A/C SYSTEM SPECIFICATIONS
| WARNING | To avoid injury from accidental air bag deployment, read and follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section. |
Note. When battery is disconnected, radio will go into anti-theft protection mode. Obtain radio anti-theft protection code from owner prior to servicing vehicle.
| Application | Specifications |
|---|
| Compressor Type | Nippondenso 10PA20 10-Cyl. |
| Compressor Belt Deflection | (1) |
| Compressor Oil Capacity (2) | 4.8 ozs. |
| Refrigerant (R-134a) Capacity | 27.9-31.5 ozs. |
| System Operating Pressures (3) |
| High Side | 199-228 psi (14-16 kg/cm 2 ) |
| Low Side | 21-36 psi (1.5-2.5 kg/cm 2 ) |
| (1) Belt tension is maintained automatically. (2) Use ND-OIL 8 Refrigerant Oil (Part No. 38885-09109). (3) Specification is with ambient temperature at 86-95°F (30-35°C) and engine speed at 1500 RPM. |
| (1) | Belt tension is maintained automatically. |
| (2) | Use ND-OIL 8 Refrigerant Oil (Part No. 38885-09109). |
| (3) | Specification is with ambient temperature at 86-95°F (30-35°C) and engine speed at 1500 RPM. |
A/C SYSTEM SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor |
| Bolt | 36 (49) |
| Nut | 21 (29) |
| A/C Compressor Bracket Bolt | 36 (49) |
| INCH Lbs. (N.m) |
| Blower Unit Fittings | 89 (10) |
| Compressor Discharge Tube | 89 (10) |
| Compressor Suction Tube | 89 (10) |
| Condenser Fittings | 89 (10) |
| Pressure Switch | 89 (10) |
| Receiver-Drier Fittings | 48 (5.4) |
| Steering Column Nut | 19 (26) |
| Steering Column Pinch Bolts | 26 (35) |
| Steering Wheel Nut | 26 (35) |
Automatic A/C-Heater System Wiring Diagram (1 Of 2). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (2 Of 2)
