Communication System: Removal & Installation Lexus RX II

REPLACEMENT

HINT

The installation is in the reverse order of the removal.

Scheme 290

Scheme 291

Scheme 292

Scheme 293

1. REMOVE MAP LAMP ASSY Using a screwdriver, pry out the lens cover. HINT: Tape the screwdriver tip before use. Using a screwdriver, pry out the 2 caps. HINT: Tape the screwdriver tip before use. Remove the 4 screws. Remove the map lamp and disconnect the connector.
2. REMOVE MICROPHONE ASSY Remove the screw. Using a screwdriver, disconnect the connector and remove the microphone.
3. REMOVE MICROPHONE AMPLIFIER ASSY Remove the screw. Remove the microphone amplifier, as shown in the illustration.

Scheme 294

Scheme 295

HINT

The installation is in the reverse order of the removal. However, when there is a special point concerning the installation, it is indicated.

Scheme 296

Scheme 297

Scheme 298

Scheme 299

Scheme 300

1. REMOVE REAR SEAT ASSY RH (4-2-4 SPLIT SEAT TYPE) (See «REAR SEAT ASSY RH»(ref-215996-S09863444282006011900000) )
2. REMOVE REAR SEAT ASSY LH (4-2-4 SPLIT SEAT TYPE) (See «REAR SEAT ASSY LH»(ref-215996-S23148733872006011900000) )
3. REMOVE DECK TRIM SIDE PANEL ASSY (See «ROOF HEADLINING ASSY»(ref-242882-S10992807412006081700000) ) Remove the rear door scuff plate LH. Remove the rear door scuff plate RH. Remove the rear door opening trim weatherstrip LH. Remove the rear door opening trim weatherstrip RH. Remove the deck board. Remove the tonneau cover. Remove the deck floor box front. Remove the deck floor box rear. Remove the deck board No. 2. Remove the deck board No. 3. Remove the back door weatherstrip. Remove the deck side trim box LH. Remove the deck side trim box RH. Remove the rear floor finish plate LH. Remove the rear floor finish plate RH. Remove the rear floor finish side plate LH. Remove the rear floor finish side plate RH. Remove the deck side trim cover LH. Remove the deck side trim cover RH. Remove the rear seat side cover LH. Remove the rear seat side cover RH. Remove the 4 rope hooks. Remove the deck trim side panel LH. Remove the deck trim side panel RH.
4. REMOVE FLOOR CARPET ASSY FRONT Remove the 5 clips. Turn over the carpet in the direction indicated by arrow.
5. REMOVE REAR SEAT SUB FLOOR PANEL ASSY Remove the 3 bolts, 3 nuts and floor panel.
6. REMOVE MAYDAY ASSY Disconnect the connectors. Remove the 2 bolts, nut and mayday.
7. REMOVE BUS BUFFER ECU Disconnect the connector. Remove the cap. Remove the nut and ECU.
8. REMOVE PORTABLE PHONE-L BATTERY Disconnect the connector. Remove the nut and mobile phone bracket. Remove the battery.
9. REMOVE MAYDAY ECU ASSY Disconnect the connector. Remove the 4 bolts and mayday ECU assy.
10. REMOVE TELEPHONE TRANSCEIVER ASSY Disconnect the connectors. Remove the 3 screws and transceiver.

HINT

The installation is in the reverse order of the removal. However, when there is a special point concerning the installation, it is indicated.

Scheme 301

Scheme 302

1. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
2. REMOVE INSTRUMENT PANEL PIN NO.1 (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
3. REMOVE DEFROSTER NOZZLE ASSY (See «REPLACEMENT»(ref-209595-S07742720212005121000000) )
4. REMOVE GPS ANTENNA Remove the 2 screws. Disconnect the clamp and antenna.
5. INSTALL GPS ANTENNA Install the antenna as shown in the illustration. Install the 2 screws.

HINT

The installation is in the reverse order of the removal.

Scheme 303

1. REMOVE ROOF HEADLINING ASSY (See «ROOF HEADLINING ASSY»(ref-242882-S10992807412006081700000) )
2. REMOVE AMPLIFIER ANTENNA ASSY Disconnect the connectors. Remove the nut and antenna.
