Horn: Removal & Installation Lexus RX II рестайлинг

INSTALLATION

1. INSTALL LOW PITCHED HORN Install the low pitched horn with the bolt. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) Connect the connector. see scheme 14: Locating Low Pitched Horn Bolt
2. INSTALL COOL AIR INTAKE DUCT SEAL Install the cool air intake duct seal with the 4 clips. see scheme 15: Locating Cool Air Intake Duct Seal With Clips

Scheme 10

1. REMOVE COOL AIR INTAKE DUCT SEAL (See «LOW PITCHED HORN»(ref-283017-S04125513342008041400000) )
2. REMOVE HIGH PITCHED HORN Disconnect the connector. Remove the bolt and high pitched horn. (Scheme 10): Locating High Pitched Horn Bolt

1. INSTALL HIGH PITCHED HORN Install the high pitched horn with the bolt. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) Connect the connector.
2. INSTALL COOL AIR INTAKE DUCT SEAL (See «LOW PITCHED HORN»(ref-283017-S04125513342008041400000) )

Scheme 11

1. INSPECT SPIRAL CABLE ASSEMBLY Disconnect the spiral cable assembly. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition A-1 - C-8 Always Below 1 ohms (Scheme 11): Identifying Spiral Cable Assembly Connectors Terminals
