Starting System: Specifications Lexus LX J100

Starter 15 illustrations

TORQUE SPECIFICATIONS

Application		Ft. Lbs. (N.m)
Starter Mounting Bolts
Avalon, Corolla, ECHO, Land Cruiser, RAV4, Tundra & 4Runner		29 (39)
Camry, Camry Solara, Sienna & Tacoma		27 (37)
Celica		28 (38)
MR2		28 (37)
INCH Lbs. (N.m)
Park Neutral Position Switch
Land Cruiser, Tacoma, Tundra & 4Runner		116 (13)
All Others		48 (5.4)

TORQUE SPECIFICATIONS

Fig. 18: Starting System Wiring Diagram (Avalon)

Scheme 18: Starting System Wiring Diagram (Avalon)

Fig. 19: Starting System Wiring Diagram (Camry - 2.2L & 3.0L)

Scheme 19: Starting System Wiring Diagram (Camry - 2.2L & 3.0L)

Fig. 20: Starting System Wiring Diagram (Camry - 2.2L CNG)

Scheme 20: Starting System Wiring Diagram (Camry - 2.2L CNG)

Fig. 21: Starting System Wiring Diagram (Camry Solara)

Scheme 21: Starting System Wiring Diagram (Camry Solara)

Fig. 22: Starting System Wiring Diagram (Celica)

Scheme 22: Starting System Wiring Diagram (Celica)

Fig. 23: Starting System Wiring Diagram (Corolla)

Scheme 23: Starting System Wiring Diagram (Corolla)

Fig. 24: Starting System Wiring Diagram (ECHO)

Scheme 24: Starting System Wiring Diagram (ECHO)

Fig. 25: Starting System Wiring Diagram (Land Cruiser)

Scheme 25: Starting System Wiring Diagram (Land Cruiser)

Fig. 26: Starting System Wiring Diagram (Lexus LX470)

Scheme 26: Starting System Wiring Diagram (Lexus LX470)

Fig. 27: Starting System Wiring Diagram (MR2)

Scheme 27: Starting System Wiring Diagram (MR2)

Fig. 28: Starting System Wiring Diagram (RAV4)

Scheme 28: Starting System Wiring Diagram (RAV4)

Fig. 29: Starting System Wiring Diagram (Sienna)

Scheme 29: Starting System Wiring Diagram (Sienna)

Fig. 30: Starting System Wiring Diagram (Tacoma)

Scheme 30: Starting System Wiring Diagram (Tacoma)

Fig. 31: Starting System Wiring Diagram (Tundra)

Scheme 31: Starting System Wiring Diagram (Tundra)

Fig. 32: Starting System Wiring Diagram (4Runner)

Scheme 32: Starting System Wiring Diagram (4Runner)
