Air Conditioning: Removal & Installation Lexus LS IV

INSTALLATION

1. INSTALL AIR FILTER Attach the 2 claws to install the filter.
2. INSTALL BLOWER WITH FAN MOTOR SUB-ASSEMBLY Install the motor with the 3 screws.
3. INSTALL DAMPER SERVO SUB-ASSEMBLY Install the damper servo with the 3 screws.
4. INSTALL BLOWER ASSEMBLY Attach the claw to install the blower unit. Connect the connector. Install the screw.
5. INSTALL AIR CONDITIONING UNIT Install the air conditioning unit (see «INSTALLATION»(ref-349723-S32631377022009120800000) ).

Scheme 309

Scheme 310

1. REMOVE AIR CONDITIONING UNIT ASSEMBLY Remove the air conditioning unit (see «REMOVAL»(ref-349723-S30542307522009120800000) ).
2. REMOVE REAR MODE SERVO MOTOR LH (See «REASSEMBLY»(ref-349723-S34862737132009120800000) )
3. REMOVE PTC HEATER ASSEMBLY Remove the 2 screws, 3 clamps and PTC heater.

Scheme 311

1. INSPECT PTC HEATER ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE CHART Tester Connection Condition Specified Condition A-1 - B-1 23 to 25°C (73 to 77°F) 0.5 to 2.5 ohms A-2 - B-1 23 to 25°C (73 to 77°F) 0.5 to 2.5 ohms A-2 - B-2 23 to 25°C (73 to 77°F) 0.5 to 2.5 ohms A-3 - B-2 23 to 25°C (73 to 77°F) 0.5 to 2.5 ohms If the result is not as specified, replace the PTC heater assembly.

Scheme 312

1. INSTALL PTC HEATER ASSEMBLY Install the PTC heater with the 2 screws and 3 clamps.
2. INSTALL REAR MODE SERVO MOTOR LH (See «REASSEMBLY»(ref-349723-S28028408392009120800000) )
3. INSTALL AIR CONDITIONING UNIT ASSEMBLY Install the air conditioning unit (see «INSTALLATION»(ref-349723-S32631377022009120800000) ).

Scheme 313

Scheme 314

Scheme 315

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Scheme 320

Scheme 321

Scheme 322

Scheme 323

Scheme 324

Scheme 325

Scheme 326

1. RECOVER REFRIGERANT FROM REFRIGERATION SYSTEM (See «REPLACEMENT»(ref-349723-S35523775142009120800000) )
2. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
4. REMOVE AIR CLEANER INLET COVER SUB-ASSEMBLY
5. REMOVE ENGINE ROOM SIDE COVER RH Remove the 4 clips and engine room side cover.
6. REMOVE ENGINE ROOM SIDE COVER LH Remove the 4 clips and engine room side cover.
7. REMOVE V-BANK COVER SUB-ASSEMBLY (See «REMOVAL»(ref-349724-S31319866602009120800000) )
8. REMOVE NO. 1 ENGINE UNDER COVER (See «COOLANT»(ref-349716-S00642260722009120800000) )
9. REMOVE NO. 2 ENGINE UNDER COVER (See «REMOVAL»(ref-349714-S31912998822009120800000) )
10. REMOVE FRONT SUSPENSION MEMBER PROTECTOR LOWER (See «REMOVAL»(ref-349714-S31912998822009120800000) )
11. REMOVE FRONT WHEEL
12. REMOVE RADIATOR SUPPORT OPENING COVER
13. REMOVE FRONT BUMPER COVER Remove the front bumper cover (see «REMOVAL»(ref-349736-S30791494642009120800000) ).
14. REMOVE FRONT SUSPENSION CROSSMEMBER LOWER (See «REMOVAL»(ref-349714-S31912998822009120800000) )
15. REMOVE REAR FRAME SIDE RAIL Remove the 6 bolts, 4 nuts and frame rail.
16. REMOVE NO. 1 AIR CLEANER INLET
17. REMOVE RADIATOR RESERVOIR ASSEMBLY
18. REMOVE INTAKE AIR CONNECTOR PIPE
19. REMOVE FAN AND GENERATOR V BELT (See «REMOVAL»(ref-349714-S30226729992009120800000) )
20. REMOVE AIR CLEANER CAP SUB-ASSEMBLY LH
21. REMOVE AIR CLEANER ASSEMBLY LH (See «REMOVAL»(ref-349728-S13350104582009120800000) )
22. REMOVE AIR CLEANER CAP SUB-ASSEMBLY RH
23. REMOVE AIR CLEANER ASSEMBLY RH (See «REMOVAL»(ref-349728-S13350104582009120800000) )
24. REMOVE ENGINE ROOM ECU OUTLET DUCT Remove the outlet duct.
25. REMOVE FRONT EXHAUST PIPE ASSEMBLY Remove the front exhaust pipe (see «REMOVAL»(ref-349729-S00174219962009120800000) ).
26. REMOVE NO. 1 EXHAUST PIPE SUPPORT BRACKET SUB-ASSEMBLY (See «REMOVAL»(ref-349729-S00174219962009120800000) )
27. REMOVE REAR ENGINE UNDER COVER RH
28. REMOVE FRONT STABILIZER BAR (See «REMOVAL»(ref-349722-S35890121652009120800000) )
29. REMOVE FRONT SUSPENSION MEMBER REINFORCEMENT RH (See «REMOVAL»(ref-349722-S35890121652009120800000) )
30. REMOVE FRONT SUSPENSION MEMBER REINFORCEMENT LH (See «REMOVAL»(ref-349722-S35890121652009120800000) )
31. REMOVE STEERING SLIDING WITH SHAFT YOKE SUB-ASSEMBLY w/ VGRS: Remove the steering sliding with shaft yoke (see «REMOVAL»(ref-349720-S38166401772009120800000) ). w/o VGRS: Remove the steering sliding with shaft yoke (see «REMOVAL»(ref-349720-S06801168612009120800000) ).
32. REMOVE NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY w/ VGRS: Remove the No. 2 steering intermediate shaft (see «REMOVAL»(ref-349720-S38166401772009120800000) ). w/o VGRS: Remove the No. 2 steering intermediate shaft (see «REMOVAL»(ref-349720-S06801168612009120800000) ).
33. REMOVE POWER STEERING LINK ASSEMBLY w/ VGRS: Remove the power steering link (see «REMOVAL»(ref-349733-S36942300362009120800000) ). w/o VGRS: Remove the power steering link (see «REMOVAL»(ref-349733-S32560895422009120800000) ).
34. REMOVE NO. 2 EXHAUST MANIFOLD HEAT INSULATOR (See «REMOVAL»(ref-349729-S25993239512009120800000) )
35. REMOVE EXHAUST MANIFOLD SUB-ASSEMBLY (for Bank 1) (See «REMOVAL»(ref-349729-S25993239512009120800000) )
36. DISCONNECT SUCTION HOSE SUB-ASSEMBLY Remove the bolt and disconnect the cooler refrigerant suction hose from the cooler compressor. Remove the O-ring from the cooler refrigerant suction hose. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent moisture and foreign matter from entering them.
37. DISCONNECT DISCHARGE HOSE SUB-ASSEMBLY Remove the bolt and disconnect the cooler refrigerant discharge hose from the cooler compressor. Remove the O-ring from the cooler refrigerant discharge hose. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent moisture and foreign matter from entering them.
38. REMOVE COOLER COMPRESSOR ASSEMBLY Disconnect the connector. Remove the 2 bolts and 2 nuts. Remove the 2 stud bolts and cooler compressor.

Scheme 327

Scheme 328

Scheme 329

1. ADJUST COMPRESSOR OIL When replacing the compressor and magnetic clutch with a new one, gradually discharge the refrigerant gas from the service valve, and drain the following amount of oil from the new compressor and magnetic clutch before installation. Standard: (Oil capacity inside the new compressor and magnetic clutch: 130 +15 cc (4.6 + 0.51 fl.oz.)) - (Remaining oil amount in the removed compressor and magnetic clutch) = (Oil amount to be removed from the new compressor when replacing) NOTE: When checking the compressor oil level, observe the A/C system's precautions. If a new compressor and magnetic clutch is installed without removing some oil remaining in the pipes of the vehicle, the oil amount will be too large. This prevents heat exchange in the refrigerant cycle and causes refrigerant failure. If the volume of oil remaining in the removed compressor and magnetic clutch is too small, check for oil leakage. Be sure to use ND-OIL 8 or equivalent for compressor oil.
2. INSTALL COOLER COMPRESSOR ASSEMBLY Install the cooler compressor with the 2 stud bolts Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Install the 2 bolts and 2 nuts. Torque: 24.5 N*m (250 kgf*cm, 18 ft.*lbf) NOTE: Tighten the nuts and bolts in the order shown in the illustration to install the cooler compressor. Connect the connector.
3. CONNECT DISCHARGE HOSE SUB-ASSEMBLY Remove the attached vinyl tape from the hose. Sufficiently apply compressor oil to a new O-ring and the fitting surface of the cooler compressor. Compressor oil: ND-OIL 8 or equivalent Install the O-ring to the cooler refrigerant discharge hose. Install the cooler refrigerant discharge hose to the cooler compressor with the bolt. Torque: 9.8 N*m (100 kgf*cm, 7 ft.*lbf)
4. CONNECT SUCTION HOSE SUB-ASSEMBLY Remove the attached vinyl tape from the hose. Sufficiently apply compressor oil to a new O-ring and the fitting surface of the cooler compressor. Compressor oil: ND-OIL 8 or equivalent Install the O-ring to the cooler refrigerant suction hose. Install the cooler refrigerant suction hose to the cooler compressor with the bolt. Torque: 9.8 N*m (100 kgf*cm, 7 ft.*lbf)
5. INSTALL EXHAUST MANIFOLD SUB-ASSEMBLY (for Bank 1) (See «INSTALLATION»(ref-349729-S11393153782009120800000) )
6. INSTALL NO. 2 EXHAUST MANIFOLD HEAT INSULATOR (See «INSTALLATION»(ref-349729-S11393153782009120800000) )
7. INSTALL POWER STEERING LINK ASSEMBLY w/ VGRS: Install the power steering link (see «INSTALLATION»(ref-349733-S30676435532009120800000) ). w/o VGRS: Install the power steering link (see «INSTALLATION»(ref-349733-S39831072802009120800000) ).
8. INSTALL NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY w/ VGRS: Install the No. 2 steering intermediate shaft (see «INSTALLATION»(ref-349720-S01586454122009120800000) ). w/o VGRS: Install the No. 2 steering intermediate shaft (see «INSTALLATION»(ref-349733-S39831072802009120800000) ).
9. INSTALL STEERING SLIDING WITH SHAFT YOKE SUB-ASSEMBLY w/ VGRS: Install the steering sliding with shaft yoke (see «INSTALLATION»(ref-349720-S01586454122009120800000) ). w/o VGRS: Install the steering sliding with shaft yoke (see «INSTALLATION»(ref-349720-S29560656232009120800000) ).
10. INSTALL FRONT SUSPENSION MEMBER REINFORCEMENT LH (See «INSTALLATION»(ref-349722-S20556009772009120800000) )
11. INSTALL FRONT SUSPENSION MEMBER REINFORCEMENT RH (See «INSTALLATION»(ref-349722-S20556009772009120800000) )
12. INSTALL FRONT STABILIZER BAR (See «INSTALLATION»(ref-349722-S20556009772009120800000) )
13. INSTALL REAR ENGINE UNDER COVER RH
14. INSTALL NO. 1 EXHAUST PIPE SUPPORT BRACKET SUB-ASSEMBLY (See «INSTALLATION»(ref-349729-S37582603882009120800000) )
15. INSTALL FRONT EXHAUST PIPE ASSEMBLY Install the front exhaust pipe (see «INSTALLATION»(ref-349729-S37582603882009120800000) ).
16. INSTALL ENGINE ROOM ECU OUTLET DUCT Install the engine room outlet duct.
17. INSTALL AIR CLEANER ASSEMBLY RH (See «INSTALLATION»(ref-349728-S03199878042009120800000) )
18. INSTALL AIR CLEANER CAP SUB-ASSEMBLY RH
19. INSTALL AIR CLEANER ASSEMBLY LH (See «INSTALLATION»(ref-349728-S03199878042009120800000) )
20. INSTALL AIR CLEANER CAP SUB-ASSEMBLY LH
21. INSTALL FAN AND GENERATOR V BELT (See «INSTALLATION»(ref-349714-S35834705202009120800000) )
22. INSTALL INTAKE AIR CONNECTOR PIPE
23. INSTALL RADIATOR RESERVOIR ASSEMBLY
24. INSTALL NO. 1 AIR CLEANER INLET
25. INSTALL FRONT SUSPENSION CROSSMEMBER LOWER Install the frame rail with the 6 bolts and 4 nuts. Torque: 30 N*m (306 kgf*cm, 22 ft.*lbf)
26. INSTALL REAR FRAME SIDE RAIL Install the frame rail with the 6 bolts and 4 nuts. Torque: 30 N*m (306 kgf*cm, 22 ft.*lbf)
27. INSTALL FRONT BUMPER COVER Install the front bumper cover (see «INSTALLATION»(ref-349736-S16181480572009120800000) ).
28. INSTALL RADIATOR SUPPORT OPENING COVER
29. INSPECT FOR EXHAUST GAS LEAK
30. INSTALL FRONT WHEEL
31. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
32. CHECK AND ADJUST FRONT WHEEL ALIGNMENT Check and adjust the front wheel alignment (see «FRONT WHEEL ALIGNMENT (FOR 2WD)»(ref-349722-S22862354252009120800000) ).
33. CHECK SHIFT LEVER POSITION
34. INSTALL FRONT SUSPENSION MEMBER PROTECTOR LOWER Install the suspension member protector with the 8 bolts.
35. INSTALL NO. 2 ENGINE UNDER COVER Install the under cover with the 8 bolts.
36. INSTALL NO. 1 ENGINE UNDER COVER (See «REPLACEMENT»(ref-349716-S35220647352009120800000) )
37. INSTALL V-BANK COVER SUB-ASSEMBLY
38. INSTALL ENGINE ROOM SIDE COVER RH Install the side cover with the 4 clips.
39. INSTALL ENGINE ROOM SIDE COVER LH Install the side cover with the 4 clips.
40. INSTALL AIR CLEANER INLET COVER SUB-ASSEMBLY
41. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
42. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
43. ADD COMPRESSOR OIL (See «REPLACEMENT»(ref-349723-S35523775142009120800000) )
44. CHARGE REFRIGERANT (See «REPLACEMENT»(ref-349723-S35523775142009120800000) )
45. WARM UP ENGINE (See «REPLACEMENT»(ref-349723-S35523775142009120800000) )
46. CHECK FOR LEAKAGE OF REFRIGERANT (See «REPLACEMENT»(ref-349723-S35523775142009120800000) )
47. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 330

Scheme 331

Scheme 332

Scheme 333

1. INSTALL ROOM TEMPERATURE SENSOR Connect the connector. Attach the 4 claws to install the sensor.

Scheme 334

Scheme 335

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE FRONT BUMPER COVER Remove the front bumper cover (see «REMOVAL»(ref-349736-S30791494642009120800000) ).
4. REMOVE AMBIENT TEMPERATURE SENSOR Disconnect the connector. Detach the clamp and remove the sensor.

Scheme 336

1. INSPECT AMBIENT TEMPERATURE SENSOR Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE CHART Tester Connection Condition Specified Condition 1 - 2 10°C (50°F) 3.00 to 3.73 kohms 1 - 2 15°C (59°F) 2.45 to 2.88 kohms 1 - 2 20°C (68°F) 1.95 to 2.30 kohms 1 - 2 25°C (77°F) 1.60 to 1.80 kohms 1 - 2 30°C (86°F) 1.28 to 1.47 kohms 1 - 2 35°C (95°F) 1.00 to 1.22 kohms 1 - 2 40°C (104°F) 0.80 to 1.00 kohms 1 - 2 45°C (113°F) 0.65 to 0.85 kohms 1 - 2 50°C (122°F) 0.50 to 0.70 kohms 1 - 2 55°C (131°F) 0.44 to 0.60 kohms 1 - 2 60°C (140°F) 0.36 to 0.50 kohms NOTE: Touching the sensor even slightly may change the resistance value. Hold the connector of the sensor. When measuring the resistance, the sensor temperature must be the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (see the graph below). If the result is not as specified, replace the ambient temperature sensor.

1. INSTALL AMBIENT TEMPERATURE SENSOR Attach the clamp to install the sensor. Connect the connector.
2. INSTALL FRONT BUMPER COVER Install the front bumper cover (see «INSTALLATION»(ref-349736-S16181480572009120800000) ).
3. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
5. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
6. CHECK SRS WARNING LIGHT Check the SRS warning light (see «DIAGNOSIS SYSTEM»(ref-349738-S23481667942009120800000) ).

Scheme 337

Scheme 338

REMOVAL

1. REMOVE AIR CONDITIONING UNIT Remove the air conditioning unit (see «REMOVAL»(ref-349723-S30542307522009120800000) ).

1. INSTALL AIR CONDITIONING UNIT Install the air conditioning unit (see «INSTALLATION»(ref-349723-S32631377022009120800000) ).

Scheme 339

Scheme 340

1. REMOVE REAR COOLING UNIT ASSEMBLY Remove the rear cooling unit (see «REMOVAL»(ref-349723-S30601776122009120800000) ).
2. REMOVE COOLER REFRIGERANT LIQUID PIPE A Remove the packing and butyl tape. Using a 4 mm hexagon wrench, remove the 2 hexagon bolts. Remove the screw and plate. Remove the cooler refrigerant liquid pipe A. Remove the 2 O-rings from the cooler refrigerant liquid pipe A.
3. REMOVE REAR COOLING UNIT EXPANSION VALVE Disconnect the connector. Detach the clamp. Remove the expansion valve from the cooler refrigerant suction pipe A.

1. INSTALL REAR COOLING UNIT EXPANSION VALVE Install the expansion valve to the cooler refrigerant suction pipe A. Attach the clamp. Connect the connector.
2. INSTALL COOLER REFRIGERANT LIQUID PIPE A Sufficiently apply compressor oil to 2 new O-rings and the fitting surface of the hose joint. Compressor oil: ND-OIL 8 or equivalent Install the 2 O-rings to the cooler refrigerant liquid pipe A. Install the cooler refrigerant liquid pipe A to the expansion valve. Using a 4 mm hexagon wrench, install the 2 hexagon bolts. Torque: 3.5 N*m (35 kgf*cm, 30 in.*lbf) Install the plate with the screw. Install new packing and butyl tape as shown in the illustration.
3. INSTALL REAR COOLING UNIT ASSEMBLY Install the rear cooling unit (see «INSTALLATION»(ref-349723-S01438201792009120800000) ).

Scheme 341

Scheme 342

1. REMOVE SOLAR SENSOR Detach the 2 claws. Disconnect the connector and remove the sensor.

Scheme 343

1. INSPECT SOLAR SENSOR Connect the battery's positive (+) lead to terminal 6 and the negative (-) lead to terminal 3, then measure the according to the value(s) in the table below. Standard voltage VOLTAGE REFERENCE CHART Tester Connection Connection Specified Condition 1 (TSL) - 3 (CLTE) Sensor subject to electric light 4.0 to 4.6 V 1 (TSL) - 3 (CLTE) Sensor covered with a cloth 0.8 V or less 2 (TSR) - 3 (CLTE) Sensor subject to electric light 4.0 to 4.6 V 2 (TSR) - 3 (CLTE) Sensor covered with a cloth 0.8 V or less NOTE: The connection procedure for using a digital tester such as a TOYOTA electrical tester is shown above. HINT: As the inspection light is moved away from the sensor, the voltage increases. Use an incandescent lamp for inspection. Bring it within 30 cm (11.8 in.) of the A/C solar sensor. If the result is not as specified, replace the solar sensor.

Scheme 344

1. INSTALL SOLAR SENSOR Connect the connector. Attach the 2 claws to install the sensor.

Scheme 345

1. REMOVE SOLAR SENSOR Detach the 2 claws. Disconnect the connector and remove the sensor.

Scheme 346

1. INSPECT COOLER (SOLAR SENSOR) THERMISTOR Using an ohmmeter, connect the positive lead to terminal 2 and the negative lead to terminal 1, then measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE CHART Tester Connection Connection Specified Condition 1 - 2 Sensor subject to electric light Except infinity ohms 1 - 2 Sensor covered with a cloth infinity ohms (No continuity) NOTE: The connection procedure for using a digital tester such as a TOYOTA electrical tester is shown above. When using an analog tester, connect the positive (+) lead to terminal 1 and the negative (-) lead to terminal 2 of the A/C solar sensor. HINT: Use an incandescent lamp for inspection. Bring it within 30 cm (11.8 in.) of the A/C solar sensor. If the result is not as specified, replace the thermistor.

Scheme 347

1. INSTALL SOLAR SENSOR Connect the connector. Attach the 2 claws to install the sensor.

Scheme 348

Scheme 349

Scheme 350

1. REMOVE ENGINE ROOM SIDE COVER LH Remove the 4 clips and cover.
2. REMOVE ENGINE ROOM SIDE COVER RH Remove the 4 clips and cover.
3. REMOVE AIR CLEANER INLET COVER Remove the 2 clips and cover.
4. REMOVE COOL AIR INTAKE DUCT SEAL Remove the 2 clips and duct seal.
5. REMOVE SMOG VENTILATION SENSOR Disconnect the connector. Remove the bolt and sensor.

Scheme 351

Scheme 352

1. INSPECT SMOG VENTILATION SENSOR HC, CO Apply battery voltage between terminals 3 (IG) and 6 (E). Allow exhaust gas (HC, CO) to travel to the sensing portion of the smog ventilation sensor, and measure the resistance between terminals 1 (SG) and 2 (DGS). OK: When the sensor is exposed to the exhaust gas, the resistance decreases. HINT: The resistance before blowing exhaust gas is 10 to 40 kohms. If the resistance is not as specified, replace the smog ventilation sensor. NOx Apply battery voltage between terminals 3 (IG) and 6 (E). Allow exhaust gas (NOx) to travel to the sensing portion of the smog ventilation sensor, and measure the resistance between terminals 1 (SG) and 4 (DGS1). OK: When the sensor is exposed to the exhaust gas, the resistance increases. HINT: The resistance before blowing exhaust gas is 10 to 40 kohms. If the resistance is not as specified, replace the smog ventilation sensor.

1. INSTALL SMOG VENTILATION SENSOR Install the sensor with the bolt. Torque: 9.8 N*m (100 kgf*cm, 7 ft.*lbf) Connect the connector.
2. INSTALL COOL AIR INTAKE DUCT SEAL Install the duct seal with the 2 clips.
3. INSTALL AIR CLEANER INLET COVER Install the cover with the 2 clips.
4. INSTALL ENGINE ROOM SIDE COVER LH Install the cover with the 4 clips.
5. INSTALL ENGINE ROOM SIDE COVER RH Install the cover with the 4 clips.

Scheme 353

Scheme 354

Scheme 355

Scheme 356

1. REMOVE ROOF CONSOLE BOX ASSEMBLY Detach the 4 claws and remove the spot light lens. Remove the 2 screws. Detach the 6 clips and 2 claws. Disconnect the 2 connectors and remove the roof console box.
2. REMOVE AIR CONDITIONING INFRARED RAYS SENSOR Remove the tape. Remove the 2 screws. Detach the clamp and remove the sensor.

Scheme 357

1. INSTALL AIR CONDITIONING INFRARED RAYS SENSOR Attach the clamp to install the sensor. Install the 2 screws. Apply new tape.
2. INSTALL ROOF CONSOLE BOX ASSEMBLY Connect the 2 connectors, and then attach the 6 clips and 2 claws to install the roof console box. Install the 2 screws. Attach the 4 claws to install the spot light lens.
3. PERFORM AIR CONDITIONING INFRARED RAYS SENSOR OPERATION Operate the air conditioning infrared rays sensor to recognize it in the ECU. Turn the engine switch on (IG) so that the air conditioning amplifier recognizes the infrared rays sensor. NOTE: After removing and installing the infrared rays sensor, if the infrared sensor is not operated once, the ECU cannot detect the presence of an infrared rays sensor.

Scheme 358

Scheme 359

Scheme 360

1. REMOVE INSTRUMENT PANEL SAFETY PAD Remove the instrument panel safety pad (see «REMOVAL»(ref-349746-S04541701892009120800000) ).
2. REMOVE SIDE NO. 2 DEFROSTER NOZZLE DUCT (See «DISASSEMBLY»(ref-349746-S05234743332009120800000) )
3. REMOVE DEFROSTER NOZZLE ASSEMBLY (See «DISASSEMBLY»(ref-349746-S05234743332009120800000) )
4. REMOVE SIDE NO. 1 DEFROSTER NOZZLE DUCT (See «DISASSEMBLY»(ref-349746-S05234743332009120800000) )
5. REMOVE NO. 1 HEATER TO REGISTER DUCT (See «DISASSEMBLY»(ref-349746-S05234743332009120800000) )
6. REMOVE NO. 3 HEATER TO REGISTER DUCT (See «DISASSEMBLY»(ref-349746-S05234743332009120800000) )
7. REMOVE DUCT TEMPERATURE SENSOR Detach the 4 claws and remove the 2 sensors.

Scheme 361

1. INSPECT DUCT TEMPERATURE SENSOR Remove the air duct sensor. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE CHART Tester Connection Condition Specified Condition 1 - 2 at 10°C (50°F) 9.4 to 10.5 kohms 1 - 2 at 15°C (59°F) 7.5 to 8.3 kohms 1 - 2 at 20°C (68°F) 6.0 to 6.5 kohms 1 - 2 at 25°C (77°F) 4.5 to 5.2 kohms 1 - 2 at 30°C (86°F) 3.8 to 4.2 kohms 1 - 2 at 35°C (95°F) 3.1 to 3.4 kohms 1 - 2 at 40°C (104°F) 2.5 to 2.8 kohms 1 - 2 at 45°C (113°F) 2.0 to 2.3 kohms 1 - 2 at 50°C (122°F) 1.6 to 2.0 kohms 1 - 2 at 55°C (131°F) 1.3 to 1.6 kohms 1 - 2 at 60°C (140°F) 1.1 to 1.4 kohms NOTE: Touching the sensor even slightly may change the resistance value. Hold the connector of the sensor. When measuring the resistance, the sensor temperature must be the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (see the graph below). If the resistance value is not as specified, replace the sensor.

1. INSTALL DUCT TEMPERATURE SENSOR Attach the 4 claws to install the 2 sensors.
2. INSTALL NO. 3 HEATER TO REGISTER DUCT (See «REASSEMBLY»(ref-349746-S33213030562009120800000) )
3. INSTALL NO. 1 HEATER TO REGISTER DUCT (See «REASSEMBLY»(ref-349746-S33213030562009120800000) )
4. INSTALL SIDE NO. 1 DEFROSTER NOZZLE DUCT (See «REASSEMBLY»(ref-349746-S33213030562009120800000) )
5. INSTALL DEFROSTER NOZZLE ASSEMBLY (See «REASSEMBLY»(ref-349746-S33213030562009120800000) )
6. INSTALL SIDE NO. 2 DEFROSTER NOZZLE DUCT (See «REASSEMBLY»(ref-349746-S33213030562009120800000) )
7. INSTALL INSTRUMENT PANEL SAFETY PAD Install the instrument panel safety pad (see «INSTALLATION»(ref-349746-S09854143102009120800000) ).

Scheme 362

Scheme 363

Scheme 364

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE PTC HEATER RELAY (PTC HTR 1, PTC HTR 2, PTC HTR 3) Remove the 3 PTC heater relays from the No. 5 relay box.
3. INSPECT PTC HEATER RELAY (PTC HTR 2) Measure the resistance of the relay. Standard resistance RESISTANCE REFERENCE CHART Tester Connection Condition Specified Condition 3 - 5 When battery voltage is not applied between terminals 10 kohms or higher When battery voltage is applied to terminal 1 and 2 Below 1 ohms If the result is not as specified, replace the relay.
4. INSPECT PTC HEATER RELAY (PTC HTR 1, PTC HTR 3) Measure the resistance of the magnet clutch relay. Standard resistance RESISTANCE REFERENCE CHART Tester Connection Condition Specified Condition 3 - 5 When battery voltage is not applied between terminals 10 kohms or higher When battery voltage is applied to terminal 1 and 2 Below 1 ohms If the result is not as specified, replace the relay.
5. INSTALL PTC HEATER RELAY
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 365

Scheme 366

Scheme 367

Scheme 368

Scheme 369

Scheme 370

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE INSTRUMENT PANEL FINISH PANEL END LH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
4. REMOVE INSTRUMENT PANEL FINISH PANEL END RH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
5. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
6. REMOVE NO. 3 BOX PANEL (See «REMOVAL»(ref-349746-S04541701892009120800000) )
7. REMOVE REAR CONSOLE PANEL UPPER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
8. REMOVE CONSOLE PANEL SUB-ASSEMBLY UPPER (See «REMOVAL»(ref-349746-S04541701892009120800000) )
9. REMOVE RADIO RECEIVER ASSEMBLY (See «REMOVAL»(ref-349754-S18155731442009120800000) )
10. REMOVE INTEGRATION CONTROL AND PANEL ASSEMBLY WITH BRACKET Remove the 2 bolts. Pull the panel to detach the 6 clips on the backside of the panel. Disconnect the connectors and remove the panel.
11. REMOVE NO. 2 RADIO BRACKET Remove the 2 bolts and bracket.
12. REMOVE NO. 1 RADIO BRACKET Remove the 2 bolts and bracket.

1. INSTALL AIR CONDITIONING AMPLIFIER ASSEMBLY Install the amplifier with the screw. Connect the 3 connectors.
2. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
3. INSTALL FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY (See «INSTALLATION»(ref-349738-S07188766952009120800000) )
4. INSTALL INSTRUMENT PANEL LOWER (See «INSTALLATION»(ref-349738-S07188766952009120800000) )
5. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
6. INSTALL NO. 2 INSTRUMENT CLUSTER MOLDING (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
7. INSTALL INSTRUMENT SIDE PANEL RH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
8. INSTALL INSTRUMENT PANEL FINISH PANEL END RH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
9. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
10. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
11. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
12. CHECK SRS WARNING LIGHT Check the SRS warning light (see «DIAGNOSIS SYSTEM»(ref-349738-S23481667942009120800000) ).
