Inner Rear View Mirror: Removal & Installation Lexus LS III рестайлинг

REPLACEMENT

HINT

1. The installation procedures are the removal procedures in reverse order.
2. Use the same procedures for the RH side and LH side.
3. The procedures listed below are for the LH side.
4. A bolt without a torque specification is shown in the standard bolt chart (see «SUSPENSION CONTROL SYSTEM»(ref-209417-S38959968142005121000000) ).

Scheme 155

Scheme 156

Scheme 157

1. REMOVE MAP LAMP ASSY w/o LEXUS link system: Open the upper console. Using a screwdriver, pry out the lens cover. HINT: Tape the screwdriver tip before use. Using a screwdriver, pry out the 2 caps. HINT: Tape the screwdriver tip before use. Remove the 4 screws. Remove the map lamp and disconnect the connector.
2. REMOVE INNER REAR VIEW MIRROR ASSY Remove the 2 screws and mirror. Disconnect the connector.

Scheme 158
