REMOVAL & INSTALLATION
| CAUTION | To prevent damage, pry out decorative trim pieces with a plastic tool or a screwdriver with a taped tip. |
Remove trim cover and pad from below left side of instrument panel. Remove 3 screws, then lower the parking brake release lever out of the way. Remove 2 screws under power mirror switch. Pry switch out of instrument panel. Disconnect electrical connectors. To install, reverse removal procedure.
- Disconnect negative battery cable. Pry cover away from upper speaker. Remove screws and inner door handle bezel. Pry up the front edge of switch base plate, then pull it forward to remove it. Remove courtesy light.
- Remove the following 7 or 8 screws that secure door trim panel: Three or four screws at bottom of panel One screw under a cap, at rear edge of panel One screw under a cap, at top edge of door pocket One screw accessible through vent hole (upper right corner) One screw accessible through switch base plate hole.
- Pry door trim panel away from door to release retaining clips. Pull door trim panel upward to disengage it from door. Remove screw and door window frame trim. Remove upper speaker. Remove screws and mirror assembly. To install, reverse removal procedure.
Disconnect negative battery cable. Slide a shop towel between mirror glass and housing. Use shop towel to pull out bottom of mirror (2 clips at bottom of mirror glass secure it to motor assembly). Pull bottom of mirror upward until tabs at top of mirror disengage from motor assembly. To install, reverse removal procedure.
Remove center visor panel. Remove mirror screws. Disconnect electrical connector. Remove mirror. To install, reverse removal procedure.
