TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m.) |
|---|
| Brake Caliper Bolt |
| Front Brake Caliper | 25 (34) |
| Rear Brake Caliper | 32 (43) |
| Brake Caliper Torque Plate Bolt |
| Front Brake Caliper | 77 (104) |
| Rear Brake Caliper | 58 (78) |
| Brake Hose-To-Brake Caliper Bolt | 21 (29) |
| Brake Pedal Pivot Bolt/Nut | 27 (37) |
| Brake Pedal Push Rod Lock Nut | 19 (26) |
| Brakeline-To-Master Cylinder Nut | 11 (15) |
| Front Suspension Brace Sub-Assembly Nut | 59 (80) |
| Wheel Lug Nut | 76 (103) |
| INCH Lbs. (N.m) |
| Bleeder Screw | 74 (8.3) |
| Brake Booster Retaining Nut | 115 (13) |
| Master Cylinder Mounting Nut | 115 (13) |
| Parking Brake Adjustment Lock Nut | 53 (6) |
DISC BRAKE SPECIFICATIONS
| Application | In. (mm) |
|---|
| Front Disc |
| Original Disc Thickness | 1.102 (28) |
| Minimum Refinish Thickness | 1.024 (26) |
| Maximum Disc Runout | .002 (.05) |
| Brake Pad Thickness |
| Standard Thickness | .433 (11) |
| Minimum Thickness | .039 (1.0) |
| Rear Disc |
| Original Disc Thickness | .394 (10) |
| Minimum Refinish Thickness | .335 (8.5) |
| Maximum Disc Runout | .006 (.15) |
| Brake Pad Thickness |
| Standard Thickness | .394 (10) |
| Minimum Thickness | .039 (1.0) |
| Rear Disc Parking Brake Drum (1) |
| Brake Shoe-To-Lever Clearance | Less Than .014 (.35) |
| Drum Diameter |
| Original Diameter | 7.48 (190) |
| Maximum Diameter | 7.52 (191) |
| Parking Brake Shoe Lining Thickness (2) |
| Standard Thickness | .098 (2.5) |
| Minimum Thickness | .039 (1.0) |
| (1) This is the drum for the parking brake on the inside of the rear disc. (2) This is brake lining for the parking brake on the inside of the rear disc. |
| (1) | This is the drum for the parking brake on the inside of the rear disc. |
| (2) | This is brake lining for the parking brake on the inside of the rear disc. |
DISC BRAKE SPECIFICATIONS
Scheme 1
