Engine Control System (Service Information): Other Lexus IS III

Testing & Diagnostics 31 illustrations ~7895 words

PROCEDURE

  1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch on. Inspect the camshaft timing oil control valve assembly (for intake camshaft). Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1). Powertrain > Engine > Active Test Tester Display Control the VVT Linear (Bank 1) Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. Standard Condition Control Range Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls If the operation is not as specified, check the camshaft timing oil control valve assembly, wire harness and ECM. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 2). Powertrain > Engine > Active Test Tester Display Control the VVT Linear (Bank 2) Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. Standard Condition Control Range Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls If the operation is not as specified, check the camshaft timing oil control valve assembly, wire harness and ECM. Inspect the camshaft timing oil control valve assembly (for exhaust camshaft). Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1). Powertrain > Engine > Active Test Tester Display Control the VVT Exhaust Linear (Bank 1) Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. Standard Condition Control Range Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls If the operation is not as specified, check the camshaft timing oil control valve assembly, wire harness and ECM. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 2). Powertrain > Engine > Active Test Tester Display Control the VVT Exhaust Linear (Bank 2) Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. Standard Condition Control Range Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls If the operation is not as specified, check the camshaft timing oil control valve assembly, wire harness and ECM.
  1. REMOVE INTAKE AIR SURGE TANK ASSEMBLY Refer to «REMOVAL [04/2013 - ]»(ref-665769-S18378390412014102400000)
  2. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side of Bank 1) Disconnect the camshaft timing oil control valve assembly connector. Remove the bolt and camshaft timing oil control valve assembly from the cylinder head cover sub-assembly. NOTE: Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly). Remove the O-ring from the camshaft timing oil control valve assembly. *1 O-ring
  3. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side of Bank 1) Remove the bolt and V-bank cover bracket sub-assembly from the cylinder head cover sub-assembly. Disconnect the camshaft timing oil control valve assembly connector. Remove the bolt and camshaft timing oil control valve assembly from the cylinder head cover sub-assembly. NOTE: Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly). Remove the O-ring from the camshaft timing oil control valve assembly. *1 O-ring
  4. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side of Bank 2) Disconnect the 2 wire harness clamps from the ignition coil cover bracket. Remove the 2 bolts and ignition coil cover bracket from the cylinder head cover sub-assembly LH. Disconnect the camshaft timing oil control valve assembly connector. Remove the bolt and camshaft timing oil control valve assembly from the cylinder head cover sub-assembly LH. NOTE: Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly LH). Remove the O-ring from the camshaft timing oil control valve assembly. *1 O-ring
  5. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side of Bank 2) Disconnect the camshaft timing oil control valve assembly connector. Remove the bolt and camshaft timing oil control valve assembly from the cylinder head cover sub-assembly LH. NOTE: Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly LH). Remove the O-ring from the camshaft timing oil control valve assembly. *1 O-ring

Scheme 194

Scheme 194: PROCEDURE
Scheme 194: PROCEDURE
  1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms If the result is not as specified, replace the camshaft timing oil control valve assembly. Check the operation. Connect a battery positive (+) lead to terminal 1 and negative (-) lead to terminal 2, and check the movement of the spool valve. OK Condition Specified Condition Battery voltage is applied Valve moves in left arrow direction shown in illustration Battery voltage is cut off Valve moves in right arrow direction shown in illustration NOTE: Accumulation of foreign matter can cause minor pressure leaks. Minor pressure leaks in the intake side oil control valve will cause the intake camshaft to advance. Minor pressure leaks in the exhaust side oil control valve will cause the exhaust camshaft to retard. The inappropriate camshaft timing that results from these leaks will cause a DTC to be stored. *a Component without harness connected (Camshaft Timing Oil Control Valve Assembly) *b When Applied *c When Cut Off *d Spool Valve If the result is not as specified, replace the camshaft timing oil control valve assembly.

Scheme 195

Scheme 195: PROCEDURE
Scheme 195: PROCEDURE
  1. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side of Bank 2) Apply a light coat of engine oil to a new O-ring and install it to the camshaft timing oil control valve assembly. Install the camshaft timing oil control valve assembly to the cylinder head cover sub-assembly LH with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly LH). Make sure that the O-ring is not cracked or moved out of place when installing the camshaft timing oil control valve assembly. Connect the camshaft timing oil control valve assembly connector.
  2. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side of Bank 2) Apply a light coat of engine oil to a new O-ring and install it to the camshaft timing oil control valve assembly. Install the camshaft timing oil control valve assembly to the cylinder head cover sub-assembly LH with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly LH). Make sure that the O-ring is not cracked or moved out of place when installing the camshaft timing oil control valve assembly. Connect the camshaft timing oil control valve assembly connector. Install the ignition coil cover bracket to the cylinder head cover sub-assembly LH with the 2 bolts. Bolt A Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Bolt B Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Connect the 2 wire harness clamps to the ignition coil cover bracket.
  3. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side of Bank 1) Apply a light coat of engine oil to a new O-ring and install it to the camshaft timing oil control valve assembly. Install the camshaft timing oil control valve assembly to the cylinder head cover sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly). Make sure that the O-ring is not cracked or moved out of place when installing the camshaft timing oil control valve assembly. Connect the camshaft timing oil control valve assembly connector. Install the V-bank cover bracket sub-assembly to the cylinder head cover sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
  4. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side of Bank 1) Apply a light coat of engine oil to a new O-ring and install it to the camshaft timing oil control valve assembly. Install the camshaft timing oil control valve assembly to the cylinder head cover sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly). Make sure that the O-ring is not cracked or moved out of place when installing the camshaft timing oil control valve assembly. Connect the camshaft timing oil control valve assembly connector.
  5. INSTALL INTAKE AIR SURGE TANK ASSEMBLY Refer to «INSTALLATION [04/2013 - ]»(ref-665769-S35629936752014102400000)

Scheme 196

Scheme 196: ILLUSTRATION
Scheme 196: ILLUSTRATION

*A for 2WD *B for AWD *C w/ Intake Air Sound Creator *D w/o Intake Air Sound Creator *1 AIR CLEANER CAP WITH AIR CLEANER HOSE *2 CENTER NO. 4 ENGINE UNDER COVER *3 INTAKE AIR SOUND CREATOR *4 NO. 2 VENTILATION HOSE *5 THROTTLE BODY GASKET *6 THROTTLE BODY WITH MOTOR ASSEMBLY *7 V-BANK COVER SUB-ASSEMBLY *8 NO. 2 FUEL VAPOR FEED HOSE *9 NO. 1 WATER BY-PASS HOSE *10 NO. 2 WATER BY-PASS HOSE N*m (kgf*cm, ft.*lbf): Specified torque • Non-reusable part

  1. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY Check the idle speed. Start the engine and check that the MIL is not illuminated. After the engine is warmed up, check that the idle speed is within the specified range with the A/C switch off. Standard 650 to 750 rpm NOTE: Be sure to perform this step with all accessories off. Make sure that the shift lever is in P. Perform a road test and confirm that there are no abnormalities. Check the throttle position sensor. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Throttle Sensor Position. Powertrain > Engine > Data List Tester Display Throttle Sensor Position Depress the accelerator pedal. When the throttle valve is fully open, check that the Throttle Sensor Position value is within specification. Standard Throttle Valve Opening Percentage Tester Display Specified Condition Throttle Sensor Position 60% or higher NOTE: When checking the throttle valve opening percentage, the shift lever should be in N. Fully depress the accelerator pedal. If the percentage is less than 60%, replace the throttle body with motor assembly.
  1. REMOVE V-BANK COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 3»(ref-665703-S21356895402014102400000)
  2. REMOVE CENTER NO. 4 ENGINE UNDER COVER Refer to «PROCEDURE - Step 2»(ref-665705-S34609640792014102400000)
  3. DRAIN ENGINE COOLANT Refer to «PROCEDURE - Step 4»(ref-665707-S40400098752014102400000)
  4. REMOVE INTAKE AIR SOUND CREATOR HINT: Only perform this procedure when replacement of the intake air sound creator is necessary. Loosen the hose clamp. Remove the bolt and intake air sound creator from the air cleaner cap with air cleaner hose.
  5. DISCONNECT NO. 2 VENTILATION HOSE Slide the clip and disconnect the No. 2 ventilation hose from the cylinder head cover sub-assembly.
  6. REMOVE AIR CLEANER CAP WITH AIR CLEANER HOSE Disconnect the mass air flow meter sub-assembly connector. Disconnect the wire harness clamp from the air cleaner cap with air cleaner hose. Disconnect the No. 2 fuel vapor feed hose clamp from the air cleaner cap with air cleaner hose. Release the 4 clamps. Loosen the hose clamp and remove the air cleaner cap with air cleaner hose from the throttle body with motor assembly.
  7. REMOVE THROTTLE BODY WITH MOTOR ASSEMBLY Disconnect the throttle body with motor assembly connector. Remove the 4 bolts and throttle body with motor assembly from the intake air surge tank assembly. Slide the 2 clips and disconnect the No. 1 water by-pass hose and No. 2 water by-pass hose from the throttle body with motor assembly. *1 No. 1 Water By-pass Hose *2 No. 2 Water By-pass Hose
  8. REMOVE THROTTLE BODY GASKET Remove the throttle body gasket from the intake air surge tank assembly.
  1. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (M-) - 2 (M+) 20°C (68°F) 0.3 to 100 ohms *a Component without harness connected (Throttle Body with Motor Assembly) If the result is not as specified, replace the throttle body with motor assembly.

Scheme 197

Scheme 197: PROCEDURE
Scheme 197: PROCEDURE

Scheme 198

Scheme 198
Scheme 198
  1. INSTALL THROTTLE BODY GASKET Install a new throttle body gasket onto the intake air surge tank assembly with the protrusion of the throttle body gasket oriented as shown in the illustration. *a Protrusion Throttle Body with Motor Assembly Side Intake Air Surge Tank Assembly Side
  2. INSTALL THROTTLE BODY WITH MOTOR ASSEMBLY Connect the No. 1 water by-pass hose and No. 2 water by-pass hose to the throttle body with motor assembly and slide the 2 clips to secure them. Install the throttle body with motor assembly to the intake air surge tank assembly with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the throttle body with motor assembly connector.
  3. INSTALL AIR CLEANER CAP WITH AIR CLEANER HOSE Connect the air cleaner cap with air cleaner hose to the throttle body with motor assembly. Install the air cleaner cap with air cleaner hose with the 4 clamps. *a Protrusion Tighten the hose clamp. Torque: 4.0 N*m (41 kgf*cm, 35 in.*lbf) NOTE: Fit the protrusion on the air cleaner hose into the hole of the hose clamp on the throttle body with motor assembly side. Connect the No. 2 fuel vapor feed hose clamp to the air cleaner cap with air cleaner hose. Connect the wire harness clamp to the air cleaner cap with air cleaner hose. Connect the mass air flow meter sub-assembly connector.
  4. CONNECT NO. 2 VENTILATION HOSE Connect the No. 2 ventilation hose to the cylinder head cover sub-assembly and slide the clip to secure it. *a Top *b Front *c Paint Mark HINT: Make sure the direction of the clip is as shown in the illustration.
  5. INSTALL INTAKE AIR SOUND CREATOR HINT: Only perform this procedure when replacement of the intake air sound creator is necessary. Connect the intake air sound creator to the air cleaner cap with air cleaner hose. Install the bolt and tighten the hose clamp. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) *1 Air Cleaner Hose HINT: Make sure the direction of the hose clamp is as shown in the illustration.
  6. ADD ENGINE COOLANT Refer to «PROCEDURE - Step 5»(ref-665707-S40400098752014102400000)
  7. INSPECT FOR ENGINE COOLANT LEAK Refer to «PROCEDURE - Step 1»(ref-665770-S12066795872014102400000)
  8. INSTALL CENTER NO. 4 ENGINE UNDER COVER Refer to «PROCEDURE - Step 9»(ref-665705-S34609640792014102400000)
  9. INSTALL V-BANK COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 104»(ref-665703-S03876486602014102400000)
  10. PERFORM INITIALIZATION NOTE: Be sure to perform this procedure after removing and reinstalling the throttle body with motor assembly or any throttle body with motor assembly components. Perform the following procedure after replacing the throttle body with motor assembly or any throttle body with motor assembly components. The following procedure should also be performed if the throttle body with motor assembly is cleaned. Connect the Techstream to the DLC3 and clear the DTCs. Refer to «DTC CHECK/CLEAR [04/2013 - ]»(ref-665554-S38092923772014102400000) Turn the engine switch on (IG) without operating the accelerator pedal. NOTE: If the accelerator pedal is operated, perform the above steps again. Perform "Inspection After Repair". Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000) Start the engine and check that the MIL is not illuminated. After the engine is warmed up, check that the idle speed is within the specified range with the A/C switch off. Standard 650 to 750 rpm NOTE: Be sure to perform this step with all accessories off. Make sure that the shift lever is in N or P. Enter the following menus: Powertrain / Engine and ECT / Data List / Throttle Sensor Position. Powertrain > Engine > Data List Tester Display Throttle Sensor Position Fully depress the accelerator pedal and check that the value is 60% or higher. Perform a road test and confirm that there are no abnormalities.

Scheme 199

Scheme 199: ILLUSTRATION
Scheme 199: ILLUSTRATION

*1 ECM *2 NO. 1 ECM BRACKET *3 ENGINE ROOM ECU COVER *4 NO. 2 ECM BRACKET *5 WIRE HARNESS *6 CONNECTOR HOLDER N*m (kgf*cm, ft.*lbf): Specified torque

CAUTION / NOTICE / HINT

Note. Perform the Vehicle Identification Number (VIN) registration when replacing the ECM. Refer to REGISTRATION [04/2013 - ] After turning the engine switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notice before proceeding with work. Refer to PRECAUTION [04/2013 - ]

  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [04/2013 - ]»(ref-665529-S01115916402014102400000)
  2. REMOVE ENGINE ROOM ECU COVER NOTE: Remove all water on and around the engine room ECU cover. Perform the inspection indoors to avoid rain. Be sure to prevent water intrusion to the ECM (connectors and screw parts). Remove the 3 bolts and engine room ECU cover.
  3. DISCONNECT WIRE HARNESS Disconnect the 2 engine wire harness connectors from the connector holder. Disengage the claw and disconnect the connector from the connector holder. Using a screwdriver, disengage the claw. Disconnect the connector holder from the engine room ECU box. Disconnect the 6 ECM connectors.
  4. REMOVE ECM Remove the 2 nuts and ECM from the engine room ECU box. NOTE: If the ECM has been struck or dropped, replace it.
  5. REMOVE NO. 1 ECM BRACKET Remove the 2 screws and No. 1 ECM bracket from the ECM.
  6. REMOVE NO. 2 ECM BRACKET Remove the 2 screws and No. 2 ECM bracket from the ECM.
  1. INSTALL NO. 2 ECM BRACKET Install the No. 2 ECM bracket to the ECM with the 2 screws. Torque: 3.0 N*m (31 kgf*cm, 27 in.*lbf)
  2. INSTALL NO. 1 ECM BRACKET Install the No. 1 ECM bracket to the ECM with the 2 screws. Torque: 3.0 N*m (31 kgf*cm, 27 in.*lbf)
  3. INSTALL ECM Install the ECM to the engine room ECU box with the 2 nuts. Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf) NOTE: Install the ECM to the engine room ECU box with the name plate facing the outside of the vehicle. When connecting the connectors, make sure that dirt, water or other foreign matter does not become stuck between the connectors and other part. If the ECM has been struck or dropped, replace it.
  4. CONNECT WIRE HARNESS Connect the 6 ECM connectors. NOTE: Be sure to securely connect the ECM connector. Engage the claw to connect the connector holder to the engine room ECU box. Connect the connector to the connector holder. Connect the 2 engine wire harness connectors to the connector holder.
  5. INSTALL ENGINE ROOM ECU COVER Install the engine room ECU cover with the 3 bolts. Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf) NOTE: Make sure that the wire harness does not get caught between the parts.
  6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [04/2013 - ]»(ref-665529-S01115916402014102400000)
  7. PERFORM INITIALIZATION Refer to «PRECAUTION [04/2013 - ]»(ref-665554-S16770774442014102400000)

Scheme 200

Scheme 200: ILLUSTRATION
Scheme 200: ILLUSTRATION

*1 ACCELERATOR PEDAL ASSEMBLY *2 ACCELERATOR PEDAL PAD *3 ACCELERATOR PEDAL SENSOR ASSEMBLY - - N*m (kgf*cm, ft.*lbf): Specified torque

  1. INSPECT ACCELERATOR PEDAL SENSOR ASSEMBLY Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Accel Sensor Out No. 1 and Accel Sensor Out No. 2. Powertrain > Engine > Data List Tester Display Accel Sensor Out No. 1 Accel Sensor Out No. 2 Read the values displayed on the Techstream. Standard Voltage Accelerator Pedal Operation Accel Sensor Out No. 1 Accel Sensor Out No. 2 Fully released 0.5 to 1.1 V 1.2 to 2.0 V Fully depressed 2.6 to 4.5 V 3.4 to 4.75 V If the result is not as specified, check the accelerator pedal sensor assembly, wire harness and ECM.

Scheme 201

Scheme 201: PROCEDURE
Scheme 201: PROCEDURE
  1. REMOVE ACCELERATOR PEDAL SENSOR ASSEMBLY NOTE: Avoid physical shock to the accelerator pedal sensor assembly. Do not disassemble the accelerator pedal sensor assembly. This accelerator pedal sensor assembly does not require lubrication. Do not apply oil or other lubrication to the accelerator pedal sensor assembly. If applied, the accelerator pedal sensor assembly must be replaced. Disconnect the accelerator pedal sensor assembly connector. Remove the 2 nuts and accelerator pedal sensor assembly.
  2. REMOVE ACCELERATOR PEDAL PAD Disengage the 2 claws and remove the accelerator pedal pad.
  3. REMOVE ACCELERATOR PEDAL ASSEMBLY Remove the 2 bolts and accelerator pedal assembly.
  1. INSTALL ACCELERATOR PEDAL ASSEMBLY Install the accelerator pedal assembly with the 2 bolts. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf)
  2. INSTALL ACCELERATOR PEDAL PAD Engage the 2 claws to install the accelerator pedal pad.
  3. INSTALL ACCELERATOR PEDAL SENSOR ASSEMBLY NOTE: Avoid physical shock to the accelerator pedal sensor assembly. Do not disassemble the accelerator pedal sensor assembly. This accelerator pedal sensor assembly does not require lubrication. Do not apply oil or other lubrication to the accelerator pedal sensor assembly. If applied, the accelerator pedal sensor assembly must be replaced. Install the accelerator pedal sensor assembly with the 2 nuts. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) Connect the accelerator pedal sensor assembly connector.

Scheme 202

Scheme 202: ILLUSTRATION
Scheme 202: ILLUSTRATION
*1MASS AIR FLOW METER SUB-ASSEMBLY

Note. Perform the mass air flow meter sub-assembly inspection according to the following procedure. Only replace the mass air flow meter sub-assembly when the mass air flow meter sub-assembly value in the Data List (with the engine stopped) is not within the normal operating range or there is foreign matter on the mass air flow meter sub-assembly platinum hot wire (heater).

  1. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000) Read the value using the Techstream (MAF). NOTE: Perform the inspection with the vehicle indoors and on a level surface. Perform the inspection of the mass air flow meter sub-assembly while it is installed to the air cleaner cap sub-assembly (installed to the vehicle). During the test, do not use an exhaust air duct on the exhaust pipe. Connect the Techstream to the DLC3. Turn the engine switch on (IG) (do not start the engine). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / MAF. Powertrain > Engine > Data List Tester Display MAF Wait for 30 seconds, and read the value on the Techstream. Standard Condition Tester Display Condition Specified Condition MAF Engine not running 30 seconds after engine switch turned on (IG) 0.54 gm/sec or less If the result is not as specified, replace the mass air flow meter sub-assembly. If the result is within the specified range, remove and inspect the mass air flow meter sub-assembly. Refer to «INSPECTION [04/2013 - ]»(ref-665751-S26977866142014102400000)
  2. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000)

Scheme 203

Scheme 203: PROCEDURE
Scheme 203: PROCEDURE
  1. REMOVE MASS AIR FLOW METER SUB-ASSEMBLY Disconnect the mass air flow meter sub-assembly connector. Remove the 2 screws and mass air flow meter sub-assembly from the air cleaner cap sub-assembly.

Scheme 204

Scheme 204: PROCEDURE
Scheme 204: PROCEDURE
  1. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY Perform a visual check for any foreign matter on the platinum hot wire (heater) of the mass air flow meter sub-assembly shown in the illustration. OK There is no foreign matter. *a Platinum Hot Wire (Heater) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (THA) - 2 (E2) -20°C (-4°F) 13.6 to 18.4 kohms 20°C (68°F) 2.21 to 2.69 kohms 60°C (140°F) 0.49 to 0.67 kohms *a Component without harness connected (Mass Air Flow Meter Sub-assembly) If the result is not as specified, replace the mass air flow meter sub-assembly.
  1. INSTALL MASS AIR FLOW METER SUB-ASSEMBLY HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000) Install the mass air flow meter sub-assembly to the air cleaner cap sub-assembly with the 2 screws. NOTE: Make sure that the O-ring is not cracked or moved out of place when installing the mass air flow meter sub-assembly. Connect the mass air flow meter sub-assembly connector.
  2. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000)

Scheme 205

Scheme 205: ILLUSTRATION
Scheme 205: ILLUSTRATION

*1 V-BANK COVER SUB-ASSEMBLY *2 VVT SENSOR (for Intake Side of Bank 1) *3 VVT SENSOR (for Exhaust Side of Bank 1) *4 VVT SENSOR (for Intake Side of Bank 2) *5 VVT SENSOR (for Exhaust Side of Bank 2) - - N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 206

Scheme 206: PROCEDURE
Scheme 206: PROCEDURE
  1. REMOVE V-BANK COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 3»(ref-665703-S21356895402014102400000)
  2. REMOVE VVT SENSOR (for Intake Side of Bank 1) Disconnect the VVT sensor connector. Remove the bolt and VVT sensor from the cylinder head cover sub-assembly.
  3. REMOVE VVT SENSOR (for Exhaust Side of Bank 1) Disconnect the VVT sensor connector. Remove the bolt and VVT sensor from the cylinder head cover sub-assembly.
  4. REMOVE VVT SENSOR (for Intake Side of Bank 2) Disconnect the VVT sensor connector. Remove the bolt and VVT sensor from the cylinder head cover sub-assembly LH.
  5. REMOVE VVT SENSOR (for Exhaust Side of Bank 2) Disconnect the VVT sensor connector. Remove the bolt and VVT sensor from the cylinder head cover sub-assembly LH.
  1. INSTALL VVT SENSOR (for Exhaust Side of Bank 2) Clean and degrease the threads of the bolt for the VVT sensor. Apply a light coat of engine oil to the O-ring of the VVT sensor. Install the VVT sensor to the cylinder head cover sub-assembly LH with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If a VVT sensor has been struck or dropped, replace it. Make sure that the O-ring is not cracked or does not move out of place during installation. Connect the VVT sensor connector.
  2. INSTALL VVT SENSOR (for Intake Side of Bank 2) Clean and degrease the threads of the bolt for the VVT sensor. Apply a light coat of engine oil to the O-ring of the VVT sensor. Install the VVT sensor to the cylinder head cover sub-assembly LH with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If a VVT sensor has been struck or dropped, replace it. Make sure that the O-ring is not cracked or does not move out of place during installation. Connect the VVT sensor connector.
  3. INSTALL VVT SENSOR (for Exhaust Side of Bank 1) Clean and degrease the threads of the bolt for the VVT sensor. Apply a light coat of engine oil to the O-ring of the VVT sensor. Install the VVT sensor to the cylinder head cover sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If a VVT sensor has been struck or dropped, replace it. Make sure that the O-ring is not cracked or does not move out of place during installation. Connect the VVT sensor connector.
  4. INSTALL VVT SENSOR (for Intake Side of Bank 1) Clean and degrease the threads of the bolt for the VVT sensor. Apply a light coat of engine oil to the O-ring of the VVT sensor. Install the VVT sensor to the cylinder head cover sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If a VVT sensor has been struck or dropped, replace it. Make sure that the O-ring is not cracked or does not move out of place during installation. Connect the VVT sensor connector.
  5. INSTALL V-BANK COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 104»(ref-665703-S03876486602014102400000)

Scheme 207

Scheme 207: ILLUSTRATION
Scheme 207: ILLUSTRATION

*1 CRANKSHAFT POSITION SENSOR N*m (kgf*cm, ft.*lbf): Specified torque

  1. REMOVE COMPRESSOR AND MAGNETIC CLUTCH for 2WD: Refer to «REMOVAL [04/2013 - ]»(ref-665718-S37916415182014102400000) for AWD: Refer to «REMOVAL [04/2013 - ]»(ref-665718-S30893690972014102400000)
  2. REMOVE CRANKSHAFT POSITION SENSOR Disconnect the crankshaft position sensor connector. Remove the bolt and crankshaft position sensor from the cylinder block sub-assembly.
  1. INSPECT CRANKSHAFT POSITION SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Temperature Specified Condition 1 - 2 Cold 1630 to 2740 ohms Hot 2065 to 3225 ohms HINT: In the table above, the terms "Cold" and "Hot" mean the temperature of the coils themselves. "Cold" is from -10 to 50°C (14 to 122°F) and "Hot" is from 50 to 100°C (122 to 212°F). If the resistance is not as specified, replace the crankshaft position sensor.
  1. INSTALL CRANKSHAFT POSITION SENSOR Clean and degrease the threads of the bolt for the crankshaft position sensor. Apply a light coat of engine oil to the O-ring of the crankshaft position sensor. Install the crankshaft position sensor to the cylinder block sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If a crankshaft position sensor has been struck or dropped, replace it. Make sure that the O-ring is not cracked or does not move out of place during installation. Connect the crankshaft position sensor connector.
  2. INSTALL COMPRESSOR AND MAGNETIC CLUTCH for 2WD: Refer to «INSTALLATION [04/2013 - ]»(ref-665718-S24247534412014102400000) for AWD: Refer to «INSTALLATION [04/2013 - ]»(ref-665718-S08119568252014102400000)

Scheme 208

Scheme 208: ILLUSTRATION
Scheme 208: ILLUSTRATION

*1 IGNITION COIL ASSEMBLY *2 SPARK PLUG *3 WIRE HARNESS *4 IGNITION COIL COVER BRACKET N*m (kgf*cm, ft.*lbf): Specified torque

  1. REMOVE INTAKE AIR SURGE TANK ASSEMBLY Refer to «REMOVAL [04/2013 - ]»(ref-665769-S18378390412014102400000)
  2. REMOVE IGNITION COIL ASSEMBLY Remove the 2 nuts and disconnect the wire harness from the cylinder head cover sub-assembly. Remove the 2 bolts and disconnect the ignition coil cover bracket from the cylinder head cover sub-assembly LH. Disconnect the 6 ignition coil assembly connectors. Remove the 6 bolts and 6 ignition coil assemblies from the cylinder head cover sub-assembly. NOTE: If an ignition coil assembly has been struck or dropped, replace it. HINT: Arrange the removed parts in the correct order.
  3. REMOVE SPARK PLUG Remove the 6 spark plugs from the cylinder head assembly. NOTE: If a spark plug has been struck or dropped, replace it. HINT: Arrange the removed parts in the correct order.

Scheme 209

Scheme 209: PROCEDURE
Scheme 209: PROCEDURE
  1. INSTALL SPARK PLUG HINT: Perform "Inspection After Repair" after replacing a spark plug. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000) Install the 6 spark plugs to the cylinder head sub-assembly. Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf) NOTE: If a spark plug has been struck or dropped, replace it. HINT: Install the same parts to their original positions.
  2. INSTALL IGNITION COIL ASSEMBLY HINT: Perform "Inspection After Repair" after replacing an ignition coil assembly. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000) Install the 6 ignition coil assemblies to the cylinder head cover sub-assembly with the 6 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If an ignition coil assembly has been struck or dropped, replace it. HINT: Install the same parts to their original positions. Connect the 6 ignition coil assembly connectors. Connect the ignition coil cover bracket to the cylinder head cover sub-assembly LH with the 2 bolts. Bolt A Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Bolt B Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Connect the wire harness to the cylinder head cover sub-assembly with the 2 nuts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
  3. INSTALL INTAKE AIR SURGE TANK ASSEMBLY Refer to «INSTALLATION [04/2013 - ]»(ref-665769-S35629936752014102400000)
  4. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing an ignition coil assembly and spark plug. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000)

Scheme 210

Scheme 210: ILLUSTRATION
Scheme 210: ILLUSTRATION

*1 ENGINE COOLANT TEMPERATURE SENSOR *2 WATER BY-PASS HOSE *3 GASKET - - N*m (kgf*cm, ft.*lbf): Specified torque • Non-reusable part

  1. REMOVE FUEL PRESSURE SENSOR Refer to «REMOVAL [04/2013 - ]»(ref-665752-S08165459162014102400000)
  2. DISCONNECT WATER BY-PASS HOSE Slide the clip and disconnect the water by-pass hose from the rear water by-pass joint.
  3. REMOVE ENGINE COOLANT TEMPERATURE SENSOR Disconnect the engine coolant temperature sensor connector. Using a 19 mm ball joint lock nut wrench, remove the engine coolant temperature sensor from the rear water by-pass joint. Remove the gasket from the engine coolant temperature sensor.

Scheme 211

Scheme 211: PROCEDURE
Scheme 211: PROCEDURE
  1. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 2.32 to 2.59 kohms 80°C (176°F) 0.310 to 0.326 kohms NOTE: If checking the engine coolant temperature sensor in water, be careful not to allow water to contact the terminals. After checking, wipe the water off the engine coolant temperature sensor. *a Component without harness connected (Engine Coolant Temperature Sensor) If the result is not as specified, replace the engine coolant temperature sensor.
  1. INSTALL ENGINE COOLANT TEMPERATURE SENSOR HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000) Install a new gasket onto the engine coolant temperature sensor. Using a 19 mm ball joint lock nut wrench, install the engine coolant temperature sensor to the rear water by-pass joint. Torque: 19.6 N*m (200 kgf*cm, 14 ft.*lbf) NOTE: Use the torque value compensation formula to calculate the torque value for use when a torque wrench is combined with a tool such as a ball joint lock nut wrench. Refer to «PRECAUTION [04/2013 - ]»(ref-665529-S00420865962014102400000) Connect the engine coolant temperature sensor connector.
  2. CONNECT WATER BY-PASS HOSE Connect the water by-pass hose to the rear water by-pass joint and slide the clip to secure it.
  3. INSTALL FUEL PRESSURE SENSOR Refer to «INSTALLATION [04/2013 - ]»(ref-665752-S32604996022014102400000)
  4. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000)

Scheme 212

Scheme 212: ILLUSTRATION
Scheme 212: ILLUSTRATION

*1 KNOCK CONTROL SENSOR (for Bank 1) *2 KNOCK CONTROL SENSOR (for Bank 2) N*m (kgf*cm, ft.*lbf): Specified torque

  1. REMOVE FUEL INJECTOR SEAL Refer to «REMOVAL [04/2013 - ]»(ref-665752-S02581426282014102400000)
  2. REMOVE KNOCK CONTROL SENSOR Disconnect the 2 knock control sensor connectors. Engine Front Remove the 2 bolts and 2 knock control sensors from the cylinder block sub-assembly.
  1. INSPECT KNOCK CONTROL SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 120 to 280 kohms If the result is not as specified, replace the knock control sensor.
  1. INSTALL KNOCK CONTROL SENSOR HINT: Perform "Inspection After Repair" after replacing a knock control sensor. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000) Install the 2 knock control sensors to the cylinder block sub-assembly with the 2 bolts so that the knock control sensor installation position is as shown in the illustration. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) NOTE: Make sure that each knock control sensor is in the correct position. *A for Bank 1 *B for Bank 2 *a View A *b View B *c Top *d Engine Front *e Engine Rear Front View A View B Connect the 2 knock control sensor connectors.
  2. INSTALL FUEL INJECTOR SEAL Refer to «INSTALLATION [04/2013 - ]»(ref-665752-S25245865322014102400000)
  3. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing a knock control sensor. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000)

Scheme 213

Scheme 213: ILLUSTRATION
Scheme 213: ILLUSTRATION

*1 AIR FUEL RATIO SENSOR (for Bank 1) *2 BATTERY TRAY *3 V-BANK COVER SUB-ASSEMBLY *4 AIR FUEL RATIO SENSOR (for Bank 2) *5 FUEL PIPE - - N*m (kgf*cm, ft.*lbf): Specified torque * For use with SST

Scheme 214

Scheme 214: PROCEDURE
Scheme 214: PROCEDURE
  1. REMOVE V-BANK COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 3»(ref-665703-S21356895402014102400000)
  2. REMOVE POWER STEERING ECU ASSEMBLY Refer to «REMOVAL [04/2013 - ]»(ref-665742-S15988043842014102400000)
  3. REMOVE BATTERY TRAY Disconnect the fuel pipe clamp from the battery tray. Remove the 3 bolts and battery tray.
  4. REMOVE AIR FUEL RATIO SENSOR for Bank 1: Disconnect the air fuel ratio sensor connector. Disconnect the 2 wire harness clamps from the wire harness bracket. Using SST, remove the air fuel ratio sensor from the exhaust manifold RH. SST: 09224-00010 for Bank 2: Disconnect the air fuel ratio sensor connector. Using SST, remove the air fuel ratio sensor from the exhaust manifold LH. SST: 09224-00010
  1. INSPECT AIR FUEL RATIO SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (HA1A) - 2 (+B) 1 (HA2A) - 2 (+B) 20°C (68°F) 1.6 to 3.2 ohms 1 (HA1A) - 4 (A1A-) 1 (HA2A) - 4 (A2A-) Always 10 kohms or higher *A for Bank 1 *B for Bank 2 *a Component without harness connected (Air Fuel Ratio Sensor) If the result is not as specified, replace the air fuel ratio sensor.
  1. INSTALL AIR FUEL RATIO SENSOR HINT: Perform "Inspection After Repair" after replacing an air fuel ratio sensor. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000) for Bank 2: Using SST, install the air fuel ratio sensor to the exhaust manifold LH. SST: 09224-00010 without SST [Torque (N*m (kgf*cm, ft.*lbf))] Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST [Reading of Torque wrench (N*m (kgf*cm, ft.*lbf))] Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) NOTE: If an air fuel ratio sensor has been struck or dropped, replace it. HINT: This torque value is effective when SST is parallel to the torque wrench. The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 260 mm (10.2 in.). If using a torque wrench with a different length, or connecting the torque wrench and SST at an angle, refer to the alternate torque values. Refer to «PRECAUTION [04/2013 - ]»(ref-665529-S00420865962014102400000) *a Length of SST 30 mm (1.18 in.) *b Length of Torque Wrench 260 mm (10.2 in.) Connect the air fuel ratio sensor connector. for Bank 1: Using SST, install the air fuel ratio sensor to the exhaust manifold RH. SST: 09224-00010 without SST [Torque (N*m (kgf*cm, ft.*lbf))] Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST [Reading of Torque wrench (N*m (kgf*cm, ft.*lbf))] Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) NOTE: If an air fuel ratio sensor has been struck or dropped, replace it. HINT: This torque value is effective when SST is parallel to the torque wrench. The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 260 mm (10.2 in.). If using a torque wrench with a different length, or connecting the torque wrench and SST at an angle, refer to the alternate torque values. Refer to «PRECAUTION [04/2013 - ]»(ref-665529-S00420865962014102400000) *a Length of SST 30 mm (1.18 in.) *b Length of Torque Wrench 260 mm (10.2 in.) Connect the 2 wire harness clamps to the wire harness bracket. Connect the air fuel ratio sensor connector.
  2. INSTALL BATTERY TRAY Install the battery tray with the 3 bolts. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) Connect the fuel pipe clamp to the battery tray.
  3. INSTALL POWER STEERING ECU ASSEMBLY Refer to «INSTALLATION [04/2013 - ]»(ref-665742-S21367795172014102400000)
  4. INSTALL V-BANK COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 104»(ref-665703-S03876486602014102400000)
  5. INSPECT FOR EXHAUST GAS LEAK Refer to «PROCEDURE - Step 9»(ref-665769-S09616163602014102400000)
  6. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing an air fuel ratio sensor. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000)

Scheme 215

Scheme 215: ILLUSTRATION
Scheme 215: ILLUSTRATION

*A for 2WD - - *1 HEATED OXYGEN SENSOR (for Bank 1) *2 HEATED OXYGEN SENSOR (for Bank 2) N*m (kgf*cm, ft.*lbf): Specified torque * For use with SST

Scheme 216

Scheme 216: ILLUSTRATION
Scheme 216: ILLUSTRATION

*A for AWD *B w/ Front Floor Cover LH *1 HEATED OXYGEN SENSOR (for Bank 1) *2 HEATED OXYGEN SENSOR (for Bank 2) *3 FRONT FLOOR COVER LH - - N*m (kgf*cm, ft.*lbf): Specified torque * For use with SST

Scheme 217

Scheme 217: PROCEDURE
Scheme 217: PROCEDURE

Scheme 218

Scheme 218
Scheme 218

Scheme 219

Scheme 219
Scheme 219

Scheme 220

Scheme 220
Scheme 220

Scheme 221

Scheme 221
Scheme 221

Scheme 222

Scheme 222
Scheme 222
  1. REMOVE FRONT SEAT ASSEMBLY LH (for AWD) Refer to «REMOVAL [04/2013 - ]»(ref-665743-S20114744952014102400000)
  2. REMOVE CONSOLE BOX ASSEMBLY Refer to «REMOVAL [04/2013 - ]»(ref-665744-S15890969802014102400000)
  3. DISCONNECT HEATED OXYGEN SENSOR CONNECTOR for Bank 1: Turn back the floor carpet. Disconnect the heated oxygen sensor connector. for Bank 2: Turn back the floor carpet. Disconnect the heated oxygen sensor connector. *A for 2WD *B for AWD
  4. REMOVE HEATED OXYGEN SENSOR for Bank 1: Disconnect the heated oxygen sensor grommet from the body. *a Grommet Using SST, remove the heated oxygen sensor from the front exhaust pipe assembly. SST: 09224-00010 for Bank 2 (for 2WD): Disconnect the heated oxygen sensor grommet from the body. *a Grommet Using SST, remove the heated oxygen sensor from the front exhaust pipe assembly. SST: 09224-00010 for Bank 2 (for AWD with Front Floor Cover LH): Disconnect the 6 clips and remove the front floor cover LH. Disconnect the heated oxygen sensor grommet from the body. *a Grommet Disconnect the 2 clamps from the body. Using SST, remove the heated oxygen sensor from the front exhaust pipe assembly. SST: 09224-00010 for Bank 2 (for AWD without Front Floor Cover LH): Disconnect the heated oxygen sensor grommet from the body. *a Grommet Disconnect the 3 clamps from the body. Using SST, remove the heated oxygen sensor from the front exhaust pipe assembly. SST: 09224-00010
  1. INSPECT HEATED OXYGEN SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (HT1B) - 2 (+B) 1 (HT2B) - 2 (+B) 20°C (68°F) 11 to 16 ohms 1 (HT1B) - 4 (E2) 1 (HT2B) - 4 (E2) Always 10 kohms or higher *A for Bank 1 *B for Bank 2 *a Component without harness connected (Heated Oxygen Sensor) If the resistance is not as specified, replace the heated oxygen sensor.

Scheme 223

Scheme 223: PROCEDURE
Scheme 223: PROCEDURE

Scheme 224

Scheme 224
Scheme 224
  1. INSTALL HEATED OXYGEN SENSOR HINT: Perform "Inspection After Repair" after replacing a heated oxygen sensor. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000) for Bank 2 (for 2WD): Using SST, install the heated oxygen sensor to the front exhaust pipe assembly. SST: 09224-00010 without SST [Torque (N*m (kgf*cm, ft.*lbf))] Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST [Reading of Torque wrench (N*m (kgf*cm, ft.*lbf))] Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) NOTE: If a heated oxygen sensor has been struck or dropped, replace it. HINT: This torque value is effective when SST is parallel to the torque wrench. The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 260 mm (10.2 in.). If using a torque wrench with a different length, or connecting the torque wrench and SST at an angle, refer to the alternate torque values. Refer to «PRECAUTION [04/2013 - ]»(ref-665529-S00420865962014102400000) *a Length of SST 30 mm (1.18 in.) *b Length of Torque Wrench 260 mm (10.2 in.) Install the heated oxygen sensor grommet to the body. for Bank 2 (for AWD with Front Floor Cover LH): Using SST, install the heated oxygen sensor to the front exhaust pipe assembly. *a Length of SST 30 mm (1.18 in.) *b Length of Torque Wrench 260 mm (10.2 in.) SST: 09224-00010 without SST [Torque (N*m (kgf*cm, ft.*lbf))] Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST [Reading of Torque wrench (N*m (kgf*cm, ft.*lbf))] Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) NOTE: If a heated oxygen sensor has been struck or dropped, replace it. HINT: This torque value is effective when SST is parallel to the torque wrench. The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 260 mm (10.2 in.). If using a torque wrench with a different length, or connecting the torque wrench and SST at an angle, refer to the alternate torque values. Refer to «PRECAUTION [04/2013 - ]»(ref-665529-S00420865962014102400000) Install the 2 clamps to the body. Install the heated oxygen sensor grommet to the body. Install the front floor cover LH with the 6 clips. for Bank 2 (for AWD without Front Floor Cover LH): Using SST, install the heated oxygen sensor to the front exhaust pipe assembly. *a Length of SST 30 mm (1.18 in.) *b Length of Torque Wrench 260 mm (10.2 in.) SST: 09224-00010 without SST [Torque (N*m (kgf*cm, ft.*lbf))] Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST [Reading of Torque wrench (N*m (kgf*cm, ft.*lbf))] Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) NOTE: If a heated oxygen sensor has been struck or dropped, replace it. HINT: This torque value is effective when SST is parallel to the torque wrench. The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 260 mm (10.2 in.). If using a torque wrench with a different length, or connecting the torque wrench and SST at an angle, refer to the alternate torque values. Refer to «PRECAUTION [04/2013 - ]»(ref-665529-S00420865962014102400000) Install the 3 clamps to the body. Install the heated oxygen sensor grommet to the body. for Bank 1: Using SST, install the heated oxygen sensor to the front exhaust pipe assembly. SST: 09224-00010 without SST [Torque (N*m (kgf*cm, ft.*lbf))] Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST [Reading of Torque wrench (N*m (kgf*cm, ft.*lbf))] Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) NOTE: If a heated oxygen sensor has been struck or dropped, replace it. *a Length of SST 30 mm (1.18 in.) *b Length of Torque Wrench 260 mm (10.2 in.) HINT: This torque value is effective when SST is parallel to the torque wrench. The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 260 mm (10.2 in.). If using a torque wrench with a different length, or connecting the torque wrench and SST at an angle, refer to the alternate torque values. Refer to «PRECAUTION [04/2013 - ]»(ref-665529-S00420865962014102400000) Install the heated oxygen sensor grommet to the body.
  2. CONNECT HEATED OXYGEN SENSOR CONNECTOR for Bank 2: Connect the heated oxygen sensor connector. Install the floor carpet. for Bank 1: Connect the heated oxygen sensor connector. Install the floor carpet.
  3. INSTALL CONSOLE BOX ASSEMBLY Refer to «INSTALLATION [04/2013 - ]»(ref-665744-S11998814112014102400000)
  4. INSTALL FRONT SEAT ASSEMBLY LH (for AWD) Refer to «INSTALLATION [04/2013 - ]»(ref-665743-S36391795312014102400000)
  5. INSPECT FOR EXHAUST GAS LEAK Refer to «PROCEDURE - Step 9»(ref-665769-S09616163602014102400000)
  6. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing a heated oxygen sensor. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000)
  1. INSPECT EFI INJECTION RELAY (INJ) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Battery voltage is not applied between terminals 1 and 2 10 kohms or higher Battery voltage is applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the EFI injection relay (INJ).
  2. INSPECT EFI 2 RELAY (EFI MAIN NO. 2) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Battery voltage is not applied between terminals 1 and 2 10 kohms or higher Battery voltage is applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the EFI 2 relay (EFI MAIN NO. 2).

More articles — Engine Control System (Service Information)
