Seats (Service Information): Overview Lexus LX J200 рестайлинг

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

MANUAL OPEN OPERATION [01/2012 - ]

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

Scheme 13

Scheme 14

Scheme 15

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: w/ Navigation System: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [01/2012 - ]»(ref-603789-S23769828912014031100000) .
2. REMOVE REAR SEAT CUSHION HINGE COVER LH Remove the rear seat cushion hinge cover LH See step 2 .
3. REMOVE REAR NO. 2 SEAT HINGE COVER LH Remove the rear No. 2 seat hinge cover LH See step 3 .
4. REMOVE RECLINING ADJUSTER COVER RH Remove the reclining adjuster cover RH See step 11 .
5. OPEN BOTTOM OF SEATBACK COVER Detach the hook.
6. REMOVE REAR SEATBACK LOCK STRIKER ASSEMBLY LH Detach the clamp. Remove the nut, bolt and remove the striker.
7. REMOVE POWER SEAT MOTOR SUB-ASSEMBLY Remove the power seat motor sub-assembly See step 1 .
8. REMOVE REAR NO. 2 SEAT ASSEMBLY Remove the rear No. 2 seat See step 5 .
9. REMOVE REAR STEP COVER
10. REMOVE REAR DOOR SCUFF PLATE LH
11. REMOVE REAR FLOOR MAT REAR SUPPORT PLATE
12. REMOVE NO. 1 LUGGAGE COMPARTMENT TRIM HOOK
13. REMOVE FRONT QUARTER TRIM PANEL ASSEMBLY LH
14. REMOVE REAR ROOF NO. 1 AIR DUCT
15. REMOVE NO. 1 WOOFER BOX SPEAKER ASSEMBLY (for RH Side, w/ Woofer)
16. UNLOCK FOLD SEAT LEG LOCK SUB-ASSEMBLY BY HAND Pull the release lever in the direction shown in the illustration to release the lock.
