Seat Belt: Removal & Installation Lexus LS IV

REMOVAL

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

Scheme 40

1. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «REMOVAL»(ref-349741-S20172361262009120800000) )
2. REMOVE FRONT SEAT ASSEMBLY (See «REMOVAL»(ref-349741-S20172361262009120800000) )
3. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
4. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
5. REMOVE FRONT SEAT INNER BELT ASSEMBLY for Driver Seat: Disconnect the 3 connectors and detach the 5 clamps. for Passenger Seat: Disconnect the 2 connectors and detach the clamp. Remove the nut and front seat inner belt assembly.

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. INSPECT FRONT SEAT INNER BELT ASSEMBLY LH Check the buckle switch. Measure the resistance according to the value (s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition connector A-3 - connector A-4 Fasten the seat belt (buckle switch is ON) Below 1 ohms connector A-3 - connector A-4 Release the seat belt (buckle switch is OFF) 1 Mohms or higher connector B-2 - connector C-1 Always Below 1 ohms connector B-4 - connector C-2 Always Below 1 ohms If the result is not as specified, replace the inner belt assembly. Check that the LED illuminates. Apply battery voltage to the front seat inner belt and check that the LED illuminates. OK MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> connector A-1 Battery negative (-) --> connector A-2 LED illuminates If the result is not as specified, replace the inner belt assembly.
2. INSPECT FRONT SEAT INNER BELT ASSEMBLY RH Check the buckle switch. Measure the resistance according to the value (s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Condition Specified Condition Connector A-1 - Connector A-2 Seat belt is fastened Below 1 ohms Connector A-1 - Connector A-2 Seat belt is unfastened 1 Mohms or higher If the result is not as specified, replace the inner belt assembly. Check that the LED illuminates. Apply battery voltage to the front seat inner belt and check that the LED illuminates. OK MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Connector A-3 Battery negative (-) --> Connector A-4 LED illuminates If the result is not as specified, replace the inner belt assembly.

Scheme 45

1. INSTALL FRONT SEAT INNER BELT ASSEMBLY Install the front seat inner belt assembly with the nut. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) NOTE: Do not allow the anchor part of the front seat inner belt assembly to overlap the protruding parts of the front seat adjuster. for Driver Seat: Connect the 3 connectors and attach the 5 clamps. for Passenger Seat: Connect the 2 connectors and attach the clamp.
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
3. INSTALL FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-349741-S29651146302009120800000) )
4. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
5. CONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «INSTALLATION»(ref-349741-S29651146302009120800000) )
6. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
7. CHECK SRS WARNING LIGHT Check the SRS warning light (see «DIAGNOSIS SYSTEM»(ref-349738-S23481667942009120800000) ).

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

Scheme 46

Scheme 47

Scheme 48

Scheme 49

1. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «REMOVAL»(ref-349741-S20172361262009120800000) )
2. REMOVE FRONT SEAT ASSEMBLY (See «REMOVAL»(ref-349741-S20172361262009120800000) )
3. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
4. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
5. REMOVE FRONT DOOR SCUFF PLATE (See «REMOVAL»(ref-349734-S03706653952009120800000) )
6. REMOVE REAR DOOR SCUFF PLATE for Standard Body: Remove the rear door scuff plate (IR-80). for Long Body: Remove the rear door scuff plate (IR-119).
7. REMOVE CENTER PILLAR GARNISH LOWER (See «REMOVAL»(ref-349734-S03706653952009120800000) )
8. REMOVE CENTER PILLAR GARNISH UPPER (See «REMOVAL»(ref-349734-S03706653952009120800000) )
9. REMOVE FRONT SEAT SHOULDER BELT GUIDE Remove the 2 screws and belt guide.
10. REMOVE FRONT SEAT OUTER BELT ASSEMBLY Remove the nut and shoulder anchor. Disconnect the pretensioner connector as shown in the illustration labeled A. Disconnect the tension reducer connector labeled B. w/ Pre-collision system: Disconnect the pre-collision connector labeled C. Remove the 2 bolts and seat belt.

Scheme 50

Scheme 51

Scheme 52

1. INSPECT FRONT SEAT OUTER BELT ASSEMBLY CAUTION: Do not disassemble the retractor. Before installing the seat belt, check the ELR. When the inclination of the retractor is 15° or less, check that the belt can be pulled from the retractor. When the inclination of the retractor is over 45°, check that the belt locks. If the operation is not as specified, replace the seat belt assembly. Check the tension reducer operation. CAUTION: Do not apply battery voltage to the pretensioner connector. Connect the battery's positive (+) lead to terminal 1 (IG) of the tension reducer connector and the negative (-) lead to terminal 2 (L). Check that an operating sound is heard when the magnetized solenoid is attracting the plunger. Pull out the seat belt and let it retract. Listen to the operating sound. Pull out the seat belt again, disconnect the battery's negative (-) lead and let it retract. Listen to the operating sound again and check that the operating sound volume has increased. If the result is not as specified, replace the outer belt assembly. for Passenger's Seat only: Check the fastening function of the child restraint system. NOTE: The check should be performed with the outer belt installed. When the belt is pulled out fully, the belt should automatically start to retract. After the belt has fully retracted, the belt should be able to be pulled out and retracted again. If the operation is not as specified, replace the belt assembly.

INSTALLATION

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 53

Scheme 54

1. INSTALL FRONT SEAT OUTER BELT ASSEMBLY NOTE: When installing the retractor, make sure the vehicle's claws (labeled "a" in the illustration) only contact the installation areas of the retractor. Align the vehicle's claws with the seat belt retractor positioning holes. Install the seat belt with the 2 bolts. First install the upper bolt, and then install the lower bolt. Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf) for bolt A Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) for bolt B Connect the pretensioner connector labeled A, as shown in the illustration. Connect the tension reducer connector labeled B. w/ Pre-collision system: Connect the pre-collision connector labeled C. Install the shoulder anchor to the shoulder belt anchor adjuster with the nut. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf)
2. INSTALL FRONT SEAT SHOULDER BELT GUIDE Install the belt guide with the 2 screws. NOTE: Make sure the belt is not pinched as this may damage the belt.
3. INSTALL CENTER PILLAR GARNISH UPPER (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
4. INSTALL CENTER PILLAR GARNISH LOWER (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
5. INSTALL REAR DOOR SCUFF PLATE for Standard Body: Install the rear door scuff plate (IR-101). for Long Body: Install the rear door scuff plate (IR-143).
6. INSTALL FRONT DOOR SCUFF PLATE (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
7. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
8. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
9. INSTALL FRONT SEAT ASSEMBLY (See «INSTALLATION»(ref-349741-S29651146302009120800000) )
10. CONNECT FRONT SEAT OUTER BELT ASSEMBLY (See «INSTALLATION»(ref-349741-S29651146302009120800000) )
11. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
12. CHECK SRS WARNING LIGHT Check the SRS warning light (RS-38).

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 55

1. INSTALL FRONT SHOULDER BELT ANCHOR ADJUSTER ASSEMBLY Install the seat belt with the 2 bolts. First install the upper bolt, and then install the lower bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf)
2. INSTALL HEIGHT ADJUSTABLE ANCHOR MOTOR Insert the motor into the adjuster as shown in the illustration. Install the connector.
3. INSTALL FRONT SEAT OUTER BELT ASSEMBLY Install the front seat outer belt (see «INSTALLATION»(ref-349752-S09911868622009120800000) ).

Scheme 56

Scheme 57

Scheme 58

1. REMOVE REAR SEAT ASSEMBLY Remove the rear seat (see «REMOVAL»(ref-349741-S26853688812009120800000) ).
2. REMOVE REAR SEAT INNER BELT ASSEMBLY LH Remove the bolt and seat belt.
3. REMOVE REAR SEAT INNER BELT ASSEMBLY RH Use the same procedures described for the LH side.
4. REMOVE REAR SEAT INNER BELT ASSEMBLY CENTER Remove the bolt and seat belt.

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 59

1. INSTALL REAR SEAT INNER BELT ASSEMBLY CENTER Install the belt with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) NOTE: Do not overlap the anchor part of the seat belt and protruding parts of the vehicle body.
2. INSTALL REAR SEAT INNER BELT ASSEMBLY LH Install the belt with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf)
3. INSTALL REAR SEAT INNER BELT ASSEMBLY RH Use the same procedures described for the LH side.
4. INSTALL REAR SEAT ASSEMBLY Install the rear seat (see «INSTALLATION»(ref-349741-S24840229242009120800000) ).

Scheme 60

Scheme 61

Scheme 62

1. REMOVE REAR SEAT ASSEMBLY Remove the rear seat (SE-402).
2. REMOVE REAR SEAT INNER BELT ASSEMBLY RH Remove the bolt and belt.
3. REMOVE REAR SEAT INNER BELT ASSEMBLY LH Remove the bolt and belt.

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

1. INSTALL REAR SEAT INNER BELT ASSEMBLY LH Install the seat belt with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf)
2. INSTALL REAR SEAT INNER BELT ASSEMBLY RH Install the seat belt with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf)
3. INSTALL REAR SEAT ASSEMBLY Install the rear seat (see «INSTALLATION»(ref-349741-S09487469022009120800000) ).

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. REMOVE REAR SEAT CUSHION ASSEMBLY (See «REMOVAL»(ref-349741-S36365163922009120800000) )
2. DISCONNECT REAR SEAT OUTER BELT ASSEMBLY CENTER Remove the nut and disconnect the anchor part of the rear seat outer belt assembly center.
3. REMOVE REAR SEAT INNER BELT ASSEMBLY Remove the bolt and rear seat inner belt assembly.
4. REMOVE REAR SEAT INNER BELT ASSEMBLY CENTER Remove the bolt and rear seat inner belt assembly center.

Scheme 67

Scheme 68

Scheme 69

1. INSTALL REAR SEAT INNER BELT ASSEMBLY CENTER Install the rear seat inner belt assembly center with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) NOTE: Do not overlap the anchor part of the seat belt and protruding parts of the vehicle body.
2. INSTALL REAR SEAT INNER BELT ASSEMBLY Install the rear seat inner belt assembly with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) NOTE: Do not overlap the anchor part of the seat belt and protruding parts of the vehicle body.
3. CONNECT REAR SEAT OUTER BELT ASSEMBLY CENTER Connect the rear seat outer belt assembly with the nut. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) NOTE: Do not overlap the anchor part of the seat belt and protruding parts of the vehicle body.
4. INSTALL REAR SEAT CUSHION ASSEMBLY (See «INSTALLATION»(ref-349741-S36437420052009120800000) )

Scheme 70

Scheme 71

Scheme 72

HINT

Use the same procedures for the RH side and LH side.

1. The procedures listed below are for the LH side.

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE REAR SEAT CUSHION ASSEMBLY LH for Power Seat: Remove the rear seat cushion (see «REMOVAL»(ref-349741-S26853688812009120800000) ). for Ottoman: Remove the rear seat cushion (see «REMOVAL»(ref-349741-S19112888892009120800000) ).
4. REMOVE REAR SEAT CUSHION ASSEMBLY RH for Power Seat: Remove the rear seat cushion (see «REMOVAL»(ref-349741-S26853688812009120800000) ). for Ottoman: Remove the rear seat cushion (see «REMOVAL»(ref-349741-S19112888892009120800000) ).
5. REMOVE REAR SEAT CUSHION ASSEMBLY (for Fixed Seat Type) (See «REMOVAL»(ref-349741-S36365163922009120800000) )
6. REMOVE REAR DOOR SCUFF PLATE LH for Standard Body: Remove the rear door scuff plate (see «REMOVAL»(ref-349734-S03706653952009120800000) ). for Long Body: Remove the rear door scuff plate (see «REMOVAL»(ref-349734-S29426050782009120800000) ).
7. REMOVE REAR DOOR SCUFF PLATE RH for Standard Body: Remove the rear door scuff plate (see «REMOVAL»(ref-349734-S03706653952009120800000) ). for Long Body: Remove the rear door scuff plate (see «REMOVAL»(ref-349734-S29426050782009120800000) ).
8. REMOVE REAR SEAT SIDE GARNISH LH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
9. REMOVE REAR SEAT SIDE GARNISH RH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
10. REMOVE ROOF SIDE GARNISH INNER LH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
11. REMOVE ROOF SIDE GARNISH INNER RH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
12. DISCONNECT REAR SEAT 3 POINT TYPE BELT ASSEMBLY LH Remove the bolt and disconnect the floor anchor.
13. DISCONNECT REAR SEAT 3 POINT TYPE BELT ASSEMBLY RH Use the same procedures described for the LH side.
14. DISCONNECT REAR SEAT OUTER BELT ASSEMBLY CENTER for Power Seat: Remove the nut and anchor part of the rear seat outer belt assembly. for Fixed Seat Type: Remove the nut and anchor part of the rear seat outer belt assembly.
15. REMOVE REAR SEATBACK ASSEMBLY LH for Power Seat: Remove the rear seatback (see «REMOVAL»(ref-349741-S26853688812009120800000) ). for Ottoman: Remove the rear seatback (see «REMOVAL»(ref-349741-S19112888892009120800000) ).
16. REMOVE REAR SEATBACK ASSEMBLY RH for Power Seat: Remove the rear seatback (see «REMOVAL»(ref-349741-S26853688812009120800000) ). for Ottoman: Remove the rear seatback (see «REMOVAL»(ref-349741-S19112888892009120800000) ).
17. REMOVE REAR SEATBACK ASSEMBLY (for Fixed Seat Type) (See «REMOVAL»(ref-349741-S36365163922009120800000) )
18. REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) (See «REMOVAL»(ref-349734-S29129796022009120800000) )
19. REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (w/o Rear Sunshade) Except Ottoman: Using a molding remover, detach the 4 claws and remove the 3 belt guides. Disengage the 2 clips and raise the front portion of the package tray trim panel assembly. Pass the 3 rear seat belt floor anchors through the package tray trim panel assembly. Disengage the 5 claws and remove the package tray trim panel assembly. for Ottoman: Using a molding remover, detach the 4 claws and remove the 2 belt guides. Disengage the 2 clips and raise the front portion of the package tray trim panel assembly. Pass the 2 rear seat belt floor anchors through the package tray trim panel assembly. Disengage the 5 claws and remove the package tray trim panel assembly.
20. REMOVE ROOF SIDE NO. 2 AIR DUCT LH (w/ Rear Cooler) (See «REMOVAL»(ref-349723-S30601776122009120800000) )
21. REMOVE ROOF SIDE NO. 2 AIR DUCT RH (w/ Rear Cooler) (See «REMOVAL»(ref-349723-S30601776122009120800000) )
22. REMOVE NO. 4 AIR DUCT REAR (w/ Rear Cooler) (See «REMOVAL»(ref-349723-S30601776122009120800000) )
23. REMOVE NO. 5 AIR DUCT REAR (w/ Rear Cooler) (See «REMOVAL»(ref-349723-S30601776122009120800000) )
24. REMOVE REAR SEAT 3 POINT TYPE BELT ASSEMBLY LH Disconnect the pretensioner connector, as shown in the illustration. Remove the bolt and seat belt.
25. REMOVE REAR SEAT 3 POINT TYPE BELT ASSEMBLY RH Disconnect the pretensioner connector, as shown in the illustration. Remove the bolt and seat belt.
26. REMOVE REAR SEAT OUTER BELT ASSEMBLY CENTER Remove the 2 bolts and rear seat outer belt assembly center.

Scheme 83

Scheme 84

1. INSPECT REAR SEAT 3 POINT TYPE BELT ASSEMBLY Check the ELR. When the inclination of the retractor is 15° or less, check that the belt can be pulled from the retractor. When the inclination of the retractor is over 45°, check that the belt locks. If the operation is not as specified, replace the seat belt assembly. Check the fastening function of the child restraint system. NOTE: The check should be performed with the outer belt installed. When the belt is pulled out fully, the belt should automatically start to retract. After the belt has fully retracted, the belt should be able to be pulled out and retracted again. If the operation is not as specified, replace the belt assembly.
2. INSPECT REAR SEAT OUTER BELT ASSEMBLY CENTER Check the ELR. When the inclination of the retractor is 15° or less, check that the belt can be pulled from the retractor. When the inclination of the retractor is over 45°, check that the belt locks. If the operation is not as specified, replace the seat belt assembly. Check the fastening function of the child restraint system. NOTE: The check should be performed with the outer belt installed. When the belt is pulled out fully, the belt should automatically start to retract. After the belt has fully retracted, the belt should be able to be pulled out and retracted again. If the operation is not as specified, replace the belt assembly.

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

1. INSTALL REAR SEAT OUTER BELT ASSEMBLY CENTER Align the seat belt positioning hole with the claw. Temporarily install the outer belt with the 2 bolts. Tighten the rear side bolt first, then the front side bolt to install the outer belt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) for rear bolt 7.5 N*m (77 kgf*cm, 66 in.*lbf) for front bolt
2. INSTALL REAR SEAT 3 POINT TYPE BELT ASSEMBLY LH Insert the claw of the retractor (a) into the hole. Align the seat belt positioning hole with the claw and install the retractor of the seat belt with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) Connect the pretensioner connector, as shown in the illustration.
3. INSTALL REAR SEAT 3 POINT TYPE BELT ASSEMBLY RH Insert the claw of the retractor (a) into the hole. Align the seat belt positioning hole with the claw and install the retractor of the seat belt with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) Connect the pretensioner connector, as shown in the illustration.
4. INSTALL NO. 4 AIR DUCT REAR (w/ Rear Cooler) (See «INSTALLATION»(ref-349723-S01438201792009120800000) )
5. INSTALL NO. 5 AIR DUCT REAR (w/ Rear Cooler) (See «INSTALLATION»(ref-349723-S01438201792009120800000) )
6. INSTALL ROOF SIDE NO. 2 AIR DUCT LH (w/ Rear Cooler) (See «INSTALLATION»(ref-349723-S01438201792009120800000) )
7. INSTALL ROOF SIDE NO. 2 AIR DUCT RH (w/ Rear Cooler) (See «INSTALLATION»(ref-349723-S01438201792009120800000) )
8. INSTALL NO. 2 PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) (See «INSTALLATION»(ref-349734-S21460801522009120800000) )
9. INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) (See «INSTALLATION»(ref-349734-S21460801522009120800000) )
10. INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY (w/o Rear Sunshade) Except Ottoman: Pass the 3 rear seat belt floor anchors through the package tray trim panel assembly. Attach the 5 claws and 2 clips to install the package tray trim panel assembly. Attach the 4 claws to install the 3 belt guides. for Ottoman: Pass the 2 rear seat belt floor anchors through the package tray trim panel assembly. Attach the 5 claws and 2 clips to install the package tray trim panel assembly. Attach the 4 claws to install the 2 belt guides.
11. INSTALL ROOF SIDE GARNISH INNER LH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
12. INSTALL ROOF SIDE GARNISH INNER RH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
13. INSTALL REAR SEAT SIDE GARNISH LH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
14. INSTALL REAR SEAT SIDE GARNISH RH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
15. INSTALL REAR DOOR SCUFF PLATE LH for Standard Body: Install the rear door scuff plate (see «INSTALLATION»(ref-349734-S14494944522009120800000) ). for Long Body: Install the rear door scuff plate (see «INSTALLATION»(ref-349734-S24814211142009120800000) ).
16. INSTALL REAR DOOR SCUFF PLATE RH for Standard Body: Install the rear door scuff plate (see «INSTALLATION»(ref-349734-S14494944522009120800000) ). for Long Body. Install the rear door scuff plate (see «INSTALLATION»(ref-349734-S24814211142009120800000) ).
17. INSTALL REAR SEATBACK ASSEMBLY (for Fixed Seat Type) (See «INSTALLATION»(ref-349741-S36437420052009120800000) )
18. INSTALL REAR SEATBACK ASSEMBLY LH (for Power Seat) (See «INSTALLATION»(ref-349741-S24840229242009120800000) )
19. INSTALL REAR SEATBACK ASSEMBLY RH (for Power Seat) (See «INSTALLATION»(ref-349741-S24840229242009120800000) )
20. INSTALL REAR SEATBACK ASSEMBLY LH (for Ottoman) (See «INSTALLATION»(ref-349741-S09487469022009120800000) )
21. INSTALL REAR SEATBACK ASSEMBLY RH (for Ottoman) (See «INSTALLATION»(ref-349741-S09487469022009120800000) )
22. CONNECT REAR SEAT 3 POINT TYPE BELT ASSEMBLY LH Install the floor end of the rear seat outer belt assembly LH with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) NOTE: Do not allow the anchor part of the rear seat 3 point type belt assembly LH to overlap the protruding parts of the floor panel. Check if the ELR locks. NOTE: The check should be performed with the outer belt assembly installed. With the belt assembly installed, check that the belt locks when it is pulled out quickly.
23. CONNECT REAR SEAT 3 POINT TYPE BELT ASSEMBLY RH Use the same procedures described for the LH side.
24. CONNECT REAR SEAT OUTER BELT ASSEMBLY CENTER for Power Seat: Install the floor end of the rear seat outer belt assembly center with the nut. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) NOTE: Do not allow the anchor part of the rear seat outer belt assembly to overlap the protruding parts of the floor panel. for Fixed Seat Type: Install the floor end of the rear seat outer belt assembly center with the nut. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) NOTE: Do not allow the anchor part of the rear seat outer belt assembly to overlap the protruding parts of the floor panel. Check if the ELR locks. NOTE: The check should be performed with the outer belt assembly installed. With the belt assembly installed, check that the belt locks when it is pulled out quickly.
25. INSTALL REAR SEAT CUSHION ASSEMBLY (for Fixed Seat Type) (See «INSTALLATION»(ref-349741-S36437420052009120800000) )
26. INSTALL REAR SEAT CUSHION ASSEMBLY LH for Power Seat: Remove the rear seat cushion assembly (see «INSTALLATION»(ref-349741-S09487469022009120800000) ). for Ottoman Seat: Remove the rear seat cushion assembly (see «INSTALLATION»(ref-349741-S24840229242009120800000) ).
27. INSTALL REAR SEAT CUSHION ASSEMBLY RH for Power Seat: Remove the rear seat cushion assembly (see «INSTALLATION»(ref-349741-S09487469022009120800000) ). for Ottoman Seat: Remove the rear seat cushion assembly (see «INSTALLATION»(ref-349741-S24840229242009120800000) ).
28. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
29. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
30. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 95

Scheme 96

1. INSTALL CHILD RESTRAINT SEAT ANCHOR BRACKET SUB-ASSEMBLY for Ottoman: for Passenger Side: Install the anchor bracket with the 2 bolts. Torque: 33 N*m (337 kgf*cm, 24 ft.*lbf) for Driver Side: Install the anchor bracket with the bolt. Torque: 33 N*m (337 kgf*cm, 24 ft.*lbf) Except Ottoman: Align the claw with the positioning hole and install the 2 anchor brackets with the 2 bolts. Torque: 33 N*m (337 kgf*cm, 24 ft.*lbf)
2. INSTALL CHILD RESTRAINT SEAT ANCHOR BRACKET SUB-ASSEMBLY INNER Except Ottoman: Align the hole with the positioning pin and install the 2 anchor brackets with the 2 bolts. Torque: 33 N*m (337 kgf*cm, 24 ft.*lbf) for Ottoman: Align the hole with the positioning pin and install the anchor bracket with the bolt. Torque: 33 N*m (337 kgf*cm, 24 ft.*lbf)
3. INSTALL REAR SEAT ASSEMBLY for Power Seat: Install the rear seat (see «INSTALLATION»(ref-349741-S24840229242009120800000) ). for Ottoman: Install the rear seat (see «INSTALLATION»(ref-349741-S09487469022009120800000) ). for Fixed Seat Type: Install the rear seat (see «INSTALLATION»(ref-349741-S36437420052009120800000) ).

Scheme 97

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedure listed below are for the LH side.

Scheme 98

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG (See «REMOVAL»(ref-349743-S08783415772009120800000) )
4. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See «REMOVAL»(ref-349743-S08783415772009120800000) )
5. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-349743-S08783415772009120800000) )
6. REMOVE HEIGHT ADJUSTABLE ANCHOR SWITCH Using a screwdriver, detach the 2 claws and remove the switch. HINT: Tape the screwdriver tip before use.

Scheme 99

Scheme 100

1. INSPECT HEIGHT ADJUSTABLE ANCHOR SWITCH (for LH Side) Measure the resistance according to the value (s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition 2 (UL) - 3 (UP) UP Below 1 ohms 1 (DW) - 3 (UP) UP 10 kohms or higher 1 (DW) - 2 (UL) DOWN Below 1 ohms 2 (UL) - 3 (UP) DOWN 10 kohms or higher If the result is not as specified, replace the switch.
2. INSPECT HEIGHT ADJUSTABLE ANCHOR SWITCH (for RH Side) Measure the resistance according to the value (s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION CHART Tester Connection Switch Condition Specified Condition 2 (UL) -1 (UP) UP Below 1 ohms 3 (DW) -1 (UP) UP 10 kohms or higher 3 (DW) - 2 (UL) DOWN Below 1 ohms 2 (UL) -1 (UP) DOWN 10 kohms or higher If the result is not as specified, replace the switch.

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

1. INSTALL HEIGHT ADJUSTABLE ANCHOR SWITCH Attach the 2 claws to install the switch.
2. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
3. INSTALL POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
4. INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG LH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
6. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
