Automatic Transmission (Diagnostic Codes & Circuit Tests): Diagnosis Lexus LX J200 рестайлинг

INSPECTION PROCEDURE

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. According to the display on the Techstream, read the Data List. ENGINE AND ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note Neutral Position SW Signal PNP switch status/ ON or OFF Shift lever: In P or N: ON Not in P or N: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. Shift SW Status (P Range) PNP switch status/ ON or OFF Shift lever: In P: ON Not in P: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. Shift SW Status (R Range) PNP switch status/ ON or OFF Shift lever: In R: ON Not in R: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. Shift SW Status (N Range) PNP switch status/ ON or OFF Shift lever: In N: ON Not in N: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect. Sports Shift Up SW Sport shift up switch status/ ON or OFF ON: Shift lever held in "+" (up-shift) OFF: Shift lever not held in "+" (up-shift) - Sports Shift Down SW Sport shift down switch status/ ON or OFF ON: Shift lever held in "-" (down-shift) OFF: Shift lever not held in "-" (down-shift) - Sports Mode Selection SW Sport mode select switch status/ ON or OFF Shift lever: ON: In S, "+" or "-" OFF: Not in S, "+" or "-" - Shift SW Status (D Range) PNP switch status/ ON or OFF Shift lever: In D: ON Not in D: OFF When the shift lever position displayed on the Techstream differs from the actual position, the adjustment of the PNP switch or shift cable may be incorrect.

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. According to the display on the Techstream, read the Data List. ENGINE AND ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note A/T Oil Temperature 1 No. 1 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall test: Approximately 80°C (176°F) With engine cold: Equal to ambient temperature If the value is -40°C (-40°F) or 215°C (419°F), the No. 1 ATF temperature sensor circuit is open or shorted. HINT: When DTC P0712 is stored and the Techstream output is 150°C (302°F) or higher, there is a short circuit. When DTC P0713 is stored and the Techstream output is -40°C (-40°F), there is an open circuit. Check the temperature displayed on the Techstream in order to check if a malfunction exists. Temperature Displayed Malfunction -40°C (-40°F) Open circuit 150°C (302°F) or higher Short circuit If a circuit related to the ATF temperature sensor becomes open, P0713 is immediately stored (in 0.5 seconds). When P0713 is stored, P0711 cannot be stored. It is not necessary to inspect the circuit when P0711 is stored.

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. According to the display on the Techstream, read the Data List. ENGINE AND ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note A/T Oil Temperature 1 No. 1 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall test: Approximately 80°C (176°F) With engine cold: Equal to ambient temperature If the value is -40°C (-40°F) or 215°C (419°F), the No. 1 ATF temperature sensor circuit is open or shorted. HINT: When DTC P0712 is stored and the Techstream output is 150°C (302°F) or higher, there is a short circuit. When DTC P0713 is stored and the Techstream output is -40°C (-40°F), there is an open circuit. Check the temperature displayed on the Techstream in order to check if a malfunction exists. Temperature Displayed Malfunction -40°C (-40°F) Open circuit 150°C (302°F) or higher Short circuit If a circuit related to the ATF temperature sensor becomes open, P0713 is immediately stored (in 0.5 seconds). When P0713 is stored, P0711 cannot be stored. It is not necessary to inspect the circuit when P0711 is stored.

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. According to the display on the Techstream, read the Data List. ENGINE AND ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note SPD (NT) Input shaft speed/ Min.: 0 rpm Max.: 12750 rpm Lock-up: ON (after warming up engine): Input turbine speed (NT) equal to engine speed OFF (idling with shift lever in N): Input turbine speed (NT) nearly equal to engine speed The data is displayed in increments of 50 rpm. HINT: SPD (NT) is always 0 while driving: Open or short in the sensor or circuit. SPD (NT) is always more than 0 and less than 300 rpm while driving the vehicle at 50 km/h (30 mph) or more: Sensor trouble, improper installation, or intermittent connection trouble in the circuit.

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. According to the display on the Techstream, read the Data List. ENGINE AND ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note SPD (SP2) Output shaft speed/ Min.: 0 km/h (0 mph) Max.: 255 km/h (158 mph) Vehicle stopped: 0 km/h (0 mph) (output shaft speed equal to vehicle speed) - HINT: SPD (SP2) is always 0 while driving: Open or short in the sensor or circuit. The SPD (SP2) value displayed on the Techstream is much less than the actual vehicle speed: Sensor trouble, improper installation, or intermittent connection trouble in the circuit.

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. According to the display on the Techstream, read the Data List. ENGINE AND ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note Stop Light Switch Stop light switch status/ ON or OFF Brake pedal: Depressed: ON Released: OFF

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

HINT

Shift solenoid valve SL1 turns ON/OFF normally when the shift lever is in D

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. HINT: While driving, the shift position can be forcibly changed with the Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART [01/2012 - ]»(ref-603921-S13574664832014031100000) . ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operate shift solenoid valve and set each shift position Press "-->" button: Shift up Press "<--" button: Shift down It is possible to check the operation of the shift solenoid valves. [Vehicle Condition] The vehicle speed is 50 km/h (30 mph) or less. HINT: This test can be conducted when the vehicle speed is 50 km/h (30 mph) or less. The 4th to 5th and 5th to 6th up-shifts must be performed with the accelerator pedal released. The 6th to 5th and 5th to 4th down-shifts must be performed with the accelerator pedal released. Do not operate the accelerator pedal for at least 2 seconds after shifting and do not shift successively. The shift position commanded by the ECM is shown in the Data List display on the Techstream. Shift solenoid valve S1 turns ON/OFF normally when the shift lever is in D. ECM gear shift command 1st 2nd 3rd 4th 5th 6th Shift solenoid valve S1 OFF ON ON ON ON ON

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. HINT: While driving, the shift position can be forcibly changed with the Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART [01/2012 - ]»(ref-603921-S13574664832014031100000) . ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operate shift solenoid valve and set each shift position Press "-->" button: Shift up Press "<--" button: Shift down It is possible to check the operation of the shift solenoid valves. [Vehicle Condition] The vehicle speed is 50 km/h (30 mph) or less. HINT: This test can be conducted when the vehicle speed is 50 km/h (30 mph) or less. The 4th to 5th and 5th to 6th up-shifts must be performed with the accelerator pedal released. The 6th to 5th and 5th to 4th down-shifts must be performed with the accelerator pedal released. Do not operate the accelerator pedal for at least 2 seconds after shifting and do not shift successively. The shift position commanded by the ECM is shown in the Data List display on the Techstream. Shift solenoid valve S2 turns ON/OFF normally when the shift lever is in D. ECM gear shift command 1st 2nd 3rd 4th 5th 6th Shift solenoid valve S2 ON ON OFF OFF OFF ON

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. HINT: While driving, the shift position can be forcibly changed with the Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART [01/2012 - ]»(ref-603921-S13574664832014031100000) . ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operate shift solenoid valve and set each shift position Press "-->" button: Shift up Press "<--" button: Shift down It is possible to check the operation of the shift solenoid valves. [Vehicle Condition] The vehicle speed is 50 km/h (30 mph) or less. HINT: This test can be conducted when the vehicle speed is 50 km/h (30 mph) or less. The 4th to 5th and 5th to 6th up-shifts must be performed with the accelerator pedal released. The 6th to 5th and 5th to 4th down-shifts must be performed with the accelerator pedal released. Do not operate the accelerator pedal for at least 2 seconds after shifting and do not shift successively. The shift position commanded by the ECM is shown in the Data List display on the Techstream. Shift solenoid valve SL2 turns ON/OFF normally when the shift lever is in D. ECM gear shift command 1st 2nd 3rd 4th 5th 6th Shift solenoid valve S3 ON ON ON OFF OFF OFF

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. HINT: While driving, the shift position can be forcibly changed with the Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART [01/2012 - ]»(ref-603921-S13574664832014031100000) . ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operate shift solenoid valve and set each shift position Press "-->" button: Shift up Press "<--" button: Shift down It is possible to check the operation of the shift solenoid valves. [Vehicle Condition] The vehicle speed is 50 km/h (30 mph) or less. HINT: This test can be conducted when the vehicle speed is 50 km/h (30 mph) or less. The 4th to 5th and 5th to 6th up-shifts must be performed with the accelerator pedal released. The 6th to 5th and 5th to 4th down-shifts must be performed with the accelerator pedal released. Do not operate the accelerator pedal for at least 2 seconds after shifting and do not shift successively. The shift position commanded by the ECM is shown in the Data List display on the Techstream. Shift solenoid valve SL2 turns ON/OFF normally when the shift lever is in D. ECM gear shift command 1st 2nd 3rd 4th 5th 6th Shift solenoid valve S4 OFF OFF OFF OFF ON ON Shift solenoid valve SL2 ON ON ON ON OFF OFF

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

HINT

Shift solenoid valve SL2 is turned ON/OFF normally when the shift lever is in D

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

HINT

Shift solenoid valve S1 is turned ON/OFF normally when the shift lever is in D

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

HINT

Shift solenoid valve S2 is turned ON/OFF normally when the shift lever is in D

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

HINT

Shift solenoid valve S3 is turned ON/OFF normally when the shift lever is in D

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

HINT

Shift solenoid valve S4 is turned ON/OFF normally when the shift lever is in D

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

HINT

Shift solenoid valve SR is turned ON/OFF normally when the shift lever is in D

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. According to the display on the Techstream, read the Data List. ENGINE AND ECT Tester Display Measurement Item/Range Normal Condition Diagnostic Note A/T Oil Temperature 2 No. 2 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall test: Approximately 80°C (176°F) With engine cold: Equal to ambient temperature If the value is -40°C (-40°F) or 215°C (419°F), the No. 2 ATF temperature sensor circuit is open or shorted. HINT: When DTC P2742 is stored and the Techstream output is 150°C (302°F) or higher, there is a short circuit. When DTC P2743 is stored and the Techstream output is -40°C (-40°F), there is an open circuit. Check the temperature displayed on the Techstream in order to check if a malfunction exists. Temperature Displayed Malfunction -40°C (-40°F) Open circuit 150°C (302°F) or higher Short circuit

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

Scheme 436

1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Activate the Lock Up Control shift solenoid valve SLU to set automatic transmission to lock-up condition ON or OFF It is possible to check the shift solenoid valve SLU operation. [Vehicle Condition] The throttle valve opening angle is less than 35%. The vehicle speed is 60 km/h (38 mph) or more. HINT: This test can be conducted when the vehicle speed is 60 km/h (38 mph) or more. Perform this test while driving in 5th or 6th gear. Lightly depress the accelerator pedal and check that the engine speed does not change abruptly. HINT: When changing the accelerator pedal opening angle while driving, if the engine speed does not change abruptly, lock-up is on. Slowly release the accelerator pedal in order to decelerate, but do not fully release the pedal (fully releasing the pedal will close the throttle valve and lock-up may be turned off automatically).

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR [01/2012 - ] .

When the pattern select switch (PWR) is pushed, switch contact is made and power mode is selected. To cancel power mode, push the pattern select switch (PWR) once again.

When the pattern select switch (2ND) is pushed, switch contact is made and 2nd mode is selected. To cancel 2nd mode, push the pattern select switch (2ND) once again.

HINT

2nd mode is automatically canceled when the engine switch is turned off.
