Hybrid Battery Control (P310): Removal & Installation Lexus RX II рестайлинг

Charging System 22 illustrations ~2324 words

REMOVAL

  1. PRECAUTION (See «REPAIR INSTRUCTION»(ref-282976-S00474831072008041400000) )
  2. READ OUTPUT DTC (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
  4. REMOVE SERVICE PLUG GRIP (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  5. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S07504066712008041400000) )
  6. REMOVE REAR SEAT ASSEMBLY LH (See «REMOVAL»(ref-283009-S07504066712008041400000) )
  7. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S26161021142008041400000) )
  8. REMOVE REAR SEAT ASSEMBLY RH (See «REMOVAL»(ref-283009-S26161021142008041400000) )
  9. REMOVE AIR INTAKE COVER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  10. REMOVE AIR INTAKE COVER CENTER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  11. SEPARATE FLOOR CARPET ASSEMBLY FRONT (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  12. REMOVE REAR CENTER SEAT INNER BELT (See «REMOVAL»(ref-283010-S23644030632008041400000) )
  13. REMOVE BATTERY CARRIER BRACKET (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  14. REMOVE BATTERY CARRIER DUCT (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  15. REMOVE HV BATTERY SERVICE HOLE COVER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  16. REMOVE BATTERY COVER SUB-ASSEMBLY (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  17. REMOVE BATTERY SMART UNIT

Note. Wear insulating gloves and protective glasses.

Scheme 105

Scheme 105
Scheme 105
  1. Disconnect the 5 connectors and 2 clamps.
  2. Remove the 4 bolts and battery smart unit.

Scheme 106

Scheme 106: INSTALLATION
Scheme 106: INSTALLATION
  1. INSTALL BATTERY SMART UNIT NOTE: Wear insulating gloves and protective glasses. Install the battery smart unit with the 4 bolts. Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf) Connect the 5 connectors and 2 clamps.
  2. CHECK HIGH VOLTAGE CABLE CONNECTION (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  3. INSTALL BATTERY COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  4. INSTALL HV BATTERY SERVICE HOLE COVER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  5. INSTALL BATTERY CARRIER DUCT (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  6. INSTALL BATTERY CARRIER BRACKET (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  7. INSTALL REAR CENTER SEAT INNER BELT (See «INSTALLATION»(ref-283010-S30451716422008041400000) )
  8. INSTALL FLOOR CARPET ASSEMBLY FRONT (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  9. INSTALL AIR INTAKE COVER CENTER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  10. INSTALL AIR INTAKE COVER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  11. INSTALL REAR SEAT ASSEMBLY LH (See «INSTALLATION»(ref-283009-S24398621582008041400000) )
  12. INSTALL REAR SEAT TRACK BRACKET COVER
  13. INSTALL REAR SEAT ASSEMBLY RH (See «INSTALLATION»(ref-283009-S26085320402008041400000) )
  14. INSTALL REAR SEAT TRACK BRACKET COVER
  15. INSPECT SLIDE ADJUSTER LOCK SIMULTANEOUSLY (See «INSTALLATION»(ref-283009-S24398621582008041400000) )
  16. INSTALL SERVICE PLUG GRIP (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  17. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  18. PERFORM INITIALIZATION Some systems need initialization when disconnecting the cable from the negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108: REMOVAL
Scheme 108: REMOVAL

Scheme 109

Scheme 109
Scheme 109

Scheme 110

Scheme 110
Scheme 110

Scheme 111

Scheme 111
Scheme 111
  1. PRECAUTION (See «REPAIR INSTRUCTION»(ref-282976-S00474831072008041400000) )
  2. READ OUTPUT DTC (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
  4. REMOVE SERVICE PLUG GRIP (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  5. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S07504066712008041400000) )
  6. REMOVE REAR SEAT ASSEMBLY LH (See «REMOVAL»(ref-283009-S07504066712008041400000) )
  7. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S26161021142008041400000) )
  8. REMOVE REAR SEAT ASSEMBLY RH (See «REMOVAL»(ref-283009-S26161021142008041400000) )
  9. REMOVE AIR INTAKE COVER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  10. REMOVE AIR INTAKE COVER CENTER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  11. SEPARATE FLOOR CARPET ASSEMBLY FRONT (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  12. REMOVE REAR CENTER SEAT INNER BELT (See «REMOVAL»(ref-283010-S23644030632008041400000) )
  13. REMOVE BATTERY CARRIER BRACKET (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  14. REMOVE BATTERY CARRIER DUCT (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  15. REMOVE HV BATTERY SERVICE HOLE COVER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  16. REMOVE BATTERY COVER SUB-ASSEMBLY (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  17. REMOVE HYBRID VEHICLE RELAY ASSEMBLY NOTE: Wear insulating gloves and protective glasses. Insulate the removed terminals with insulating tape. Disconnect the No.3 wire frame connector from the HV relay assembly. Remove the 2 nuts, then disconnect the No.3 wire frame from the HV relay assembly. Disconnect the 2 main battery cable connectors from the HV relay assembly. Disconnect the 2 connectors from the HV relay assembly. Remove the 3 nuts and HV relay assembly.

Scheme 112

Scheme 112: INSPECTION
Scheme 112: INSPECTION

Scheme 113

Scheme 113
Scheme 113

Scheme 114

Scheme 114
Scheme 114
  1. SMR1 AND SYSTEM MAIN RESISTOR Measure the resistance between the 3 (CON1) and 4 (GND) terminals of the connector for the relay drive of the HV relay assembly. Standard resistance: 70 to 165 ohms (at -30°C (-22°F) to 80°C (176°F)) Increase battery voltage between the 3 (CON1) and 4 (GND) terminals of the connector for the relay drive of the HV relay assembly, and measure the resistance between the terminal of the HV battery side positive connector and the w/ convertor inverter assembly side positive terminal of the HV relay assembly. HINT: The standard resistance indicates the resistance of the system main resistor. Standard resistance: 28.5 to 31.5 ohms
  2. SMR2 Measure the resistance between the 1 (CON2) and 4 (GND) terminals of the connector for the relay drive of the HV relay assembly. Standard resistance: 20 to 60 ohms (at -35°C (-31°F) to 80°C (176°F)) Increase battery voltage between the 1 (CON2) and 4 (GND) terminals of the connector for the relay drive of the HV relay assembly, and measure the resistance between the terminal of the HV battery side positive connector and the w/ converter inverter assembly side positive terminal of the HV relay assembly. Standard resistance: Below 1 ohms
  3. SMR3 Measure the resistance between the 2 (CON3) and 4 (GND) terminals of the connector for the relay drive of the HV relay assembly. Standard resistance: 20 to 60 ohms (at -35°C (-31°F) to 80°C (176°F)) Increase battery voltage between the 2 (CON3) and 4 (GND) terminals of the connector for the relay drive of the HV relay assembly, and measure the resistance between the terminal of the HV battery side negative connector and the w/ converter inverter assembly side negative terminal of the HV relay assembly. Standard resistance: Below 1 ohms

Scheme 115

Scheme 115
Scheme 115
  1. INSTALL HYBRID VEHICLE RELAY ASSEMBLY NOTE: Wear insulating gloves and protective glasses. Install the HV relay assembly with the 3 nuts. Torque: 4.5 N*m (46 kgf*cm, 40 in.*lbf) Connect the 2 connectors on the HV relay assembly. Connect the 2 main battery cable connectors on the HV relay assembly. Install the No.3 wire frame on the HV relay with the 2 nuts. NOTE: Make sure that the No. 3 wire frame do not cross each other. Be sure to connect the No. 3 wire frame to each correct terminal as shown in the illustration. Torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf) Install the No.3 wire frame connector on the HV relay assembly.
  2. CHECK HIGH VOLTAGE CABLE CONNECTION (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  3. INSTALL BATTERY COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  4. INSTALL HV BATTERY SERVICE HOLE COVER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  5. INSTALL BATTERY CARRIER DUCT (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  6. INSTALL BATTERY CARRIER BRACKET (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  7. INSTALL REAR CENTER SEAT INNER BELT (See «INSTALLATION»(ref-283010-S30451716422008041400000) )
  8. INSTALL FLOOR CARPET ASSEMBLY FRONT (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  9. INSTALL AIR INTAKE COVER CENTER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  10. INSTALL AIR INTAKE COVER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  11. INSTALL REAR SEAT ASSEMBLY LH (See «INSTALLATION»(ref-283009-S24398621582008041400000) )
  12. INSTALL REAR SEAT TRACK BRACKET COVER
  13. INSTALL REAR SEAT ASSEMBLY RH (See «INSTALLATION»(ref-283009-S26085320402008041400000) )
  14. INSTALL REAR SEAT TRACK BRACKET COVER
  15. INSPECT SLIDE ADJUSTER LOCK SIMULTANEOUSLY (See «INSTALLATION»(ref-283009-S24398621582008041400000) )
  16. INSTALL SERVICE PLUG GRIP (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  17. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  18. PERFORM INITIALIZATION Some systems need initialization when disconnecting the cable from the negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 116

Scheme 116
Scheme 116

Scheme 117

Scheme 117
Scheme 117

Scheme 118

Scheme 118
Scheme 118
  1. PRECAUTION (See «REPAIR INSTRUCTION»(ref-282976-S00474831072008041400000) )
  2. READ OUTPUT DTC (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
  4. REMOVE SERVICE PLUG GRIP (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  5. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S07504066712008041400000) )
  6. REMOVE REAR SEAT ASSEMBLY LH (See «REMOVAL»(ref-283009-S07504066712008041400000) )
  7. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S26161021142008041400000) )
  8. REMOVE REAR SEAT ASSEMBLY RH (See «REMOVAL»(ref-283009-S26161021142008041400000) )
  9. REMOVE AIR INTAKE COVER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  10. REMOVE AIR INTAKE COVER CENTER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  11. SEPARATE FLOOR CARPET ASSEMBLY FRONT (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  12. REMOVE REAR CENTER SEAT INNER BELT (See «REMOVAL»(ref-283010-S23644030632008041400000) )
  13. REMOVE BATTERY CARRIER BRACKET (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  14. REMOVE BATTERY CARRIER DUCT (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  15. REMOVE HV BATTERY SERVICE HOLE COVER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  16. REMOVE BATTERY COVER SUB-ASSEMBLY (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  17. REMOVE BATTERY SMART UNIT (See «REMOVAL»(ref-283000-S27528752952008041400000) )
  18. REMOVE HV BATTERY NOTE: Wear insulating gloves and protective glasses. Insulate the removed terminals with insulating tape. Remove the HV battery LH. Remove the battery room ventilation hose between the HV batteries LH and CTR. Disconnect the wire harness clamp of the battery thermo sensor. Remove the nut and main battery cable from the HV battery. NOTE: Insulate the tool with insulating tape. Do not use the universal joint. Remove the nut, then disconnect the EV battery plug from the HV battery. NOTE: Insulate the tool with insulating tape. Do not use the universal joint. Remove the HV battery LH.
  19. REMOVE ELECTRIC VEHICLE BATTERY PLUG ASSEMBLY NOTE: Wear insulating gloves and protective glasses. Insulate the removed terminals with insulating tape. Disconnect the 2 connectors and clamps. Remove the 2 bolts, nut, and EV battery plug.

Scheme 119

Scheme 119: INSPECTION
Scheme 119: INSPECTION
  1. INSPECT ELECTRIC VEHICLE BATTERY PLUG ASSEMBLY Measure the resistance between each terminal of the EV battery plug. Standard resistance RESISTANCE SPECIFICATION Measurement terminal Standard A - C Below 1 ohms B - D Below 1 ohms

Scheme 120

Scheme 120
Scheme 120
  1. INSTALL ELECTRIC VEHICLE BATTERY PLUG ASSEMBLY NOTE: Wear insulating gloves and protective glasses. Install the EV battery plug with the 2 bolts and nut. Torque: Bolt 5.4 N*m (55 kgf*cm, 48 in.*lbf) Nut 7.5 N*m (76 kgf*cm, 66 in.*lbf) Connect the 2 connectors and clamps.
  2. INSTALL HV BATTERY NOTE: Wear insulating gloves and protective glasses. Install the HV battery LH. Install the HV battery LH. NOTE: After installing the HV battery LH, pull the ropes for hanging toward the front of the vehicle to eliminate the slacks. Connect the EV battery plug on the HV battery with a new nut. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) NOTE: Be sure to engage the plastic cover securely. Insulate the tool with insulating tape. Do not use the universal joint. Connect the main battery cable on the HV battery with a new nut. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) NOTE: Be sure to engage the plastic cover securely. Insulate the tool with insulating tape. Do not use the universal joint. Connect the wire harness clamp of the battery thermo sensor. Connect the battery room ventilation hose between the HV batteries LH and CTR. NOTE: Align the projections of the battery room ventilation hose and the rubber tube, and install the hose.
  3. INSTALL BATTERY SMART UNIT (See «INSTALLATION»(ref-283000-S39692870372008041400000) )
  4. CHECK HIGH VOLTAGE CABLE CONNECTION (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  5. INSTALL BATTERY COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  6. INSTALL HV BATTERY SERVICE HOLE COVER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  7. INSTALL BATTERY CARRIER DUCT (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  8. INSTALL BATTERY CARRIER BRACKET (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  9. INSTALL REAR CENTER SEAT INNER BELT (See «INSTALLATION»(ref-283010-S30451716422008041400000) )
  10. INSTALL FLOOR CARPET ASSEMBLY FRONT (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  11. INSTALL AIR INTAKE COVER CENTER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  12. INSTALL AIR INTAKE COVER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  13. INSTALL REAR SEAT ASSEMBLY LH (See «INSTALLATION»(ref-283009-S24398621582008041400000) )
  14. INSTALL REAR SEAT TRACK BRACKET COVER
  15. INSTALL REAR SEAT ASSEMBLY RH (See «INSTALLATION»(ref-283009-S26085320402008041400000) )
  16. INSTALL REAR SEAT TRACK BRACKET COVER
  17. INSPECT SLIDE ADJUSTER LOCK SIMULTANEOUSLY (See «INSTALLATION»(ref-283009-S24398621582008041400000) )
  18. INSTALL SERVICE PLUG GRIP (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  19. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  20. PERFORM INITIALIZATION Some systems need initialization when disconnecting the cable from the negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 121

Scheme 121
Scheme 121

Scheme 122

Scheme 122: REMOVAL
Scheme 122: REMOVAL
  1. PRECAUTION (See «REPAIR INSTRUCTION»(ref-282976-S00474831072008041400000) )
  2. READ OUTPUT DTC (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
  4. REMOVE SERVICE PLUG GRIP (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  5. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S07504066712008041400000) )
  6. REMOVE REAR SEAT ASSEMBLY LH (See «REMOVAL»(ref-283009-S07504066712008041400000) )
  7. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S26161021142008041400000) )
  8. REMOVE REAR SEAT ASSEMBLY RH (See «REMOVAL»(ref-283009-S26161021142008041400000) )
  9. REMOVE AIR INTAKE COVER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  10. REMOVE AIR INTAKE COVER CENTER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  11. SEPARATE FLOOR CARPET ASSEMBLY FRONT (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  12. REMOVE BATTERY CARRIER DUCT (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  13. REMOVE ELECTRIC VEHICLE FUSE NOTE: Wear insulating gloves. Release the claws and remove the fuse block cover. Remove the 2 bolts and electric vehicle fuse.

Scheme 123

Scheme 123: INSPECTION
Scheme 123: INSPECTION
  1. ELECTRIC VEHICLE FUSE Measure the resistance between the terminals of the electric vehicle fuse. Standard resistance: Below 1 ohms

INSTALLATION

  1. INSTALL ELECTRIC VEHICLE FUSE NOTE: Wear insulating gloves. Install the electric vehicle battery fuse with the 2 bolts. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) Install the fuse block cover.
  2. INSTALL BATTERY CARRIER BRACKET (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  3. INSTALL FLOOR CARPET ASSEMBLY FRONT (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  4. INSTALL AIR INTAKE COVER CENTER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  5. INSTALL AIR INTAKE COVER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  6. INSTALL REAR SEAT ASSEMBLY LH (See «INSTALLATION»(ref-283009-S24398621582008041400000) )
  7. INSTALL REAR SEAT TRACK BRACKET COVER
  8. INSTALL REAR SEAT ASSEMBLY RH (See «INSTALLATION»(ref-283009-S26085320402008041400000) )
  9. INSTALL REAR SEAT TRACK BRACKET COVER
  10. INSPECT SLIDE ADJUSTER LOCK SIMULTANEOUSLY (See «INSTALLATION»(ref-283009-S24398621582008041400000) )
  11. INSTALL SERVICE PLUG GRIP (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  12. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  13. PERFORM INITIALIZATION Some systems need initialization when disconnecting the cable from the negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 124

Scheme 124
Scheme 124

Scheme 125

Scheme 125: REMOVAL
Scheme 125: REMOVAL

Scheme 126

Scheme 126
Scheme 126
  1. PRECAUTION (See «REPAIR INSTRUCTION»(ref-282976-S00474831072008041400000) )
  2. READ OUTPUT DTC (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
  4. REMOVE SERVICE PLUG GRIP (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  5. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S07504066712008041400000) )
  6. REMOVE REAR SEAT ASSEMBLY LH (See «REMOVAL»(ref-283009-S07504066712008041400000) )
  7. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S26161021142008041400000) )
  8. REMOVE REAR SEAT ASSEMBLY RH (See «REMOVAL»(ref-283009-S26161021142008041400000) )
  9. REMOVE AIR INTAKE COVER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  10. REMOVE AIR INTAKE COVER CENTER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  11. SEPARATE FLOOR CARPET ASSEMBLY FRONT (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  12. REMOVE REAR CENTER SEAT INNER BELT (See «REMOVAL»(ref-283010-S23644030632008041400000) )
  13. REMOVE BATTERY CARRIER BRACKET (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  14. REMOVE BATTERY CARRIER DUCT (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  15. REMOVE HV BATTERY SERVICE HOLE COVER (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  16. REMOVE BATTERY COVER SUB-ASSEMBLY (See «REMOVAL»(ref-283000-S30250630812008041400000) )
  17. REMOVE BATTERY COOLING BLOWER ASSEMBLY NOTE: Wear insulating gloves and protective glasses. Disconnect each battery cooling blower assembly connector and clamp. Remove the 9 nuts and 3 battery cooling blower assemblies.
  1. INSTALL BATTERY COOLING BLOWER ASSEMBLY NOTE: Wear insulating gloves and protective glasses. Install the 3 battery cooling blower assemblies with the 9 nuts. Torque: 4.5 N*m (46 kgf*cm, 40 in.*lbf) Connect each battery cooling blower assembly connector and clamp.
  2. INSTALL BATTERY COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  3. INSTALL BATTERY CARRIER DUCT (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  4. INSTALL BATTERY CARRIER BRACKET (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  5. INSTALL REAR CENTER SEAT INNER BELT (See «REMOVAL»(ref-283010-S23644030632008041400000) )
  6. INSTALL FLOOR CARPET ASSEMBLY FRONT (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  7. INSTALL AIR INTAKE COVER CENTER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  8. INSTALL AIR INTAKE COVER (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  9. INSTALL REAR SEAT ASSEMBLY LH (See «INSTALLATION»(ref-283009-S24398621582008041400000) )
  10. INSTALL REAR SEAT TRACK BRACKET COVER
  11. INSTALL REAR SEAT ASSEMBLY RH (See «INSTALLATION»(ref-283009-S26085320402008041400000) )
  12. INSTALL REAR SEAT TRACK BRACKET COVER
  13. INSPECT SLIDE ADJUSTER LOCK SIMULTANEOUSLY
  14. INSTALL SERVICE PLUG GRIP (See «INSTALLATION»(ref-283000-S32862437702008041400000) )
  15. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  16. PERFORM INITIALIZATION Some systems need initialization when disconnecting the cable from the negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

More articles — Hybrid Battery Control (P310)
