Front Skid Control Sensor Lexus LS III facelift

Anti-Lock/traction Control 6 illustrations ~373 words

Scheme 283

Scheme 283: COMPONENTS
Scheme 283: COMPONENTS

REPLACEMENT

HINT

  1. Replace the RH side by using the same procedures as for the LH side.
  2. The procedures listed below are for the LH side.

Scheme 284

Scheme 284
Scheme 284

Scheme 285

Scheme 285
Scheme 285

Scheme 286

Scheme 286
Scheme 286

Scheme 287

Scheme 287
Scheme 287

Scheme 288

Scheme 288
Scheme 288
  1. REMOVE FRONT WHEEL
  2. DISCONNECT SKID CONTROL SENSOR WIRE Disconnect the skid control sensor connector.
  3. SEPARATE FRONT DISC BRAKE CALIPER ASSY LH (SEE «FRONT BRAKE CALIPER»(ref-162352-S35455565472004052600000) )
  4. REMOVE FRONT DISC (SEE «FRONT BRAKE DISC»(ref-162352-S34822341232004052600000) )
  5. REMOVE FRONT AXLE HUB SUB-ASSY LH (see «YAWRATE SENSOR»(/lexus/ls/iii-facelift-2003-2006/remont/anti-locktraction-control/#yawrate-sensor) )
  6. REMOVE SKID CONTROL SENSOR FRONT Mount the front axle hub sub-assy LH on a soft jaw vise. NOTE: Replace the hub & bearing assy if it is dropped or receives a strong shock. Using a pin punch and hammer, drive out the 2 pins and remove the 2 attachments from SST. Using SST and 2 bolts (Diameter: 12 mm, pitch: 1.5 mm), remove the skid control sensor from the hub & bearing assy. SST 09520-00031 (09520-00040), 09521-00020, 09950-00020 NOTE: If the sensor rotor is damaged, replace the axle hub sub-assy. Do not scratch the contacting surface of the hub & bearing assy and the skid control sensor.
  7. INSTALL SKID CONTROL SENSOR FRONT Clean the contacting surface of the front axle hub and a new skid control sensor. NOTE: Make sure the sensor rotor is clean. Place the skid control sensor on the front axle hub so that the connector makes the lowest position under the on vehicle condition. Using SST and a press, install the skid control sensor onto the hub & bearing assy. SST 09214-76011 NOTE: Do not tap the skid control sensor directly with a hammer. Check that the skid control sensor detection part is clean. Press in the skid control sensor straight and slowly.
  8. INSTALL FRONT AXLE HUB SUB-ASSY LH (see «YAWRATE SENSOR»(/lexus/ls/iii-facelift-2003-2006/remont/anti-locktraction-control/#yawrate-sensor) )
  9. INSTALL FRONT DISC (SEE «FRONT BRAKE DISC»(ref-162352-S34822341232004052600000) )
  10. INSTALL FRONT DISC BRAKE CALIPER ASSY LH (SEE «FRONT BRAKE CALIPER»(ref-162352-S35455565472004052600000) )
  11. CONNECT SKID CONTROL SENSOR WIRE Connect the skid control sensor connector.
  12. INSTALL FRONT WHEEL Torque: 103 N.m (1,050 kgf.cm, 76 ft.lbf)
  13. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT (SEE «FRONT WHEEL ALIGNMENT»(/lexus/ls/iii-facelift-2003-2006/remont/wheel-alignment/#front-wheel-alignment) )
  14. CHECK ABS SPEED SENSOR SIGNAL (SEE «TEST MODE PROCEDURE»(ref-209351-S31697443912005120900000) )
