Audio & Visual System: Removal & Installation Lexus RX II

Entertainment Systems 41 illustrations ~3206 words

REPLACEMENT

  1. DISCONNECT BATTERY NEGATIVE TERMINAL (See «AIR BAG RESTRAINT SYSTEMS»(ref-170440) )
  2. REMOVE SHIFT LEVER KNOB SUB-ASSY (See «OVERHAUL»(ref-209590-S27089889222005121000000) )
  3. REMOVE CONSOLE PANEL UPPER FRONT (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
  4. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
  5. REMOVE RADIO RECEIVER ASSEMBLY W/BRACKET (See «RADIO RECEIVER ASSY»(ref-215986-S19101602342006011900000) )
  6. REMOVE MULTI-DISPLAY ASSY
  1. Remove the 2 bolts, and disengage the 4 clips.
  2. Disconnect the connector.
  3. Remove the multi-display assy.

HINT

  1. COMPONENTS: ROOF HEADLINING ASSY, see «COMPONENTS»(ref-242882-S19422709922006081700000) , SEAT ASSY LH, see «COMPONENTS»(ref-215996-S28977527342006011900000) , SEAT ASSY RH, see «COMPONENTS»(ref-215996-S34094812632006011900000)
  2. «LOCATION»(ref-215986-S31055643072006011900000) : See

Scheme 135

Scheme 135
Scheme 135

Scheme 136

Scheme 136
Scheme 136

Scheme 137

Scheme 137
Scheme 137
  1. REMOVE REAR DOOR SCUFF PLATE RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  2. REMOVE REAR DOOR SCUFF PLATE LH
  3. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  4. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
  5. REMOVE DECK BOARD SUB-ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  6. REMOVE REAR SEAT ASSY RH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  7. REMOVE REAR SEAT ASSY LH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15005970772006011900000) )
  8. REMOVE TONNEAU COVER ASSY
  9. REMOVE DECK FLOOR BOX FRONT (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  10. REMOVE DECK FLOOR BOX REAR (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  11. REMOVE DECK BOARD SUB-ASSY NO.2 (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  12. REMOVE DECK BOARD SUB-ASSY NO.3
  13. REMOVE BACK DOOR WEATHERSTRIP (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  14. REMOVE DECK SIDE TRIM BOX RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  15. REMOVE DECK SIDE TRIM BOX LH
  16. REMOVE REAR FLOOR FINISH PLATE (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  17. REMOVE REAR FLOOR FINISH SIDE PLATE RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  18. REMOVE REAR FLOOR FINISH SIDE PLATE LH
  19. REMOVE DECK SIDE TRIM COVER RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  20. REMOVE DECK SIDE TRIM COVER LH
  21. REMOVE REAR SEAT SIDE COVER RH (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  22. REMOVE REAR SEAT SIDE COVER LH
  23. REMOVE ROPE HOOK (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  24. REMOVE DECK TRIM SIDE PANEL ASSY RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  25. REMOVE DECK TRIM SIDE PANEL ASSY LH
  26. REMOVE REAR SEAT SUB FLOOR PANEL ASSY Remove the 3 bolts, the 3 nuts and the rear seat sub floor panel assy.
  27. REMOVE STEREO COMPONENT AMPLIFIER ASSY Remove the 2 bolts and the nut. Disconnect the connector. Remove the stereo component amplifier assy. Mark Levinson System: Remove the 2 screws and amplifier bracket No.1. Mark Levinson System: Remove the 2 screws and amplifier bracket No.2.
  28. INSTALL REAR SEAT ASSY RH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  29. INSTALL REAR SEAT ASSY LH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15005970772006011900000) )

Scheme 138

Scheme 138: REPLACEMENT
Scheme 138: REPLACEMENT
  1. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSY (See «OVERHAUL»(ref-215999-S26745264462006011900000) )
  2. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See «OVERHAUL»(ref-215999-S26745264462006011900000) )
  3. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG LH (See «OVERHAUL»(ref-215999-S26745264462006011900000) )
  4. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (See «OVERHAUL»(ref-215999-S26745264462006011900000) )
  5. REMOVE FRONT NO.1 SPEAKER ASSY Disconnect the connector. Remove the 4 bolts and the front No.1 speaker assy.
  6. INSTALL FRONT NO.1 SPEAKER ASSY
  1. Install the front No.1 speaker assy with the 4 bolts.

Scheme 139

Scheme 139: REPLACEMENT
Scheme 139: REPLACEMENT
  1. REMOVE FRONT PILLAR GARNISH LH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  2. REMOVE STEREO COMPONENT SPEAKER ASSY FRONT Disconnect the connector. Remove the nut, and disengage the claw. Remove the stereo component speaker assy front.

Scheme 140

Scheme 140: REPLACEMENT
Scheme 140: REPLACEMENT

Scheme 141

Scheme 141
Scheme 141
  1. REMOVE FRONT PILLAR GARNISH LH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  2. REMOVE INSTRUMENT PANEL SPEAKER PANEL SUB-ASSY NO.1 Disengage the 2 clips and the 2 claws. Remove the instrument panel speaker panel Sub-assy No.1.
  3. REMOVE FRONT NO.2 SPEAKER ASSY Remove the 2 bolts and the front No.2 speaker assy. Disconnect the connector.

Scheme 142

Scheme 142: REPLACEMENT
Scheme 142: REPLACEMENT

Scheme 143

Scheme 143
Scheme 143
  1. DISCONNECT BATTERY NEGATIVE TERMINAL (See «AIR BAG RESTRAINT SYSTEMS»(ref-170440) )
  2. REMOVE SHIFT LEVER KNOB SUB-ASSY (See «OVERHAUL»(ref-209590-S27089889222005121000000) )
  3. REMOVE CONSOLE PANEL UPPER FRONT (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
  4. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
  5. REMOVE RADIO RECEIVER ASSEMBLY W/BRACKET (See «RADIO RECEIVER ASSY»(ref-215986-S19101602342006011900000) )
  6. REMOVE MULTI-DISPLAY ASSY (See «MULTI-DISPLAY ASSY»(ref-215986-S40979651942006011900000) )
  7. REMOVE SPEAKER HOLE COVER NO.1 Disengage the 4 clips. Remove the speaker hole cover No.1 by pushing it up from the under side of the instrument panel.
  8. REMOVE FRONT NO. 2 SPEAKER ASSY Remove the 2 bolts and front No. 2 speaker assy. Disconnect the connector.

Scheme 144

Scheme 144: REPLACEMENT
Scheme 144: REPLACEMENT
  1. REMOVE POWER WINDOW REGULATOR SWITCH ASSY REAR (See «OVERHAUL»(ref-216002-S10430326572006011900000) )
  2. REMOVE REAR DOOR INSIDE HANDLE BEZEL PLUG LH (See «OVERHAUL»(ref-216002-S10430326572006011900000) )
  3. REMOVE REAR DOOR TRIM BOARD SUB-ASSY LH (See «OVERHAUL»(ref-216002-S10430326572006011900000) )
  4. REMOVE REAR SPEAKER ASSY Disconnect the connector. Remove the 3 bolts and the rear speaker assy.

HINT

COMPONENTS: See COMPONENTS

Scheme 145

Scheme 145: REPLACEMENT
Scheme 145: REPLACEMENT
  1. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/PASSENGER AIR BAG ASSY (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
  2. REMOVE ANTENNA CORD SUB-ASSY w/ Navigation: Remove the 2 screws and the navigation antenna. Remove the 6 clamps and the antenna cord sub-assy.
  3. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/PASSENGER AIR BAG ASSY (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )

HINT

COMPONENTS: See COMPONENTS

  1. REMOVE ROOF HEADLINING ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  2. REMOVE ANTENNA CORD SUB-ASSY NO.2 w/o Navigation: Remove the 6 clamps and the antenna cord sub-assy No.2. w/ Navigation: Remove the 9 clamps and the antenna cord sub-assy No.2.
  3. INSTALL ROOF HEADLINING ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )

Scheme 146

Scheme 146: REPLACEMENT
Scheme 146: REPLACEMENT
  1. REMOVE ROOF HEADLINING ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  2. REMOVE BACK DOOR TRIM BOARD LH (W/ POWER BACK DOOR) (See «OVERHAUL»(ref-216004-S32543888962006011900000) )
  3. REMOVE BACK WINDOW PANEL TRIM UPPER (W/ POWER BACK DOOR) (See «OVERHAUL»(ref-216004-S32543888962006011900000) )
  4. REMOVE BACK WINDOW PANEL TRIM UPPER (See «OVERHAUL»(ref-216002-S10430326572006011900000) )
  5. REMOVE BACK DOOR TRIM PANEL ASSY UPPER (See «OVERHAUL»(ref-216002-S10430326572006011900000) )
  6. REMOVE BACK DOOR TRIM PANEL ASSY (See «OVERHAUL»(ref-216002-S10430326572006011900000) )
  7. REMOVE BACK DOOR TRIM COVER RH (See «OVERHAUL»(ref-216002-S10430326572006011900000) )
  8. REMOVE BACK DOOR TRIM COVER LH (See «OVERHAUL»(ref-216002-S10430326572006011900000) )
  9. REMOVE ANTENNA CORD SUB-ASSY NO.3 Disconnect the connector. Remove the 11 clamps and the bolt. Remove the antenna cord sub-assy No.3.
  10. INSTALL ROOF HEADLINING ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )

Scheme 147

Scheme 147: REPLACEMENT
Scheme 147: REPLACEMENT

Scheme 148

Scheme 148
Scheme 148

Scheme 149

Scheme 149
Scheme 149
  1. REMOVE ROOF ANTENNA POLE SUB-ASSY (See «ROOF ANTENNA POLE SUB-ASSY»(ref-215986-S15906674652006011900000) )
  2. REMOVE ROOF HEADLINING ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  3. REMOVE AMPLIFIER ANTENNA ASSY Disconnect the connector. w/o LEXUS LINK system: Remove the antenna nut and the 3 clamps. w/LEXUS LINK system: Remove the antenna nut and the 4 clamps. Disengage the 2 claws. Remove the amplifier antenna assy.
  4. INSTALL AMPLIFIER ANTENNA ASSY Set the amplifier antenna assy into the hole on the roof, and place the antenna cord in the cutout on the antenna nut. Install the amplifier antenna assy with the antenna nut. Torque: 4.5 N.m (46 kgf.cm, 40 in..lbf) w/o LEXUS LINK system: Install the 3 clamps. w/LEXUS LINK system: Install the 4 clamps.
  5. INSTALL ROOF HEADLINING ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  1. REMOVE ROOF ANTENNA POLE SUB-ASSY

Scheme 150

Scheme 150
Scheme 150
  1. Remove the roof antenna pole sub-assy turning it in the direction of the arrow (Scheme 153)

HINT

COMPONENTS

ROOF HEADLINING ASSY, see COMPONENTS , SEAT ASSY LH, see COMPONENTS , SEAT ASSY RH, see COMPONENTS

Scheme 151

Scheme 151: REPLACEMENT
Scheme 151: REPLACEMENT
  1. REMOVE REAR DOOR SCUFF PLATE RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  2. REMOVE REAR DOOR SCUFF PLATE LH
  3. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  4. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
  5. REMOVE DECK BOARD SUB-ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  6. REMOVE REAR SEAT ASSY RH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  7. REMOVE REAR SEAT ASSY LH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15005970772006011900000) )
  8. REMOVE TONNEAU COVER ASSY
  9. REMOVE DECK FLOOR BOX FRONT (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  10. REMOVE DECK FLOOR BOX REAR (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  11. REMOVE DECK BOARD SUB-ASSY NO.2 (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  12. REMOVE DECK BOARD SUB-ASSY NO.3
  13. REMOVE BACK DOOR WEATHERSTRIP (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  14. REMOVE DECK SIDE TRIM BOX RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  15. REMOVE DECK SIDE TRIM BOX LH
  16. REMOVE REAR FLOOR FINISH PLATE (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  17. REMOVE REAR FLOOR FINISH SIDE PLATE RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  18. REMOVE REAR FLOOR FINISH SIDE PLATE LH
  19. REMOVE DECK SIDE TRIM COVER RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  20. REMOVE DECK SIDE TRIM COVER LH
  21. REMOVE REAR SEAT SIDE COVER RH (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  22. REMOVE REAR SEAT SIDE COVER LH
  23. REMOVE ROPE HOOK (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  24. REMOVE DECK TRIM SIDE PANEL ASSY RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  25. REMOVE DECK TRIM SIDE PANEL ASSY LH
  26. REMOVE REAR SEAT SUB FLOOR PANEL ASSY Remove the 3 bolts, 3 nuts and the rear seat sub floor panel assy.
  27. REMOVE ROOF SIDE GARNISH ASSY INNER RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  28. REMOVE TELEPHONE ANTENNA CORD Disconnect the connectors. Remove the 8 clamps and the telephone antenna cord.
  29. INSTALL REAR SEAT ASSY RH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  30. INSTALL REAR SEAT ASSY LH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15005970772006011900000) )

HINT

COMPONENTS: See COMPONENTS

Scheme 152

Scheme 152: REPLACEMENT
Scheme 152: REPLACEMENT
  1. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/PASSENGER AIR BAG ASSY (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
  2. REMOVE NAVIGATION ANTENNA Disconnect the connector. Disengage the clamp. Remove the 2 screws and the navigation antenna assy.
  3. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/PASSENGER AIR BAG ASSY (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )

HINT

  1. COMPONENTS: ROOF HEADLINING ASSY, see «COMPONENTS»(ref-242882-S19422709922006081700000) , SEAT ASSY LH, see «COMPONENTS»(ref-215996-S28977527342006011900000) , SEAT ASSY RH, see «COMPONENTS»(ref-215996-S34094812632006011900000)
  2. «LOCATION»(ref-215986-S31055643072006011900000) : See

Scheme 153

Scheme 153
Scheme 153
  1. REMOVE REAR DOOR SCUFF PLATE RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  2. REMOVE REAR DOOR SCUFF PLATE LH
  3. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  4. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
  5. REMOVE DECK BOARD SUB-ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  6. REMOVE REAR SEAT ASSY RH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  7. REMOVE REAR SEAT ASSY LH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15005970772006011900000) )
  8. REMOVE TONNEAU COVER ASSY
  9. REMOVE DECK FLOOR BOX FRONT (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  10. REMOVE DECK FLOOR BOX REAR (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  11. REMOVE DECK BOARD SUB-ASSY NO.2 (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  12. REMOVE DECK BOARD SUB-ASSY NO.3
  13. REMOVE BACK DOOR WEATHERSTRIP (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  14. REMOVE DECK SIDE TRIM BOX RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  15. REMOVE DECK SIDE TRIM BOX LH
  16. REMOVE REAR FLOOR FINISH PLATE (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  17. REMOVE REAR FLOOR FINISH SIDE PLATE RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  18. REMOVE REAR FLOOR FINISH SIDE PLATE LH
  19. REMOVE DECK SIDE TRIM COVER RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  20. REMOVE DECK SIDE TRIM COVER LH
  21. REMOVE REAR SEAT SIDE COVER RH (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  22. REMOVE REAR SEAT SIDE COVER LH
  23. REMOVE ROPE HOOK (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  24. REMOVE DECK TRIM SIDE PANEL ASSY RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  25. REMOVE DECK TRIM SIDE PANEL ASSY LH
  26. REMOVE REAR SEAT SUB FLOOR PANEL ASSY Remove the 3 bolts, the 3 nuts and the rear seat sub floor panel assy.
  27. REMOVE MAYDAY ASSY Disconnect the connector. Disengage the clamp. Remove the 2 bolts and the nut. Remove the mayday assy.
  28. INSTALL REAR SEAT ASSY RH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  29. INSTALL REAR SEAT ASSY LH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15005970772006011900000) )

HINT

LOCATION : See

Scheme 154

Scheme 154: REPLACEMENT
Scheme 154: REPLACEMENT

Scheme 155

Scheme 155
Scheme 155

Scheme 156

Scheme 156
Scheme 156
  1. REMOVE DECK BOARD SUB-ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  2. REMOVE TONNEAU COVER ASSY
  3. REMOVE DECK FLOOR BOX FRONT (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  4. REMOVE DECK FLOOR BOX REAR (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  5. REMOVE DECK BOARD SUB-ASSY NO.2 (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  6. REMOVE DECK BOARD SUB-ASSY NO.3
  7. REMOVE DECK SIDE TRIM BOX RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  8. REMOVE NAVIGATION ECU W/BRACKET Disconnect the connector. Disconnect the wire-harness clmp. Remove the 3 nuts and the navigation ECU w/ bracket.
  9. REMOVE DISC PLAYER BRACKET Remove the screw and the disc player bracket.
  10. REMOVE DISC PLAYER BRACKET NO.2 Remove the 2 screws and the disc player bracket No.2.
  11. REMOVE NAVIGATION ECU

HINT

LOCATION : See

  1. REMOVE BACK DOOR TRIM PANEL ASSY UPPER (See «OVERHAUL»(ref-216004-S32543888962006011900000) )
  2. REMOVE BACK DOOR GARNISH OUTSIDE (See «REPLACEMENT»(ref-242882-S34652111442006081700000) )
  3. REMOVE TELEVISION CAMERA ASSY

Scheme 157

Scheme 157
Scheme 157

Scheme 158

Scheme 158
Scheme 158
  1. Disconnect the connector.
  2. Disengage the clamp.
  3. Disengage the 2 claws.
  4. Remove the television camera assy.

HINT

LOCATION : See

Scheme 159

Scheme 159: REPLACEMENT
Scheme 159: REPLACEMENT
  1. REMOVE DECK BOARD SUB-ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  2. REMOVE TONNEAU COVER ASSY
  3. REMOVE DECK FLOOR BOX FRONT (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  4. REMOVE DECK FLOOR BOX REAR (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  5. REMOVE DECK BOARD SUB-ASSY NO.2 (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  6. REMOVE DECK BOARD SUB-ASSY NO.3
  7. REMOVE BACK DOOR WEATHERSTRIP (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  8. REMOVE DECK SIDE TRIM BOX RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  9. REMOVE REAR FLOOR FINISH PLATE (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  10. REMOVE REAR FLOOR FINISH SIDE PLATE RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  11. SEPARATE DECK TRIM SIDE PANEL ASSY RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) ) HINT: Turn up the deck trim side panel assy RH until the television camera ECU can be removed.
  12. REMOVE TELEVISION CAMERA ECU Disconnect the connector. Remove the 3 bolts and the television camera ECU.

HINT

LOCATION : See

Scheme 160

Scheme 160: REPLACEMENT
Scheme 160: REPLACEMENT

Scheme 161

Scheme 161
Scheme 161
  1. REMOVE TELEVISION BASE Disengage the 4 clips, and remove the television base.
  2. REMOVE TELEVISION DISPLAY ASSY Disconnect the connector. Remove the 4 nuts and the television display assy.

HINT

LOCATION : See

Scheme 162

Scheme 162: REPLACEMENT
Scheme 162: REPLACEMENT

Scheme 163

Scheme 163
Scheme 163
  1. REMOVE DECK BOARD SUB-ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  2. REMOVE TONNEAU COVER ASSY
  3. REMOVE DECK FLOOR BOX FRONT (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  4. REMOVE DECK FLOOR BOX REAR (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  5. REMOVE DECK BOARD SUB-ASSY NO.2 (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  6. REMOVE DECK BOARD SUB-ASSY NO.3
  7. REMOVE BACK DOOR WEATHERSTRIP (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  8. REMOVE DECK SIDE TRIM BOX RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  9. REMOVE REAR FLOOR FINISH PLATE (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  10. REMOVE REAR FLOOR FINISH SIDE PLATE RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  11. SEPARATE DECK TRIM SIDE PANEL ASSY RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) ) HINT: Turn up the deck trim side panel assy RH until the multi-display controller w/ bracket can be removed.
  12. REMOVE TELEVISION CAMERA ECU (W/ EMV & NAVIGATION SYSTEM) (See «TELEVISION CAMERA ECU»(ref-215986-S28853566682006011900000) )
  13. REMOVE MULTI-DISPLAY CONTROLLER W/BRACKET Disconnect the connector. Remove the 3 nuts and the multi-display controller w/ bracket.
  14. REMOVE MULTI-DISPLAY CONTROLLER BRACKET A Remove the 2 screws and the multi-display controller bracket A.
  15. REMOVE MULTI-DISPLAY CONTROLLER BRACKET B Remove the 2 screws and the multi-display controller bracket B.
  16. REMOVE MULTI-DISPLAY CONTROLLER SUB-ASSY

HINT

  1. COMPONENTS: ROOF HEADLINING ASSY, see «COMPONENTS»(ref-242882-S19422709922006081700000) , SEAT ASSY LH, see «COMPONENTS»(ref-215996-S28977527342006011900000) , SEAT ASSY RH, SEE «COMPONENTS»(ref-215996-S34094812632006011900000)
  2. «LOCATION»(ref-215986-S31055643072006011900000) : See

Scheme 164

Scheme 164
Scheme 164
  1. REMOVE REAR DOOR SCUFF PLATE RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  2. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  3. REMOVE DECK BOARD SUB-ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  4. REMOVE REAR SEAT ASSY RH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  5. REMOVE REAR SEAT ASSY LH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15005970772006011900000) )
  6. REMOVE TONNEAU COVER ASSY
  7. REMOVE DECK FLOOR BOX FRONT (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  8. REMOVE DECK FLOOR BOX REAR (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  9. REMOVE DECK BOARD SUB-ASSY NO.2 (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  10. REMOVE DECK BOARD SUB-ASSY NO.3
  11. REMOVE BACK DOOR WEATHERSTRIP (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  12. REMOVE DECK SIDE TRIM BOX RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  13. REMOVE REAR FLOOR FINISH PLATE (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  14. REMOVE REAR FLOOR FINISH SIDE PLATE RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  15. REMOVE DECK SIDE TRIM COVER RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  16. REMOVE REAR SEAT SIDE COVER RH (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  17. REMOVE ROPE HOOK (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  18. REMOVE DECK TRIM SIDE PANEL ASSY RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  19. REMOVE VIDEO (VIDEO ADAPTER) TERMINAL Disconnect the connector. Disengage the 4 claws, and remove the video (video adapter) terminal.
  20. INSTALL REAR SEAT ASSY RH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  21. INSTALL REAR SEAT ASSY LH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15005970772006011900000) )

HINT

LOCATION : See

Scheme 165

Scheme 165: REPLACEMENT
Scheme 165: REPLACEMENT

Scheme 166

Scheme 166
Scheme 166

Scheme 167

Scheme 167
Scheme 167
  1. REMOVE SHIFT LEVER KNOB SUB-ASSY (See «OVERHAUL»(ref-209590-S27089889222005121000000) )
  2. REMOVE CONSOLE PANEL UPPER FRONT (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
  3. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
  4. REMOVE CIGARETTE LIGHTER COVER Disengage the 2 claws, and remove the cigarette lighter cover.
  5. REMOVE CIGARETTE LIGHTER ASSY Remove the cigarette lighter knob and element assy. Turn the socket in counterclockwise (Scheme 170) Disengage the claw between the socket and the cigarette lighter bezel stay, and push out the socket. Align the socket with the notch on the cigarette lighter bezel stay, and remove the cigarette lighter assy.
  6. INSTALL CIGARETTE LIGHTER ASSY Align the socket with the notch on the cigarette lighter bezel stay, push in the cigarette lighter assy as hard as possible to install it. Install the cigarette lighter knob and element assy.

HINT

LOCATION : See

Scheme 168

Scheme 168: REPLACEMENT
Scheme 168: REPLACEMENT
  1. REMOVE POWER POINT SOCKET ASSY Turn the socket counterclockwise (Scheme 172) Disengage the claw between the socket and the power point socket cover, and push out the socket.
  2. INSTALL POWER POINT SOCKET ASSY Align the socket with the notch on the power point socket cover, push in the power point socket assy as hard as possible to install it.

HINT

  1. COMPONENTS: ROOF HEADLINING, see «COMPONENTS»(ref-242882-S19422709922006081700000) , SEAT ASSY LH, see «COMPONENTS»(ref-215996-S28977527342006011900000) , SEAT ASSY RH, see «COMPONENTS»(ref-215996-S34094812632006011900000)
  2. «LOCATION»(ref-215986-S31055643072006011900000) : See

Scheme 169

Scheme 169
Scheme 169
  1. REMOVE REAR DOOR SCUFF PLATE RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  2. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  3. REMOVE DECK BOARD SUB-ASSY (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  4. REMOVE REAR SEAT ASSY RH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  5. REMOVE REAR SEAT ASSY LH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15005970772006011900000) )
  6. REMOVE TONNEAU COVER ASSY
  7. REMOVE DECK FLOOR BOX FRONT (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  8. REMOVE DECK FLOOR BOX REAR (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  9. REMOVE DECK BOARD SUB-ASSY NO.2 (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  10. REMOVE DECK BOARD SUB-ASSY NO.3
  11. REMOVE BACK DOOR WEATHERSTRIP (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  12. REMOVE DECK SIDE TRIM BOX RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  13. REMOVE REAR FLOOR FINISH PLATE (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  14. REMOVE REAR FLOOR FINISH SIDE PLATE RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  15. REMOVE DECK SIDE TRIM COVER RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  16. REMOVE REAR SEAT SIDE COVER RH (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  17. REMOVE ROPE HOOK (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  18. REMOVE DECK TRIM SIDE PANEL ASSY RH (See «REPLACEMENT»(ref-242882-S04285829632006081700000) )
  19. REMOVE POWER OUTLET SOCKET ASSY Disconnect the connector. Disengage the 2 claws, and remove the power outlet socket assy.
  20. INSTALL REAR SEAT ASSY RH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15642352962006011900000) )
  21. INSTALL REAR SEAT ASSY LH (4-2-4 SPLIT SEAT TYPE) (See «OVERHAUL»(ref-215996-S15005970772006011900000) )

HINT

COMPONENTS: See COMPONENTS

Scheme 170

Scheme 170: REPLACEMENT
Scheme 170: REPLACEMENT
  1. REMOVE POWER POINT SOCKET ASSY RR Turn the socket counterclockwise (Scheme 174) Disengage the claw between the socket and the power point socket cover, and push out the socket.
  2. INSTALL POWER POINT SOCKET ASSY RR Align the socket with the notch on the power point socket cover, push in the power point socket assy as hard as possible to install it.

HINT

  1. COMPONENTS: See «AIR BAG RESTRAINT SYSTEMS»(ref-170440)
  2. «LOCATION»(ref-215986-S31055643072006011900000) : See
  1. DISCONNECT BATTERY NEGATIVE TERMINAL (See «AIR BAG RESTRAINT SYSTEMS»(ref-170440) )
  2. REMOVE HORN BUTTON ASSY (See «AIR BAG RESTRAINT SYSTEMS»(ref-170440) )
  3. REMOVE STEERING PAD SWITCH LH
  1. Disconnect the connector.
  2. Remove the screw.
  3. Disengage the 2 claws and the pin.
  4. Remove the steering pad switch LH.

HINT

  1. COMPONENTS: See «AIR BAG RESTRAINT SYSTEMS»(ref-170440)
  2. «LOCATION»(ref-215986-S31055643072006011900000) : See
  1. DISCONNECT BATTERY NEGATIVE TERMINAL (See «AIR BAG RESTRAINT SYSTEMS»(ref-170440) )
  2. REMOVE HORN BUTTON ASSY (See «AIR BAG RESTRAINT SYSTEMS»(ref-170440) )
  3. REMOVE STEERING PAD SWITCH ASSY
  1. Disconnect the connector.
  2. Remove the steering pad switch LH (See «STEERING PAD SWITCH LH»(ref-215986-S05575450542006011900000) ).
  3. Remove the screw.
  4. Disengage the 2 claws and the pin.
  5. Remove the steering pad switch assy.

HINT

COMPONENTS: See COMPONENTS

  1. REMOVE INSTRUMENT PANEL UNDER COVER SUB-ASSY NO.2 (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
  2. REMOVE GLOVE COMPARTMENT DOOR ASSY (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
  3. REMOVE NETWORK GATEWAY ECU

Scheme 171

Scheme 171
Scheme 171
  1. Disconnect the connector.
  2. Remove the screw and the network gateway ECU.

Scheme 172

Scheme 172: REPAIR
Scheme 172: REPAIR

Scheme 173

Scheme 173
Scheme 173

Scheme 174

Scheme 174
Scheme 174

Scheme 175

Scheme 175
Scheme 175
  1. INSPECT WINDOW GLASS (ANTENNA WIRE) NOTE: When cleaning the glass, wipe it in the direction of the wire with a soft and dry cloth. Take care not to damage the wire. Do not use detergents or glass cleaners with abrasive ingredients. When measuring voltage, wind a piece of tin foil around the tip of the tester probe and press the foil against the wire with your finger see scheme 51 Check the continuity, at the center of each antenna wire see scheme 52
  2. REPAIR WINDOW GLASS (ANTENNA WIRE) Clean the broken wire tips with a grease, wax and silicone remover. Place the masking tape along both sides of the wire to be repaired. Thoroughly mix the repair agent (Dupont paste No.4817). Using a fine tip brush, apply a small amount of the mixture to the wire. After a few minutes, remove the masking tape. Do not repair the defogger wire for at least 24 hours afterwards.

More articles — Audio & Visual System
