Starting/charging — Charging circuit Lexus RC I facelift
All systems — 39 systems
- Active bodyworks
- Air conditioning
- Anti-lock brakes
- Anti-theft 2
- Body control modules 2
- Computer data lines
- Cooling fan
- Cruise control 3
- Defoggers 2
- Electronic power steering 3
- Electronic suspension
- Engine performance 2.0l turbo
- Engine performance 3.5l
- Engine performance 5.0l
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 3
- Navigation 5
- Passive restraints
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 5
- Power top/sunroof
- Power windows
- Radio 4
- Shift interlock 2
- Starting/charging 2
- Supplemental restraints
- Transmission 3
- Transmission 2.0l turbo
- Transmission 3.5l 2
- Trunk, tailgate, fuel door
- Warning systems 2
- Wiper/washer 2
Components on these wiring diagrams 7
Click a component to highlight it on every diagram it appears on.
