning Buzzer ON Function to sound the seat belt warning buzzer ON/OFF HINT: This setting is only valid when the vehicle is driven at 20 km/h (12 mph) or more.

PROCEDURE

  1. CHECK DTC OUTPUT (AIRBAG SYSTEM) Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-400811-S35984818542011051800000) . Recheck for DTCs. Result Result Proceed to DTC is not output A DTC is output B B --> See step 3 A: Go to next step
  2. PERFORM ACTIVE TEST USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Combination Meter / Active Test. Perform the Active Test according to the display on the Techstream. COMBINATION METER (COMBINATION METER ASSEMBLY) Tester Display Test Part Control Range Diagnostic Note Driver Side Seat Belt Driver side seat belt warning light OFF or ON Confirm that the vehicle stopped with the engine idling OK The driver side seat belt warning light on the combination meter assembly operates normally. NG --> See step 4 OK --> See step 5
  3. GO TO AIRBAG SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-400811-S03730430612011051800000)
  4. REPLACE COMBINATION METER ASSEMBLY. Refer to «REMOVAL»(ref-400807-S03467652992011051800000)
  5. USE SIMULATION METHOD TO CHECK. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-400649-S11887826212011051800000)
  1. CHECK DTC OUTPUT (AIRBAG SYSTEM) Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-400811-S31749659202011051800000) . Recheck for DTCs. Result Result Proceed to DTC is not output A DTC is output B B --> See step 3 A: Go to next step
  2. PERFORM ACTIVE TEST USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Combination Meter / Active Test. Perform the Active Test according to the display on the Techstream. COMBINATION METER (COMBINATION METER ASSEMBLY) Tester Display Test Part Control Range Diagnostic Note Driver Side Seat Belt Driver side seat belt warning light OFF or ON Confirm that the vehicle stopped with the engine idling OK The driver side seat belt warning light on the combination meter assembly operates normally. NG --> See step 4 OK --> See step 5
  3. GO TO AIRBAG SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-400811-S02490402752011051800000)
  4. REPLACE COMBINATION METER ASSEMBLY. Refer to «REMOVAL»(ref-400807-S21743066462011051800000)
  5. USE SIMULATION METHOD TO CHECK. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-400649-S16126263452011051800000)
  1. SYSTEM CHECK Check the vehicle specification. Result Result Proceed to w/ Occupant Classification System A w/o Occupant Classification System B B --> See step 5 A: Go to next step
  2. CHECK DTC OUTPUT (OCCUPANT CLASSIFICATION SYSTEM) Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-400952-S11089516862011051800000) . Recheck for DTCs. Result Result Proceed to DTC is not output A DTC is output B B --> See step 17 A: Go to next step
  3. CHECK DTC OUTPUT (AIRBAG SYSTEM) Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-400811-S31749659202011051800000) . Recheck for DTCs. Result Result Proceed to DTC is not output A DTC is output B B --> See step 19 A: Go to next step
  4. PERFORM ACTIVE TEST USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Combination Meter / Active Test. Perform the Active Test according to the display on the Techstream. COMBINATION METER (COMBINATION METER ASSEMBLY) Tester Display Test Part Control Range Diagnostic Note Front Passenger Side Seat Belt Front passenger side seat belt warning light OFF or ON Confirm that the vehicle stopped with the engine idling OK The front passenger side seat belt warning light on the accessory meter assembly*1 or radio receiver assembly*2 operates normally. *1: w/o Navigation System *2: w/ Navigation System NG --> See step 10 OK --> See step 18
  5. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Combination Meter / Active Test. Read the Data List according to the display on the Techstream. COMBINATION METER (COMBINATION METER ASSEMBLY) Tester Display Measurement Item/Range Normal Condition Diagnostic Note P-Seatbelt Buckle SW Front passenger side seat belt buckle switch signal/ON or OFF ON: Front passenger side seat belt fastened OFF: Front passenger side seat belt not fastened - OK ON of OFF appears on the Techstream screen according to the front passenger side seat belt condition. NG --> See step 7 OK: Go to next step
  6. PERFORM ACTIVE TEST USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Combination Meter / Active Test. Perform the Active Test according to the display on the Techstream. COMBINATION METER (COMBINATION METER ASSEMBLY) Tester Display Test Part Control Range Diagnostic Note Front Passenger Side Seat Belt Front passenger side seat belt warning light OFF or ON Confirm that the vehicle stopped with the engine idling OK The front passenger side seat belt warning light on the radio receiver assembly operates normally. NG --> See step 10 OK --> See step 18
  7. CHECK HARNESS AND CONNECTOR (FRONT PASSENGER SIDE SEAT INNER BELT - COMBINATION METER) Disconnect the F15 meter connector. Disconnect the Z7 belt connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F15-10 (P/SB) - Z7-1 (WS+) Always Below 1 ohms F15-10 (P/SB) - Body ground Always 10 kohms or higher Z7-4 (E) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Combination Meter Assembly) *2 Front view of wire harness connector (to Front Seat Inner Belt Assembly (Front Passenger Side)) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  8. INSPECT OCCUPANT DETECTION SENSOR (SEPARATE TYPE FRONT SEAT CUSHION PAD) Remove the occupant detection sensor (separate type front seat cushion pad). Refer to «REMOVAL»(ref-400652-S30025787892011051800000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A-1 - A-3 Front passenger side seat occupied Below 100 ohms A-1 - A-3 Front passenger side seat not occupied 1 Mohms or higher TEXT IN ILLUSTRATION *1 Component without harness connected (Occupant Detection Sensor (Separate Type Front Seat Cushion Pad)) NG --> See step 22 OK: Go to next step
  9. INSPECT FRONT SEAT INNER BELT ASSEMBLY RH Remove the front seat inner belt assembly RH. Refer to «REMOVAL»(ref-400652-S31627949502011051800000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Z7-1 (WS+) - A-1 Always Below 1 ohms Z7-4 (E) - A-3 Front passenger side seat belt unfastened Below 1 ohms Z7-4 (E) - A-3 Front passenger side seat belt fastened 10 kohms or higher TEXT IN ILLUSTRATION *1 Component without harness connected (Front Seat Inner Belt Assembly RH) *2 Front view of wire harness connector (to Occupant Detection Sensor (Separate Type Front Seat Cushion Pad)) NG --> See step 23 OK --> See step 18
  10. SYSTEM CHECK Check the vehicle specification. Result Result Proceed to w/o Navigation System A w/ Navigation System B B --> See step 14 A: Go to next step
  11. CHECK HARNESS AND CONNECTOR (ACCESSORY METER ASSEMBLY - BATTERY) Disconnect the G1 connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition G1-2 (IG2) - Body ground Engine switch on (IG) 11 to 14 V G1-2 (IG2) - Body ground Engine switch off Below 1 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Accessory Meter Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  12. CHECK HARNESS AND CONNECTOR (COMBINATION METER - ACCESSORY METER) Disconnect the F16 connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F16-12 (PBLT) - G1-6 (PBEW) Always Below 1 ohms G1-6 (PBEW) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Combination Meter Assembly) *2 Front view of wire harness connector (to Accessory Meter Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  13. CHECK HARNESS AND CONNECTOR (COMBINATION METER ASSEMBLY - BATTERY) Reconnect the G1 connector.. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition F16-12 (PBLT) - Body ground Engine switch on (IG) 11 to 14 V F16-12 (PBLT) - Body ground Engine switch off Below 1 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Combination Meter Assembly) NG --> See step 20 OK --> See step 18
  14. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER ASSEMBLY - BATTERY) Disconnect the G8 connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition G8-15 (IG+) - Body ground Engine switch on (IG) 11 to 14 V G8-15 (IG+) - Body ground Engine switch off Below 1 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Radio Receiver Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  15. CHECK HARNESS AND CONNECTOR (COMBINATION METER - RADIO RECEIVER) Disconnect the F16 connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F16-12 (PBLT) - G8-2 (PBEW) Always Below 1 ohms G8-2 (PBEW) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Combination Meter Assembly) *2 Front view of wire harness connector (to Radio Receiver Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  16. CHECK HARNESS AND CONNECTOR (COMBINATION METER ASSEMBLY - BATTERY) Reconnect the G8 connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition F16-12 (PBLT) - Body ground Engine switch on (IG) 11 to 14 V F16-12 (PBLT) - Body ground Engine switch off Below 1 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Combination Meter Assembly) NG --> See step 21 OK --> See step 18
  17. GO TO OCCUPANT CLASSIFICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-400952-S23869059442011051800000)
  18. REPLACE COMBINATION METER ASSEMBLY. Refer to «REMOVAL»(ref-400807-S21743066462011051800000)
  19. GO TO AIRBAG SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-400811-S02490402752011051800000)
  20. REPLACE ACCESSORY METER ASSEMBLY. Refer to «REMOVAL»(ref-400807-S19040315352011051800000)
  21. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-400843-S38254967922011051800000)
  22. REPLACE OCCUPANT DETECTION SENSOR (SEPARATE TYPE FRONT SEAT CUSHION PAD). Refer to «REMOVAL»(ref-400652-S30025787892011051800000)
  23. REPLACE FRONT SEAT INNER BELT ASSEMBLY RH. Refer to «REMOVAL»(ref-400652-S31627949502011051800000)
