Front Light (Body No. 5) Control System: Other Lexus LS III

Body, Cab Control Systems 4 illustrations

CUSTOMER PROBLEM ANALYSIS CHECK

FRONT LIGHT (BODY NO.5) CONTROL SYSTEM Check Sheet

Front Light (Body No.5) Control System Troubleshooting Flow Chart. Scheme 110

Scheme 110: Front Light (Body No.5) Control System Troubleshooting Flow Chart

Front Light (Body No.5) Control System Customer Problem Analysis Check Sheet. Scheme 111

Scheme 111: Front Light (Body No.5) Control System Customer Problem Analysis Check Sheet

Locating Front Light (Body No.5) Control System Components. Scheme 112

Scheme 112: Locating Front Light (Body No.5) Control System Components

Identifying ECU Terminals. Scheme 113

Scheme 113: Identifying ECU Terminals
Symbols (Terminals No.)Wiring ColorConditionSTD Voltage (V)
1 <-> 25 (FOGR <-> E)R-W <-> W-BFront fog light switch ON10-14 V
2 <-> 25 (FOGL <-> E)R-Y <-> W-BFront fog light switch ON10-14 V
3 <-> 25 (FFOG <-> E)R <-> W-BConstant10-14 V
4 <-> 25 (W+ <-> E)B-W <-> W-BWasher switch ON10-14 V
6 <-> 25 (FWAS <-> E)R-L <-> W-BConstant10-14 V
7 <-> 25 (CRAR <-> E)G <-> W-BLight control switch TAIL10-14 V
8 <-> 25 (CRAL <-> E)G-O <-> W-BLight control switch TAIL10-14 V
9 <-> 25 (FTAL <-> E)G-Y <->W-BConstant10-14 V
12 <-> 25 (FHHI <-> E)R-L <->W-BConstant10-14 V
13 <-> 25 (HORH <-> E)B <-> W-BHorn switch ON (Horn HI sounding)10-14 V
14 <-> 25 (HORL <-> E)G-W <-> W-BHorn switch ON (Horn LO sounding)10-14 V
15 <-> 25 (FHOR <-> E)G-B <->W-BConstant10-14 V
16 <-> 25 (SIDR <-> E)V-W <->W-BLight control switch TAIL10-14 V
17 <-> 25 (SIDL <-> E)V-R <->W-BLight control switch TAIL10-14 V
18 <-> 25 (HLHR <-> E)L-O <->W-BLight control switch HEAD10-14 V
24 <-> 25 (HLHL <-> E)R-B <->W-BLight control switch HEAD10-14 V
25 <-> Body ground (E <-> Body ground)W-B <-> Body groundConstantBelow 1 V
26 <-> 25 (WLVL <-> E)V <-> W-BWasher fluid level warning switch ON10-14 V
29 <-> 25 (FMB3 <-> E)R-B <-> W-BConstant10-14 V
30 <-> 25 (FMIG <-> E)R-L <-> W-BIgnition switch ON10-14 V
31 (MPX2)V-GMultiplex communication circuit
32 (MPX1)V-GMultiplex communication circuit

ECU TERMINALS SPECIFICATIONS
