PRECAUTION [04/2013 - ]

1. PRECAUTION FOR DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. System Name See Procedure Variable Gear Ratio Steering System Refer to «INITIALIZATION [04/2013 - ]»(ref-665529-S01115916402014102400000) Air Conditioning System

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

COMMUNICATION TABLE

CAUTION / NOTICE / HINT

HINT

1. Use the following procedure to troubleshoot the power mirror control system (w/ Memory).
2. *: Use the Techstream.

PROCEDURE

1. VEHICLE BROUGHT TO WORKSHOP Result Proceed to NEXT Result: 1 NEXT See step 2
2. CUSTOMER PROBLEM ANALYSIS HINT: In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points for problem analysis: What Vehicle model, system name When Date, time, occurrence frequency Where Road conditions Under what conditions? Driving conditions, weather conditions How did it happen? Problem symptoms Result Proceed to NEXT Result: 1 NEXT See step 3
3. PRE-CHECK Measure the battery voltage. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step. Check the fuses and relays. Check the connector connections and terminals to make sure that there are no abnormalities such as loose connections, deformation, etc. Result Proceed to NEXT Result: 1 NEXT See step 4
4. INSPECT COMMUNICATION FUNCTION OF CAN COMMUNICATION SYSTEM* Using the Techstream, check for CAN communication system DTCs. Refer to «DIAGNOSIS SYSTEM [04/2013 - ]»(ref-665810-S14264089842014102400000) Result Result Proceed to CAN DTCs are not output A CAN DTCs are output B Result: 2 B GO TO CAN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665785-S15342612202014102400000) Result: 1 A See step 5
5. INSPECT COMMUNICATION FUNCTION OF LIN COMMUNICATION SYSTEM* Using the Techstream, check for LIN communication system DTCs. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665832-S32731231342014102400000) Result Result Proceed to LIN DTCs are not output A LIN DTCs are output B Result: 2 B GO TO LIN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665832-S17970494342014102400000) Result: 1 A See step 6
6. PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [04/2013 - ]»(ref-665550-S37985539332014102400000) Result Result Proceed to Fault is not listed in problem symptoms table A Fault is listed in problem symptoms table B Result: 2 B See step 8 Result: 1 A See step 7
7. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check Refer to «OPERATION CHECK [04/2013 - ]»(ref-665550-S02861934412014102400000) Terminals of ECU Refer to «TERMINALS OF ECU [04/2013 - ]»(ref-665550-S32619736392014102400000) Data List / Active Test Refer to «DATA LIST / ACTIVE TEST [04/2013 - ]»(ref-665550-S01577038722014102400000) Inspection Result Proceed to NEXT Result: 1 NEXT See step 8
8. REPAIR OR REPLACE Result Proceed to NEXT Result: 1 NEXT See step 9
9. CONFIRMATION TEST Result Proceed to NEXT Result: 1 NEXT END

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. CHECK ELECTRICAL REMOTE CONTROL MIRROR FUNCTION Turn the engine switch on (IG). With the mirror select switch L switch on, check that the outer rear view mirror assembly LH surface moves up, down, left and right normally. With the mirror select switch R switch on, check that the outer rear view mirror assembly RH surface moves up, down, left and right normally.
2. CHECK MEMORY AND REACTIVATION FUNCTION *a M1 Switch *b M2 Switch *c M3 Switch *d SET Switch HINT: The SET, M1, M2 and M3 seat memory switches are shown in the illustration. Turn the engine switch on (IG) and move the shift lever to P. Check the M1 switch. *a Turn to Fully Left Position Using the multiplex network master switch assembly, turn the mirror surface to the fully left position. Check that the buzzer sounds for 0.5 seconds and the seat and mirror surface position is memorized when the M1 switch is pressed within 3 seconds of the SET switch being pressed. NOTE: The mirror surface position will also be memorized when the M1 switch is pressed after first pressing and holding the SET switch. The mirror surface position will not be memorized when the SET switch and M1 switch are pressed simultaneously. The mirror surface position will not be memorized when 2 or more of the memory switches are pressed simultaneously (for example, M1 and M2) after first pressing the SET switch. Using the multiplex network master switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the mirror surface automatically moves to the memorized fully left position. *a Turn to Fully Right Position Check the M2 switch. Using the multiplex network master switch assembly, turn the mirror surface to the fully right position. Check that the buzzer sounds for 0.5 seconds and the seat and mirror surface position is memorized when the M2 switch is pressed within 3 seconds of the SET switch being pressed. NOTE: The mirror surface position will also be memorized when the M2 switch is pressed after first pressing and holding the SET switch. The mirror surface position will not be memorized when the SET switch and M2 switch are pressed simultaneously. The mirror surface position will not be memorized when 2 or more of the memory switches are pressed simultaneously (for example, M1 and M2) after first pressing the SET switch. Using the multiplex network master switch assembly, turn the mirror surface to the fully left position. Press the M2 switch. Check that the buzzer sounds for 0.1 seconds and the mirror surface automatically moves to the memorized fully right position. Check the M3 switch. *a Turn to Fully Upward Position Using the multiplex network master switch assembly, turn the mirror surface to the fully upward position. Check that the buzzer sounds for 0.5 seconds and the seat and mirror surface position is memorized when the M3 switch is pressed within 3 seconds of the SET switch being pressed. NOTE: The mirror surface position will also be memorized when the M3 switch is pressed after first pressing and holding the SET switch. The mirror surface position will not be memorized when the SET switch and M3 switch are pressed simultaneously. The mirror surface position will not be memorized when 2 or more of the memory switches are pressed simultaneously (for example, M1 and M2) after first pressing the SET switch. Using the multiplex network master switch assembly, turn the mirror surface to the fully downward position. Press the M3 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the stored fully upward position.
3. CHECK REVERSE SHIFT-LINKED FUNCTION Turn the engine switch on (IG). Turn the mirror select switch L or R switch on. Check that the mirror surface turns downward when the shift lever is moved to R. Check that the mirror surface position returns to the original position when one of the following conditions is met: Shift lever is moved to any position other than R. Both mirror select switch L and R switches are off. Engine switch is turned off.
4. CHECK REVERSE SHIFT-LINKED MIRROR POSITION MEMORIZATION FUNCTION HINT: The reverse shift-linked mirror position memorization function can be customized. Refer to «CUSTOMIZE PARAMETERS [04/2013 - ]»(ref-665537-S08708930112014102400000) Turn the engine switch on (IG). Turn the mirror select switch L or R switch on. Check that the mirror surface turns downward when the shift lever is moved to R. While the mirror is in the reverse shift-linked operation position, move the mirror surface to the desired position. HINT: If the mirror surface is set to turn to the upward position, the mirror surface turns upward when the shift lever is moved to R. Check that the mirror surface moves to its normal position when the shift lever is moved to a position other than R, and then moves back to the memorized position when the shift lever is moved to R again.
5. CHECK MEMORY CALL FUNCTION Memory call function check With an electrical key transmitter sub-assembly recognition code registered, perform a wireless door unlock operation and check that opening the driver door causes the following: The buzzer sounds for 0.1 seconds. The driver seat and mirror surface positions automatically move to the memorized positions. HINT: The registered electrical key transmitter sub-assembly recognition code is recalled automatically. If the memory call function is not operated, the buzzer will not sound. With the engine switch off and the driver door closed, press and hold the M1, M2 or M3 switch while carrying the electrical key transmitter sub-assembly. The main body ECU (multiplex network body ECU) will enter electrical key transmitter sub-assembly recognition code registration mode to allow a key to be linked to mirror surface memory position. HINT: If the seat memory switch is released before entering registration mode, the main body ECU (multiplex network body ECU) will not enter registration mode. When the manual door lock switch is pressed, check that the buzzer sounds once (0.5 seconds). With the engine switch off and the driver door closed, press and hold the SET switch while carrying the electrical key transmitter sub-assembly. The main body ECU (multiplex network body ECU) will enter electrical key transmitter sub-assembly recognition code deletion mode. HINT: If the seat memory switch is released before entering deletion mode, the main body ECU (multiplex network body ECU) will not enter deletion mode. When the manual door lock switch is pressed, check that the buzzer sounds twice (0.1 seconds each time).
6. CHECK MEMORY CALL EMERGENCY STOP FUNCTION While a memory call function is operating, check that any one of the following actions will stop the memory call operation: 1) pressing the SET, M1, M2 or M3 switch, 2) moving the shift lever to R, 3) moving the mirror surface manually, or 4) moving the mirror surface to the uppermost, lowermost, leftmost or rightmost position.
7. CHECK MIRROR HEATER FUNCTION Turn the engine switch on (IG). Check that pressing the mirror heater switch (rear window defogger switch) illuminates the indicator and warms the mirror surfaces. Check that after approximately 15 minutes, the indicator light turns off and the mirror heaters deactivate. HINT: There is a timer extension function which can operate the mirror heaters for up to an additional 45 minutes.
8. CHECK AUTOMATIC GLARE-RESISTANT EC MIRROR FUNCTION (w/ EC Mirror) Check that the automatic glare-resistant EC mirror function of the outer rear view mirror assemblies operates when the automatic glare-resistant function of the inner rear view mirror assembly is operating.

CUSTOMIZE PARAMETERS [04/2013 - ]

1. CUSTOMIZE POWER MIRROR CONTROL SYSTEM (w/ Memory) HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Record the current settings before customizing. Customizing with the Techstream Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Customize Setting / Others. Select the setting by referring to the table below. Others Tester Display Description Default Setting ECU Reverse Coupled Actuation Mirror Angle Function that turns the reverse shift-linked mirror position memorization function on or off User Setting 0:Default Setting, 1:User Setting Main body ECU (Multiplex network body ECU)

Note. The power mirror control system (w/ Memory) uses the CAN communication system and LIN communication system. Inspect the communication functions by following How to Proceed with Troubleshooting. Troubleshoot the power window control system after confirming that the communication systems are functioning properly. Refer to HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ] If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [04/2013 - ]

1. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Master Switch / Data List. Read the Data List according to the display on the Techstream. Body Electrical > Master Switch > Data List Tester Display Measurement Item Range Normal Condition Diagnostic Note Mirror Selection SW (L) Mirror select switch signal for LH mirror OFF or ON OFF: Mirror select switch off ON: Mirror select switch L switch on - Mirror Position SW (L) Mirror adjust switch signal (Left) OFF or ON OFF: Mirror adjust switch not pressed left ON: Mirror adjust switch pressed left Check with the mirror select switch L or R switch on Mirror Position SW (R) Mirror adjust switch signal (Right) OFF or ON OFF: Mirror adjust switch not pressed right ON: Mirror adjust switch pressed right Check with the mirror select switch L or R switch on Mirror Position SW (Up) Mirror adjust switch signal (Up) OFF or ON OFF: Mirror adjust switch not pressed up ON: Mirror adjust switch pressed up Check with the mirror select switch L or R switch on Mirror Position SW (Dwn) Mirror adjust switch signal (Down) OFF or ON OFF: Mirror adjust switch not pressed down ON: Mirror adjust switch pressed down Check with the mirror select switch L or R switch on Body Electrical > Master Switch > Data List Tester Display Mirror Selection SW (L) Mirror Position SW (L) Mirror Position SW (R) Mirror Position SW (Up) Mirror Position SW (Dwn) OK On the Techstream screen, ON or OFF is displayed for each item according to the table above. Result Proceed to OK NG Result: 2 NG See step 3 Result: 1 OK See step 2
2. INSPECT OUTER MIRROR ACTUATOR ASSEMBLY (DRIVER DOOR) (MIRROR SURFACE) Remove the outer mirror actuator assembly (driver door). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000) Inspect the outer mirror actuator assembly (driver door) (mirror surface). Refer to «INSPECTION [04/2013 - ]»(ref-665850-S29253690092014102400000) Result Proceed to OK NG Result: 1 OK REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S29959522862014102400000) Result: 2 NG REPLACE OUTER MIRROR ACTUATOR ASSEMBLY (DRIVER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000)
3. REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Temporarily replace the multiplex network master switch assembly with a new or known good one. Refer to «REMOVAL [04/2013 - ]»(ref-665802-S39186220902014102400000) Result Proceed to NEXT Result: 1 NEXT See step 4
4. CHECK POWER MIRROR CONTROL OPERATION Check the electrical remote control mirror function. Refer to «OPERATION CHECK [04/2013 - ]»(ref-665550-S02861934412014102400000) OK Electrical remote control mirror function operates normally. Result Proceed to OK NG Result: 1 OK END (MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY WAS DEFECTIVE) Result: 2 NG REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL [04/2013 - ]»(ref-665734-S14624714932014102400000)

Note. The power mirror control system (w/ Memory) uses the CAN communication system and LIN communication system. Inspect the communication functions by following How to Proceed with Troubleshooting. Troubleshoot the power window control system after confirming that the communication systems are functioning properly. Refer to HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ] If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [04/2013 - ]

1. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Master Switch / Data List. Read the Data List according to the display on the Techstream. Body Electrical > Master Switch > Data List Tester Display Measurement Item Range Normal Condition Diagnostic Note Mirror Selection SW (R) Mirror select switch signal for RH mirror OFF or ON OFF: Mirror select switch off ON: Mirror select switch R switch on - Mirror Position SW (L) Mirror adjust switch signal (Left) OFF or ON OFF: Mirror adjust switch not pressed left ON: Mirror adjust switch pressed left Check with the mirror select switch L or R switch on Mirror Position SW (R) Mirror adjust switch signal (Right) OFF or ON OFF: Mirror adjust switch not pressed right ON: Mirror adjust switch pressed right Check with the mirror select switch L or R switch on Mirror Position SW (Up) Mirror adjust switch signal (Up) OFF or ON OFF: Mirror adjust switch not pressed up ON: Mirror adjust switch pressed up Check with the mirror select switch L or R switch on Mirror Position SW (Dwn) Mirror adjust switch signal (Down) OFF or ON OFF: Mirror adjust switch not pressed down ON: Mirror adjust switch pressed down Check with the mirror select switch L or R switch on Body Electrical > Master Switch > Data List Tester Display Mirror Selection SW (R) Mirror Position SW (L) Mirror Position SW (R) Mirror Position SW (Up) Mirror Position SW (Dwn) OK On the Techstream screen, ON or OFF is displayed for each item according to the table above. Result Proceed to OK NG Result: 2 NG See step 3 Result: 1 OK See step 2
2. INSPECT OUTER MIRROR ACTUATOR ASSEMBLY (FRONT PASSENGER DOOR) (MIRROR SURFACE) Remove the outer mirror actuator assembly (front passenger door). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000) Inspect the outer mirror actuator assembly (front passenger door) (mirror surface). Refer to «INSPECTION [04/2013 - ]»(ref-665850-S29253690092014102400000) Result Proceed to OK NG Result: 1 OK REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (FRONT PASSENGER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S29959522862014102400000) Result: 2 NG REPLACE OUTER MIRROR ACTUATOR ASSEMBLY (FRONT PASSENGER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000)
3. REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Temporarily replace the multiplex network master switch assembly with a new or known good one. Refer to «REMOVAL [04/2013 - ]»(ref-665802-S39186220902014102400000) Result Proceed to NEXT Result: 1 NEXT See step 4
4. CHECK POWER MIRROR CONTROL OPERATION Check the electrical remote control mirror function. Refer to «OPERATION CHECK [04/2013 - ]»(ref-665550-S02861934412014102400000) OK Electrical remote control mirror function operates normally. Result Proceed to OK NG Result: 1 OK END (MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY WAS DEFECTIVE) Result: 2 NG REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL [04/2013 - ]»(ref-665734-S14624714932014102400000)

Note. The power mirror control system (w/ Memory) uses the CAN communication system and LIN communication system. Inspect the communication functions by following How to Proceed with Troubleshooting. Troubleshoot the power window control system after confirming that the communication systems are functioning properly. Refer to HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ] If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [04/2013 - ]

1. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Master Switch / Data List. Read the Data List according to the display on the Techstream. Body Electrical > Master Switch > Data List Tester Display Measurement Item Range Normal Condition Diagnostic Note Mirror Selection SW (L) Mirror select switch signal for LH mirror OFF or ON OFF: Mirror select switch off ON: Mirror select switch L switch on - Mirror Selection SW (R) Mirror select switch signal for RH mirror OFF or ON OFF: Mirror select switch off ON: Mirror select switch R switch on - Mirror Position SW (L) Mirror adjust switch signal (Left) OFF or ON OFF: Mirror adjust switch not pressed left ON: Mirror adjust switch pressed left Check with the mirror select switch L or R switch on Mirror Position SW (R) Mirror adjust switch signal (Right) OFF or ON OFF: Mirror adjust switch not pressed right ON: Mirror adjust switch pressed right Check with the mirror select switch L or R switch on Mirror Position SW (Up) Mirror adjust switch signal (Up) OFF or ON OFF: Mirror adjust switch not pressed up ON: Mirror adjust switch pressed up Check with the mirror select switch L or R switch on Mirror Position SW (Dwn) Mirror adjust switch signal (Down) OFF or ON OFF: Mirror adjust switch not pressed down ON: Mirror adjust switch pressed down Check with the mirror select switch L or R switch on Body Electrical > Master Switch > Data List Tester Display Mirror Selection SW (L) Mirror Selection SW (R) Mirror Position SW (L) Mirror Position SW (R) Mirror Position SW (Up) Mirror Position SW (Dwn) OK On the Techstream screen, ON or OFF is displayed for each item according to the table above. Result Proceed to OK NG Result: 2 NG REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY. Refer to «REMOVAL [04/2013 - ]»(ref-665802-S39186220902014102400000) Result: 1 OK See step 2
2. REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) Temporarily replace the main body ECU (multiplex network body ECU) with a new or known good one. Refer to «REMOVAL [04/2013 - ]»(ref-665734-S14624714932014102400000) Result Proceed to NEXT Result: 1 NEXT See step 3
3. CHECK POWER MIRROR CONTROL OPERATION Check the electrical remote control mirror function. Refer to «OPERATION CHECK [04/2013 - ]»(ref-665550-S02861934412014102400000) OK Electrical remote control mirror function operates normally. Result Proceed to OK NG Result: 1 OK END (MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) WAS DEFECTIVE) Result: 2 NG REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY. Refer to «REMOVAL [04/2013 - ]»(ref-665802-S39186220902014102400000)

Note. The power mirror control system (w/ Memory) uses the CAN communication system. First, confirm that there is no malfunction in the CAN communication system. Refer to the How to Proceed with Troubleshooting procedure. Refer to HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ] If the battery voltage is low, the mirror heater function may not operate. When "Operation of Electrical Items Restricted." is not displayed on the multi-information display in the combination meter assembly, check the Data List item "Battery Control Count (Body ECU)". Refer to DATA LIST / ACTIVE TEST [04/2013 - ] If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [04/2013 - ]

1. CHECK WINDOW DEFOGGER SYSTEM Check window defogger system operation. Refer to «OPERATION CHECK [04/2013 - ]»(ref-665880-S28977650192014102400000) OK Window defogger system is normal. Result Proceed to OK NG Result: 2 NG GO TO WINDOW DEFOGGER SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665880-S13431012142014102400000) Result: 1 OK See step 2
2. PERFORM ACTIVE TEST USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Mirror L or Mirror R / Active Test. Perform an Active Test according to the display on the Techstream. Body Electrical > Mirror L > Active Test Tester Display Measurement Item Control Range Diagnostic Note Mirror Heater Mirror heater operation OFF or ON Operate with the engine switch on (IG) and the vehicle stopped. This test turns the mirror heater on or off. Mirror heater operation can be confirmed by touch. Body Electrical > Mirror L > Active Test Tester Display Mirror Heater Body Electrical > Mirror R > Active Test Tester Display Measurement Item Control Range Diagnostic Note Mirror Heater Mirror heater operation OFF or ON Operate with the engine switch on (IG) and the vehicle stopped. This test turns the mirror heater on or off. Mirror heater operation can be confirmed by touch. Body Electrical > Mirror R > Active Test Tester Display Mirror Heater Result Result Proceed to Mirror heater operation on both mirrors is normal A Mirror heater operation on driver door mirror is not normal B Mirror heater operation on front passenger door mirror is not normal C Result: 1 A REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY. Refer to «REMOVAL [04/2013 - ]»(ref-665718-S03696019692014102400000) Result: 3 C See step 5 Result: 2 B See step 3
3. INSPECT OUTER MIRROR ACTUATOR ASSEMBLY (DRIVER DOOR) (MIRROR HEATER) Remove the outer mirror actuator assembly (driver door). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000) Remove the outer mirror actuator assembly (driver door) (mirror heater). Refer to «INSPECTION [04/2013 - ]»(ref-665850-S29253690092014102400000) Result Proceed to OK NG Result: 1 OK REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S29959522862014102400000) Result: 2 NG See step 4
4. INSPECT OUTER MIRROR (DRIVER DOOR) Remove the outer mirror (driver door). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S19367747912014102400000) Inspect the outer mirror (driver door). Refer to «INSPECTION [04/2013 - ]»(ref-665850-S22598739682014102400000) Result Proceed to OK NG Result: 1 OK REPLACE OUTER MIRROR ACTUATOR ASSEMBLY (DRIVER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000) Result: 2 NG REPLACE OUTER MIRROR (DRIVER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S19367747912014102400000)
5. INSPECT OUTER MIRROR ACTUATOR ASSEMBLY (FRONT PASSENGER DOOR) (MIRROR HEATER) Remove the outer mirror actuator assembly (front passenger door). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000) Remove the outer mirror actuator assembly (front passenger door) (mirror heater). Refer to «INSPECTION [04/2013 - ]»(ref-665850-S29253690092014102400000) Result Proceed to OK NG Result: 1 OK REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (FRONT PASSENGER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S29959522862014102400000) Result: 2 NG See step 6
6. INSPECT OUTER MIRROR (FRONT PASSENGER DOOR) Remove the outer mirror (front passenger door). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S19367747912014102400000) Inspect the outer mirror (front passenger door). Refer to «INSPECTION [04/2013 - ]»(ref-665850-S22598739682014102400000) Result Proceed to OK NG Result: 1 OK REPLACE OUTER MIRROR ACTUATOR ASSEMBLY (FRONT PASSENGER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000) Result: 2 NG REPLACE OUTER MIRROR (FRONT PASSENGER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S19367747912014102400000)

Note. The power mirror control system (w/ Memory) uses the CAN communication system. First, confirm that there is no malfunction in the CAN communication system. Refer to the How to Proceed with Troubleshooting procedure. Refer to HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ] If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [04/2013 - ] The mirror surface position will not be memorized if the engine switch is not on (IG). The mirror surface position will not be stored if the seat memory SET switch and 2 or more seat memory switches are pressed simultaneously. If the operation fails, the mirror surface position will not be memorized until the seat memory SET switch is released and the operation is attempted again. The mirror surface position will not be memorized when the mirror is operated manually.

HINT

Each outer rear view mirror assembly has a built-in mirror vertical position sensor and mirror horizontal position sensor.

Scheme 19

1. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Mirror L / Data List. Read the Data List according to the display on the Techstream. Body Electrical > Mirror L > Data List Tester Display Measurement Item Range Normal Condition Diagnostic Note Seat Memory Switch1 Seat memory switch M1 switch signal OFF or ON OFF: Seat memory switch M1 switch off ON: Seat memory switch M1 switch on - Seat Memory Switch2 Seat memory switch M2 switch signal OFF or ON OFF: Seat memory switch M2 switch off ON: Seat memory switch M2 switch on - Seat Memory Switch3 Seat memory switch M3 switch signal OFF or ON OFF: Seat memory switch M3 switch off ON: Seat memory switch M3 switch on - Seat Memory Set SW Seat memory switch SET switch signal OFF or ON OFF: Seat memory switch SET switch off ON: Seat memory switch SET switch on - Body Electrical > Mirror L > Data List Tester Display Seat Memory Switch1 Seat Memory Switch2 Seat Memory Switch3 Seat Memory Set SW OK On the Techstream screen, ON or OFF is displayed for each item according to the table above. Result Proceed to OK NG Result: 2 NG See step 8 Result: 1 OK See step 2
2. CHECK SEAT MEMORY SWITCH FUNCTION When any seat memory switch (M1, M2 or M3) is pressed, check that the driver seat moves to the memorized position. Refer to «OPERATION CHECK [04/2013 - ]»(ref-665543-S33272433052014102400000) OK The driver seat moves to the memorized position. Result Proceed to OK NG Result: 2 NG GO TO FRONT POWER SEAT CONTROL SYSTEM (Power Seat does not Return to Memorized Position). Refer to «Power Seat does not Return to Memorized Position [04/2013 - ]»(ref-665873-S23831592482014102400000) Result: 1 OK See step 3
3. CHECK MEMORY AND REACTIVATION FUNCTION Turn the engine switch on (IG). *a Turn to Fully Left Position Using the multiplex network master switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the multiplex network master switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the memorized fully left position. Result Result Proceed to Memory and reactivation functions on both mirrors are not normal A Memory and reactivation functions on driver door mirror are not normal B Memory and reactivation functions on front passenger door mirror are not normal C Result: 1 A REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL [04/2013 - ]»(ref-665734-S14624714932014102400000) Result: 3 C See step 6 Result: 2 B See step 4
4. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY (DRIVER DOOR) Temporarily replace the outer mirror actuator assembly (driver door) with a new or known good one. Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000) Result Proceed to NEXT Result: 1 NEXT See step 5
5. CHECK MEMORY AND REACTIVATION FUNCTION Turn the engine switch on (IG). *a Turn to Fully Left Position Using the multiplex network master switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the multiplex network master switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the memorized fully left position. Result Proceed to OK NG Result: 1 OK END (OUTER MIRROR ACTUATOR ASSEMBLY (DRIVER DOOR) WAS DEFECTIVE) Result: 2 NG REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000)
6. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY (FRONT PASSENGER DOOR) Temporarily replace the outer mirror actuator assembly (front passenger door) with a new or known good one. Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000) Result Proceed to NEXT Result: 1 NEXT See step 7
7. CHECK MEMORY AND REACTIVATION FUNCTION Turn the engine switch on (IG). *a Turn to Fully Left Position Using the multiplex network master switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the multiplex network master switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the memorized fully left position. Result Proceed to OK NG Result: 1 OK END (OUTER MIRROR ACTUATOR ASSEMBLY (FRONT PASSENGER DOOR) WAS DEFECTIVE) Result: 2 NG REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (FRONT PASSENGER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000)
8. INSPECT SEAT MEMORY SWITCH Remove the seat memory switch (driver door). Refer to «REMOVAL [04/2013 - ]»(ref-665743-S12102839082014102400000) Inspect the seat memory switch (driver door). Refer to «INSPECTION [04/2013 - ]»(ref-665743-S15057718432014102400000) Result Proceed to OK NG Result: 2 NG REPLACE SEAT MEMORY SWITCH. Refer to «REMOVAL [04/2013 - ]»(ref-665743-S12102839082014102400000) Result: 1 OK See step 9
9. CHECK HARNESS AND CONNECTOR (SEAT MEMORY SWITCH - OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER DOOR) - BODY GROUND) Disconnect the N9 outer mirror control ECU assembly (driver door) connector. Disconnect the N5 seat memory switch connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition N9-1 (MM) - N5-4 (MRY) Always Below 1 ohms N9-1 (MM) - Body ground Always 10 kohms or higher N5-4 (MRY) - Body ground Always 10 kohms or higher N9-2 (M1) - N5-1 (M1) Always Below 1 ohms N9-2 (M1) - Body ground Always 10 kohms or higher N5-1 (M1) - Body ground Always 10 kohms or higher N9-3 (M2) - N5-2 (M2) Always Below 1 ohms N9-3 (M2) - Body ground Always 10 kohms or higher N5-2 (M2) - Body ground Always 10 kohms or higher N9-4 (M3) - N5-3 (M3) Always Below 1 ohms N9-4 (M3) - Body ground Always 10 kohms or higher N5-3 (M3) - Body ground Always 10 kohms or higher N5-5 (E) - Body ground Always Below 1 ohms Result Proceed to OK NG Result: 1 OK REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000) Result: 2 NG REPAIR OR REPLACE HARNESS AND CONNECTOR

Note. The power mirror control system (w/ Memory) uses the CAN communication system. First, confirm that there is no malfunction in the CAN communication system. Refer to the How to Proceed with Troubleshooting procedure. Refer to HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ] If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [04/2013 - ]

1. CHECK SEAT MEMORY SWITCH FUNCTION When any seat memory switch (M1, M2 or M3) is pressed, check that the driver seat moves to the memorized position. Refer to «OPERATION CHECK [04/2013 - ]»(ref-665543-S33272433052014102400000) OK Driver seat moves to the memorized position. Result Proceed to OK NG Result: 2 NG GO TO FRONT POWER SEAT CONTROL SYSTEM (Power Seat does not Return to Memorized Position). Refer to «Power Seat does not Return to Memorized Position [04/2013 - ]»(ref-665873-S23831592482014102400000) Result: 1 OK See step 2
2. CHECK ELECTRICAL REMOTE CONTROL MIRROR FUNCTION Check the electrical remote control mirror function. Refer to «OPERATION CHECK [04/2013 - ]»(ref-665550-S02861934412014102400000) OK Electrical remote control mirror function is normal. Result Proceed to OK NG Result: 2 NG GO TO OTHER DIAGNOSIS PROCEDURE (Power Mirror cannot be Adjusted with Power Mirror Switch). Refer to «Power Mirror cannot be Adjusted with Power Mirror Switch [04/2013 - ]»(ref-665550-S41871887502014102400000) Result: 1 OK See step 3
3. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Mirror L or Mirror R / Data List. Read the Data List according to the display on the Techstream. Body Electrical > Mirror L > Data List Tester Display Measurement Item Range Normal Condition Diagnostic Note Mirror Memory No. 1 Mirror position memorized in memory switch M1 OFF or ON OFF: Not memorized ON: Memorized - Mirror Memory No. 2 Mirror position memorized in memory switch M2 OFF or ON OFF: Not memorized ON: Memorized - Mirror Memory No. 3 Mirror position memorized in memory switch M3 OFF or ON OFF: Not memorized ON: Memorized - Body Electrical > Mirror L > Data List Tester Display Mirror Memory No. 1 Mirror Memory No. 2 Mirror Memory No. 3 Body Electrical > Mirror R > Data List Tester Display Measurement Item Range Normal Condition Diagnostic Note Mirror Memory No. 1 Mirror position memorized in memory switch M1 OFF or ON OFF: Not memorized ON: Memorized - Mirror Memory No. 2 Mirror position memorized in memory switch M2 OFF or ON OFF: Not memorized ON: Memorized - Mirror Memory No. 3 Mirror position memorized in memory switch M3 OFF or ON OFF: Not memorized ON: Memorized - Body Electrical > Mirror R > Data List Tester Display Mirror Memory No. 1 Mirror Memory No. 2 Mirror Memory No. 3 OK ON (Memorized) appears on the screen. Result Proceed to OK NG Result: 2 NG GO TO OTHER DIAGNOSIS PROCEDURE (Power Mirror Surface Position is not Memorized). Refer to «Power Mirror Surface Position is not Memorized [04/2013 - ]»(ref-665550-S34399335772014102400000) Result: 1 OK See step 4
4. CHECK MEMORY AND REACTIVATION FUNCTION Turn the engine switch on (IG). *a Turn to Fully Left Position Using the multiplex network master switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the multiplex network master switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the memorized fully left position. Result Result Proceed to Memory and reactivation functions on both mirrors are not normal A Memory and reactivation function on driver door mirror is not normal B Memory and reactivation function on front passenger door mirror is not normal C Result: 1 A REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL [04/2013 - ]»(ref-665734-S14624714932014102400000) Result: 3 C See step 7 Result: 2 B See step 5
5. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY (DRIVER DOOR) Temporarily replace the outer mirror actuator assembly (driver door) with a new or known good one. Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000) Result Proceed to NEXT Result: 1 NEXT See step 6
6. CHECK MEMORY AND REACTIVATION FUNCTION Turn the engine switch on (IG). *a Turn to Fully Left Position Using the multiplex network master switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the multiplex network master switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the memorized fully left position. Result Proceed to OK NG Result: 1 OK END (OUTER MIRROR ACTUATOR ASSEMBLY (DRIVER DOOR) WAS DEFECTIVE) Result: 2 NG REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000)
7. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY (FRONT PASSENGER DOOR) Temporarily replace the outer mirror actuator assembly (front passenger door) with a new or known good one. Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000) Result Proceed to NEXT Result: 1 NEXT See step 8
8. CHECK MEMORY AND REACTIVATION FUNCTION Turn the engine switch on (IG). *a Turn to Fully Left Position Using the multiplex network master switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the multiplex network master switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the memorized fully left position. Result Proceed to OK NG Result: 1 OK END (OUTER MIRROR ACTUATOR ASSEMBLY (FRONT PASSENGER DOOR) WAS DEFECTIVE) Result: 2 NG REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (FRONT PASSENGER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S37716490412014102400000)

Note. The power mirror control system (w/ Memory) uses the CAN communication system. First, confirm that there is no malfunction in the CAN communication system. Refer to the How to Proceed with Troubleshooting procedure. Refer to HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ] If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [04/2013 - ]

HINT

The reverse shift-linked function will not activate when both the mirror select switch L and R switch are off.

Scheme 20

1. CHECK MEMORY AND REACTIVATION FUNCTION Turn the engine switch on (IG). *a Turn to Fully Left Position Using the multiplex network master switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the multiplex network master switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the memorized fully left position. Result Result Proceed to Memory and reactivation functions are normal A Memory function is not normal B Reactivation function is not normal C Result: 2 B GO TO OTHER DIAGNOSIS PROCEDURE (Power Mirror Surface Position is not Memorized). Refer to «Power Mirror Surface Position is not Memorized [04/2013 - ]»(ref-665550-S34399335772014102400000) Result: 3 C GO TO OTHER DIAGNOSIS PROCEDURE (Power Mirrors do not Return to Memorized Position). Refer to «Power Mirrors do not Return to Memorized Position [04/2013 - ]»(ref-665550-S20150055222014102400000) Result: 1 A See step 2
2. CHECK TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / DTC. Check if SFI system DTCs are output. Powertrain > Engine > Trouble Codes OK SFI system DTCs are not output. Result Proceed to OK NG Result: 2 NG GO TO SFI SYSTEM for 2GR-FSE: Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665553-S21212879812014102400000) for 4GR-FSE: Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665554-S38477685902014102400000) Result: 1 OK See step 3
3. CHECK COMBINATION METER ASSEMBLY Check if the shift position indicator light in the combination meter assembly operates normally. OK Shift position indicator light indicates the actual shift position correctly. Result Proceed to OK NG Result: 2 NG GO TO METER / GAUGE SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665542-S15097588262014102400000) Result: 1 OK See step 4
4. CHECK REVERSE SHIFT-LINKED FUNCTION Turn the engine switch on (IG). *a Turns Downward Turn the mirror select switch R or L switch on. Check that the mirror surface turns downward when the shift lever is moved to R. Result Result Proceed to Reverse shift-linked functions on both mirrors are not normal A Reverse shift-linked function on driver door is not normal B Reverse shift-linked function on front passenger door is not normal C Result: 2 B REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S29959522862014102400000) Result: 3 C REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (FRONT PASSENGER DOOR). Refer to «REMOVAL [04/2013 - ]»(ref-665850-S29959522862014102400000) Result: 1 A See step 5
5. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Master Switch / Data List. Read the Data List according to the display on the Techstream. Body Electrical > Master Switch > Data List Tester Display Measurement Item Range Normal Condition Diagnostic Note Mirror Selection SW (L) Mirror select switch signal for LH mirror OFF or ON OFF: Mirror select switch off ON: Mirror select switch L switch on - Mirror Selection SW (R) Mirror select switch signal for RH mirror OFF or ON OFF: Mirror select switch off ON: Mirror select switch R switch on - Body Electrical > Master Switch > Data List Tester Display Mirror Selection SW (L) Mirror Selection SW (R) OK On the Techstream screen, ON or OFF is displayed for each item according to the table above. Result Proceed to OK NG Result: 1 OK REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL [04/2013 - ]»(ref-665734-S14624714932014102400000) Result: 2 NG REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY. Refer to «REMOVAL [04/2013 - ]»(ref-665802-S39186220902014102400000)
