Seat Heater (Diagnostics): Overview Lexus LX J200 рестайлинг

Scheme 427

Scheme 428

Scheme 429

Scheme 430

Scheme 431

Scheme 432

Scheme 433

SYSTEM DESCRIPTION [01/2012 - ]

1. GENERAL By operating the seat heater switch which is located in the console box, the temperature can be controlled within the range of 30 to 40°C (86 to 104°F). Whether the seat heater is on or off can be determined by checking if the seat heater switch indicator light is on or off. w/o Climate Control Seat System: The seat heaters of the front seats are controlled by the seat heater controls, which are located under the respective seat. w/ Climate Control Seat System: The seat heaters of the front seats are controlled by the seat climate control ECUs, which are located under the respective seat. w/ Rear Seat Heater System: The seat heaters of the rear seats are controlled by the seat heater controls, which are located under the respective seat.

See also:
• INSPECTION [01/2012 - ]
