PRECAUTION

1. PRECAUTION OF WASHER NOZZLE ADJUSTMENT Do not clean or adjust the washer nozzle with a safety pin, etc. because the washer nozzle tip is made of resin and could be damaged. adjustment is not necessary because the washer nozzle is a spray type. In case the washer nozzle is clogged with wax, etc., remove it and clean the nozzle hole with a soft resin brush, etc.

Scheme 122

Scheme 123

Scheme 124

1. INSPECT WINDSHIELD WASHER MOTOR AND PUMP ASSY Operation Check Fill the washer jar with washer fluid. Connect the positive battery (+) lead to terminal 2 of the windshield washer motor and pump assy, and the negative battery (-) lead to terminal 1. Check that washer fluid flows from the washer jar.
2. INSPECT HEADLAMP CLEANER MOTOR AND PUMP ASSY Operation Check Fill the washer jar with washer fluid. Connect the positive battery (+) lead to terminal 1 of the headlamp cleaner motor and pump assy, and the negative battery (-) lead to terminal 2. Check that washer fluid flows from the washer jar.
3. INSPECT RAIN SENSOR Measure the voltage according the value(s) in the table below. Standard: VOLTAGE SPECIFICATION Tester connection Condition Specified voltage 1 - 3 Ignition switch ON 10 to 14 V 2 - 3 Ignition switch ON Signal waveform

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

1. WINDSHIELD WIPER MOTOR ASSY LO Operation Check Connect the positive battery (+) lead to terminal 3 (+1) of the connector, and the negative battery (-) lead to terminal 1 (E), and check that the motor operates at low speed (LO). HI Operation Check Connect the positive battery (+) lead to terminal 2 (+2) of the connector, and the negative battery (-) lead to terminal 1 (E), and check that the motor operates at high speed (HI). Automatic Stop Operation Check Put matchmarks on the windshield wiper motor assy. Connect the positive battery (+) lead to terminal 3 (+1) of the connector, and the negative battery (-) lead to terminal 1 (E). With the motor operating at low speed (LO), disconnect terminal 3 (+1) to stop wiper motor operation at any position other than the matchmarks. Using SST, connect terminals 3 (+1) and 5 (S), and the positive battery (+) lead to terminal 6 (B) to restart motor operation at low speed. SST 09843-18040 Align the matchmarks with the windshield wiper motor assy.
2. TRACTION CONTROL SWITCH Inspect the headlamp cleaner switch on the traction control switch. Measure the resistance according to the value(s) in the table below. Standard: CONDITION SPECIFICATION Tester condition Condition Specified condition 10 - 11 OFF 10 kohm or higher 10 - 11 ON Below 1 ohm Inspect illumination operation. Connect the positive (+) lead from the battery to terminal 20 and the negative (-) lead to terminal 5, then check that the illumination comes on.
3. HEADLAMP CLEANER CONTROL RELAY Inspect headlamp cleaner control relay operation. Check that no continuity exists between terminals 2 and 5. Connect the positive (+) lead of the battery to terminal 1, and the negative (-) lead of the battery to terminal 5. Connect the negative (-) lead of the battery to terminals 3 and 4, and check that continuity exists between terminals 2 and 5 for 0.8 to 0.9 seconds, then no continuity exists. Disconnect the positive (+) lead of the battery from terminal 1, and then reconnect. Connect the negative (-) lead of the battery to terminals 3 and 6, and check that continuity exists between terminals 2 and 5 for 0.8 to 0.9 seconds. No continuity should then exist.

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

1. REMOVE FR WIPER ARM LH Remove the bolt and nut, then remove the front wiper arm LH.
2. REMOVE FR WIPER ARM RH Remove the nut and the front wiper arm RH.
3. REMOVE FRONT FENDER TO COWL SIDE SEAL RH Disengage the clamp. Remove the front fender to cowl side seal RH.
4. REMOVE FRONT FENDER TO COWL SIDE SEAL LH
5. REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSY Using a clip remover, disengage the 4 clips. Remove the 2 clips, and disengage the 9 claws. Remove the cowl top ventilator louver sub-assy.
6. REMOVE WINDSHIELD WIPER MOTOR & LINK ASSY Disconnect the connector. Remove the 4 bolts and the windshield wiper motor & link assy.
7. REMOVE WINDSHIELD WIPER MOTOR ASSY Remove the wiper motor cover and rubber cover. Using a screwdriver, disengage the meshing of the rod at the crank arm pivot of the windshield wiper motor assy. Remove the nut and washer. Put matchmarks on the crank arm assy and windshield wiper motor assy (when reinstalling the windshield wiper motor assy). Remove the 3 bolts and windshield wiper motor assy from the windshield wiper link assy.
8. INSTALL WINDSHIELD WIPER MOTOR ASSY Apply MP grease to the crank arm pivot of the windshield wiper motor assy. Install the windshield wiper motor assy with the 3 bolts. Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf) Align the matchmarks on the crank arm assy to windshield wiper motor assy (when reinstalling the windshield wiper motor assy). Install the crank arm assy with the washer and nut. Torque: 17 N.m (175 kgf.cm, 13 ft.lbf) Engage the meshing of the rod to the crank arm pivot of the windshield wiper motor assy.
9. INSTALL WINDSHIELD WIPER MOTOR & LINK ASSY Install the windshield wiper motor & link assy with the 4 bolts. Torque: 5.5 N.m (56 kgf.cm, 49 in.lbf) Connect the connector.
10. INSTALL COWL TOP VENTILATOR LOUVER SUB-ASSY Engage the 9 claws and install the cowl top ventilator louver sub-assy. Install the 2 clips. Engage the 4 clips.
11. INSTALL FRONT FENDER TO COWL SIDE SEAL RH Engage the clamp and install the front fender to cowl side seal RH.
12. INSTALL FRONT FENDER TO COWL SIDE SEAL LH
13. INSTALL FR WIPER ARM LH Scrape off the wiper arm serration with a round file or equivalent. Clean the wiper pivot serration with a wire brush. Install the front wiper arm LH with the bolt and nut. Torque: Bolt: 5.5 N.m (56 kgf.cm, 49 in.lbf) Nut: 20 N.m (205 kgf.cm, 15 ft.lbf) HINT: Hold down the arm hinge by hand in order to fasten the bolt and nut.
14. INSTALL FR WIPER ARM RH Scrape off the wiper arm serration with a round file or equivalent. Clean the wiper pivot serration with a wire brush. Install the front wiper arm RH with the nut. Torque: 20 N.m (205 kgf.cm, 15 ft.lbf) HINT: Hold down the arm hinge by hand in order to fasten the nut. Operate the wipers while spraying water or washer fluid on the windshield. Ensure that the wipers function properly and there is no interference with the body.
15. INSPECT AND ADJUST WIPER ARM POINT CONFIRMATION Inspect each of the wiper arm positions after operating the wipers once and turning the wiper switch OFF. 30 to 40 mm (1.18 to 1.57 in.) 65 to 85 mm (2.56 to 3.35 in.) Operate the wipers while spraying water or washer fluid on the windshield. Ensure that the wipers function properly and there is no interference with the body.
