Automatic Transmission (Diagnostics - Introduction): Diagnosis Lexus LX J200 рестайлинг

HOW TO PROCEED WITH TROUBLESHOOTING [01/2012 - ]

HINT

1. The ECM is connected to the CAN communication system. Therefore, before starting troubleshooting, make sure to check that there is no trouble in the CAN communication system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS Refer to customer problem analysis. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [01/2012 - ]»(ref-603789-S02048416482014031100000) . NEXT: Go to next step
3. INSPECT BATTERY VOLTAGE Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding. NEXT: Go to next step
4. CONNECT TECHSTREAM TO DLC3* NEXT: Go to next step
5. CHECK AND CLEAR DTCS AND FREEZE FRAME DATA* Refer to the DTC Check / Clear. Refer to «DTC CHECK / CLEAR [01/2012 - ]»(ref-603921-S27047736462014031100000) . NEXT: Go to next step
6. VISUAL INSPECTION NEXT: Go to next step
7. SETTING CHECK MODE DIAGNOSIS* Refer to the Check Mode Procedure. Refer to «CHECK MODE PROCEDURE [01/2012 - ]»(ref-603921-S13305026562014031100000) . NEXT: Go to next step
8. PROBLEM SYMPTOM CONFIRMATION Refer to the Road Test. Refer to «ROAD TEST [01/2012 - ]»(ref-603921-S27271749362014031100000) . RESULT Result Proceed to Symptom does not occur A Symptom occurs B B --> GO TO STEP 10 A: Go to next step
9. SYMPTOM SIMULATION Refer to the Electronic Circuit Inspection Procedure. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [01/2012 - ]»(ref-603789-S26835722402014031100000) . NEXT: Go to next step
10. DTC CHECK* Refer to the DTC Check / Clear. Refer to «DTC CHECK / CLEAR [01/2012 - ]»(ref-603921-S27047736462014031100000) . RESULT Result Proceed to DTC is not output A DTC is output B B --> GO TO STEP 18 A: Go to next step
11. BASIC INSPECTION Refer to the Park/Neutral Position Switch. Refer to «ON-VEHICLE INSPECTION [01/2012 - ]»(ref-603912-S14389180252014031100000) . Refer to the Shift Lever Assembly. Refer to «ON-VEHICLE INSPECTION [01/2012 - ]»(ref-603912-S29971237852014031100000) . NG --> GO TO STEP 21 OK: Go to next step
12. MECHANICAL SYSTEM TESTS Refer to the Mechanical System Tests. Refer to «MECHANICAL SYSTEM TESTS [01/2012 - ]»(ref-603921-S26567089622014031100000) . NG --> GO TO STEP 17 OK: Go to next step
13. HYDRAULIC TEST Refer to the Hydraulic Test. Refer to «HYDRAULIC TEST [01/2012 - ]»(ref-603921-S30669295432014031100000) . NG --> GO TO STEP 17 OK: Go to next step
14. MANUAL SHIFTING TEST Refer to the Manual Shifting Test. Refer to «MANUAL SHIFTING TEST [01/2012 - ]»(ref-603921-S28497827602014031100000) . NG --> GO TO STEP 16 OK: Go to next step
15. PROBLEM SYMPTOMS TABLE CHAPTER 1 Refer to the Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [01/2012 - ]»(ref-603921-S41098702422014031100000) . NG --> GO TO STEP 19 OK: Go to next step
16. PROBLEM SYMPTOMS TABLE CHAPTER 2 Refer to the Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [01/2012 - ]»(ref-603921-S41098702422014031100000) . NEXT: Go to next step
17. PART INSPECTION NG --> GO TO STEP 21 OK: Go to next step
18. DTC CHART Refer to the Diagnostic Trouble Code Chart. Refer to «DIAGNOSTIC TROUBLE CODE CHART [01/2012 - ]»(ref-603921-S15194002072014031100000) . NEXT: Go to next step
19. CIRCUIT INSPECTION NEXT: Go to next step
20. IDENTIFICATION OF PROBLEM NEXT: Go to next step
21. REPAIR OR REPLACE NEXT: Go to next step
22. CONFIRMATION TEST NEXT --> END

ROAD TEST [01/2012 - ]

1. PROBLEM SYMPTOM CONFIRMATION Based on the result of the customer problem analysis, try to reproduce the symptoms. If the problem is that the transmission does not shift up or down, or that the shift point is too high or too low, conduct the following road test referring to the automatic shift schedule and attempt to duplicate the problem symptoms.
2. ROAD TEST Perform a road test. WARNING: Check for safety before performing any tests. NOTE: Be sure to inspect and adjust the engine before performing these tests. Perform the road test with the engine coolant temperature between 60 and 100°C (140 and 212°F) and the ATF temperature between 50 and 100°C (122 and 212°F). Perform these tests with the air conditioning and cruise control off. Inspection Procedure Transmission Control Switch Test With the vehicle stationary and the shift lever in D, move the shift lever to S and return it to D. Check that the meter display changes from D to the appropriate S range and then back again. S Position Test With the vehicle stationary and the shift lever in S, move the shift lever to "+" and "-". Check that the meter display changes between S ranges properly. D Position Shift Test While driving the vehicle normally, check that the transmission shifts up and down through each gear properly. Lock-up Function While driving on a level surface at a constant speed in the lock-up range (80 km/h (50 mph) or more) with the shift lever in D, lightly depress the accelerator pedal and check that the engine speed does not change abruptly. P Position Test Stop the vehicle on an incline (approximately 5° or more). Then move the shift lever to P and release the parking brake. Check that the parking lock pawl holds the vehicle in place. Abnormal Noise and Vibration Check for abnormal noise and vibration while driving the vehicle forward and backward, and during shift operations. Fluid Leakage After performing all other road test inspections, check for fluid leakage.

PROBLEM SYMPTOMS TABLE [01/2012 - ]

HINT

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. The Matrix Chart is divided into 2 chapters. When troubleshooting, check Chapter 1 first. If instructions are given in Chapter 1 to proceed to 2, proceed as instructed.
3. If the instruction "Proceed to next suspected area shown in problem symptoms table" is given in the flowchart for a circuit, proceed to the next suspected area in the table.
4. If the problem still occurs even though there are no malfunctions in any of the circuits, check the ECM and replace it if necessary.
5. *: When the circuit is defective, a DTC may be output.

1. CHAPTER 1: ELECTRONIC CIRCUIT MATRIX CHART

2. CHAPTER 2: ON-VEHICLE REPAIR AND OFF-VEHICLE REPAIR

Scheme 411

Scheme 412

Scheme 413

Scheme 414

Scheme 415

1. CHECK ECM HINT: Each ECM terminal standard voltage is shown in the table below. In the table, first follow the information under "Condition". Look under "Terminal No. (Symbol)" for the terminals to be inspected. The standard voltage between the terminals is shown under "Specified Condition". Use the illustration above as a reference for the ECM terminals. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A38-21 (L4) - C53-81 (E1) BR-R - W-B Transfer L4 position signal Engine switch on (IG) Transfer position switch on L4 Below 1.5 V A38-21 (L4) - C53-81 (E1) BR-R - W-B Transfer L4 position signal Engine switch on (IG) Transfer position switch not on L4 11 to 14 V A38-5 (TFN) - C53-81 (E1) G - W-B Transfer neutral position signal Engine switch on (IG) Transfer position in neutral Below 1.5 V A38-5 (TFN) - C53-81 (E1) G - W-B Transfer neutral position signal Engine switch on (IG) Transfer position not in neutral 11 to 14 V C53-120 (NSW) - C53-81 (E1) L - W-B PNP switch signal Engine switch on (IG) Shift lever in P or N Below 1 V C53-120 (NSW) - C53-81 (E1) L - W-B PNP switch signal Engine switch on (IG) Shift lever not in P or N 11 to 14 V C53-2 (P) - C53-81 (E1) G-B - W-B P shift position switch signal Engine switch on (IG) Shift lever in P 11 to 14 V C53-2 (P) - C53-81 (E1) G-B - W-B P shift position switch signal Engine switch on (IG) Shift lever not in P Below 1 V C53-26 (R) - C53-81 (E1) L-R - W-B R shift position switch signal Engine switch on (IG) Shift lever in R 11 to 14 V C53-26 (R) - C53-81 (E1) L-R - W-B R shift position switch signal Engine switch on (IG) Shift lever not in R Below 1 V C53-25 (N) - C53-81 (E1) G-W - W-B N shift position switch signal Engine switch on (IG) Shift lever in N 11 to 14 V C53-25 (N) - C53-81 (E1) G-W - W-B N shift position switch signal Engine switch on (IG) Shift lever not in N Below 1 V C53-27 (D) - C53-81 (E1) G - W-B D shift position switch signal Engine switch on (IG) Shift lever in D 11 to 14 V C53-27 (D) - C53-81 (E1) G - W-B D shift position switch signal Engine switch on (IG) Shift lever not in D Below 1 V A38-25 (S) - C53-81 (E1) W - W-B S shift position switch signal Engine switch on (IG) Shift lever in S 11 to 14 V A38-25 (S) - C53-81 (E1) W - W-B S shift position switch signal Engine switch on (IG) Shift lever not in S Below 1 V A38-38 (SFTU) - C53-81 (E1) Y - W-B Up-shift position switch signal Engine switch on (IG) Shift lever in S 11 to 14 V A38-38 (SFTU) - C53-81 (E1) Y - W-B Up-shift position switch signal Engine switch on (IG) Shift lever "+" position (up-shift) Below 1 V A38-27 (SFTD) - C53-81 (E1) L - W-B Down-shift position switch signal Engine switch on (IG) Shift lever in S 11 to 14 V A38-27 (SFTD) - C53-81 (E1) L - W-B Down-shift position switch signal Engine switch on (IG) Shift lever "-" position (down-shift) Below 1 V A38-36 (STP) - C53-81 (E1) R - W-B Stop light switch signal Brake pedal depressed 11 to 14 V A38-36 (STP) - C53-81 (E1) R - W-B Stop light switch signal Brake pedal released Below 1.5 V C53-7 (S1) - C53-81 (E1) R - W-B Shift solenoid valve S1 signal 1st gear Below 1 V C53-7 (S1) - C53-81 (E1) R - W-B Shift solenoid valve S1 signal Not in 1st gear 11 to 14 V C53-6 (S2) - C53-81 (E1) W - W-B Shift solenoid valve S2 signal 1st, 2nd or 6th gear 11 to 14 V C53-6 (S2) - C53-81 (E1) W - W-B Shift solenoid valve S2 signal 3rd, 4th or 5th gear Below 1 V C53-3 (S3) - C53-81 (E1) B-R - W-B Shift solenoid valve S3 signal 1st, 2nd or 3rd gear 11 to 14 V C53-3 (S3) - C53-81 (E1) B-R - W-B Shift solenoid valve S3 signal 4th, 5th or 6th gear Below 1 V C53-5 (S4) - C53-81 (E1) G-R - W-B Shift solenoid valve S4 signal 5th or 6th gear 11 to 14 V C53-5 (S4) - C53-81 (E1) G-R - W-B Shift solenoid valve S4 signal 1st, 2nd, 3rd or 4th gear Below 1 V C53-4 (SR) - C53-81 (E1) G - W-B Shift solenoid valve SR signal 1st, 2nd, 3rd or 4th gear 11 to 14 V C53-4 (SR) - C53-81 (E1) G - W-B Shift solenoid valve SR signal 5th or 6th gear Below 1 V C53-14 (SL1+) - C53-15 (SL1-) Y - L Shift solenoid valve SL1 signal 5th or 6th gear Pulse generation C53-12 (SL2+) - C53-13 (SL2-) G-R - L-W Shift solenoid valve SL2 signal Engine idling Pulse generation C53-9 (SLT+) - C53-8 (SLT-) B - G-B Shift solenoid valve SLT signal Engine idling Pulse generation C53-10 (SLU+) - C53-11 (SLU-) L-Y - L-R Shift solenoid valve SLU signal 5th (lock-up) gear or 6th (lock-up) gear Pulse generation C53-122 (THO1) - C53-98 (ETHA) G-Y - BR No. 1 ATF temperature sensor signal No. 1 ATF temperature: 115°C (239°F) or higher Below 1.5 V C53-99 (THO2) - C53-98 (ETHA) L - BR No. 2 ATF temperature sensor signal No. 2 ATF temperature: 115°C (239°F) or higher Below 1.5 V C53-101 (SP2+) - C53-100 (SP2-) Y - B Speed sensor SP2 signal Vehicle speed 20 km/h (12 mph) Pulse generation (see waveform 1) C53-124 (NT+) - C53-123 (NT-) Y - B Speed sensor NT signal Engine idling (shift lever in P or N) Pulse generation (see waveform 2) A38-10 (CANH) - C53-81 (E1) P - W-B CAN communication line Engine switch on (IG) Pulse generation (see waveform 3) A38-11 (CANL) - C53-81 (E1) B - W-B CAN communication line Engine switch on (IG) Pulse generation (see waveform 4) A38-51 (PWR) - C53-81 (E1) L-B - W-B Pattern select switch (PWR) signal Engine switch on (IG) Pattern select switch (PWR) off 11 to 14 V A38-51 (PWR) - C53-81 (E1) L-B - W-B Pattern select switch (PWR) signal Engine switch on (IG) Pattern select switch (PWR) on Below 1.5 V A38-4 (SNWI) - C53-81 (E1) P-L - W-B Pattern select switch (2ND) signal Engine switch on (IG) Pattern select switch (2ND) off 11 to 14 V A38-4 (SNWI) - C53-81 (E1) P-L - W-B Pattern select switch (2ND) signal Engine switch on (IG) Pattern select switch (2ND) pressed and held Below 1.5 V Using an oscilloscope, check waveform 1. REFERENCE: Terminal No. (Symbol) Tool Setting Condition C53-101 (SP2+) - C53-100 (SP2-) 2 V/DIV., 2 msec./DIV. Vehicle speed 20 km/h (12 mph) Using an oscilloscope, check waveform 2. REFERENCE: Terminal No. (Symbol) Tool Setting Condition C53-124 (NT+) - C53-123 (NT-) 1 V/DIV., 2 msec./DIV. Engine idling (shift lever in P or N) Using an oscilloscope, check waveform 3. REFERENCE: Terminal No. (Symbol) Tool Setting Condition A38-10 (CANH) - C53-81 (E1) 1 V/DIV., 10 μsec./DIV. Engine switch on (IG) Using an oscilloscope, check waveform 4. REFERENCE: Terminal No. (Symbol) Tool Setting Condition A38-11 (CANL) - C53-81 (E1) 1 V/DIV., 10 μsec./DIV. Engine switch on (IG)

Scheme 416

Scheme 417

1. DESCRIPTION When troubleshooting On-Board Diagnostic (OBD II) vehicles, the vehicle must be connected to the OBD II scan tool (complying with SAE J1987). Various data output from the vehicle ECM can then be read. OBD II regulations require that the vehicle on-board computer illuminate the Malfunction Indicator Lamp (MIL) on the instrument panel when the computer detects a malfunction in: The emission control system/components The powertrain control components (which affect vehicle emissions) The computer In addition, the applicable Diagnostic Trouble Codes (DTCs) prescribed by SAE J2012 are stored in the ECM memory. When the malfunction does not reoccur, the MIL stays illuminated until the engine switch is turned off, and the MIL turns off when the engine is started. However, the DTCs remain stored in the ECM memory. To check DTCs, connect the Techstream to the Data Link Connector 3 (DLC3) of the vehicle. The Techstream displays output DTCs, the freeze frame data and a variety of engine data. The DTCs and freeze frame data can be cleared with the Techstream. Refer to «DTC CHECK / CLEAR [01/2012 - ]»(ref-603921-S27047736462014031100000) .
2. NORMAL MODE AND CHECK MODE The diagnosis system operates in "normal mode" during normal vehicle use. In normal mode, "2 trip detection logic" is used to ensure accurate detection of malfunctions. "Check mode" is also available to technicians as an option. In check mode, "1 trip detection logic" is used for simulating malfunction symptoms and increasing the system ability to detect malfunctions, including intermittent malfunctions.
3. 2 TRIP DETECTION LOGIC When a malfunction is first detected, the malfunction is temporarily stored in the ECM memory (1st trip). If the same malfunction is detected during the next drive cycle, the MIL is illuminated (2nd trip).
4. FREEZE FRAME DATA Freeze frame data records the engine conditions (fuel system, calculated load, engine coolant temperature, fuel trim, engine speed, vehicle speed, etc.) when a malfunction is detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data from the time the malfunction occurred. The ECM records freeze frame data at 5 different times: 1) 3 times before the DTC is stored, 2) once when the DTC is stored, and 3) once after the DTC is stored. These data can be used to simulate the vehicle condition around the time when the malfunction occurred. The data may help find the cause of the malfunction, or judge if the DTC is being caused by a temporary malfunction or not.
5. CHECK DATA LINK CONNECTOR 3 (DLC3)
6. CHECK MIL Check that the MIL illuminates when turning the engine switch on (IG). If the MIL does not illuminate, there is a problem in the MIL circuit. Refer to «MIL Circuit»(ref-603922-S41274926422014031100000) . When the engine is started, the MIL should turn off.

DTC CHECK / CLEAR [01/2012 - ]

Note. When the diagnosis system is changed from normal mode to check mode or vice versa, all DTCs and freeze frame data recorded in normal mode are cleared. Before changing modes, always check and make a note of DTCs and freeze frame data.

HINT

1. DTCs which are stored in the ECM can be displayed on the Techstream. The Techstream can display the current, pending and permanent DTCs.
2. If a malfunction is detected during the current driving cycle, current and permanent DTCs are stored.
3. Some DTCs are not stored if the ECM does not detect the same malfunction again during a second consecutive driving cycle. However, such malfunctions, detected on only one occasion, are stored as pending DTCs.
4. Current and pending DTCs can be cleared by using the Techstream or by disconnecting the cable from the negative battery terminal. However, permanent DTCs cannot be cleared using either of these two methods.
5. After clearing current DTCs using the Techstream (or by disconnecting the cable from the negative battery terminal), permanent DTCs are cleared when the system is determined to be normal for the relevant DTCs and then the universal trip is performed.

2-TRIP DETECTION EXAMPLES

Scheme 418

Scheme 419

Scheme 420

1. CHECK DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check the DTC(s) and freeze frame data, and then write them down. Check the details of the DTC(s). Refer to «DIAGNOSTIC TROUBLE CODE CHART [01/2012 - ]»(ref-603921-S15194002072014031100000) .
2. CLEAR DTC (Pending and Current DTC) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Clear the DTCs.
3. CLEAR DTC (Pending and Current DTC without using Techstream) Perform either of the following operations: Disconnect the cable from the negative (-) battery terminal for more than 1 minute. Remove the EFI MAIN and ETCS fuses from the engine room relay block located inside the engine compartment for more than 1 minute.
4. CLEAR PERMANENT DTC HINT: Even if the following procedure is not performed, permanent DTCs are cleared if no malfunctions are detected during 3 consecutive driving cycles. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check if permanent DTCs are stored. HINT: If permanent DTCs are not output, it is not necessary to continue this procedure. Clear DTCs. Perform the universal trip. Idle the engine for 30 seconds or more. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more. HINT: It is possible to complete the drive pattern even if the vehicle decelerates to less than 40 km/h (25 mph) during the driving cycle, provided that the vehicle is driven at 40 km/h (25 mph) or more for a total of 5 minutes. When accelerating through the gears, make sure the vehicle is driven so all gears are used in order and no gears are skipped. Allow 10 minutes or more to elapse from the time the engine is started. Turn the engine switch off. Wait 15 seconds. Turn the engine switch on (IG). Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check that the permanent DTCs have been cleared. HINT: If the permanent DTCs have not been cleared, perform the universal trip again. The permanent DTCs are cleared when the universal trip is completed.

Scheme 421

1. DESCRIPTION Check mode has a higher sensitivity to malfunctions and can detect malfunctions that normal mode cannot detect. Check mode can also detect all the malfunctions that normal mode can detect. In check mode, DTCs are stored with 1 trip detection logic.
2. CHECK MODE PROCEDURE Make sure that the following conditions are met: Battery positive voltage 11 V or higher. Throttle valve fully closed. Shift lever in P or N. A/C turned off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / Check Mode. Check that the MIL flashes as shown in the illustration. NOTE: All DTCs and freeze frame data will be cleared if: 1) the Techstream is used to change the ECM from normal mode to check mode or vice versa; or 2) during check mode, the engine switch is turned from on (IG) to on (ACC) or off. Before changing to check mode, make notes of the DTCs and freeze frame data. Start the engine. The MIL should turn off after the engine starts. Perform the Monitor Drive Pattern for the ECT test. Refer to «MONITOR DRIVE PATTERN [01/2012 - ]»(ref-603921-S36052832652014031100000) . (Or, simulate the conditions of the malfunction described by the customer). After simulating the malfunction conditions, use the Techstream to check the DTC and freeze frame data.

DATA LIST / ACTIVE TEST [01/2012 - ]

1. READ DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. According to the display on the Techstream, read the Data List. ENGINE AND ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note Vehicle Speed Vehicle speed/ Min.: 0 km/h, Max.: 255 km/h Actual vehicle speed Speed indicated on speedometer. Engine Speed Engine speed/ Min.: 0 rpm, Max.: 16383 rpm 650 to 750 rpm: Idling - Calculate Load Load calculated by ECM/ Min.: 0%, Max.: 100% 11 to 25%: Idling 12 to 26%: Running without load (2500 rpm) - Intake Air Intake air temperature/ Min.: -40°C, Max.: 140°C Equivalent to ambient air temperature - N Range Status Shift lever N status/ ON or OFF ON: Shift lever in P or N OFF: Shift lever not in P or N - Neutral Position SW Signal PNP switch status/ ON or OFF ON: Shift lever in P or N OFF: Shift lever not in any position P or N When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-603950-S21397403802014031100000) . Transfer L4 Transfer status/ ON or OFF ON: Transfer position in L4 OFF: Transfer position not L4 - Stop Light Switch Stop light switch status/ ON or OFF ON: Brake pedal depressed OFF: Brake pedal released - SPD (NT) Input shaft speed/ Min.: 0 rpm Max.: 12750 rpm Lock-up: ON (after warming up engine): Input turbine speed (NT) equal to engine speed OFF (idling with shift lever in N): Input turbine speed (NT) nearly equal to engine speed The data is displayed in increments of 50 rpm. SPD (SP2) Output shaft speed/ Min.: 0 km/h (0 mph) Max.: 255 km/h (158 mph) Vehicle stopped: 0 km/h (0 mph) (output shaft speed equal to vehicle speed) - Shift SW Status (P Range) PNP switch status/ ON or OFF ON: Shift lever in P OFF: Shift lever not in P When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-603950-S21397403802014031100000) . Pattern Switch (PWR/M) Power mode status/ ON or OFF ON: Power mode on OFF: Power mode off - Shift SW Status (R Range) PNP switch status/ ON or OFF ON: Shift lever in R OFF: Shift lever not in R When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-603950-S21397403802014031100000) . Shift SW Status (N Range) PNP switch status/ ON or OFF ON: Shift lever in N OFF: Shift lever not in N When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-603950-S21397403802014031100000) . Shift SW Status (N, P Range) Supported Status of PNP switch (N or P) support/ Supp or Unsupp - - Shift SW Status (N, P Range) PNP switch status/ ON or OFF ON: Shift lever not in P or N OFF: Shift lever in P or N - Sports Shift Up SW Sport shift up switch status/ ON or OFF ON: Shift lever held in "+" (up-shift) OFF: Shift lever not held in "+" (up-shift) - Sports Shift Down SW Sport shift down switch status/ ON or OFF ON: Shift lever held in "-" (down-shift) OFF: Shift lever not held in "-" (down-shift) - Sports Mode Selection SW Sport mode select switch status/ ON or OFF Shift lever: ON: In S, "+" or "-" OFF: Not in S, "+" or "-" - Shift SW Status (D Range) PNP switch status/ ON or OFF ON: Shift lever in D OFF: Shift lever not in D When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. HINT: When failure still occurs even after adjusting these parts, refer to DTC P0705. Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-603950-S21397403802014031100000) . A/T Oil Temperature 1 No. 1 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall test: Approximately 80°C (176°F) With engine cold: Equal to ambient temperature If the value is -40°C (-40°F) or 215°C (419°F), the No. 1 ATF temperature sensor circuit is open or shorted. A/T Oil Temperature 2 No. 2 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall test: Approximately 80°C (176°F) With engine cold: Equal to ambient temperature If the value is -40°C (-40°F) or 215°C (419°F), the No. 2 ATF temperature sensor circuit is open or shorted. Lock Up Lock-up/ ON or OFF ON: Lock-up operating OFF: Lock-up not operating - Shift Status ECM gear shift command/ 1st, 2nd, 3rd, 4th, 5th or 6th Shift lever: In D: 1st, 2nd, 3rd, 4th, 5th or 6th In S: 1st, 2nd, 3rd, 4th, 5th or 6th - SLT Solenoid Status Shift solenoid valve SLT status/ ON or OFF Accelerator pedal depressed: OFF Accelerator pedal released: ON - SLU Solenoid Status Shift solenoid valve SLU status/ ON or OFF Shift solenoid valve SLU: Operating: ON Not operating: OFF - Snow or 2nd Start mode 2nd Start mode status/ ON or OFF ON: 2nd Start mode on OFF: 2nd Start mode off - AT Fluid Flex Lock-up judder judgment/ ON or OFF ON: Judder judgment occurs OFF: Judder judgment does not occur
2. PERFORM ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Connect the TC and TE1 Turn on and off TC and TE1 connection ON or OFF ON: TC and TE1 are connected. OFF: TC and TE1 are disconnected. Activate the Solenoid (SLU) Operate shift solenoid valve SLU ON or OFF [Vehicle Condition] The engine is stopped. The shift lever is in P or N. Activate the Solenoid (SLT)* Operate shift solenoid valve SLT and raise line pressure ON or OFF HINT: OFF: Line pressure up (when Active Test "Activate the Solenoid (SLT)" is performed, ECM commands shift solenoid valve SLT to turn OFF) ON: No action (normal operation) [Vehicle Condition] The vehicle is stopped. The engine is idling. Activate the Solenoid (S1) Operate shift solenoid valve S1 ON or OFF [Vehicle Condition] The engine is stopped. The shift lever is in P or N. Activate the Solenoid (S2) Operate shift solenoid valve S2 ON or OFF [Vehicle Condition] The engine is stopped. The shift lever is in P or N. Activate the Solenoid (S3) Operate shift solenoid valve S3 ON or OFF [Vehicle Condition] The engine is stopped. The shift lever is in P or N. Activate the Solenoid (S4) Operate shift solenoid valve S4 ON or OFF [Vehicle Condition] The engine is stopped. The shift lever is in P or N. Activate the Lock Up Control shift solenoid valve SLU to set automatic transmission to lock-up condition ON or OFF It is possible to check the shift solenoid valve SLU operation. [Vehicle Condition] The throttle valve opening angle is less than 35%. The vehicle speed is 60 km/h (38 mph) or more. Control the Shift Position Operate shift solenoid valve and set each shift position Press "-->" button: Shift up Press "<--" button: Shift down It is possible to check the operation of the shift solenoid valves. [Vehicle Condition] The vehicle speed is 50 km/h (30 mph) or less. Activate the Solenoid (SR) Operate shift solenoid valve SR ON or OFF [Vehicle Condition] The engine is stopped. The shift lever is in P or N. Activate the Solenoid (SL1) Operate shift solenoid valve SL1 ON or OFF [Vehicle Condition] The engine is stopped. The shift lever is in P or N. Activate the Solenoid (SL2) Operate shift solenoid valve SL2 ON or OFF [Vehicle Condition] The engine is stopped. The shift lever is in P or N. HINT: *: Activate the Solenoid (SLT) in the Active Test is performed to check the line pressure changes by connecting SST to the automatic transmission, which is used in the Hydraulic Test. Refer to «HYDRAULIC TEST [01/2012 - ]»(ref-603921-S30669295432014031100000) as well. Note that the pressure values in the Active Test and hydraulic test are different.

DIAGNOSTIC TROUBLE CODE CHART [01/2012 - ]

HINT

1. If a DTC is output during the DTC check, check the parts listed in the table below and proceed to the "See" given.
2. *1: "Comes on" means the Malfunction Indicator Lamp (MIL) illuminates.
3. *2: "DTC stored" means the ECM stores the trouble code if the ECM detects the DTC detection condition.
4. *3: The ATF temperature warning light blinks or a message is displayed in the combination meter.
5. These DTCs may be output when the clutch, brake, gear components, etc. inside the automatic transmission are damaged.

AUTOMATIC TRANSMISSION SYSTEM
