Automatic Transmission (U660E) (Diagnostics - Introduction): Diagnosis Lexus RX III

HOW TO PROCEED WITH TROUBLESHOOTING

HINT

1. The TCM of this system is connected to the CAN communication system. Therefore, before starting troubleshooting, make sure to check that there is no trouble in the CAN and multiplex communication system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS NEXT: Go to next step
3. INSPECT BATTERY VOLTAGE Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding. NEXT: Go to next step
4. CONNECT TECHSTREAM TO DLC3* NEXT: Go to next step
5. CHECK AND CLEAR DTCS AND FREEZE FRAME DATA* Refer to DTC Check / Clear. Refer to «DTC CHECK / CLEAR»(ref-400823-S37187369772011051800000) . NEXT: Go to next step
6. VISUAL INSPECTION NEXT: Go to next step
7. SELECT CHECK MODE DIAGNOSIS* Refer to Check Mode Procedure. Refer to «CHECK MODE PROCEDURE»(ref-400823-S22694075102011051800000) . NEXT: Go to next step
8. PROBLEM SYMPTOM CONFIRMATION Refer to Road Test. Refer to «ROAD TEST»(ref-400823-S08686876792011051800000) . Result Result Proceed to Symptom does not occur A Symptom occurs B B --> GO TO STEP 10 . A: Go to next step
9. SYMPTOM SIMULATION Refer to Symptom Simulation. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-400649-S11887826212011051800000) . NEXT: Go to next step
10. DTC CHECK* Refer to DTC Check / Clear. Refer to «DTC CHECK / CLEAR»(ref-400823-S37187369772011051800000) . Result Result Proceed to DTC is not output A DTC is output B B --> GO TO STEP 18 . A: Go to next step
11. BASIC INSPECTION Refer to Automatic Transmission Fluid. Refer to «ON-VEHICLE INSPECTION»(ref-400804-S35806271502011051800000) . Refer to Park/Neutral Position Switch. Refer to «ADJUSTMENT»(ref-400804-S08004764702011051800000) . Refer to Shift Lever Assembly. Refer to «ADJUSTMENT»(ref-400804-S07175329752011051800000) . NG --> GO TO STEP 21 . OK: Go to next step
12. MECHANICAL SYSTEM TESTS Refer to Mechanical System Tests. Refer to «MECHANICAL SYSTEM TESTS»(ref-400823-S30247300092011051800000) . NG --> GO TO STEP 17 . OK: Go to next step
13. HYDRAULIC TEST Refer to Hydraulic Test. Refer to «HYDRAULIC TEST»(ref-400823-S20120488542011051800000) . NG --> GO TO STEP 17 . OK: Go to next step
14. MANUAL SHIFTING TEST Refer to Manual Shifting Test. Refer to «MANUAL SHIFTING TEST»(ref-400823-S16272097812011051800000) . NG --> GO TO STEP 16 . OK: Go to next step
15. PROBLEM SYMPTOMS TABLE CHAPTER 1 Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE»(ref-400823-S27359834412011051800000) . NG --> GO TO STEP 19 . OK: Go to next step
16. PROBLEM SYMPTOMS TABLE CHAPTER 2 Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE»(ref-400823-S27359834412011051800000) . NEXT: Go to next step
17. COMPONENT INSPECTION NEXT --> GO TO STEP 21 .
18. DTC CHART Refer to Diagnostic Trouble Code Chart. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-400823-S12627040952011051800000) . NEXT: Go to next step
19. CIRCUIT INSPECTION NEXT: Go to next step
20. IDENTIFICATION OF PROBLEM NEXT: Go to next step
21. REPAIR OR REPLACE NEXT: Go to next step
22. CONFIRMATION TEST NEXT --> END

HINT

1. The TCM of this system is connected to the CAN communication system. Therefore, before starting troubleshooting, make sure to check that there is no trouble in the CAN and multiplex communication system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS NEXT: Go to next step
3. INSPECT BATTERY VOLTAGE Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding. NEXT: Go to next step
4. CONNECT TECHSTREAM TO DLC3* NEXT: Go to next step
5. CHECK AND CLEAR DTCS AND FREEZE FRAME DATA* Refer to DTC Check / Clear. Refer to «DTC CHECK / CLEAR»(ref-400823-S18744050322011051800000) . NEXT: Go to next step
6. VISUAL INSPECTION NEXT: Go to next step
7. SELECT CHECK MODE DIAGNOSIS* Refer to Check Mode Procedure. Refer to «CHECK MODE PROCEDURE»(ref-400823-S33056053052011051800000) . NEXT: Go to next step
8. PROBLEM SYMPTOM CONFIRMATION Refer to Road Test. Refer to «ROAD TEST»(ref-400823-S08686876792011051800000) . Result Result Proceed to Symptom does not occur A Symptom occurs B B --> GO TO STEP 10 . A: Go to next step
9. SYMPTOM SIMULATION Refer to Symptom Simulation. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-400649-S16126263452011051800000) . NEXT: Go to next step
10. DTC CHECK* Refer to DTC Check / Clear. Refer to «DTC CHECK / CLEAR»(ref-400823-S18744050322011051800000) . Result Result Proceed to DTC is not output A DTC is output B B --> GO TO STEP 18 . A: Go to next step
11. BASIC INSPECTION Refer to Automatic Transmission Fluid. Refer to «ON-VEHICLE INSPECTION»(ref-400804-S41001820762011051800000) . Refer to Park/Neutral Position Switch. Refer to «ADJUSTMENT»(ref-400804-S41394987592011051800000) . Refer to Shift Lever Assembly. Refer to «ADJUSTMENT»(ref-400804-S28965644182011051800000) . NG --> GO TO STEP 21 . OK: Go to next step
12. MECHANICAL SYSTEM TESTS Refer to Mechanical System Tests. Refer to «MECHANICAL SYSTEM TESTS»(ref-400823-S30247300092011051800000) . NG --> GO TO STEP 17 . OK: Go to next step
13. HYDRAULIC TEST Refer to Hydraulic Test. Refer to «HYDRAULIC TEST»(ref-400823-S20120488542011051800000) . NG --> GO TO STEP 17 . OK: Go to next step
14. MANUAL SHIFTING TEST Refer to Manual Shifting Test. Refer to «MANUAL SHIFTING TEST»(ref-400823-S09650236802011051800000) . NG --> GO TO STEP 16 . OK: Go to next step
15. PROBLEM SYMPTOMS TABLE CHAPTER 1 Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE»(ref-400823-S13051241002011051800000) . NG --> GO TO STEP 19 . OK: Go to next step
16. PROBLEM SYMPTOMS TABLE CHAPTER 2 Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE»(ref-400823-S13051241002011051800000) . NEXT: Go to next step
17. COMPONENT INSPECTION NEXT --> GO TO STEP 21 .
18. DTC CHART Refer to Diagnostic Trouble Code Chart. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-400823-S26522998412011051800000) . NEXT: Go to next step
19. CIRCUIT INSPECTION NEXT: Go to next step
20. IDENTIFICATION OF PROBLEM NEXT: Go to next step
21. REPAIR OR REPLACE NEXT: Go to next step
22. CONFIRMATION TEST NEXT --> END

ROAD TEST

1. PROBLEM SYMPTOM CONFIRMATION Based on the result of the customer problem analysis, try to reproduce the symptoms. If the problem is that the transaxle does not shift up or down, or the shift point is too high or too low, conduct the following road test referring to the automatic shift schedule and attempt to duplicate the problem symptoms.
2. ROAD TEST NOTE: Perform the test at an Automatic Transmission Fluid (ATF) temperature 50 to 80°C (122 to 176°F) in the normal operation. D position test: Move the shift lever to D and fully depress the accelerator pedal. Check the following: Check up-shift operation. Check that the 1 to 2, 2 to 3, 3 to 4, 4 to 5 and 5 to 6 up-shifts take place, and that the shift points conform to the automatic shift schedule. HINT: 6th Gear Up-shift Prohibition Control ATF temperature is 0°C (32°F) or less. 5th Gear Up-shift Prohibition Control ATF temperature is 0°C (32°F) or less. Lock-up Prohibition Control Brake pedal is depressed. Accelerator pedal is released. Engine coolant temperature is 60°C (140°F) or less. Check for shift shock and slippage. Check for shock and slippage at the 1 to 2, 2 to 3, 3 to 4, 4 to 5 and 5 to 6 up-shifts. Check for abnormal noise and vibration. Check for abnormal noise and vibration when up-shifting from 1 to 2, 2 to 3, 3 to 4, 4 to 5 and 5 to 6 while driving with the shift lever in D, and also while driving in the lock-up condition. HINT: The check for the cause of abnormal noise and vibration must be done thoroughly as it could also be due to loss of balance in the differential, torque converter clutch, etc. Check kick-down operation. Check vehicle speeds when the 2 to 1, 3 to 2, 4 to 3, 5 to 4, and 6 to 5 kick-downs take place while driving with the shift lever in D. Confirm that each speed is within the applicable vehicle speed range indicated in the automatic shift schedule. Check for abnormal shock and slippage at kick-down. Check the lock-up mechanism. Drive the vehicle with the shift lever in D (4th, 5th or 6th gear) at a steady speed (lock-up ON). Lightly depress the accelerator pedal and check that the engine speed does not change abruptly. HINT: There is no lock-up function in 1st, 2nd and 3rd gears. If there is a jump in engine speed, this indicates that lock-up is not operating. S position test Move the shift lever to S and check the following: Check shift operation. With the shift lever in S (while the vehicle is stopped), repeatedly move the shift lever toward "+" and check that the shift position on the combination meter changes as follows: 1 to 2, 2 to 3, 3 to 4, 4 to 5 and 5 to 6. While driving in 5th gear with the S5 range selected (at a vehicle speed of approximately 55 to 65 km/h (34 to 40 mph), move the shift lever toward "-" and check if the down-shift to 4th gear and proper engine braking occurs. While driving in 4th gear with the S4 range selected (at a vehicle speed of approximately 30 to 40 km/h (19 to 25 mph), move the shift lever toward "-" and check if the down-shift to 3rd gear and proper engine braking occurs. While driving in 3rd gear with the S3 range selected (at a vehicle speed of approximately 20 to 30 km/h (12 to 19 mph), move the shift lever toward "-" and check if the down-shift to 2nd gear and proper engine braking occurs. While driving in 2nd gear with the S2 range selected (at a vehicle speed of approximately 10 to 20 km/h (6 to 12 mph), move the shift lever toward "-" and check if the down-shift to 1st gear and proper engine braking occurs. HINT: Changing ranges (with the shift lever in S position) is prohibited under either of the following conditions: If down-shifting may cause excessive engine speed. If the driver continuously down-shifts. (Down-shifting to 1st may not be performed.) R position test: Move the shift lever to R and lightly depress the accelerator pedal. Check that the vehicle moves backward without any abnormal noise or vibration. WARNING: Before conducting this test ensure that the test area is free from people and obstructions. P position test: Stop the vehicle on an incline (more than 5°). Then move the shift lever to P and release the parking brake. Check that the parking lock pawl holds the vehicle in place.

MANUAL SHIFTING TEST

1. PERFORM MANUAL SHIFTING TEST HINT: Using this test, it can be determined whether a problem is in an electrical circuit or if it is a mechanical problem in the transaxle. If any abnormalities are found in the following test, the problem is in the transaxle itself. Disconnect the connector of the TCM. HINT: It is possible to deactivate the electrical shift control by disconnecting the TCM connector. The gears can then be changed mechanically with the shift lever. Drive with the TCM connector disconnected. Move the shift lever to each position to check whether the gear changes as shown in the table below. Shift Lever Position Gear P P R R D 3rd No Shift (Gears will not change) Connect the connector of the TCM. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-400823-S37187369772011051800000) .

1. PERFORM MANUAL SHIFTING TEST HINT: Using this test, it can be determined whether a problem is in an electrical circuit or if it is a mechanical problem in the transaxle. If any abnormalities are found in the following test, the problem is in the transaxle itself. Disconnect the connector of the TCM. HINT: It is possible to deactivate the electrical shift control by disconnecting the TCM connector. The gears can then be changed mechanically with the shift lever. Drive with the TCM connector disconnected. Move the shift lever to each position to check whether the gear changes as shown in the table below. Shift Lever Position Gear P P R R D 3rd No Shift (Gears will not change) Connect the connector of the TCM. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-400823-S18744050322011051800000) .

PROBLEM SYMPTOMS TABLE

HINT

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. The Matrix Chart is divided into 2 chapters. When troubleshooting, refer to «1. CHAPTER 1: ELECTRONIC CIRCUIT MATRIX CHART»(ref-400823-S03461683792011051800000) Chapter 1 first. If instructions are given in Chapter 1 to proceed to «2. CHAPTER 2: ON-VEHICLE REPAIR AND OFF-VEHICLE REPAIR»(ref-400823-S41220784762011051800000) 2, proceed as instructed.
3. If the instruction "Proceed to «PROBLEM SYMPTOMS TABLE»(ref-400823-S26896589212011051800000) next suspected area shown in problem symptoms table" is given in the flowchart for each circuit, proceed to the next suspected area in the table.
4. If the problem still occurs even though there are no malfunctions in any of the circuits, check the TCM and replace it if necessary.
5. *1: When the circuit is defective, a DTC may be output.

1. CHAPTER 1: ELECTRONIC CIRCUIT MATRIX CHART

HINT

*1: When the circuit is defective, a DTC may be output.

2. CHAPTER 2: ON-VEHICLE REPAIR AND OFF-VEHICLE REPAIR

HINT

*1: When the circuit is defective, a DTC may be output.

HINT

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. The Matrix Chart is divided into 2 chapters. When troubleshooting, refer to «1. CHAPTER 1: ELECTRONIC CIRCUIT MATRIX CHART»(ref-400823-S39166832962011051800000) Chapter 1 first. If instructions are given in Chapter 1 to proceed to «2. CHAPTER 2: ON-VEHICLE REPAIR AND OFF-VEHICLE REPAIR»(ref-400823-S29261757982011051800000) 2, proceed as instructed.
3. If the instruction "Proceed to «PROBLEM SYMPTOMS TABLE»(ref-400823-S20105410962011051800000) next suspected area shown in problem symptoms table" is given in the flowchart for each circuit, proceed to the next suspected area in the table.
4. If the problem still occurs even though there are no malfunctions in any of the circuits, check the TCM and replace it if necessary.
5. *1: When the circuit is defective, a DTC may be output.

1. CHAPTER 1: ELECTRONIC CIRCUIT MATRIX CHART

HINT

*1: When the circuit is defective, a DTC may be output.

2. CHAPTER 2: ON-VEHICLE REPAIR AND OFF-VEHICLE REPAIR

HINT

*1: When the circuit is defective, a DTC may be output.

Scheme 773

Scheme 774

Scheme 775

Scheme 776

Scheme 777

1. TCM HINT: Each TCM terminal standard voltage is shown in the table below. In the table, first follow the information under "Condition". Look under "Terminal No. (Symbol)" for the terminals to be inspected. The standard voltage between the terminals is shown under "Specified Condition". Use the illustration above as a reference for the TCM terminals. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D2-15 (R) - D2-8 (E1) W - BR R shift position switch signal Engine switch on (IG) and shift lever in R 11 to 14 V Engine switch on (IG) and shift lever in any position except R Below 1 V D2-16 (D) - D2-8 (E1) Y - BR D shift position switch signal Engine switch on (IG) and shift lever in D and S 11 to 14 V Engine switch on (IG) and shift lever in any position except D and S Below 1 V D2-12 (STP) - D2-8 (E1) W-L - BR Stop light switch signal Brake pedal is depressed 7.5 to 14 V Brake pedal is released Below 1.5 V D2-11 (NSW) - D2-8 (E1) P - BR Park/neutral switch signal Engine switch on (IG) and shift lever in P or N Below 2 V Engine switch on (IG) and shift lever in any position except P or N 11 to 14 V D2-10 (STA) - D2-8 (E1) B - BR Starter signal Cranking (shift lever in P or N, engine switch START) 11 to 14 V Engine switch on (IG) and shift lever in any position except P or N Below 2 V D2-3 (SPD) - D2-8 (E1) LG - BR Speed signal from combination meter Vehicle speed 20 km/h (12 mph) Pulse generation (see waveform 1 (Scheme 774) ) D2-1 (BATT) - D2-8 (E1) G-R - BR Battery (for measuring battery voltage and for TCM memory) Always 9 to 14 V D2-13 (IGSW) - D2-8 (E1) G - BR Engine switch Engine switch on (IG) 9 to 14 V D2-18 (+B) - D2-8 (E1) L - BR Power source of TCM Engine switch on (IG) 9 to 14 V D2-6 (CAN+) - D2-8 (E1) L - BR CAN communication line Engine switch on (IG) Pulse generation (see waveform 2 (Scheme 775) ) D2-7 (CAN-) - D2-8 (E1) R - BR CAN communication line Engine switch on (IG) Pulse generation (see waveform 3 (Scheme 776) ) Waveform 1 REFERENCE Terminal SPD - E1 Tool setting 2 V/DIV., 20 ms./DIV. Vehicle condition Vehicle speed 20 km/h (12 mph) Waveform 2 REFERENCE Terminal CAN+ - E1 Tool setting 1 V/DIV., 10 ms./DIV. Vehicle condition Engine is stopped, engine switch on (IG) Waveform 3 REFERENCE Terminal CAN- - E1 Tool setting 1 V/DIV., 10 ms./DIV. Vehicle condition Engine is stopped, engine switch on (IG)
2. ECM HINT: Each ECM terminal standard voltage is shown in the table below. In the table, first follow the information under "Condition". Look under "Terminal No. (Symbol)" for the terminals to be inspected. The standard voltage between the terminals is shown under "Specified Condition". Use the illustration below as a reference for the ECM terminals. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A43-25 (S) - D1-81 (E1) L - BR S shift position switch signal Engine switch on (IG) and shift lever in S 11 to 14 V Engine switch on (IG) and shift lever in any position except S Below 1 V A43-38 (SFTU) - D1-81 (E1) W - BR Up shift switch signal Engine switch on (IG) and shift lever in S 11 to 14 V Engine switch on (IG) and shift lever in "+" (Up shift) Below 1 V A43-27 (SFTD) - D1-81 (E1) BE - BR Down shift switch signal Engine switch on (IG) and shift lever in S 11 to 14 V Engine switch on (IG) and shift lever in "-" (Down shift) Below 1 V

Scheme 778

Scheme 779

1. DESCRIPTION When troubleshooting On-Board Diagnostic (OBD II) vehicles, the vehicle must be connected to the OBD II scan tool (complying with SAE J1987). Various data output from the vehicle TCM can then be read. OBD II regulations require that the vehicle on-board computer illuminate the Malfunction Indicator Lamp (MIL) on the instrument panel when the computer detects a malfunction in: The emission control system/components The powertrain control components (which affect vehicle emissions) The computer In addition, the applicable Diagnostic Trouble Codes (DTCs) prescribed by SAE J2012 are recorded in the TCM memory. When a malfunction does not reoccur, the MIL stays illuminated until the engine switch is turned off, and the MIL turns off when the engine is started. However, the DTCs will remain recorded in the TCM memory. To check DTCs, connect the Techstream to the Data Link Connector 3 (DLC3) of the vehicle. The Techstream displays DTCs, freeze frame data and a variety of engine data. The DTCs and freeze frame data can be cleared with the Techstream. Refer to «DTC CHECK / CLEAR»(ref-400823-S37187369772011051800000) .
2. NORMAL MODE AND CHECK MODE The diagnosis system operates in "normal mode" during normal vehicle use. In normal mode, "2 trip detection logic" is used to ensure accurate detection of malfunctions. "Check mode" is also available to technicians as an option. In check mode, "1 trip detection logic" is used for simulating malfunction symptoms and increasing the system's ability to detect malfunctions, including intermittent malfunctions.
3. 2 TRIP DETECTION LOGIC When a malfunction is first detected, the malfunction is temporarily stored in the TCM memory (1st trip). If the same malfunction is detected during the next drive cycle, the MIL is illuminated (2nd trip).
4. FREEZE FRAME DATA The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was running or stopped, whether the engine was warmed up or not, whether the air/fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction. The Techstream records freeze frame data in 5 different instances: 1) 3 times before the DTC is set, 2) once when the DTC is set, and 3) once after the DTC is set. These sets of data can be used to simulate the vehicle condition around the time when the malfunction occurred. The data may help in finding the cause of the malfunction, or in judging if the DTC was caused by a temporary malfunction.
5. CHECK DATA LINK CONNECTOR 3 (DLC3) Check the DLC3. Refer to «GENERAL INFORMATION»(ref-400649-S41373024542011051800000)
6. CHECK MIL Check that the MIL illuminates when turning the engine switch on (IG). If the MIL does not illuminate, there is a problem in the MIL circuit. Refer to «MIL Circuit»(ref-400785-S09336412852011051800000) . When the engine is started, the MIL should turn off.

DIAGNOSIS SYSTEM

1. DESCRIPTION When troubleshooting On-Board Diagnostic (OBD II) vehicles, the vehicle must be connected to the OBD II scan tool (complying with SAE J1987). Various data output from the vehicle TCM can then be read. OBD II regulations require that the vehicle on-board computer illuminate the Malfunction Indicator Lamp (MIL) on the instrument panel when the computer detects a malfunction in: The emission control system/components The powertrain control components (which affect vehicle emissions) The computer In addition, the applicable Diagnostic Trouble Codes (DTCs) prescribed by SAE J2012 are recorded in the TCM memory. When a malfunction does not reoccur, the MIL stays illuminated until the engine switch is turned off, and the MIL turns off when the engine is started. However, the DTCs will remain recorded in the TCM memory. To check DTCs, connect the Techstream to the Data Link Connector 3 (DLC3) of the vehicle. The Techstream displays DTCs, freeze frame data and a variety of engine data. The DTCs and freeze frame data can be cleared with the Techstream. Refer to «DTC CHECK / CLEAR»(ref-400823-S18744050322011051800000) .
2. NORMAL MODE AND CHECK MODE The diagnosis system operates in "normal mode" during normal vehicle use. In normal mode, "2 trip detection logic" is used to ensure accurate detection of malfunctions. "Check mode" is also available to technicians as an option. In check mode, "1 trip detection logic" is used for simulating malfunction symptoms and increasing the system's ability to detect malfunctions, including intermittent malfunctions.
3. 2 TRIP DETECTION LOGIC When a malfunction is first detected, the malfunction is temporarily stored in the TCM memory (1st trip). If the same malfunction is detected during the next drive cycle, the MIL is illuminated (2nd trip).
4. FREEZE FRAME DATA The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was running or stopped, whether the engine was warmed up or not, whether the air/fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction. The Techstream records freeze frame data in 5 different instances: 1) 3 times before the DTC is set, 2) once when the DTC is set, and 3) once after the DTC is set. These sets of data can be used to simulate the vehicle condition around the time when the malfunction occurred. The data may help in finding the cause of the malfunction, or in judging if the DTC was caused by a temporary malfunction.
5. CHECK DATA LINK CONNECTOR 3 (DLC3) Check the DLC3. Refer to «GENERAL INFORMATION»(ref-400649-S41373024542011051800000)
6. CHECK MIL Check that the MIL illuminates when turning the engine switch on (IG). If the MIL does not illuminate, there is a problem in the MIL circuit. Refer to «MIL Circuit»(ref-400785-S04845152512011051800000) . When the engine is started, the MIL should turn off.

DTC CHECK / CLEAR

Note. When the diagnosis system is changed from normal mode to check mode or vice versa, all DTCs and freeze frame data recorded in normal mode are cleared. Before changing modes, always check and make a note of DTCs and freeze frame data.

HINT

1. DTCs which are stored in the TCM can be displayed on the Techstream. The Techstream can display the current, pending and permanent DTCs.
2. If a malfunction is detected during the current driving cycle, current and permanent DTCs are stored.
3. Some DTCs are not stored if the TCM does not detect the same malfunction again during a second consecutive driving cycle. However, such malfunctions, detected on only one occasion, are stored as pending DTCs.
4. Current and pending DTCs can be cleared by using the Techstream or by disconnecting the cable from the negative battery terminal. However, permanent DTCs cannot be cleared using either of these two methods.
5. After clearing current DTCs using the Techstream (or by disconnecting the cable from the negative battery terminal), permanent DTCs can be cleared when the system is determined to be normal for the relevant DTCs and then the universal trip is performed.

2 TRIP DETECTION EXAMPLES

Scheme 780

Scheme 781

Scheme 782

1. CHECK DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Check the DTC(s) and freeze frame data, and then write them down. Check the details of the DTC(s). Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-400823-S12627040952011051800000) .
2. CLEAR DTC (Pending and Current DTC) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Clear the DTCs.
3. CLEAR PERMANENT DTC HINT: Even if the following procedure is not performed, permanent DTCs are cleared if no malfunction are detected during 3 consecutive driving cycles. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check if permanent DTCs are stored. HINT: If permanent DTCs are not output, it is not necessary to continue this procedure. Clear DTCs. Perform the universal trip. Idle the engine for 30 seconds or more. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more. HINT: It is possible to complete the drive pattern even if the vehicle decelerates to less than 40 km/h (25 mph) during the driving cycle provided that the vehicle is driven at 40 km/h (25 mph) or more for a total of 5 minutes. When accelerating through the gears, make sure the vehicle is driven so all gears are used in order and no gears are skipped. Allow 10 minutes or more to elapse from the time the engine is started. Turn the engine switch off. Wait 15 seconds. Turn the engine switch on (IG). Enter the following menus: Powertrain / ECT / Trouble Codes. Check that the permanent DTCs have been cleared. HINT: If the permanent DTCs have not been cleared, perform the universal trip again. The permanent DTCs are cleared when the universal trip is completed.

Note. When the diagnosis system is changed from normal mode to check mode or vice versa, all DTCs and freeze frame data recorded in normal mode are cleared. Before changing modes, always check and make a note of DTCs and freeze frame data.

HINT

1. DTCs which are stored in the TCM can be displayed on the Techstream. The Techstream can display the current, pending and permanent DTCs.
2. If a malfunction is detected during the current driving cycle, current and permanent DTCs are stored.
3. Some DTCs are not stored if the TCM does not detect the same malfunction again during a second consecutive driving cycle. However, such malfunctions, detected on only one occasion, are stored as pending DTCs.
4. Current and pending DTCs can be cleared by using the Techstream or by disconnecting the cable from the negative battery terminal. However, permanent DTCs cannot be cleared using either of these two methods.
5. After clearing current DTCs using the Techstream (or by disconnecting the cable from the negative battery terminal), permanent DTCs can be cleared when the system is determined to be normal for the relevant DTCs and then the universal trip is performed.

2 TRIP DETECTION EXAMPLES

1. CHECK DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Check the DTC(s) and freeze frame data, and then write them down. Check the details of the DTC(s). Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-400823-S26522998412011051800000) .
2. CLEAR DTC (Pending and Current DTC) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Clear the DTCs.
3. CLEAR PERMANENT DTC HINT: Even if the following procedure is not performed, permanent DTCs are cleared if no malfunction are detected during 3 consecutive driving cycles. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check if permanent DTCs are stored. HINT: If permanent DTCs are not output, it is not necessary to continue this procedure. Clear DTCs. Perform the universal trip. Idle the engine for 30 seconds or more. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more. HINT: It is possible to complete the drive pattern even if the vehicle decelerates to less than 40 km/h (25 mph) during the driving cycle provided that the vehicle is driven at 40 km/h (25 mph) or more for a total of 5 minutes. When accelerating through the gears, make sure the vehicle is driven so all gears are used in order and no gears are skipped. Allow 10 minutes or more to elapse from the time the engine is started. Turn the engine switch off. Wait 15 seconds. Turn the engine switch on (IG). Enter the following menus: Powertrain / ECT / Trouble Codes. Check that the permanent DTCs have been cleared. HINT: If the permanent DTCs have not been cleared, perform the universal trip again. The permanent DTCs are cleared when the universal trip is completed.

Scheme 783

1. DESCRIPTION Check mode has a higher sensitivity to malfunctions and can detect malfunctions that normal mode cannot detect. Check mode can also detect all the malfunctions that normal mode can detect. In check mode, DTCs are detected with 1 trip detection logic.
2. CHECK MODE PROCEDURE Make sure that the following conditions are met: Battery positive voltage 11 V or more. Throttle valve fully closed. Shift lever in P or N. A/C off. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Check Mode. Change the TCM to check mode. Make sure the MIL flashes as shown in the illustration. NOTE: All DTCs and freeze frame data will be cleared if: 1) the Techstream is used to change the TCM from normal mode to check mode or vice versa; or 2) during check mode, the engine switch is turned from on (IG) to on (ACC) or off. Before entering check mode, make notes of the DTCs and freeze frame data. Start the engine. The MIL should turn off after the engine starts. Perform Monitor Drive Pattern for the ECT test. Refer to «MONITOR DRIVE PATTERN»(ref-400823-S01088772892011051800000) . (Or, simulate the conditions of the malfunction described by the customer.) After simulating the malfunction conditions, use the Techstream to check the DTC and freeze frame data.

DATA LIST / ACTIVE TEST

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List. According to the display on the Techstream, read the Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note Vehicle Speed Vehicle speed / Min.: 0 km/h (0 mph), Max.: 255 km/h (158 mph) Actual vehicle speed - Engine Speed Engine speed / Min.: 0 rpm, Max.: 16383.75 rpm 550 to 800 rpm: Idling - Calculate Load Calculated load by ECM / Min.: 0%, Max.: 100% 15.0 to 35.0%: Idling 10.0 to 30.0%: Running without load (2000 rpm) - Coolant Temp Engine coolant temperature / Min.: -40°C (-40°F), Max.: 140°C (284°F) 80 to 105°C (176 to 221°F): After warming up If value -40°C (-40°F): sensor circuit open If value 140°C (284°F): sensor circuit shorted Engine Run Time Engine run time / Min.: 0 second, Max.: 65535 seconds Time after engine start - Battery Voltage Battery voltage / Min.: 0, Max.: 65.535 V 9 to 14 V: Idling - Throttle Sensor Volt % Throttle position sensor output/ Min.: 0%, Max.: 100% 10 to 22%: Idling Calculated value based on VTA1 Starter Signal Starter signal/ Open or Close - - Neutral Position SW Signal PNP switch status/ ON or OFF ON: Shift lever is in P or N OFF: Shift lever is not in P or N When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-400842-S36639628982011051800000) . Stop Light Switch Stop light switch status/ ON or OFF Brake pedal is ON: Depressed OFF: Released - TC terminal TC terminal Status / ON or OFF - - #Codes (Include History) # of Codes / Min.: 0, Max.: 255 - Number of detected DTCs MIL ON Run Distance MIL ON run distance / Min.: 0 km (0 mile), Max.: 65535 km (40723 mile) Distance after DTC detected - Running Time from MIL ON Running time from MIL ON / Min.: 0 minute, Max.: 65535 minutes Equivalent to running time after MIL ON - Time after DTC Cleared Time after DTC cleared / Min.: 0 minute, Max.: 65535 minutes Equivalent to time after DTCs cleared - Distance from DTC Cleared Distance after DTC cleared / Min.: 0 km (0 mile) Max.: 65535 km (40723 mile) Equivalent to time after DTCs cleared - Warmup Cycle Cleared DTC Warm-up cycle after DTC cleared / Min.: 0, Max.: 255 - Number of warm-up cycles after DTCs cleared TC and TE1 TC and TE1 terminals of DLC3 / ON or OFF - Active Test support data Engine Speed from EFI Engine speed / Min.: 0 rpm, Max.: 16383.75 rpm 550 to 800 rpm: Idling - Intake-Air Temp from EFI Intake air temperature / Min.: -40°C (-40°F), Max.: 215°C (419°F) Equivalent to ambient air temperature If value -40°C(-40°F): sensor circuit open If value 215°C(419°F): sensor circuit shorted Coolant Temp from EFI Engine coolant temperature / Min.: -40°C (-40°F), Max.: 215°C (419°F) 80 to 105°C (176 to 221°F): After warming up If value -40°C (-40°F): sensor circuit open If value 140°C (284°F): sensor circuit shorted Throttle Position from EFI Throttle sensor position / Min.: 0%, Max.: 100% 0%: Accelerator pedal released 64 to 96%: Accelerator pedal fully depressed Recognition value for throttle opening angle on ECM Accel Position from EFI Absolute Accelerator Pedal Position / Min.: 0%, Max.: 100% 10 to 22%: Accelerator pedal released 54 to 86%: Accelerator pedal fully depressed - SPD (NT) Input turbine speed/ display: 50 r/min Lock-up is ON (After warming up the engine): Input turbine speed (NT) is equal to engine speed OFF (idling with shift lever in N): Input turbine speed (NT) is nearly equal to engine speed - SPD (NC) Counter gear speed / Min.: 0 rpm, Max.: 12750 rpm - - Shift SW Status (P Range) PNP switch status/ ON or OFF ON: Shift lever is in P OFF: Shift lever is not in P When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-400842-S36639628982011051800000) Shift SW Status (R Range) PNP switch status/ ON or OFF ON: Shift lever is in R OFF: Shift lever is not in R When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-400842-S36639628982011051800000) Shift SW Status (N Range) PNP switch status/ ON or OFF ON: Shift lever is in N OFF: Shift lever is not in N When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-400842-S36639628982011051800000) Sports Shift Up SW Sport shift up switch status/ ON or OFF ON: Continuously shift to "+" (up-shift) OFF: Release "+" (up-shift) - Sports Shift Down SW Sport shift down switch status/ ON or OFF ON: Continuously shift to "-" (down-shift) OFF: Release "-" (down-shift) - Sports Mode Selection SW Sport mode select switch status/ ON or OFF Shift lever is: ON: S, "+" or "-" OFF: Not in S, "+" or "-" - Shift SW Status (D Range) PNP switch status/ ON or OFF ON: Shift lever is in D or S OFF: Shift lever is not in D or S When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-400842-S36639628982011051800000) A/T Oil Temperature 1 ATF temp. sensor value/ min.: -40°C (-40°F) max.: 215°C (419°F) After stall test; Approx. 80°C (176°F) Equal to ambient temperature when cold soak If the value is "-40°C (-40°F)" or "215°C (419°F)", ATF temp. sensor circuit is open or shorted. NT Sensor Voltage Input turbine speed sensor output voltage / Min.: 0 V, Max.: 5 V 0.1 to 1.9 V - NC Sensor Voltage Counter gear speed sensor output voltage / Min.: 0 V, Max.: 5 V 0.1 to 1.9 V - TPS 3 Switch ATF pressure switch No. 3 status/ 0: OFF / 1: ON ON: Shift solenoid valve SLU is ON OFF: Shift solenoid valve SLU is OFF - TPS 2 Switch ATF pressure switch No. 2 status/ 0: OFF / 1: ON ON: Gear is 4th, 5th or 6th OFF: Gear is 1st, 2nd or 3rd - TPS 1 Switch ATF pressure switch No. 1 status/ 0: OFF / 1: ON ON: Gear is 1st, 2nd, 3rd or 4th OFF: Gear is 5th or 6th - Lock Up Lock up / 0: OFF / 1: ON Lock up: ON - Shift Status TCM gear shift command/ 1st, 2nd, 3rd, 4th, 5th or 6th Same as actual gear - SLT Solenoid Status Shift solenoid SLT status/ ON or OFF Accelerator pedal is depressed: OFF Accelerator pedal is released: ON - SLU Solenoid Status Shift Solenoid SLU Status/ ON or OFF ON: Lock up OFF: Except lock up - SL Solenoid Status Shift Solenoid SL Status/ ON or OFF ON: Lock up OFF: Except lock up - AT Fluid Flex lockup judder judgment flag / 0: OFF / 1: ON
2. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Active Test. According to the display on the Techstream, perform the Active Test. Tester Display Test Part Control Range Diagnostic Note Connect the TC and TE1 Connects and disconnects TC and TE1. (transitions into the fluid temperature detection mode) ON/OFF The MIL will not blink when "Connect the TC and TE1 / ON" is selected. Activate the Solenoid (SLU) Operates shift solenoid SLU ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SLT)* Operates shift solenoid SLT to raise the line pressure. ON/OFF HINT: ON: No action (normal operation) OFF: Line pressure up (When the Active Test of "Activate the Solenoid (SLT)" is performed, the TCM commands the SLT solenoid to turn off). [Vehicle Condition] Vehicle Stopped IDL: ON Activate the Lock Up Controls the shift solenoid SLU and SL to set the automatic transaxle to the lock-up condition. ON/OFF Can be used to check SLU and SL solenoid operation. [Vehicle Condition] Vehicle speed: 60 km/h (37 mph) or more Activate the Solenoid (SL) Operates shift solenoid SL ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Control the Shift Position Operates the shift solenoid valves to allow gears to selected manually. Press "-->" button: Upshift occurs Press "<--" button: Downshift occurs Can be used to check the operation of the shift solenoid valves. Upshifts and downshifts should be performed consecutively. A 10-second interval is required between gear changes. Do not downshift at high speeds. Doing so will damage the automatic transaxle. [Vehicle Condition] 50 km/h (30 mph) or less Activate the Solenoid (SL1) Operates shift solenoid SL1 ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SL2) Operates shift solenoid SL2 ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SL3) Operates shift solenoid SL3 ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SL4) Operates shift solenoid SL4 ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N *: The "Activate the solenoid (SLT)" Active Test is performed to allow confirmation that the line pressure changes. The line pressure changes are confirmed using the same SST that is used for the Hydraulic Test. Refer to «HYDRAULIC TEST»(ref-400823-S20120488542011051800000) . HINT: Note that the pressure readings for the Active Test and Hydraulic Test are different.

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Data List. According to the display on the Techstream, read the Data List. Tester Display Measurement Item/Range Normal Condition Diagnostic Note Vehicle Speed Vehicle speed / Min.: 0 km/h (0 mph), Max.: 255 km/h (158 mph) Actual vehicle speed - Engine Speed Engine speed / Min.: 0 rpm, Max.: 16383.75 rpm 550 to 800 rpm: Idling - Calculate Load Calculated load by ECM / Min.: 0%, Max.: 100% 15.0 to 35.0%: Idling 10.0 to 30.0%: Running without load (2000 rpm) - Coolant Temp Engine coolant temperature / Min.: -40°C (-40°F), Max.: 140°C (284°F) 80 to 105°C (176 to 221°F): After warming up If value -40°C (-40°F): sensor circuit open If value 140°C (284°F): sensor circuit shorted Engine Run Time Engine run time / Min.: 0 second, Max.: 65535 seconds Time after engine start - Battery Voltage Battery voltage / Min.: 0, Max.: 65.535 V 9 to 14 V: Idling - Throttle Sensor Volt % Throttle position sensor output/ Min.: 0%, Max.: 100% 10 to 22%: Idling Calculated value based on VTA1 Starter Signal Starter signal/ Open or Close - - Neutral Position SW Signal PNP switch status/ ON or OFF ON: Shift lever is in P or N OFF: Shift lever is not in P or N When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-400842-S07052548892011051800000) . Stop Light Switch Stop light switch status/ ON or OFF Brake pedal is ON: Depressed OFF: Released - TC terminal TC terminal Status / ON or OFF - - #Codes (Include History) # of Codes / Min.: 0, Max.: 255 - Number of detected DTCs MIL ON Run Distance MIL ON run distance / Min.: 0 km (0 mile), Max.: 65535 km (40723 mile) Distance after DTC detected - Running Time from MIL ON Running time from MIL ON / Min.: 0 minute, Max.: 65535 minutes Equivalent to running time after MIL ON - Time after DTC Cleared Time after DTC cleared / Min.: 0 minute, Max.: 65535 minutes Equivalent to time after DTCs cleared - Distance from DTC Cleared Distance after DTC cleared / Min.: 0 km (0 mile) Max.: 65535 km (40723 mile) Equivalent to time after DTCs cleared - Warmup Cycle Cleared DTC Warm-up cycle after DTC cleared / Min.: 0, Max.: 255 - Number of warm-up cycles after DTCs cleared TC and TE1 TC and TE1 terminals of DLC3 / ON or OFF - Active Test support data Engine Speed from EFI Engine speed / Min.: 0 rpm, Max.: 16383.75 rpm 550 to 800 rpm: Idling - Intake-Air Temp from EFI Intake air temperature / Min.: -40°C (-40°F), Max.: 215°C (419°F) Equivalent to ambient air temperature If value -40°C(-40°F): sensor circuit open If value 215°C(419°F): sensor circuit shorted Coolant Temp from EFI Engine coolant temperature / Min.: -40°C (-40°F), Max.: 215°C (419°F) 80 to 105°C (176 to 221°F): After warming up If value -40°C (-40°F): sensor circuit open If value 140°C (284°F): sensor circuit shorted Throttle Position from EFI Throttle sensor position / Min.: 0%, Max.: 100% 0%: Accelerator pedal released 64 to 96%: Accelerator pedal fully depressed Recognition value for throttle opening angle on ECM Accel Position from EFI Absolute Accelerator Pedal Position / Min.: 0%, Max.: 100% 10 to 22%: Accelerator pedal released 54 to 86%: Accelerator pedal fully depressed - SPD (NT) Input turbine speed/ display: 50 r/min Lock-up is ON (After warming up the engine): Input turbine speed (NT) is equal to engine speed OFF (idling with shift lever in N): Input turbine speed (NT) is nearly equal to engine speed - SPD (NC) Counter gear speed / Min.: 0 rpm, Max.: 12750 rpm - - Shift SW Status (P Range) PNP switch status/ ON or OFF ON: Shift lever is in P OFF: Shift lever is not in P When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-400842-S07052548892011051800000) Shift SW Status (R Range) PNP switch status/ ON or OFF ON: Shift lever is in R OFF: Shift lever is not in R When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-400842-S07052548892011051800000) Shift SW Status (N Range) PNP switch status/ ON or OFF ON: Shift lever is in N OFF: Shift lever is not in N When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-400842-S07052548892011051800000) Sports Shift Up SW Sport shift up switch status/ ON or OFF ON: Continuously shift to "+" (up-shift) OFF: Release "+" (up-shift) - Sports Shift Down SW Sport shift down switch status/ ON or OFF ON: Continuously shift to "-" (down-shift) OFF: Release "-" (down-shift) - Sports Mode Selection SW Sport mode select switch status/ ON or OFF Shift lever is: ON: S, "+" or "-" OFF: Not in S, "+" or "-" - Shift SW Status (D Range) PNP switch status/ ON or OFF ON: Shift lever is in D or S OFF: Shift lever is not in D or S When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-400842-S07052548892011051800000) A/T Oil Temperature 1 ATF temp. sensor value/ min.: -40°C (-40°F) max.: 215°C (419°F) After stall test; Approx. 80°C (176°F) Equal to ambient temperature when cold soak If the value is "-40°C (-40°F)" or "215°C (419°F)", ATF temp. sensor circuit is open or shorted. NT Sensor Voltage Input turbine speed sensor output voltage / Min.: 0 V, Max.: 5 V 0.1 to 1.9 V - NC Sensor Voltage Counter gear speed sensor output voltage / Min.: 0 V, Max.: 5 V 0.1 to 1.9 V - TPS 3 Switch ATF pressure switch No. 3 status/ 0: OFF / 1: ON ON: Shift solenoid valve SLU is ON OFF: Shift solenoid valve SLU is OFF - TPS 2 Switch ATF pressure switch No. 2 status/ 0: OFF / 1: ON ON: Gear is 4th, 5th or 6th OFF: Gear is 1st, 2nd or 3rd - TPS 1 Switch ATF pressure switch No. 1 status/ 0: OFF / 1: ON ON: Gear is 1st, 2nd, 3rd or 4th OFF: Gear is 5th or 6th - Lock Up Lock up / 0: OFF / 1: ON Lock up: ON - Shift Status TCM gear shift command/ 1st, 2nd, 3rd, 4th, 5th or 6th Same as actual gear - SLT Solenoid Status Shift solenoid SLT status/ ON or OFF Accelerator pedal is depressed: OFF Accelerator pedal is released: ON - SLU Solenoid Status Shift Solenoid SLU Status/ ON or OFF ON: Lock up OFF: Except lock up - SL Solenoid Status Shift Solenoid SL Status/ ON or OFF ON: Lock up OFF: Except lock up - AT Fluid Flex lockup judder judgment flag / 0: OFF / 1: ON
2. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Active Test. According to the display on the Techstream, perform the Active Test. Tester Display Test Part Control Range Diagnostic Note Connect the TC and TE1 Connects and disconnects TC and TE1. (transitions into the fluid temperature detection mode) ON/OFF The MIL will not blink when "Connect the TC and TE1 / ON" is selected. Activate the Solenoid (SLU) Operates shift solenoid SLU ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SLT)* Operates shift solenoid SLT to raise the line pressure. ON/OFF HINT: ON: No action (normal operation) OFF: Line pressure up (When the Active Test of "Activate the Solenoid (SLT)" is performed, the TCM commands the SLT solenoid to turn off). [Vehicle Condition] Vehicle Stopped IDL: ON Activate the Lock Up Controls the shift solenoid SLU and SL to set the automatic transaxle to the lock-up condition. ON/OFF Can be used to check SLU and SL solenoid operation. [Vehicle Condition] Vehicle speed: 60 km/h (37 mph) or more Activate the Solenoid (SL) Operates shift solenoid SL ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Control the Shift Position Operates the shift solenoid valves to allow gears to selected manually. Press "-->" button: Upshift occurs Press "<--" button: Downshift occurs Can be used to check the operation of the shift solenoid valves. Upshifts and downshifts should be performed consecutively. A 10-second interval is required between gear changes. Do not downshift at high speeds. Doing so will damage the automatic transaxle. [Vehicle Condition] 50 km/h (30 mph) or less Activate the Solenoid (SL1) Operates shift solenoid SL1 ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SL2) Operates shift solenoid SL2 ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SL3) Operates shift solenoid SL3 ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SL4) Operates shift solenoid SL4 ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N *: The "Activate the solenoid (SLT)" Active Test is performed to allow confirmation that the line pressure changes. The line pressure changes are confirmed using the same SST that is used for the Hydraulic Test. Refer to «HYDRAULIC TEST»(ref-400823-S20120488542011051800000) . HINT: Note that the pressure readings for the Active Test and Hydraulic Test are different.

DIAGNOSTIC TROUBLE CODE CHART

HINT

1. If a DTC is displayed during the DTC check, check the parts listed in the table below and proceed to table «AUTOMATIC TRANSAXLE SYSTEM»(ref-400823-S35874384172011051800000) .
2. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Trouble Area" column of the table.
3. *1: "Comes on" means the Malfunction Indicator Lamp (MIL) illuminates.
4. *2: "DTC stored" means the TCM memorizes the trouble code if the TCM detects the DTC detection condition.
5. These DTCs may be output when clutches, brakes, gear components, etc., inside the automatic transaxle are damaged.

AUTOMATIC TRANSAXLE SYSTEM

HINT

1. If a DTC is displayed during the DTC check, check the parts listed in the table below and proceed to table «AUTOMATIC TRANSAXLE SYSTEM»(ref-400823-S32898045832011051800000) .
2. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Trouble Area" column of the table.
3. *1: "Comes on" means the Malfunction Indicator Lamp (MIL) illuminates.
4. *2: "DTC stored" means the TCM memorizes the trouble code if the TCM detects the DTC detection condition.
5. These DTCs may be output when clutches, brakes, gear components, etc., inside the automatic transaxle are damaged.

AUTOMATIC TRANSAXLE SYSTEM
