Audio & Visual System: Overview Lexus RX II

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

1. DISCONNECT BATTERY NEGATIVE TERMINAL (See «AIR BAG RESTRAINT SYSTEMS»(ref-170440) )
2. REMOVE SHIFT LEVER KNOB SUB-ASSY (See «OVERHAUL»(ref-209590-S27089889222005121000000) )
3. REMOVE CONSOLE PANEL UPPER FRONT (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
4. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
5. REMOVE RADIO RECEIVER ASSEMBLY W/BRACKET Remove the 4 bolts. Disengage the 2 claws and the 2 clips. Disconnect the connector. Remove the radio receiver assembly w/ bracket.
6. REMOVE RADIO BRACKET NO.1 Remove the 3 screws and the radio bracket No.1.
7. REMOVE RADIO BRACKET NO.2 Remove the 3 screws and the radio bracket No.2.
8. REMOVE RADIO RECEIVER ASSY
