PRECAUTION

Note. When disconnecting the negative (-) battery cable, initialize the following systems after the cable is reconnected.

SYSTEM INITIALIZATION TABLE

Scheme 75

Scheme 76

Scheme 77

Scheme 78

CUSTOMIZE PARAMETERS

HINT

The following items can be customized.

Note. After confirming whether the items requested by the customer are applicable or not for customization, perform customize operations. Be sure to record the current settings before customizing. When troubleshooting, make sure that the item in question is not set to "OFF" as a result of customization. (Example: For the symptom "the wireless function does not operate", first check that the wireless function is not set to "OFF", then perform troubleshooting).

POWER WINDOW

POWER WINDOW CUSTOMIZE PARAMETERS

INITIALIZATION

1. RESET (INITIALIZE) POWER WINDOW REGULATOR MOTOR NOTE: Resetting the power window motor (initializing the pulse sensor) is necessary when the battery terminal is disconnected; when the power window regulator master switch, power window regulator switch, wire harness, power window regulator and power window motor are replaced or removed/installed; or when the PWR fuse, RR DOOR LH fuse, RR DOOR RH and ECU-B fuse are replaced. AUTO operation function, jam protection function and remote operation function via the power window regulator master switch do not operate without resetting. Be sure to reset the power window regulator motors using the power window switch on each door because the motors cannot be reset by remote operation using the power window master switch. In order to prevent a large amount of current from flowing in the wires, do not simultaneously reset 2 or more power window regulator motors. If the power window switch has been continuously operated for a long time, the power window regulator motor will stop so that no additional load will be applied to the motor. Continuing to operate the switch even after the motor has stopped will cause the switch to blink while restricting the AUTO UP/DOWN function and the remote UP/DOWN function. If this happens, reset the motor again after several minutes have passed. Whenever disconnecting the battery terminal, reset all the other systems besides the power window control system. Turn the ignition switch ON. Halfway open the power window by pressing the power window switch. Fully pull up the switch until the power window is fully closed and continue to hold the switch for approx. 1 second after the power window is fully closed. Check that the AUTO UP/DOWN function operates normally. If the AUTO UP/DOWN function operates normally, reset operations have been completed at this time. If not normal, follow steps below. Disconnect the negative battery terminal for 10 seconds. Connect the battery terminal. Turn the ignition switch ON. Halfway open the power window by pressing the power window switch. If the AUTO UP/DOWN function operates normally, reset operations have been completed at this time. If not normal, follow steps below. Turn the ignition switch ON. Halfway open the power window by pressing the power window switch. Fully pull up the switch until the power window is fully closed and continue to hold the switch for approx. 12 seconds after the power window is fully closed. Check that the AUTO UP/DOWN function operates normally.

POWER WINDOW CONTROL SYSTEM

PROBLEM SYMPTOMS TABLE

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

1. MULTIPLEX NETWORK MASTER SWITCH Disconnect the P22 switch connector. Measure the voltage and resistance of each terminal according to the value(s) in the table below. Standard resistance TERMINALS DESCRIPTION - SPECIFIED CONDITION (RESISTANCE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition GND (P22-2) - Body ground W-B - Body ground Ground Constant Below 1 ohms Standard voltage TERMINALS DESCRIPTION - SPECIFIED CONDITION (VOLTAGE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition BDR (P22-10) - GND (P22-2) G - W-B +B power supply Constant 10 to 14 V CPUB (P22-9) - GND (P22-2) L-B - W-B +B power supply Constant 10 to 14 V SIG (P22-20) - GND (P22-2) BR - W-B Ignition power supply Ignition switch OFF --> ON 0 V --> 10 to 14 V If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the P22 switch connector and reset the power window motor. Measure the voltage according to the value(s) in the table below. Standard voltage TERMINALS DESCRIPTION - SPECIFIED CONDITION (VOLTAGE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition UP (P22-1) - GND (P22-2) GR - W-B Power window motor UP output Ignition switch ON, Driver side power window switch OFF --> UP (Manual operation) 0 V --> 10 to 14 V UP (P22-1) - GND (P22-2) GR - W-B Power window motor UP output Ignition switch ON, Driver side power window fully open --> Driver side power window switch UP (AUTO operation) --> Driver side power window fully closed 0 V --> 10 to 14 V --> 0 V DN (P22-11) - GND (P22-2) B - W-B Power window motor DOWN output Ignition switch ON, Driver side power window switch OFF --> DOWN (Manual operation) 10 to 14 V --> 0 V DN (P22-11) - GND (P22-2) B - W-B Power window motor DOWN output Ignition switch ON, Driver side power window fully closed --> Driver side power window switch DOWN (AUTO operation) --> Driver side power window fully open 10 to 14 V --> 0 V PWS (P22-6) - GND (P22-2) O - W-B Power window lock switch output Ignition switch ON, Power window lock switch UNLOCK --> LOCK 10 to 14 V --> 0 V VCC (P22-19) - GND (P22-2) O - W-B Power window motor power source Constant 10 to 14 V
2. CHECK MULTIPLEX NETWORK SWITCH (FRONT PASSENGER SIDE) Disconnect the P19 switch connector. Measure the voltage and resistance according to the value(s) in the table below. Standard resistance TERMINALS DESCRIPTION - SPECIFIED CONDITION (RESISTANCE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition GND (P19-7) - Body ground W-B - Body ground Ground Constant Below 1 ohms Standard voltage TERMINALS DESCRIPTION - SPECIFIED CONDITION (VOLTAGE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition BDR (P19-12) - GND (P19-7) G - W-B +B power supply Constant 10 to 14 V If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the P19 switch connector and reset power window motor. Measure the voltage according to the value(s) in the table below. Standard voltage TERMINALS DESCRIPTION - SPECIFIED CONDITION (VOLTAGE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition UP (P19-6) - GND (P19-7) GR - W-B Power window motor UP output Ignition switch ON, Regulator switch OFF --> UP (Manual operation) 0 V --> 10 to 14 V UP (P19-6) - GND (P19-7) GR - W-B Power window motor UP output Ignition switch ON, Front passenger side power window fully open --> Regulator switch UP (AUTO operation) --> Front passenger side power window fully closed 0 V --> 10 to 14 V --> 0 V DN (P19-1) - GND (P19-7) B - W-B Power window motor DOWN output Ignition switch ON, Regulator switch OFF --> DOWN (Manual operation) 10 to 14 V --> 0 V DN (P19-1) - GND (P19-7) B - W-B Power window motor DOWN output Ignition switch ON, Front passenger side power window fully closed --> Regulator switch DOWN (AUTO operation) --> Front passenger side power window fully open 10 to 14 V --> 0 V PCT (P19-11) - GND (P19-7) O - W-B Power window lock switch output Ignition switch ON, Power window lock switch UNLOCK --> LOCK 10 to 14 V --> 0 V VCC (P19-5) - SGND (P19-8) LG - R Power window motor power source Constant 10 to 14 V If the result is not as specified, the multiplex network switch may have a malfunction.
3. CHECK MULTIPLEX NETWORK SWITCH (REAR LH) Disconnect the P20 switch connector. Measure the voltage and resistance according to the value(s) in the table below. Standard resistance TERMINALS DESCRIPTION - SPECIFIED CONDITION (RESISTANCE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition GND (P20-7) - Body ground W-B - Body ground Ground Constant Below 1 ohms SEL2 (P20-10) - GND (P20-7) W-B - W-B Terminal for identification of rear LH switch Constant Below 1 ohms Standard voltage TERMINALS DESCRIPTION - SPECIFIED CONDITION (VOLTAGE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition BDR (P20-12) - GND (P20-7) LG - W-B +B power supply Constant 10 to 14 V Reconnect the P20 switch connector and reset the power window motor. Measure the voltage according to the value(s) in the table below. Standard voltage TERMINALS DESCRIPTION - SPECIFIED CONDITION (VOLTAGE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition UP (P20-6) - GND (P20-7) V - W-B Power window motor UP output Ignition switch ON, Regulator switch OFF --> UP (Manual operation) 0 V --> 10 to 14 V UP (P20-6) - GND (P20-7) V - W-B Power window motor UP output Ignition switch ON, Rear LH power window fully open --> Regulator switch UP (AUTO operation) --> Rear LH power window fully closed 0 V --> 10 to 14 V --> 0 V DN (P20-1) - GND (P20-7) W - W-B Power window motor DOWN output Ignition switch ON, Regulator switch OFF --> DOWN (Manual operation) 10 to 14 V --> 0 V DN (P20-1) - GND (P20-7) W - W-B Power window motor DOWN output Ignition switch ON, Rear LH power window fully closed --> Regulator switch DOWN (AUTO operation) --> Rear LH power window fully open 10 to 14 V --> 0 V PCT1 (P20-11) - GND (P20-7) GR - W-B Power window lock switch output Ignition switch ON, Power window lock switch UNLOCK --> LOCK 10 to 14 V --> 0 V VCC (P20-5) - SGND (P20-8) L - BR Power window motor power source Constant 10 to 14 V If the result is not as specified, the multiplex network switch may have a malfunction.
4. CHECK MULTIPLEX NETWORK SWITCH (REAR RH) Disconnect the P21 switch connector. Measure the voltage and resistance according to the value(s) in the table below. Standard resistance TERMINALS DESCRIPTION - SPECIFIED CONDITION (RESISTANCE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition GND (P21-7) - Body ground W-B - Body ground Ground Constant Below 1 ohms SEL1 (P21-9) - GND (P21-7) W-B - W-B Terminal for identification of rear RH switch Constant Below 1 ohms Standard voltage TERMINALS DESCRIPTION - SPECIFIED CONDITION (VOLTAGE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition BDR (P21-12) - GND (P21-7) LG - W-B +B power supply Constant 10 to 14 V Reconnect the P21 switch connector and reset the power window motor. Measure the voltage according to the value(s) in the table below. Standard voltage TERMINALS DESCRIPTION - SPECIFIED CONDITION (VOLTAGE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition UP (P21-6) - GND (P21-7) V - W-B Power window motor UP output Ignition switch ON, Regulator switch OFF --> UP (Manual operation) 0 V --> 10 to 14 V UP (P21-6) - GND (P21-7) V - W-B Power window motor UP output Ignition switch ON, Rear RH power window fully open --> Regulator switch UP (AUTO operation) --> Rear RH power window fully closed 0 V --> 10 to 14 V --> 0 V DN (P21-1) - GND (P21-7) W - W-B Power window motor DOWN output Ignition switch ON, Regulator switch OFF --> DOWN (Manual operation) 10 to 14 V --> 0 V DN (P21-1) - GND (P21-7) W - W-B Power window motor DOWN output Ignition switch ON, Rear RH power window fully closed --> Regulator switch DOWN (AUTO operation) --> Rear RH power window fully open 10 to 14 V --> 0 V PCT1 (P21-11) - GND (P21-7) GR - W-B Power window lock switch output Ignition switch ON, Power window lock switch UNLOCK --> LOCK 10 to 14 V --> 0 V VCC (P21-5) - SGND (P21-8) L - BR Power window motor power source Constant 10 to 14 V If the result is not as specified, the multiplex network switch may have a malfunction.
5. CHECK INSTRUMENT PANEL J/B (BODY ECU) Disconnect the B4, B5 and B6 ECU connectors. Disconnect the 1F and 1M J/B connectors. Measure the resistance according to the value(s) in the table below. Standard resistance TERMINALS DESCRIPTION - SPECIFIED CONDITION (RESISTANCE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition KSW (B4-21) - Body ground B - Body ground Key unlock warning switch input No key in ignition key cylinder --> Key inserted 10kohms or higher --> Below 1 ohms PCTY (B5-23) - Body ground L - W-B Front passenger side courtesy switch input Passenger side door CLOSED --> OPEN 10kohms or higher --> Below 1 ohms DCTY (B6-14) - Body ground L - Body ground Driver side courtesy switch input Driver side door CLOSED --> OPEN 10kohms or higher --> Below 1 ohms GND1 (1F-10) - Body ground W-B - Body ground Ground Constant Below 1 ohms GND2 (1M-9) - Body ground W-B - Body ground Ground Constant Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the B4, B5 and B6 ECU connectors. Reconnect the 1M and 1F J/B connectors. Measure the voltage according to the value(s) in the table below. Standard voltage TERMINALS DESCRIPTION - SPECIFIED CONDITION (VOLTAGE) Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition KSW (B4-21) - Body ground B - Body ground Key unlock warning switch input No key in ignition key cylinder --> Key inserted 10 to 14 V --> 0 V If the result is not as specified, the instrument panel J/B (body ECU) may have a malfunction.

Scheme 84

Scheme 85

Scheme 86

1. DESCRIPTION Data of the system can be read in the Data Link Connector 3 (DLC3) of the vehicle. Therefore, when the system seems to be malfunctioning, use the intelligent tester to check for a malfunction and repair it.
2. CHECK DLC3 The vehicle's ECM uses ISO 9141-2 communication protocol. The terminal arrangement of the DLC3 complies with SAE J1962 and matches the ISO 9141-2 format. Standard TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition 7 (Bus + line) - 5 (Signal ground) During communication Pulse generation 4 (Chassis ground) - Body ground Constant Below 1 ohms 5 (Signal ground) - Body ground Constant Below 1 ohms 16 (B+) - Body ground Constant 9 to 14 V HINT: If the screen displays a communication error message after you have connected the cable of the intelligent tester to the DLC3, turned the ignition switch ON and used the intelligent tester, the problem may be on the vehicle side or tester side. If communication is normal when the tester is connected to another vehicle, inspect the DLC3 of the original vehicle. If communication is still impossible when the tester is connected to another vehicle, the problem is probably in the tester itself, so consult the Service Department listed in the tester's instruction manual.
3. INSPECT BATTERY VOLTAGE Check the battery voltage. Standard voltage: 11 to 14 V If the voltage is below 11 V, replace the battery before proceeding.
4. CHECK DIAGNOSIS Turn the ignition switch ON. Operate the driver side switch of the master switch. Check the blinking pattern of the AUTO light as shown in the illustration. If pattern (A) is displayed, reset power window regulator motor. If pattern (B) or (C) is displayed, check the wire harness. If the normal pattern is displayed, replace the multiplex network master switch.

FAIL-SAFE CHART

1. CHECK POWER WINDOW FAIL-SAFE FUNCTION HINT: If there is a malfunction in the power window system, some of the power window functions will be disabled. Driver side power window DRIVER SIDE POWER WINDOW FAIL-SAFE Malfunctioning Part Disabled Function Operative Function Pulse sensor circuit in power window motor AUTO UP/DOWN function Power window operation function after ignition off Manual UP (fully pulled UP position) Manual DOWN Remote (AUTO and manual) Remote function after ignition OFF (AUTO and manual) MANUAL UP/DOWN function via driver side door lock key cylinder MANUAL DOWN function via transmitter CPU in power window master switch AUTO UP/DOWN function Remote function (AUTO and manual) MANUAL UP/DOWN function via driver side door lock key cylinder MANUAL DOWN function via transmitter Manual UP (fully pulled UP position) Manual DOWN Power windows except driver side power window POWER WINDOWS EXCEPT DRIVER SIDE POWER WINDOW FAIL SAFE Malfunctioning Part Disabled Function Operative Function Pulse sensor circuit in power window motor CPU in power window master switch Communication between master switch and each power window switch AUTO UP/DOWN function Power window operation function after ignition OFF MANUAL UP/DOWN function via driver side door lock key cylinder MANUAL DOWN function via transmitter Manual UP (fully pulled UP position) Manual DOWN

Scheme 87

1. USING INTELLIGENT TESTER Connect the intelligent tester to the DLC3. Monitor the ECU data by following the prompts on the tester screen. HINT: The intelligent tester has a "Snapshot" function which records the monitored data. Refer to the intelligent tester operator's manual for further details.
2. DATA LIST HINT: Using the DATA LIST displayed on the intelligent tester, you can read the value of the switch, sensor, actuator, etc. without parts removal. Reading the DATA LIST as the first step of troubleshooting is one way to shorten the labor time. Connect the intelligent tester to the DLC3. Turn the ignition switch ON. Read the DATA LIST according to the display on the tester. MASTER SW: MASTER SW DATA LIST Item Measurement Item/ Display (Range) Normal Condition Diagnostic Note P/W AUTO SW Driver door power window auto switch signal/ON or OFF ON: Driver door power window auto switch operates OFF: Driver door power window auto switch does not operate - P P/W AUTO SW Front passenger door remote power window auto switch signal/ ON or OFF ON: Front passenger door remote power window auto switch operates OFF: Front passenger door remote power window auto switch does not operate - RR P/W AUTO SW Rear RH door remote power window auto switch signal/ON or OFF ON: Rear RH door remote power window auto switch operates OFF: Rear RH door remote power window auto switch does not operate - RL P/W AUTO SW Rear LH door remote power window auto switch signal/ON or OFF ON: Rear LH door remote power window auto switch operates OFF: Rear LH door remote power window auto switch does not operate - P/W UP SW Driver door power window manual up switch signal/ON or OFF ON: Driver door power window manual up switch operates OFF: Driver door power window manual up switch does not operate - P P/W UP SW Front passenger door remote power window manual up switch signal/ON or OFF ON: Front passenger door remote power window manual up switch operates OFF: Front passenger door remote power window manual up switch does not operate - RR P/W UP SW Rear RH door remote power window manual up switch signal/ON or OFF ON: Rear RH door remote power window manual up switch operates OFF: Rear RH door remote power window manual up switch does not operate - RL P/W UP SW Rear LH door remote power window manual up switch signal/ON or OFF ON: Rear LH door remote power window manual up switch operates OFF: Rear LH door remote power window manual up switch does not operate - P/W DOWN SW Driver door power window manual down switch signal/ON or OFF ON: Driver door power window manual down switch operates OFF: Driver door power window manual down switch does not operate - P P/W DOWN SW Front passenger door remote power window manual down switch signal/ON or OFF ON: Front passenger door remote power window manual down switch operates OFF: Front passenger door remote power window manual down switch does not operate - RR P/W DOWN SW Rear RH door remote power window manual down switch signal/ON or OFF ON: Rear RH door remote power window manual down switch operates OFF: Rear RH door remote power window manual down switch does not operate - RL P/W DOWN SW Rear LH door remote power window manual down switch signal/ON or OFF ON: Rear LH door remote power window manual down switch operates OFF: Rear LH door remote power window manual down switch does not operate - P/W LOCK SW Power window lock switch signal/ON or OFF ON: Power window lock switch in LOCK position OFF: Power window lock switch in UNLOCK position - GLASS POS-1/4 Door glass position (Fully closed -1/4 open) signal/OK or CAUTION OK: Power window is going UP by manual operation CAUTION: CAUTION may be displayed even when no resistance is applied in each position. In this case, there must be a foreign object stuck in that position - GLASS POS-2/4 Door glass position (1/4 open - 2/4 open) signal/OK or CAUTION OK: Power window is going UP by manual operation CAUTION: CAUTION may be displayed even when no resistance is applied in each position. In this case, there must be a foreign object stuck in that position - GLASS POS-3/4 Door glass position (2/4 open - 3/4 open) signal/OK or CAUTION OK: Power window is going UP by manual operation CAUTION: CAUTION may be displayed even when no resistance is applied in each position. In this case, there must be a foreign object stuck in that position - GLASS POS-OPEN Door glass position (3/4 open -Fully open) signal/OK or CAUTION OK: Power window is going UP by manual operation CAUTION: CAUTION may be displayed even when no resistance is applied in each position. In this case, there must be a foreign object stuck in that position - DOOR KEY PW UP Door key-linked power window UP signal/AVAIL or NOT AVL AVAIL: Door key-linked power window UP is available NOT AVL: Door key-linked power window UP is unavailable - DOOR KEY PW DOWN Door key-linked power window DOWN signal/AVAIL or NOT AVL AVAIL: Door key-linked power window DOWN is available NOT AVL: Door key-linked power window DOWN is unavailable - UP/WIRELESS Power window UP w/ transmitter signal/AVAIL or NOT AVL AVAIL: Power window UP w/ transmitter is available NOT AVL: Power window UP w/ transmitter is unavailable - BODY: BODY DATA LIST Item Measurement Item/ Display (Range) Normal Condition Diagnostic Note IG SW Ignition switch signal/ ON or OFF ON: Key is in ON or START position OFF: Key is in OFF or ACC position - D DOR CTY SW Driver side door courtesy switch signal/ or OFF ON: Driver side door is open OFF: Driver side door is closed - P DOR CYT SW Front passenger side door courtesy switch signal/ ON or OFF ON: Front passenger side door is open OFF: Front passenger side door is closed
3. ACTIVE TEST HINT: Performing the ACTIVE TEST using the intelligent tester allows you to operate the relay, VSV, actuator, etc. without parts removal. Performing the ACTIVE TEST as the first step of troubleshooting is one way to shorten the labor time. It is possible to display the DATA LIST during the ACTIVE TEST. Connect the intelligent tester to the DLC3. Turn the ignition switch ON. Perform the ACTIVE TEST according to the display on the tester. MASTER SW MASTER SW ACTIVE TEST Item Test Detail Diagnostic Note P/W UP/DOWN Operates power window UP/DOWN

1. INITIALIZATION NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. SYSTEM INITIALIZATION TABLE System Name See Procedure Lighting System (Adaptive Front-Lighting system) «INITIALIZATION»(ref-236032-S32462476002006062900000) Sliding roof control System «INITIALIZATION»(ref-236021-S29807869632006062900000) (for standard) and «INITIALIZATION»(ref-236021-S01691602862006062900000) (for multi panel moon roof) Power window control system «INITIALIZATION»(ref-236041-S15540293112006062900000) Power Back Door System «INITIALIZATION»(ref-236020-S16519146372006062900000)
