WASHER MOTOR TEST
Note. DO NOT operate washer motor for more than 20 seconds.
Apply battery voltage and ground between washer motor terminals No. 1 (+) and 2 (-). (Scheme 1) Replace washer motor if it does not operate.
Scheme 1
Continuity Test
Disconnect combination switch connectors. Check for continuity between specified wiper switch terminals. See WIPER/WASHER SWITCH CONTINUITY table. (Scheme 2) If continuity is not as specified, replace combination switch.
| Switch Position | Continuity Between Terminals No. | |
|---|---|---|
| Wiper Off | ||
| Mist Off (1) | 7 & 16 | |
| Mist On (2) | 7 & 17 | |
| Wiper Intermittent | ||
| Mist Off (1) | 2 & 4; 7 & 16 | |
| Mist On (2) | 2 & 4; 7 & 17 | |
| Wiper Low | 7 & 17 | |
| Wiper High | 1 & 2; 8 & 17 | |
| Washer | ||
| Off | (3) | |
| On | 2 & 11 | |
| (1) Lever in normal position. (2) Pull lever toward you. (3) No continuity between terminals No. 2 and 11. | ||
| (1) | Lever in normal position. |
| (2) | Pull lever toward you. |
| (3) | No continuity between terminals No. 2 and 11. |
WIPER/WASHER SWITCH CONTINUITY
