Engine Control System (Diagnostic Codes (P0201-P0724)): Diagnosis Lexus IS III

Testing & Diagnostics 2 illustrations ~271 words

CONDITIONING FOR SENSOR TESTING

HINT

Perform the operation with the engine speeds and time durations described below prior to checking the waveforms of the air fuel ratio and heated oxygen sensors. This is to activate the sensors sufficiently to obtain appropriate inspection results.

Scheme 167

Scheme 167: CONDITIONING FOR SENSOR TESTING
  1. (a) Connect the Techstream to the DLC3.
  2. (b) Start the engine and warm it up with all the accessories switched off until the engine coolant temperature stabilizes.
  3. (c) Run the engine at an engine speed of between 2500 rpm and 3000 rpm for at least 3 minutes.
  4. (d) While running the engine at 3000 rpm for 2 seconds, and then 2000 rpm for 2 seconds, check the waveforms of the air fuel ratio and heated oxygen sensors using the Techstream.

HINT

  1. If the voltage output of either the air fuel ratio or heated oxygen sensor does not fluctuate, or there is a noise in the waveform of either sensor, the sensor may be malfunctioning.
  2. If the voltage outputs of both the sensors remain lean or rich, the air fuel ratio may be extremely lean or rich. In such cases, perform the Control the Injection Volume for A/F Sensor Active Test using the Techstream.
  3. If the Three-way Catalytic Converter (TWC) has deteriorated, the heated oxygen sensor (located behind the Three-way Catalytic Converter [TWC]) voltage output fluctuates up and down frequently, even under normal driving conditions (active air fuel ratio control is not performed).

Scheme 168

Scheme 168

DTC SUMMARY

DTC No.Detection ItemDTC Detection ConditionTrouble AreaMILMemory
P043EEvaporative Emission System Leak Detection Reference Orifice Low FlowReference orifice clogged during key-off EVAP monitorCanister pump module Connector/wire harness (Canister pump module - ECM) ECMComes onDTC stored
P043FEvaporative Emission System Reference Orifice High FlowReference orifice high-flow during key-off EVAP monitorCanister pump module Connector/wire harness (Canister pump module - ECM) ECMComes onDTC stored
P2401Evaporative Emission Leak Detection Pump Stuck OFFLeak detection pump off malfunction during key-off EVAP monitorCanister pump module Connector/wire harness (Canister pump module - ECM) ECMComes onDTC stored
P2402Evaporative Emission Leak Detection Pump Stuck ONLeak detection pump on malfunction during key-off EVAP monitorCanister pump module Connector/wire harness (Canister pump module - ECM) ECMComes onDTC stored
P2419Evaporative Emission System Switching Valve Control Circuit LowVent valve on (closed) malfunction during key-off EVAP monitorCanister pump module Connector/wire harness (Canister pump module - ECM) ECMComes onDTC stored
DTC No.Monitoring ItemDetection TimingDetection Logic
P043EReference orifice cloggedWhile engine switch off2 trip
P043FReference orifice high-flow
P2401Leak detection pump stuck off
P2402Leak detection pump stuck on
P2419Vent valve stuck closed

HINT

The reference orifice is located inside the canister pump module.

DTC No.Detection ItemDTC Detection ConditionTrouble AreaMILMemory
P0441Evaporative Emission Control System Incorrect Purge FlowOne of the following conditions met: Leak detection pump creates negative pressure (vacuum) in EVAP system and EVAP system pressure measured. Reference pressure is measured at start and at end of leak check. If stabilized pressure higher than [second reference pressure x 0.2], ECM determines that purge VSV stuck open. After EVAP leak check performed, purge VSV turned on (open), and atmospheric air introduced into EVAP system. Reference pressure is measured at start and at end of check. If pressure does not return to near atmospheric pressure, ECM determines that purge VSV stuck closed. While engine running, following conditions successively met: Negative pressure not created in EVAP system when purge VSV turned on (open) EVAP system pressure change less than 0.15 kPa(gauge) [1.125 mmHg(gauge)] when vent valve turned on (closed) Atmospheric pressure change before and after purge flow monitor less than 0.1 kPa(gauge) [0.75 mmHg(gauge)]Purge VSV Purge line Connector/wire harness (Purge VSV - ECM) ECM Canister pump module Canister (filter inside canister clogged) Leak from EVAP systemComes onDTC stored
DTC No.Monitoring ItemDetection TimingDetection Logic
P0441Purge VSV (Vacuum Switching Valve) stuck openWhile engine switch off2 trip
Purge VSV stuck closedWhile engine switch off2 trip
Purge flowWhile engine running2 trip
DTC No.Detection ItemDTC Detection ConditionTrouble AreaMILMemory
P0451Evaporative Emission Control System Pressure Sensor Range / PerformanceEither of the following conditions is met: Sensor output voltage fluctuates frequently in a certain time period. Sensor output voltage does not vary in a certain time period.Canister pump module Connector/wire harness (Canister pump module - ECM) EVAP system hose (pipe from air inlet port to canister pump module, canister filter, fuel tank vent hose) ECMComes onDTC stored
P0452Evaporative Emission Control System Pressure Sensor / Switch Low InputEVAP pressure sensor less than 42.11 kPa(abs) [315.867 mmHg(abs)] for 0.5 seconds.Canister pump module Connector/wire harness (Canister pump module - ECM) EVAP system hose (pipe from air inlet port to canister pump module, canister filter, fuel tank vent hose) ECMComes onDTC stored
P0453Evaporative Emission Control System Pressure Sensor / Switch High InputEVAP pressure sensor higher than 123.761 kPa(abs) [928.331 mmHg(abs)] for 0.5 seconds.Canister pump module Connector/wire harness (Canister pump module - ECM) EVAP system hose (pipe from air inlet port to canister pump module, canister filter, fuel tank vent hose) ECMComes onDTC stored
DTC No.Monitoring ItemDetection TimingDetection Logic
P0451Canister pressure sensor abnormal voltage fluctuationEVAP monitoring (engine switch off) Engine running2 trip
Canister pressure sensor constant voltageEVAP monitoring (engine switch off)2 trip
P0452Canister pressure sensor low inputEngine switch on (IG) EVAP monitoring (engine switch off)1 trip
P0453Canister pressure sensor high inputEngine switch on (IG) EVAP monitoring (engine switch off)1 trip

HINT

The canister pressure sensor is built into the canister pump module.

DTC No.Detection ItemDTC Detection ConditionTrouble AreaMILMemory
P0455Evaporative Emission Control System Leak Detected (Gross Leak)Leak detection pump creates negative pressure (vacuum) in EVAP system and EVAP system pressure is measured. Reference pressure is measured at start and end of leak check. If stabilized pressure is higher than [second reference pressure x 0.2], ECM determines that EVAP system has a large leak.Fuel cap (loose) Leakage from EVAP line (canister - fuel tank) Leakage from EVAP line (purge VSV - canister) Leakage from canister pump module Leakage from fuel tank Leakage from canisterComes onDTC stored
P0456Evaporative Emission Control System Leak Detected (Very Small Leak)Leak detection pump creates negative pressure (vacuum) in EVAP system and EVAP system pressure is measured. Reference pressure measured at start and end of leak check. If stabilized pressure is higher than second reference pressure, ECM determines that EVAP system has a small leak.Fuel cap (loose) Leakage from EVAP line (canister - fuel tank) Leakage from EVAP line (purge VSV - canister) Leakage from canister pump module Leakage from fuel tank Leakage from canisterComes onDTC stored
DTC No.Monitoring ItemDetection TimingDetection Logic
P0455EVAP gross leakWhile engine switch off2 trip
P0456EVAP small leakWhile engine switch off2 trip
