A/C-HEATER SYSTEMS SPECIFICATIONS
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section. |
| CAUTION | When battery is disconnected, radio will go into anti-theft protection mode. Obtain radio anti-theft protection code from owner prior to servicing vehicle. |
| Application | Specifications |
|---|
| Compressor Type | Nippondenso 10PA17 10-Cyl. |
| Compressor Belt Tension (1) |
| New Belt (2) | 100-150 lbs. (45.4-68.1 kg) |
| Used Belt | 60-100 lbs. (27.2-25.4 kg) |
| Compressor Oil Capacity | (3) 4.1 ozs. |
| Refrigerant (R-134a) Capacity | 28.2-31.7 ozs. |
| System Operating Pressures (4) |
| Low Side | 21-36 psi (1.5-2.5 kg/cm 2 ) |
| High Side | 199-228 psi (14-16 kg/cm 2 ) |
| (1) Using a belt tension gauge, measure at longest run of belt. (2) A new belt is one that has been in use less than 5 minutes. (3) Use ND-OIL 8 refrigerant oil (Part No. 38885-09109). (4) Specification is with ambient temperature at 86-95°F 30-35°C) and engine speed at 1500 RPM. |
| (1) | Using a belt tension gauge, measure at longest run of belt. |
| (2) | A new belt is one that has been in use less than 5 minutes. |
| (3) | Use ND-OIL 8 refrigerant oil (Part No. 38885-09109). |
| (4) | Specification is with ambient temperature at 86-95°F 30-35°C) and engine speed at 1500 RPM. |
A/C-HEATER SYSTEMS SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Bolts | 18 (25) |
| Drive Belt Idler Pulley Bolt | 27 (37) |
| Refrigerant Hoses/Lines |
| Compressor | 7 (10) |
| Condenser (Discharge) | 7 (10) |
| Evaporator | (1) |
| Expansion Valve (Fittings) | (1) |
| Receiver-Drier | (1) |
| (1) Tighten to 48 INCH lbs. (5.4 N.m). |
| (1) | Tighten to 48 INCH lbs. (5.4 N.m). |
Heater System Wiring Diagram (1996 Rear). Scheme 1
Scheme 1: Heater System Wiring Diagram (1996 Rear)
Automatic A/C-Heater System Wiring Diagram (1996 1 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (1996 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (1996 2 Of 2). Scheme 3
Scheme 3: Automatic A/C-Heater System Wiring Diagram (1996 2 Of 2)
