Automatic Transmission (U660E) (Service Information): Adjustments Lexus RX III

ADJUSTMENT

1. PRECAUTION (w/ Air Suspension) NOTE: Be sure to read Precaution thoroughly before servicing. Refer to «PRECAUTION»(ref-400816-S40570634362011051800000) .
2. PRECAUTIONS AND WORK DESCRIPTION The U660E automatic transaxle does not have an oil filler tube and oil level gauge. When adding fluid, add fluid through the refill hole on the transaxle case. The fluid level can be adjusted by draining excess fluid (allowing excess fluid to overflow) through the No. 1 transmission oil filler tube of the oil pan. HINT: "Overflow" indicates the condition under which fluid comes out of the overflow plug hole. Before adjusting the fluid level, add the specified amount of fluid when the engine is cold and warm up the engine to circulate the fluid in the transaxle. Ensure that the fluid temperature is as specified and the engine is idling. The U660E automatic transaxle requires Toyota Genuine ATF WS. The adjustment should be performed according to the procedures and notes.
3. WORK FLOW The adjustment should be performed according to the procedures referenced in the work flow below.
4. BEFORE FILLING TRANSAXLE WITH FLUID Lift the vehicle. NOTE: Set the vehicle on a lift so that the vehicle is kept level when it is lifted up. Remove the 2 bolts, clip and front fender apron seal LH.
5. PERFORM INITIAL FILLING NOTE: If the transaxle is hot (ATF temperature is high), wait until the fluid temperature becomes the same as the ambient temperature before starting the following procedure. (Recommended ATF temperature: around 20°C [68°F]) Remove the refill plug and gasket from the automatic transaxle. NOTE: After performing any of the following operations, it is not necessary to perform the initial filling procedure. Proceed to 6 the Add Specified Amount of Fluid procedure. Operations that do not require initial filling Disconnection of the oil cooler tube or oil cooler hose Repair of fluid leak due to a loose case plug, or a faulty plug gasket or O-ring Installation of a new transaxle with torque converter (filled fluid parts) Using a 6 mm hexagon socket wrench, remove the overflow plug and gasket from the automatic transaxle. NOTE: If ATF comes out after removing the overflow plug, wait until the fluid flow slows and only drips come out. If ATF comes out, it is not necessary to perform the initial filling procedure. After checking the tightening torque of the No. 1 transmission oil filler tube, temporarily tighten the overflow plug. Using a 6 mm hexagon socket wrench, check that the No. 1 transmission oil filler tube is tightened to the specified torque. TEXT IN ILLUSTRATION *1 No. 1 Transmission Oil Filler Tube *2 Hexagon Socket Wrench *3 Overflow Plug Hole Torque: 1.7 N*m (17 kgf*cm, 15 in.*lbf) NOTE: If the No. 1 transmission oil filler tube is not tightened to the specified torque, the amount of fluid cannot be precisely adjusted. HINT: To check the torque of the No. 1 transmission oil filler tube, insert the socket hexagon wrench into the overflow plug hole. Perform initial filling. Fill the transaxle through the refill hole until fluid begins to trickle out of the overflow plug hole. NOTE: Use Toyota Genuine ATF WS. Wait until the fluid flow slows and only drips come out. Temporarily install the overflow plug. HINT: Reuse the old gasket. The plug will be removed again to adjust the fluid level.
6. ADD SPECIFIED AMOUNT OF FLUID Fill the transaxle with the correct amount of fluid as listed in the table below. NOTE: Refill amount differs depending on the operation that was performed. Standard Capacity Performed Repair Fill Amount Disconnection of the oil cooler tube or oil cooler hose Repair of fluid leak due to a loose case plug, or a faulty plug gasket or O-ring Installation of a new transaxle with torque converter (filled fluid parts) 0.5 liters (0.5 US qts, 0.4 lmp. qts) Removal and installation of the drive shaft Removal and installation of the transaxle case oil seal Removal and installation of the oil pan 2.8 liters (3.0 US qts, 2.5 lmp. qts) Removal and installation of the valve body 3.2 liters (3.4 US qts, 2.8 lmp. qts) Removal and installation of the transaxle (not including removal of the torque converter) 3.4 liters (3.6 US qts, 3.0 lmp. qts) Removal and installation of the torque converter (torque converter reused) 4.8 liters (5.1 US qts, 4.2 lmp. qts) Installation of a new torque converter 5.3 liters (5.6 US qts, 4.7 lmp. qts) Temporarily install the refill plug to avoid fluid spillage. HINT: Reuse the old gasket. The plug will be removed again to adjust the fluid level. Lower the vehicle.
7. ADJUST FLUID TEMPERATURE When using the Techstream: HINT: The actual ATF temperature can be checked on the Data List using the Techstream. Connect the Techstream to the DLC3 with the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. NOTE: Check that electrical systems such as the air conditioning system, audio system and lighting system are off. Enter the following menus: Powertrain / ECT / Active Test / Connect the TC and TE1. Select the Active Test menu: Connect the TC and TE1 / ON. Select the Data List menu: A/T Oil Temperature 1. Check the ATF temperature. NOTE: If the fluid temperature is below 45°C (113°F), proceed to 7 the next step. (Recommended ATF temperature: 40°C [104°F] or less) If the fluid temperature is 45°C (113°F) or more, turn the engine switch off and wait until the fluid temperature drops below 45°C (113°F). Depress and hold the brake pedal. Start the engine. Slowly move the shift lever from P to D, then back to P. HINT: Slowly move the shift lever to circulate the fluid through each part of the transaxle. While observing the D shift indicator on the combination meter, move the shift lever back and forth between N and D at an interval of 1.5 seconds for 6 seconds or more. NOTE: Do not pause for more than 1.5 seconds. HINT: Performing this operation will cause the vehicle to enter the fluid temperature detection mode. Check that the D shift indicator comes on for 2 seconds. HINT: When the fluid temperature detection mode is activated, the D shift indicator on the combination meter comes on for 2 seconds. If the D shift indicator does not come on for 2 seconds, return to the step where terminal TC is first connected and perform the procedure again. Move the shift lever from N to P. Release the brake pedal. Select the Active Test menu: Connect the TC and TE1 / OFF. NOTE: Be sure that terminals TC and TE1 are not connected. If the terminals are connected, the fluid level cannot be precisely adjusted due to fluctuations in engine speed. HINT: Disconnecting terminals TC and TE1 activates the engine idle speed control mode. In the engine idle speed control mode, engine idle speed control starts when the fluid temperature becomes 35°C (95°F) or more and the engine speed is maintained at approximately 800 rpm. Even after terminals TC and TE1 are disconnected, the fluid temperature detection mode is active until the engine switch off. Warm up the engine with the engine idling until the fluid temperature reaches the normal operating temperature (40 to 45°C [104 to 113°F]). Below Normal Operating Temperature Normal Operating Temperature Above Normal Operating Temperature 40°C or less (104°F or less) 40 to 45°C (104 to 113°F) 45°C or more (113°F or more) NOTE: If the fluid temperature is within the normal operating temperature range, immediately proceed to 8 the Adjust Fluid Level procedure. If the fluid temperature is 45°C (113°F) or more, stop the engine and wait until the fluid temperature drops to 40°C (104°F) or less. Then perform the Adjust Fluid Temperature procedure again from the beginning. HINT: In the fluid temperature detection mode, the D shift indicator comes on, goes off, or blinks depending on the fluid temperature. D SHIFT INDICATOR Below Normal Operating Temperature (40°C or less) (104°F or less) Normal Operating Temperature (40 to 45°C) (104 to 113°F) Above Normal Operating Temperature (45°C or more) (113°F or more) OFF ON Blinks When not using the Techstream: Using SST, connect terminals 13 (TC) and 4 (CG) of the DLC3 with the engine switch off. TEXT IN ILLUSTRATION *1 DLC3 SST: 09843-18040 Depress and hold the brake pedal. Start the engine. NOTE: Check that electrical systems such as the air conditioning system, audio system and lighting system are off. HINT: The indicator lights on the combination meter blink to indicate the DTC output when terminals TC and CG are connected. Slowly move the shift lever from P to D, then back to P. HINT: Slowly move the shift lever to circulate the fluid through each part of the transaxle. While observing the D shift indicator on the combination meter, move the shift lever back and forth between N and D at an interval of 1.5 seconds for 6 seconds or more. NOTE: Do not pause for more than 1.5 seconds. HINT: Performing this operation will cause the vehicle to enter the fluid temperature detection mode. Check that the D shift indicator comes on for 2 seconds. HINT: When the fluid temperature detection mode is activated, the D shift indicator on the combination meter comes on for 2 seconds. If the D shift indicator does not come on for 2 seconds, return to the step where terminal TC is first connected and perform the procedure again. Move the shift lever from N to P. Release the brake pedal. Remove SST from terminals 13 (TC) and 4 (CG). TEXT IN ILLUSTRATION *1 DLC3 SST: 09843-18040 NOTE: Be sure that terminals TC and CG are not connected. If the terminals are connected, the fluid level cannot be precisely adjusted due to fluctuations in engine speed. HINT: Disconnecting terminals TC and CG activates the engine idle control mode. In the engine idle speed control mode, engine idle speed control starts when the fluid temperature becomes 35°C (95°F) or more and the engine speed is maintained at approximately 800 rpm. Even after terminals TC and CG are disconnected, the fluid temperature detection mode is active until the engine switch is turned off. Allow the engine to idle until the D shift indicator comes on again. D SHIFT INDICATOR Below Normal Operating Temperature (40°C or less) (104°F or less) Normal Operating Temperature (40 to 45°C) (104 to 113°F) Above Normal Operating Temperature (45°C or more) (113°F or more) OFF ON Blinks NOTE: If the D shift indicator is on, immediately proceed to 8 the Adjust Fluid Level procedure. If the D shift indicator blinks, stop the engine and wait until the fluid temperature drops to 40°C (104°F) or less (the indicator goes off). Then perform the Adjust Fluid Temperature procedure again from the beginning. HINT: In the fluid temperature detection mode, the D shift indicator comes on, goes off, or blinks depending on the fluid temperature. Fluid filling procedure should be performed when the D shift indicator is on (the fluid temperature is within the normal operating temperature range).
8. ADJUST FLUID LEVEL WARNING: Use caution while the engine is idling and the radiator fan is operating. Lift the vehicle. NOTE: Set the vehicle on a lift so that the vehicle is kept level when it is lifted up. Adjust the fluid level. Using a 6 mm hexagon socket wrench, remove the overflow plug and gasket. WARNING: Be careful as the fluid coming out of the overflow plug hole is hot. Check the amount of fluid that comes out of the overflow plug hole. NOTE: If only a small amount of fluid (approximately 1 cc) comes out of the overflow plug hole, then only fluid remaining in the No. 1 transmission oil filler tube has come out. This condition is not considered as overflow, so it is necessary to add fluid. If the amount of fluid that comes out of the overflow plug hole is large, wait until the fluid flow slows and only drips come out. If no fluid comes out of the overflow plug hole, remove the refill plug and gasket. Then add transaxle fluid through the refill hole until fluid comes out of the overflow plug hole. Wait until the fluid flow slows and only drips come out. NOTE: Use Toyota Genuine ATF WS. Check that the fluid flow has slowed and only drips come out. HINT: The fluid flow will not completely stop because the fluid expands as its temperature increases. Install the overflow plug with a new gasket. Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) Install the refill plug with a new gasket. Torque: 49 N*m (500 kgf*cm, 36 ft.*lbf) Lower the vehicle. Turn the engine switch off. HINT: Turning the engine switch off exits the fluid temperature detection mode. Remove the Techstream from the DLC3 (when using the Techstream).
9. AFTER FILLING TRANSAXLE Lift the vehicle. Clean each part. Check for fluid leaks. Install the front fender apron seal LH with the 2 bolts and clip. Lower the vehicle.

Scheme 80

Scheme 81

Scheme 82

1. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY HINT: See the steps from "Remove Engine Assembly with Transaxle" through "Remove Automatic Transaxle Assembly". Refer to «REMOVAL»(ref-400804-S01619592632011051800000) .
2. REMOVE TORQUE CONVERTER CLUTCH ASSEMBLY See step 13
3. REMOVE AUTOMATIC TRANSAXLE OIL PAN SUB-ASSEMBLY See step 3
4. REMOVE VALVE BODY OIL STRAINER ASSEMBLY See step 4
5. REMOVE TRANSMISSION VALVE BODY ASSEMBLY See step 5
6. REMOVE SPEED SENSOR Disconnect the connector. Remove the 2 bolts and speed sensor from the valve body.

1. ADJUST PARK/NEUTRAL POSITION SWITCH ASSEMBLY Remove the control shaft lever. HINT: See the steps from "Remove Windshield Wiper Motor and Link Assembly" through "Remove Park/Neutral Position Switch Assembly". Refer to «REMOVAL»(ref-400804-S07140278882011051800000) . Loosen the 2 bolts of the park/neutral position switch. Align the protrusions of the park/neutral position switch. TEXT IN ILLUSTRATION *1 Protrusion Hold the park/neutral position switch in position and tighten the 2 bolts. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) NOTE: After installing the park/neutral position switch, confirm that the 2 protrusions on the switch are aligned. Install the control shaft lever. HINT: See the steps from "Install Park/Neutral Position Switch Assembly" through "Install Windshield Wiper Motor and Link Assembly". Refer to «INSTALLATION»(ref-400804-S26734813642011051800000) . After the adjustment, perform the switch operation check See step 1 .

Scheme 83

Scheme 84

1. INSTALL PARK/NEUTRAL POSITION SWITCH ASSEMBLY Move the shift lever to N. Align the protrusions of the park/neutral position switch. TEXT IN ILLUSTRATION *1 Protrusion Install the park/neutral position switch to the control shaft with the 2 bolts. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) NOTE: Before installing the park/neutral position switch, remove any dirt or rust on the installation portion of the control shaft. Be sure to install the switch straight along the shaft while being careful not to deform the plate spring that supports the shaft. If the plate spring is deformed, the park/neutral position switch cannot be reinstalled correctly. After installing the park/neutral position switch, confirm that the 2 protrusions on the switch are aligned. Install the control shaft lever to the control shaft with the nut and washer. Torque: 13 N*m (130 kgf*cm, 9 ft.*lbf) Connect the connector to the park/neutral position switch.
2. CONNECT TRANSMISSION CONTROL CABLE ASSEMBLY Install a new clip to the control cable bracket. Install the control cable to the control cable bracket. TEXT IN ILLUSTRATION *1 Claw A *2 Claw B *3 Control Cable NOTE: Make sure that the claws A on the clip are securely fit into the bracket holes. Make sure that the cable is securely installed inside of the claws B of the clip. Connect the transmission control cable to the control shaft lever with the nut. Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf) NOTE: Before connecting the transmission control cable assembly, check that the park/neutral position switch and the shift lever are in neutral.
3. INSTALL AIR CLEANER ASSEMBLY . Refer to «INSTALLATION - Step 2»(ref-400788-S16135119482011051800000)
4. INSTALL INLET NO. 1 AIR CLEANER . Refer to «INSTALLATION - Step 72»(ref-400790-S30060480932011051800000)
5. INSTALL INLET NO. 2 AIR CLEANER . Refer to «INSTALLATION - Step 73»(ref-400790-S30060480932011051800000)
6. INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S30060480932011051800000)
7. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) .
8. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S30060480932011051800000)
9. INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-400778-S06004016952011051800000)
10. INSTALL FRONT SHOCK ABSORBER CAP (w/ Air Suspension) . Refer to «INSTALLATION - Step 10»(ref-400810-S37673499492011051800000)
11. INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY HINT: See the steps from "Install Windshield Wiper Motor and Link Assembly" through "Install Engine Room Side Cover LH". Refer to «INSTALLATION»(ref-400809-S31962938082011051800000) .
12. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY OPERATION See step 1
13. INSPECT SHIFT LEVER POSITION See step 1
14. ADJUST SHIFT LEVER POSITION See step 2

1. INSPECT SHIFT LEVER POSITION When moving the shift lever from P to R with the engine switch on (IG) and the brake pedal depressed, make sure that the shift lever moves smoothly and correctly into position. Start the engine and make sure that the vehicle moves forward when moving the shift lever from N to D and moves rearward when moving the shift lever to R. If the operation cannot be performed as specified, inspect the park/neutral position switch assembly and check the shift lever assembly installation condition.
2. ADJUST SHIFT LEVER POSITION Apply the parking brake and move the shift lever to N. Remove the console box. Refer to «REMOVAL»(ref-400804-S23319245912011051800000) . Disconnect the shift lock control ECU connector and transmission control switch wire connector. Disconnect the 3 clamps. Remove the 4 nuts and shift lever assembly. Disconnect the end of the transmission control cable assembly from the shift lever assembly. Turn the lock nut counterclockwise. While holding the lock nut, disconnect the transmission control cable from the shift lever retainer. Slide the slider of the transmission control cable in the direction indicated by the arrow and pull the lock piece outward. TEXT IN ILLUSTRATION *1 Slide *2 Pull *3 Slider *4 Lock Piece Turn the lock nut of the transmission control cable counterclockwise. While holding the lock nut, push in the stopper. TEXT IN ILLUSTRATION *1 Lock Nut *2 Push in *3 Stopper Connect the outer part of the transmission control cable to the shift lever retainer. TEXT IN ILLUSTRATION *1 Shift Lever Retainer *2 Stopper *3 Lock Nut - - NOTE: The lock nut is fully seated against the shift lever retainer. Install the transmission control cable end to the shift lever assembly. TEXT IN ILLUSTRATION *1 Lock Piece NOTE: Check that the lock piece is pulled up. Install the cable end all the way to the base of the pin. Install the shift lever assembly with the 4 nuts. Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf) Connect the 3 clamps to the shift lever assembly. Connect the 2 connectors. Push the lock piece into the adjuster case. NOTE: Check that the park/neutral position switch and the shift lever are in neutral. Securely push in the lock piece until the slider lock is engaged. After adjusting the shift lever position, check the operation and function of the shift lever. If there is a problem, adjust the position again. Install the console box See step 2 .

1. INSPECT SHIFT LEVER POSITION When moving the shift lever from P to R with the engine switch on (IG) and the brake pedal depressed, make sure that the shift lever moves smoothly and correctly into position. Start the engine and make sure that the vehicle moves forward when moving the shift lever from N to D and moves rearward when moving the shift lever to R. If the operation cannot be performed as specified, inspect the park/neutral position switch assembly and check the shift lever assembly installation condition.
2. ADJUST SHIFT LEVER POSITION Apply the parking brake and move the shift lever to N. Remove the console box. Refer to «REMOVAL»(ref-400804-S17494373972011051800000) . Disconnect the shift lock control ECU connector and transmission control switch wire connector. Disconnect the 3 clamps. Remove the 4 nuts and shift lever assembly. Disconnect the end of the transmission control cable assembly from the shift lever assembly. Turn the lock nut counterclockwise. While holding the lock nut, disconnect the transmission control cable from the shift lever retainer. Slide the slider of the transmission control cable in the direction indicated by the arrow and pull the lock piece outward. TEXT IN ILLUSTRATION *1 Slide *2 Pull *3 Slider *4 Lock Piece Turn the lock nut of the transmission control cable counterclockwise. While holding the lock nut, push in the stopper. TEXT IN ILLUSTRATION *1 Lock Nut *2 Push in *3 Stopper Connect the outer part of the transmission control cable to the shift lever retainer. TEXT IN ILLUSTRATION *1 Shift Lever Retainer *2 Stopper *3 Lock Nut - - NOTE: The lock nut is fully seated against the shift lever retainer. Install the transmission control cable end to the shift lever assembly. TEXT IN ILLUSTRATION *1 Lock Piece NOTE: Check that the lock piece is pulled up. Install the cable end all the way to the base of the pin. Install the shift lever assembly with the 4 nuts. Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf) Connect the 3 clamps to the shift lever assembly. Connect the 2 connectors. Push the lock piece into the adjuster case. NOTE: Check that the park/neutral position switch and the shift lever are in neutral. Securely push in the lock piece until the slider lock is engaged. After adjusting the shift lever position, check the operation and function of the shift lever. If there is a problem, adjust the position again. Install the console box See step 2 .

Scheme 85

1. INSTALL TRANSMISSION CONTROL CABLE ASSEMBLY NOTE: Before installing the transmission control cable assembly, check that the park/neutral position switch and the shift lever are in neutral. Pass the control cable from the cabin to the engine compartment. Install the transmission control cable assembly with the 3 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) Connect the transmission control cable to the clamp. Install a new clip to the control cable bracket. Install the control cable to the control cable bracket. TEXT IN ILLUSTRATION *1 Claw A *2 Claw B *3 Control Cable NOTE: Make sure that the claws A on the clip are securely fit into the bracket holes. Make sure that the cable is securely installed inside of the claws B of the clip. Connect the transmission control cable to the control shaft lever with the nut. Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf) NOTE: Before connecting the transmission control cable assembly, check that the park/neutral position switch and the shift lever are in neutral.
2. INSTALL AIR CLEANER ASSEMBLY . Refer to «INSTALLATION - Step 2»(ref-400788-S16135119482011051800000)
3. INSTALL INLET NO. 1 AIR CLEANER . Refer to «INSTALLATION - Step 72»(ref-400790-S30060480932011051800000)
4. INSTALL INLET NO. 2 AIR CLEANER . Refer to «INSTALLATION - Step 73»(ref-400790-S30060480932011051800000)
5. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 113»(ref-400790-S30060480932011051800000)
6. INSTALL BATTERY . Refer to «INSTALLATION - Step 71»(ref-400790-S30060480932011051800000)
7. INSTALL INSTRUMENT PANEL REINFORCEMENT ASSEMBLY WITH AIR CONDITIONING UNIT ASSEMBLY HINT: See the steps from "Install Instrument Panel Reinforcement Assembly with Air Conditioning Unit Assembly" through "Inspect SRS Warning Light". Refer to «INSTALLATION»(ref-400783-S15543800872011051800000) .
8. INSPECT SHIFT LEVER POSITION See step 1
9. ADJUST SHIFT LEVER POSITION See step 2
