SERVICE VALVE LOCATIONS
| Vehicle | High | Low | ||
|---|---|---|---|---|
| Acura | ||||
| Integra | (1) | (2) | ||
| MDX | (8) | (9) | ||
| 3.2CL | (1) | (4) | ||
| 3.2TL | (1) | (4) | ||
| 3.5RL | (6) | (4) | ||
| Audi | ||||
| Except TT | (7) | (7) | ||
| TT | (8) | (9) | ||
| Honda | ||||
| Accord | (1) | (4) | ||
| Civic | (10) | (10) | ||
| CR-V | (11) | (9) | ||
| Insight | (8) | (9) | ||
| Odyssey | (10) | (10) | ||
| Passport | (13) | (14) | ||
| Prelude | (1) | (2) | ||
| S2000 | (1) | (9) | ||
| Hyundai | ||||
| Accent | (8) | (5) | ||
| Elantra | (8) | (9) | ||
| Santa Fe | (8) | (9) | ||
| Sonata | (8) | (9) | ||
| Tiburon | (8) | (9) | ||
| XG300 | (8) | (9) | ||
| Infiniti | (15) | (4) | ||
| Isuzu | ||||
| Amigo & Rodeo | (13) | (14) | ||
| Hombre | (3) | (4) | ||
| Trooper | (3) | (4) | ||
| Vehi-CROSS | (12) | (14) | ||
| Jaguar | (6) | (4) | ||
| Kia | (3) | (4) | ||
| Land Rover | ||||
| Discovery | (3) | (4) | ||
| Range Rover | (8) | (4) | ||
| Lexus | ||||
| ES 300, GS 300, GS 400, GS 430, IS 300, SC 300 & SC 400 | (17) | (4) | ||
| LS 400 & LS 430 | (6) | (4) | ||
| LX 470 | (8) | (9) | ||
| RX 300 | (17) | (9) | ||
| Mazda | ||||
| B2300, B2500, B3000 & B4000 | (15) | (6) | ||
| Millenia | (15) | (4) | ||
| MPV | (15) | (9) | ||
| MX-5 Miata | (8) | (4) | ||
| Protege | (3) | (4) | ||
| Tribute | (15) | (18) | ||
| 626 | (16) | (4) | ||
| Mercedes-Benz | (17) | (6) | ||
| Mitsubishi | ||||
| Diamante | (8) | (9) | ||
| Eclipse | (8) | (9) | ||
| Galant | (8) | (9) | ||
| Mirage | (8) | (9) | ||
| Montero & Montero Sport | ||||
| 2000 Models | (11) | (6) | ||
| 2001 Models | (8) | (9) | ||
| Nissan | ||||
| Altima | (3) | (4) | ||
| Frontier & Xterra | (15) | (4) | ||
| Maxima | (15) | (4) | ||
| Pathfinder | (15) | (4) | ||
| Quest | (12) | (18) | ||
| Sentra | (8) | (9) | ||
| Saab | (6) | (2) | ||
| Subaru | (19) | (19) | ||
| Suzuki | ||||
| Esteem | (15) | (4) | ||
| Vitara & Grand Vitara | (6) | (2) | ||
| Swift | (3) | (4) | ||
| Toyota | ||||
| Avalon | (1) | (4) | ||
| Camry, Camry Solara & Celica | (17) | (4) | ||
| Corolla | (15) | (4) | ||
| ECHO | (8) | (9) | ||
| Highlander | (8) | (9) | ||
| Land Cruiser | (10) | (4) | ||
| MR2 | (8) | (9) | ||
| Prius | (8) | (9) | ||
| RAV4 | (8) | (14) | ||
| Sequoia | (17) | (14) | ||
| Sienna | (6) | (2) | ||
| Tacoma | (7) | (7) | ||
| Tundra | (17) | (14) | ||
| 4Runner | (17) | (7) | ||
| Volvo | (8) | (9) | ||
| (1) On high pressure line, near receiver-drier. (2) On low pressure line, near top of condenser. (3) On high pressure line, between accumulator/receiver-drier and evaporator. (4) On low pressure line, between evaporator and compressor. (5) On low pressure line, on or near compressor. (6) On top of accumulator/receiver-drier. (7) On thin evaporator inlet (high pressure) line or thick outlet (low pressure) line. (8) On high pressure hose/line. For Volvo (Scheme 27) (9) On low pressure hose/line. For Toyota MR2 (Scheme 26) (10) On top of condenser, on right side. (11) On high pressure outlet at compressor. For Honda CRV (Scheme 25)(12) On high pressure (thin) line, at rear of engine compartment. (13) On high pressure outlet at compressor. (14) On low pressure (thick) line, at rear of engine compartment. (15) On high pressure line, between compressor and condenser. (16) On high pressure hose/line between condenser and evaporator. (17) In front/back of condenser. (18) On low pressure line, between accumulator and compressor. (19) On high and low pressure lines, near compressor. | ||||
| (1) | On high pressure line, near receiver-drier. |
| (2) | On low pressure line, near top of condenser. |
| (3) | On high pressure line, between accumulator/receiver-drier and evaporator. |
| (4) | On low pressure line, between evaporator and compressor. |
| (5) | On low pressure line, on or near compressor. |
| (6) | On top of accumulator/receiver-drier. |
| (7) | On thin evaporator inlet (high pressure) line or thick outlet (low pressure) line. |
| (8) | On high pressure hose/line. For Volvo (Scheme 27) |
| (9) | On low pressure hose/line. For Toyota MR2 (Scheme 26) |
| (10) | On top of condenser, on right side. |
| (11) | On high pressure outlet at compressor. For Honda CRV (Scheme 25) |
| (12) | On high pressure (thin) line, at rear of engine compartment. |
| (13) | On high pressure outlet at compressor. |
| (14) | On low pressure (thick) line, at rear of engine compartment. |
| (15) | On high pressure line, between compressor and condenser. |
| (16) | On high pressure hose/line between condenser and evaporator. |
| (17) | In front/back of condenser. |
| (18) | On low pressure line, between accumulator and compressor. |
| (19) | On high and low pressure lines, near compressor. |
