PROBLEM SYMPTOMS TABLE [04/2013 - ]
Note. If the battery voltage is low, the mirror heater function may not operate. When "Operation of Electrical Items Restricted." is displayed on the multi-information display in the combination meter assembly, check the Data List item "Battery Control Count (Body ECU)". Refer to DATA LIST / ACTIVE TEST [04/2013 - ]
HINT
- Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
- Inspect the fuses and relays related to this system before inspecting the suspected areas below.
| Symptom | Suspected Area | Link |
|---|---|---|
| Driver side power mirror cannot be adjusted with power mirror switch | Proceed to "Driver Side Power Mirror cannot be Adjusted with Power Mirror Switch" | Refer to Driver Side Power Mirror cannot be Adjusted with Power Mirror Switch [04/2013 - ] |
| Front passenger side power mirror cannot be adjusted with power mirror switch | Proceed to "Front Passenger Side Power Mirror cannot be Adjusted with Power Mirror Switch" | Refer to Front Passenger Side Power Mirror cannot be Adjusted with Power Mirror Switch [04/2013 - ] |
| Power mirror cannot be adjusted with power mirror switch | Proceed to "Power Mirror cannot be Adjusted with Power Mirror Switch" | Refer to Power Mirror cannot be Adjusted with Power Mirror Switch [04/2013 - ] |
| Mirror heater does not operate with rear defogger switch | Proceed to "Mirror Heater does not Operate with Rear Defogger Switch" | Refer to Mirror Heater does not Operate with Rear Defogger Switch [04/2013 - ] |
| Power mirror surface position is not memorized (Registration operation that does not use wireless or smart key is not functioning) | Proceed to "Power Mirror Surface Position is not Memorized" | Refer to Power Mirror Surface Position is not Memorized [04/2013 - ] |
| Power mirrors do not return to memorized position (Recall operation that does not use wireless or smart key is not functioning) | Proceed to "Power Mirrors do not Return to Memorized Position" | Refer to Power Mirrors do not Return to Memorized Position [04/2013 - ] |
| Reverse shift-linked function of power mirrors does not operate | Proceed to "Reverse Shift-linked Function of Power Mirrors does not Operate" | Refer to Reverse Shift-linked Function of Power Mirrors does not Operate [04/2013 - ] |
| Wireless transmitter memory function does not operate (Registration operation that uses wireless or smart key is not functioning) | Operation check - memory and reactivation function | Refer to OPERATION CHECK [04/2013 - ] |
| Front power seat control system | Refer to HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ] | |
| Outer mirror control ECU assembly (driver door) | ||
| Outer mirror control ECU assembly (front passenger door) | ||
| Wireless-linked return function does not operate (Recall operation that uses wireless or smart key is not functioning) | Operation check - memory and reactivation function | Refer to OPERATION CHECK [04/2013 - ] |
| Front power seat control system | Refer to HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ] | |
| Outer mirror control ECU assembly (driver door) | ||
| Outer mirror control ECU assembly (front passenger door) | ||
| Automatic glare-resistant EC mirror does not operate* | Inner rear view mirror assembly | Refer to INSPECTION [04/2013 - ] |
| Outer mirror actuator assembly (driver door) | ||
| Outer mirror actuator assembly (front passenger door) | ||
| Wire harness or connector |
POWER MIRROR CONTROL SYSTEM (W/ MEMORY)
- *: w/ EC Mirror
Scheme 8
![Scheme 8: TERMINALS OF ECU [04/2013 - ]](https://i.diagnostdata.com/repair/ad/ada69e2ff41f80872e6f1415955d78cc367e1cd93ea543e6af07f6391b5b01cb.webp)
Scheme 9
- CHECK OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER DOOR) Disconnect the N9 outer mirror control ECU assembly (driver door) connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition N9-14 (BDR) - Body ground G - Body ground +B power supply Always 11 to 14 V N9-6 (CPUB) - Body ground L - Body ground +B power supply Always 11 to 14 V N9-5 (SIG) - Body ground B - Body ground Ignition power supply Engine switch off --> on (IG) Below 1 V --> 11 to 14 V N9-7 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the N9 outer mirror control ECU assembly (driver door) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition z12-1 (MV) - z12-10 (M+) W - B Vertical mirror motor drive voltage Driver door mirror surface moving upward --> stopped 11 to 14 V --> Below 1 V z12-10 (M+) - z12-1 (MV) B - W Vertical mirror motor drive voltage Driver door mirror surface moving downward --> stopped 11 to 14 V --> Below 1 V z12-10 (M+) - z12-9 (MH) B - R Horizontal mirror motor drive voltage Driver door mirror surface moving right --> stopped 11 to 14 V --> Below 1 V z12-9 (MH) - z12-10 (M+) R - B Horizontal mirror motor drive voltage Driver door mirror surface moving left --> stopped 11 to 14 V --> Below 1 V z12-4 (+) - z12-12 (-) BR-W - B-R Mirror heater relay drive voltage Mirror heater switch (rear window defogger switch) on 11 to 14 V z12-5 (VC) - N9-7 (GND) SB - W-B Mirror position sensor power supply Engine switch on (IG) 4.75 to 5.25 V z12-6 (VSSR) - N9-7 (GND) V - W-B Mirror position sensor signal Engine switch on (IG) 0 to 5 V z12-13 (HSSR) - N9-7 (GND) LG - W-B Mirror position sensor signal Engine switch on (IG) 0 to 5 V z12-7 (EC+) - z12-15 (EC-) BR - B-L Automatic glare-resistant EC mirror drive signal Automatic glare-resistant EC mirror on 1.05 to 1.35 V Automatic glare-resistant EC mirror off Below 1 V N9-4 (M3) - N9-7 (GND) R - W-B M3 switch signal for seat memory switch M3 switch on Below 1 V M3 switch off 11 to 14 V N9-3 (M2) - N9-7 (GND) LG - W-B M2 switch signal for seat memory switch M2 switch on Below 1 V M2 switch off 11 to 14 V N9-2 (M1) - N9-7 (GND) BE - W-B M1 switch signal for seat memory switch M1 switch on Below 1 V M1 switch off 11 to 14 V N9-1 (MM) - N9-7 (GND) L - W-B SET switch signal for seat memory switch SET switch on Below 1 V SET switch off 11 to 14 V If the result is not as specified, the outer mirror control ECU assembly (driver door) may be malfunctioning.
- CHECK OUTER MIRROR CONTROL ECU ASSEMBLY (FRONT PASSENGER DOOR) Disconnect the N24 outer mirror control ECU assembly (front passenger door) connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition N24-14 (BDR) - Body ground B - Body ground +B power supply Always 11 to 14 V N24-6 (CPUB) - Body ground LG - Body ground +B power supply Always 11 to 14 V N24-5 (SIG) - Body ground R - Body ground Ignition power supply Engine switch off --> on (IG) Below 1 V --> 11 to 14 V N24-7 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the N24 outer mirror control ECU assembly (front passenger door) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition z11-1 (MV) - z11-10 (M+) W - B Vertical mirror motor drive voltage Front passenger door mirror surface moving upward --> stopped 11 to 14 V --> Below 1 V z11-10 (M+) - z11-1 (MV) B - W Vertical mirror motor drive voltage Front passenger door mirror surface moving downward --> stopped 11 to 14 V --> Below 1 V z11-10 (M+) - z11-9 (MH) B - R Horizontal mirror motor drive voltage Front passenger door mirror surface moving right --> stopped 11 to 14 V --> Below 1 V z11-9 (MH) - z11-10 (M+) R - B Horizontal mirror motor drive voltage Front passenger door mirror surface moving left --> stopped 11 to 14 V --> Below 1 V z11-4 (+) - z11-12 (-) GR-W - B-R Mirror heater relay drive voltage Mirror heater switch (rear window defogger switch) on 11 to 14 V z11-5 (VC) - N24-7 (GND) SB - W-B Mirror position sensor power supply Engine switch on (IG) 4.75 to 5.25 V z11-6 (VSRL) - N24-7 (GND) V - W-B Mirror position sensor signal Engine switch on (IG) 0 to 5 V z11-13 (HSRL) - N24-7 (GND) LG - W-B Mirror position sensor signal Engine switch on (IG) 0 to 5 V z11-7 (EC+) - z11-15 (EC-) BR - B-L Automatic glare-resistant EC mirror drive signal Automatic glare-resistant EC mirror on 1.05 to 1.35 V Automatic glare-resistant EC mirror off Below 1 V If the result is not as specified, the outer mirror control ECU assembly (front passenger door) may be malfunctioning.
DIAGNOSIS SYSTEM [04/2013 - ]
- CHECK DLC3 Check the DLC3. Refer to «GENERAL INFORMATION [04/2013 - ]»(ref-665529-S26412111322014102400000)
- INSPECT BATTERY VOLTAGE Measure the battery voltage. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery.
DATA LIST / ACTIVE TEST [04/2013 - ]
- DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Mirror L or Mirror R / Data List. Read the Data List according to the display on the Techstream. Body Electrical > Mirror L > Data List Tester Display Measurement Item Range Normal Condition Diagnostic Note Seat Memory Switch1 Seat memory switch M1 switch signal OFF or ON OFF: Seat memory switch M1 switch off ON: Seat memory switch M1 switch on - Seat Memory Switch2 Seat memory switch M2 switch signal OFF or ON OFF: Seat memory switch M2 switch off ON: Seat memory switch M2 switch on - Seat Memory Switch3 Seat memory switch M3 switch signal OFF or ON OFF: Seat memory switch M3 switch off ON: Seat memory switch M3 switch on - Seat Memory Set SW Seat memory switch SET switch signal OFF or ON OFF: Seat memory switch SET switch off ON: Seat memory switch SET switch on - Mirror Memory No. 1 Mirror position memorized in memory switch M1 OFF or ON OFF: Not memorized ON: Memorized - Mirror Memory No. 2 Mirror position memorized in memory switch M2 OFF or ON OFF: Not memorized ON: Memorized - Mirror Memory No. 3 Mirror position memorized in memory switch M3 OFF or ON OFF: Not memorized ON: Memorized - Mirror Memory No. 4 Mirror position memorized in memory switch M4* OFF or ON OFF: Not memorized ON: Memorized Not applicable Mirror Memory No. 5 Mirror position memorized in memory switch M5* OFF or ON OFF: Not memorized ON: Memorized Not applicable Mirror Memory No. 6 Mirror position memorized in memory switch M6* OFF or ON OFF: Not memorized ON: Memorized Not applicable Mirror Vertical Sensor Vol Vertical mirror position MIN: 0, MAX: 5 V 0 to 5 V - Mirror Horizontal Sensor Vol Horizontal mirror position MIN: 0, MAX: 5 V 0 to 5 V - Mirror Fold Detect Condition of retractable outer mirror* Error or Normal Error: Retractable outer mirror is malfunctioning Normal: Retractable outer mirror is normal Not applicable +B Voltage Input Value Power supply for outer mirror control ECU assembly MIN: 0 V, MAX: 25.5 V 11 to 14 V - # Codes Number of trouble codes 0 to 255 Number of stored DTCs displayed - *: Although the item is displayed on the Techstream, it is not applicable to this vehicle. Body Electrical > Mirror R > Data List Tester Display Measurement Item Range Normal Condition Diagnostic Note Seat Memory Switch1 Seat memory switch M1 switch signal* OFF or ON OFF: Seat memory switch M1 switch off ON: Seat memory switch M1 switch on Not applicable Seat Memory Switch2 Seat memory switch M2 switch signal* OFF or ON OFF: Seat memory switch M2 switch off ON: Seat memory switch M2 switch on Not applicable Seat Memory Switch3 Seat memory switch M3 switch signal* OFF or ON OFF: Seat memory switch M3 switch off ON: Seat memory switch M3 switch on Not applicable Seat Memory Set SW Seat memory switch SET switch signal* OFF or ON OFF: Seat memory switch SET switch off ON: Seat memory switch SET switch on Not applicable Mirror Memory No. 1 Mirror position memorized in memory switch M1 OFF or ON OFF: Not memorized ON: Memorized - Mirror Memory No. 2 Mirror position memorized in memory switch M2 OFF or ON OFF: Not memorized ON: Memorized - Mirror Memory No. 3 Mirror position memorized in memory switch M3 OFF or ON OFF: Not memorized ON: Memorized - Mirror Memory No. 4 Mirror position memorized in memory switch M4* OFF or ON OFF: Not memorized ON: Memorized Not applicable Mirror Memory No. 5 Mirror position memorized in memory switch M5* OFF or ON OFF: Not memorized ON: Memorized Not applicable Mirror Memory No. 6 Mirror position memorized in memory switch M6* OFF or ON OFF: Not memorized ON: Memorized Not applicable Mirror Vertical Sensor Vol Vertical mirror position MIN: 0, MAX: 5 V 0 to 5 V - Mirror Horizontal Sensor Vol Horizontal mirror position MIN: 0, MAX: 5 V 0 to 5 V - Mirror Fold Detect Condition of retractable outer mirror* Error or Normal Error: Retractable outer mirror is malfunctioning Normal: Retractable outer mirror is normal Not applicable +B Voltage Input Value Power supply for outer mirror control ECU assembly MIN: 0 V, MAX: 25.5 V 11 to 14 V - # Codes Number of trouble codes 0 to 255 Number of stored DTCs displayed - *: Although the item is displayed on the Techstream, it is not applicable to this vehicle. Enter the following menus: Body Electrical / Main Body / Data List. Read the Data List according to the display on the Techstream. Body Electrical > Main Body > Data List Tester Display Measurement Item Range Normal Condition Diagnostic Note Mem SW No. w/KeyID1 Switch linked with key ID1 NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID1 MEM SW1: M1 linked with key ID1 MEM SW2: M2 linked with key ID1 MEM SW3: M3 linked with key ID1 - Mem SW No. w/KeyID2 Switch linked with key ID2 NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID2 MEM SW1: M1 linked with key ID2 MEM SW2: M2 linked with key ID2 MEM SW3: M3 linked with key ID2 - Mem SW No. w/KeyID3 Switch linked with key ID3 NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID3 MEM SW1: M1 linked with key ID3 MEM SW2: M2 linked with key ID3 MEM SW3: M3 linked with key ID3 - Mem SW No. w/KeyID4 Switch linked with key ID4 NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID4 MEM SW1: M1 linked with key ID4 MEM SW2: M2 linked with key ID4 MEM SW3: M3 linked with key ID4 - Mem SW No. w/KeyID5 Switch linked with key ID5 NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID5 MEM SW1: M1 linked with key ID5 MEM SW2: M2 linked with key ID5 MEM SW3: M3 linked with key ID5 - Mem SW No. w/KeyID6 Switch linked with key ID6 NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID6 MEM SW1: M1 linked with key ID6 MEM SW2: M2 linked with key ID6 MEM SW3: M3 linked with key ID6 - Mem SW No. w/KeyID7 Switch linked with key ID7 NONE, MEM SW1, MEM SW2, or MEM SW3 NONE: No switches linked with key ID7 MEM SW1: M1 linked with key ID7 MEM SW2: M2 linked with key ID7 MEM SW3: M3 linked with key ID7 - Enter the following menus: Body Electrical / Master Switch / Data List. Read the Data List according to the display on the Techstream. Body Electrical > Master Switch > Data List Tester Display Measurement Item Range Normal Condition Diagnostic Note Mirror Selection SW (L) Mirror select switch signal for LH mirror OFF or ON OFF: Mirror select switch off ON: Mirror select switch L switch on - Mirror Selection SW (R) Mirror select switch signal for RH mirror OFF or ON OFF: Mirror select switch off ON: Mirror select switch R switch on - Mirror Position SW (L) Mirror adjust switch signal (Left) OFF or ON OFF: Mirror adjust switch not pressed left ON: Mirror adjust switch pressed left Check with the mirror select switch L or R switch on Mirror Position SW (R) Mirror adjust switch signal (Right) OFF or ON OFF: Mirror adjust switch not pressed right ON: Mirror adjust switch pressed right Check with the mirror select switch L or R switch on Mirror Position SW (Up) Mirror adjust switch signal (Up) OFF or ON OFF: Mirror adjust switch not pressed up ON: Mirror adjust switch pressed up Check with the mirror select switch L or R switch on Mirror Position SW (Dwn) Mirror adjust switch signal (Down) OFF or ON OFF: Mirror adjust switch not pressed down ON: Mirror adjust switch pressed down Check with the mirror select switch L or R switch on Outer Mirror Fold SW Retractable outer mirror switch signal* OFF or ON OFF: Retractable outer mirror switch off ON: Retractable outer mirror switch on Not applicable Auto Mirror SW Auto retractable outer mirror switch signal* OFF or ON OFF: Auto retractable outer mirror switch off ON: Auto retractable outer mirror switch on Not applicable *: Although the item is displayed on the Techstream, it is not applicable to this vehicle.
- ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Mirror L, Mirror R or Air Conditioner / Active Test. Perform the Active Test according to the display on the Techstream. Body Electrical > Mirror L > Active Test Tester Display Measurement Item Control Range Diagnostic Note Mirror Up/Down Mirror vertical operation OFF, Down or Up Operate with engine switch on (IG) and the vehicle stopped. This test tilts the mirror up or down. This operation can be confirmed by watching the mirror move in the desired direction. Mirror Right/Left Mirror horizontal operation OFF, Right or Left Operate with engine switch on (IG) and the vehicle stopped. This test tilts the mirror right or left. This operation can be confirmed by watching the mirror move in the desired direction. Mirror Heater Mirror heater operation OFF or ON Operate with engine switch on (IG) and the vehicle stopped. This test turns the mirror heater on or off. Mirror heater operation can be confirmed by touch. Body Electrical > Mirror R > Active Test Tester Display Measurement Item Control Range Diagnostic Note Mirror Up/Down Mirror vertical operation OFF, Down or Up Operate with engine switch on (IG) and the vehicle stopped. This test tilts the mirror up or down. This operation can be confirmed by watching the mirror move in the desired direction. Mirror Right/Left Mirror horizontal operation OFF, Right or Left Operate with engine switch on (IG) and the vehicle stopped. This test tilts the mirror right or left. This operation can be confirmed by watching the mirror move in the desired direction. Mirror Heater Mirror heater operation OFF or ON Operate with engine switch on (IG) and the vehicle stopped. This test turns the mirror heater on or off. Mirror heater operation can be confirmed by touch. Body Electrical > Air Conditioner > Active Test Tester Display Measurement Item Control Range Diagnostic Note Defogger Relay (Rear) Mirror Heater OFF or ON
