Yawrate Sensor Lexus LS III facelift

Anti-Lock/traction Control 4 illustrations

Scheme 289

Scheme 289: REPLACEMENT
Scheme 289: REPLACEMENT

Scheme 290

Scheme 290
Scheme 290

Scheme 291

Scheme 291
Scheme 291

Scheme 292

Scheme 292
Scheme 292
  1. REMOVE CONSOLE UPPER REAR PANEL SUB-ASSY (SEE «REPLACEMENT»(ref-215685-S19902335712006011600000) )
  2. REMOVE CONSOLE BOX CARPET
  3. REMOVE REAR CONSOLE ARMREST ASSY (SEE «REPLACEMENT»(ref-215685-S19902335712006011600000) )
  4. REMOVE YAWRATE SENSOR Disconnect the yawrate sensor connector. Remove the 2 nuts and yawrate sensor
  5. INSTALL YAWRATE SENSOR Install the yawrate sensor with 2 nuts. Torque: 12.5 N.m (127.5 kgf.cm, 9 ft.lbf) Connect the yawrate sensor connector.
  6. INSTALL REAR CONSOLE ARMREST ASSY (SEE «REPLACEMENT»(ref-215685-S19902335712006011600000) )
  7. INSTALL CONSOLE BOX CARPET
  8. INSTALL CONSOLE UPPER REAR PANEL SUB-ASSY (SEE «REPLACEMENT»(ref-215685-S19902335712006011600000) )
  9. PERFORM YAWRATE SENSOR ZERO POINT CALIBRATION (SEE «CALIBRATION»(ref-209351-S01242850182005120900000) )
