Lexus RC I facelift (2018-2024) Tire pressure monitoring circuit

ALSI BLK WIRE BLU WIRE BRN WIRE CAN I/F CERTIFICATION ECU COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM CSEL DATA DISPLAY DRIVER DRIVER TIRE PRESSURE MONITOR INITIATOR ECU-B FUSE F IN F OT FRONT TIRE PRESSURE MONITOR INITIATOR GRN WIRE HOT AT ALL TIMES HOT W/ INSTRUMENT PANEL J/B ASSEMBLY J/B-AM FUSE LED DRIVER LEFT "C" PILLAR) LT GRN WIRE MAIN BODY ECU METER FUSE OA (LEFT KICK PANEL) R IN R OT RCO RDAM REAR TIRE PRESSURE MONITOR INITIATOR RED WIRE RIGHT END OF DASH) SPEAKER TELLTALES TIRE PRESSURE WARNING SWITCH (PRESSURE WARNING SWITCH 1) WHT WIRE WHT/BLK WIRE YEL WIRE
