Power Window Control System (Diagnostic Codes & Symptom Tests): Diagnosis

INSPECTION PROCEDURE

Note. When the power window regulator motor assembly is reinstalled or replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly and holding it at the auto up position. Open the power window by fully pushing down the switch.

Scheme 100

Scheme 100: PROCEDURE

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

CHECK DTC OUTPUT Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-387457-S11667955312011022400000) . Check for DTCs. Refer to «DTC CHECK / CLEAR»(ref-387457-S11667955312011022400000) . Result Result Proceed to DTC output from multiplex network master switch assembly A DTC output from power window regulator motor assembly (for driver side) B DTC output from power window regulator motor assembly (for front passenger side) C DTC output from power window regulator motor assembly (for rear LH side) D DTC output from power window regulator motor assembly (for rear RH side) E E --> See step 11 D --> See step 8 C --> See step 5 B --> See step 3 A: Go to next step
READ VALUE USING TECHSTREAM (Master Switch) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Master Switch / Data List. Read the Data List according to the display on the Techstream. MASTER SWITCH (MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY) Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door P/W Auto SW Driver side power window auto switch signal / ON or OFF ON: Driver side power window auto switch operated OFF: Driver side power window auto switch not operated - P Door P/W Auto SW Front passenger side power window auto up/down switch signal / ON or OFF ON: Front passenger door power window auto switch operated OFF: Front passenger door power window auto switch not operated - RL Door P/W Auto SW Rear LH side power window auto up/down switch signal / ON or OFF ON: Rear LH power window auto switch operated OFF: Rear LH power window auto switch not operated - RR Door P/W Auto SW Rear RH side power window auto up/down switch signal / ON or OFF ON: Rear RH power window auto switch operated OFF: Rear RH power window auto switch not operated - P Door P/W Up SW Front passenger side power window manual up switch signal / ON or OFF ON: Front passenger door power window manual up switch operated OFF: Front passenger door power window manual up switch not operated - RL Door P/W Up SW Rear LH side power window manual up switch signal / ON or OFF ON: Rear LH power window manual up switch operated OFF: Rear LH power window manual up switch not operated - RR Door P/W Up SW Rear RH side power window manual up switch signal / ON or OFF ON: Rear RH power window manual up switch operated OFF: Rear RH power window manual up switch not operated - P Door P/W Down SW Front passenger side power window manual down switch signal / ON or OFF ON: Front passenger door power window manual down switch operated OFF: Front passenger door power window manual down switch not operated - RL Door P/W Down SW Rear LH side power window manual down switch signal / ON or OFF ON: Rear LH power window manual down switch operated OFF: Rear LH power window manual down switch not operated - RR Door P/W Down SW Rear RH side power window manual down switch signal / ON or OFF ON: Rear RH power window manual down switch operated OFF: Rear RH power window manual down switch not operated - Window Lock Switch Status Window lock switch signal / ON or OFF ON: Window lock switch LOCK position OFF: Window lock switch UNLOCK position - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 14 OK --> END (DUE TO SWITCH BEING OPERATED FOR 20 SECONDS OR MORE)
READ VALUE USING TECHSTREAM (D-Door Motor) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / D-Door Motor / Data List. Read the Data List according to the display on the Techstream. D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door P/W Up SW Driver side power window manual up switch signal / ON or OFF ON: Driver door power window manual up switch operated OFF: Driver door power window manual up switch not operated - D Door P/W Down SW Driver side power window manual down switch signal / ON or OFF ON: Driver door power window manual down switch operated OFF: Driver door power window manual down switch not operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 4 OK --> END (DUE TO SWITCH BEING OPERATED FOR 20 SECONDS OR MORE)
CHECK HARNESS AND CONNECTOR (MASTER SWITCH - DRIVER SIDE MOTOR) Disconnect the multiplex network master switch assembly connector. Disconnect the power window regulator motor assembly (for driver side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition M17-20 (U) - Body ground Always 10 kohms or higher M17-16 (D) - Body ground Always 10 kohms or higher M16-10 (UP1) - Body ground Always 10 kohms or higher M16-7 (DWN1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 18
READ VALUE USING TECHSTREAM (P-Door Motor) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / P-Door Motor / Data List. Read the Data List according to the display on the Techstream. P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note P Door P/W Auto SW Front passenger side power window auto up/down switch signal / ON or OFF ON: Front passenger side door power window auto switch operated OFF: Front passenger side door power window auto switch not operated - P Door P/W Up SW Front passenger side power window manual up switch signal / ON or OFF ON: Front passenger side door power window manual up switch operated OFF: Front passenger side door power window manual up switch not operated - P Door P/W Down SW Front passenger side power window manual down switch signal / ON or OFF ON: Front passenger side door power window manual down switch operated OFF: Front passenger side door power window manual down switch not operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 6 OK --> END (DUE TO SWITCH BEING OPERATED FOR 20 SECONDS OR MORE)
INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Front Passenger Side) Remove the power window regulator switch assembly (for front passenger side). Refer to «REMOVAL»(ref-387465-S06239671762011022400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 2 (U) - 5 (E) Auto up or up position Below 1 ohms 4 (A) - 5 (E) Auto up or auto down position Below 1 ohms 10 (D) - 5 (E) Auto down or down position Below 1 ohms 2 (U) - 5 (E) Free 10 kohms or higher 4 (A) - 5 (E) Free 10 kohms or higher 10 (D) - 5 (E) Free 10 kohms or higher NG --> See step 15 OK: Go to next step
CHECK HARNESS AND CONNECTOR (FRONT PASSENGER SIDE SWITCH - FRONT PASSENGER SIDE MOTOR) Disconnect the power window regulator motor assembly (for front passenger side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition L17-2 (U) - Body ground Always 10 kohms or higher L17-4 (A) - Body ground Always 10 kohms or higher L17-10 (D) - Body ground Always 10 kohms or higher L15-10 (UP1) - Body ground Always 10 kohms or higher L15-4 (AUTO) - Body ground Always 10 kohms or higher L15-7 (DWN1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 19
READ VALUE USING TECHSTREAM (RL-Door Motor) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / RL-Door Motor / Data List. Read the Data List according to the display on the Techstream. RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note RL Door P/W Auto SW Rear LH side power window auto up/down switch signal / ON or OFF ON: Rear LH door power window auto switch operated OFF: Rear LH door power window auto switch not operated - RL Door P/W Up SW Rear LH side power window manual up switch signal / ON or OFF ON: Rear LH door power window manual up switch operated OFF: Rear LH door power window manual up switch not operated - RL Door P/W Down SW Rear LH side power window manual down switch signal / ON or OFF ON: Rear LH door power window manual down switch operated OFF: Rear LH door power window manual down switch not operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 9 OK --> END (DUE TO SWITCH BEING OPERATED FOR 20 SECONDS OR MORE)
INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear LH Side) Remove the power window regulator switch assembly (for rear LH side). Refer to «REMOVAL»(ref-387465-S03559737962011022400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 2 (U) - 5 (E) Auto up or up position Below 1 ohms 4 (A) - 5 (E) Auto up or auto down position Below 1 ohms 10 (D) - 5 (E) Auto down or down position Below 1 ohms 2 (U) - 5 (E) Free 10 kohms or higher 4 (A) - 5 (E) Free 10 kohms or higher 10 (D) - 5 (E) Free 10 kohms or higher NG --> See step 16 OK: Go to next step
CHECK HARNESS AND CONNECTOR (REAR LH SWITCH - REAR LH MOTOR) Disconnect the power window regulator motor assembly (for rear LH side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition O9-2 (U) - Body ground Always 10 kohms or higher O9-4 (A) - Body ground Always 10 kohms or higher O9-10 (D) - Body ground Always 10 kohms or higher O10-10 (UP1) - Body ground Always 10 kohms or higher O10-4 (AUTO) - Body ground Always 10 kohms or higher O10-7 (DWN1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 20
READ VALUE USING TECHSTREAM (RR-Door Motor) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / RR-Door Motor / Data List. Read the Data List according to the display on the Techstream. RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note RR Door P/W Auto SW Rear RH side power window auto up/down switch signal / ON or OFF ON: Rear RH door power window auto switch operated OFF: Rear RH door power window auto switch not operated - RR Door P/W Up SW Rear RH side power window manual up switch signal / ON or OFF ON: Rear RH door power window manual up switch operated OFF: Rear RH door power window manual up switch not operated - RR Door P/W Down SW Rear RH side power window manual down switch signal / ON or OFF ON: Rear RH door power window manual down switch operated OFF: Rear RH door power window manual down switch not operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 12 OK --> END (DUE TO SWITCH BEING OPERATED FOR 20 SECONDS OR MORE)
INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear RH Side) Remove the power window regulator switch assembly (for rear RH side). Refer to «REMOVAL»(ref-387465-S03559737962011022400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 2 (U) - 5 (E) Auto up or up position Below 1 ohms 4 (A) - 5 (E) Auto up or auto down position Below 1 ohms 10 (D) - 5 (E) Auto down or down position Below 1 ohms 2 (U) - 5 (E) Free 10 kohms or higher 4 (A) - 5 (E) Free 10 kohms or higher 10 (D) - 5 (E) Free 10 kohms or higher NG --> See step 17 OK: Go to next step
CHECK HARNESS AND CONNECTOR (REAR RH SWITCH - REAR RH MOTOR) Disconnect the power window regulator motor assembly (for rear RH side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition N9-2 (U) - Body ground Always 10 kohms or higher N9-4 (A) - Body ground Always 10 kohms or higher N9-10 (D) - Body ground Always 10 kohms or higher N10-10 (UP1) - Body ground Always 10 kohms or higher N10-4 (AUTO) - Body ground Always 10 kohms or higher N10-7 (DWN1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 21
REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY. Refer to «DISASSEMBLY - Step 2»(ref-387450-S00524585432011022400000)
REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Front Passenger Side). Refer to «REMOVAL»(ref-387465-S06239671762011022400000)
REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear LH side). Refer to «REMOVAL»(ref-387465-S03559737962011022400000)
REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear RH side). Refer to «REMOVAL»(ref-387465-S03559737962011022400000)
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000)
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Front Passenger Side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000)
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear LH side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000)
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear RH side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000)

Note. The power window control system uses a multiplex communication system (BEAN). Inspect the communication function by following How to Proceed with Troubleshooting. Refer to HOW TO PROCEED WITH TROUBLESHOOTING . Troubleshoot the power window control system after confirming that the communication system is functioning properly. When the power window regulator motor assembly (for driver side) is reinstalled or replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the multiplex network master switch assembly and holding it at the auto up position. Open the power window by fully pushing down the multiplex network master switch assembly. When the ECU determines that the power window regulator motor assembly (for driver side) has a malfunction, DTC B2311 is set.

Scheme 107

Scheme 107: PROCEDURE

Scheme 108

CHECK DTC OUTPUT (MULTIPLEX COMMUNICATION SYSTEM) Use the Techstream to check if the multiplex communication system (BEAN) is functioning normally. Refer to «DTC CHECK / CLEAR»(ref-387386-S41628963162011022400000) . OK DTC(s) is not output. NG --> See step 10 OK: Go to next step
READ VALUE USING TECHSTREAM (D-Door Motor) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / D-Door Motor / Data List. Read the Data List according to the display on the Techstream. D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door P/W Up SW Driver side power window manual up switch signal / ON or OFF ON: Driver door power window manual up switch operated OFF: Driver door power window manual up switch not operated - D Door P/W Down SW Driver side power window manual down switch signal / ON or OFF ON: Driver door power window manual down switch operated OFF: Driver door power window manual down switch not operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 4 OK: Go to next step
PERFORM ACTIVE TEST USING TECHSTREAM (D-Door Motor) Enter the following menus: Body Electrical / D-Door Motor / Active Test. Perform the Active Test according to the display on the Techstream. D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER SIDE)) Tester Display Test Part Control Range Diagnostic Note Power Window Power window UP or OFF - Power Window Power window DOWN or OFF - OK Driver side power window operates normally. WARNING: Be careful to avoid injuries as this test causes vehicle parts to move. During the Active Test, the jam protection function will not operate. NG --> See step 8 OK --> See step 9
CHECK HARNESS AND CONNECTOR (MASTER SWITCH - DRIVER SIDE MOTOR) Disconnect the multiplex network master switch assembly connector. Disconnect the power window regulator motor assembly (for driver side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition M17-20 (U) - M16-10 (UP1) Always Below 1 ohms M17-16 (D) - M16-7 (DWN1) Always Below 1 ohms M17-9 (LIN2) - M16-9 (LIN) Always Below 1 ohms M17-20 (U) - Body ground Always 10 kohms or higher M17-16 (D) - Body ground Always 10 kohms or higher M17-9 (LIN2) - Body ground Always 10 kohms or higher M16-10 (UP1) - Body ground Always 10 kohms or higher M16-7 (DWN1) - Body ground Always 10 kohms or higher M16-9 (LIN) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK HARNESS AND CONNECTOR (REGULATOR MOTOR - BATTERY AND BODY GROUND) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition M16-2 (B) - Body ground Always 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition M16-1 (E) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Replace the multiplex network master switch assembly. Refer to «DISASSEMBLY - Step 2»(ref-387450-S00524585432011022400000) . NEXT: Go to next step
CHECK MANUAL UP / DOWN FUNCTION (for Driver Side) Check that the driver side door power window moves when the manual up/down function of the multiplex network master switch assembly is operated. Refer to «OPERATION CHECK»(ref-387457-S01402700302011022400000) . OK Driver side manual up/down function is normal. NG --> See step 8 OK --> END (MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY IS DEFECTIVE)
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000)
REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY. Refer to «DISASSEMBLY - Step 2»(ref-387450-S00524585432011022400000)
GO TO MULTIPLEX COMMUNICATION SYSTEM (Proceed to Diagnostic Trouble Code Chart). Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-387386-S38489328662011022400000)

Note. When the power window regulator motor assembly (for front passenger side) is reinstalled or replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the power window regulator switch assembly (for front passenger side) and holding it at the auto up position. Open the power window by fully pushing down the power window regulator switch assembly (for front passenger side). When the ECU determines that the power window regulator motor assembly (for front passenger side) has a malfunction, DTC B2311 is set.

Scheme 109

Scheme 109: PROCEDURE

Scheme 110

Scheme 111

PERFORM ACTIVE TEST USING TECHSTREAM (P-Door Motor) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / P-Door Motor / Active Test. Perform the Active Test according to the display on the Techstream. P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER SIDE)) Tester Display Test Part Control Range Diagnostic Note Power Window Power window UP or OFF - Power Window Power window DOWN or OFF - OK Front passenger side power window operates normally. WARNING: Be careful to avoid injuries as this test causes vehicle parts to move. During the Active Test, the jam protection function will not operate. NG --> See step 7 OK: Go to next step
READ VALUE USING TECHSTREAM (P-Door Motor) Enter the following menus: Body Electrical / P-Door Motor / Data List. Read the Data List according to the display on the Techstream. P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note P Door P/W Up SW Front passenger side power window manual up switch signal / ON or OFF ON: Front passenger door power window manual up switch operated OFF: Front passenger power window manual up switch not operated - P Door P/W Down SW Front passenger side power window manual down switch signal / ON or OFF ON: Front passenger door power window manual down switch operated OFF: Front passenger power window manual down switch not operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 5 OK: Go to next step
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Front Passenger Side) Replace the power window regulator motor assembly (for front passenger side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000) . NEXT: Go to next step
CHECK MANUAL UP / DOWN FUNCTION Check that the passenger side door power window moves when the manual up/down function of the power window regulator assembly (for front passenger side) is operated. Refer to «OPERATION CHECK»(ref-387457-S01402700302011022400000) . OK Passenger side manual up/down function is normal. NG --> See step 10 OK --> END (POWER WINDOW REGULATOR MOTOR ASSEMBLY IS DEFECTIVE)
INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Front Passenger Side) Remove the power window regulator switch assembly (for front passenger side). Refer to «REMOVAL»(ref-387465-S06239671762011022400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 2 (U) - 5 (E) Auto up or up position Below 1 ohms 10 (D) - 5 (E) Auto down or down position Below 1 ohms NG --> See step 9 OK: Go to next step
CHECK HARNESS AND CONNECTOR (FRONT PASSENGER SIDE SWITCH - MOTOR AND BODY GROUND) Disconnect the power window regulator motor assembly (for front passenger side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition L17-2 (U) - L15-10 (UP1) Always Below 1 ohms L17-10 (D) - L15-7 (DWN1) Always Below 1 ohms L17-5 (E) - Body ground Always Below 1 ohms L17-2 (U) - Body ground Always 10 kohms or higher L17-10 (D) - Body ground Always 10 kohms or higher L15-10 (UP1) - Body ground Always 10 kohms or higher L15-7 (DWN1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
CHECK HARNESS AND CONNECTOR (REGULATOR MOTOR - BATTERY AND BODY GROUND) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition L15-2 (B) - Body ground Always 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition L15-1 (E) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Front Passenger Side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000)
REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Front Passenger Side). Refer to «REMOVAL»(ref-387465-S06239671762011022400000)
REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY. Refer to «DISASSEMBLY - Step 2»(ref-387450-S00524585432011022400000)

Note. When the power window regulator motor assembly (for rear LH side) is reinstalled or replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the power window regulator switch assembly (for rear LH side) and holding it at the auto up position. Open the power window by fully pushing down the power window regulator switch assembly (for rear LH side). When the ECU determines that the power window regulator motor assembly (for rear LH side) has a malfunction, DTC B2311 is set.

Scheme 112

Scheme 112: PROCEDURE

Scheme 113

Scheme 114

PERFORM ACTIVE TEST USING TECHSTREAM (RL-Door Motor) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / RL-Door Motor / Active Test. Perform the Active Test according to the display on the Techstream. RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE)) Tester Display Test Part Control Range Diagnostic Note Power Window Power window UP or OFF - Power Window Power window DOWN or OFF - OK Rear LH power window operates normally. WARNING: Be careful to avoid injuries as this test causes vehicle parts to move. During the Active Test, the jam protection function will not operate. NG --> See step 7 OK: Go to next step
READ VALUE USING TECHSTREAM (RL-Door Motor) Enter the following menus: Body Electrical / RL-Door Motor / Data List. Read the Data List according to the display on the Techstream. RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note RL Door P/W Up SW Rear LH side power window manual up switch signal / ON or OFF ON: Rear LH door power window manual up switch operated OFF: Rear LH door power window manual up switch not operated - RL Door P/W Down SW Rear LH side power window manual down switch signal / ON or OFF ON: Rear LH door power window manual down switch operated OFF: Rear LH door power window manual down switch not operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 5 OK: Go to next step
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear LH Side) Replace the power window regulator motor assembly (for rear LH side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000) . NEXT: Go to next step
CHECK MANUAL UP / DOWN FUNCTION Check that the rear LH side door power window moves when the manual up/down function of the power window regulator assembly (for rear LH side) is operated. Refer to «OPERATION CHECK»(ref-387457-S01402700302011022400000) . OK Rear LH side manual up/down function is normal. NG --> See step 10 OK --> END (POWER WINDOW REGULATOR MOTOR ASSEMBLY IS DEFECTIVE)
INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear LH Side) Remove the power window regulator switch assembly (for rear LH side). Refer to «REMOVAL»(ref-387465-S03559737962011022400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 2 (U) - 5 (E) Auto up or up position Below 1 ohms 10 (D) - 5 (E) Auto down or down position Below 1 ohms NG --> See step 9 OK: Go to next step
CHECK HARNESS AND CONNECTOR (REAR LH SIDE SWITCH - REAR LH SIDE MOTOR AND BODY GROUND) Disconnect the power window regulator motor assembly (for rear LH side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition O9-2 (U) - O10-10 (UP1) Always Below 1 ohms O9-10 (D) - O10-7 (DWN1) Always Below 1 ohms O9-5 (E) - Body ground Always Below 1 ohms O9-2 (U) - Body ground Always 10 kohms or higher O9-10 (D) - Body ground Always 10 kohms or higher O10-10 (UP1) - Body ground Always 10 kohms or higher O10-7 (DWN1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
CHECK HARNESS AND CONNECTOR (REGULATOR MOTOR - BATTERY AND BODY GROUND) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition O10-2 (B) - Body ground Always 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition O10-1 (E) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear LH side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000)
REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear LH side). Refer to «REMOVAL»(ref-387465-S03559737962011022400000)
REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY. Refer to «DISASSEMBLY - Step 2»(ref-387450-S00524585432011022400000)

Note. When the power window regulator motor assembly (for rear RH side) is reinstalled or replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the power window regulator switch assembly (for rear RH side) and holding it at the auto up position. Open the power window by fully pushing down the power window regulator switch assembly (for rear RH side). When the ECU determines that the power window regulator motor assembly (for rear RH side) has a malfunction, DTC B2311 is set.

Scheme 115

Scheme 115: PROCEDURE

Scheme 116

Scheme 117

PERFORM ACTIVE TEST USING TECHSTREAM (RR-Door Motor) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / RR-Door Motor / Active Test. Perform the Active Test according to the display on the Techstream. RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE)) Tester Display Test Part Control Range Diagnostic Note Power Window Power window UP or OFF - Power Window Power window DOWN or OFF - OK Rear RH power window operates normally. WARNING: Be careful to avoid injuries as this test causes vehicle parts to move. During the Active Test, the jam protection function will not operate. NG --> See step 7 OK: Go to next step
READ VALUE USING TECHSTREAM (RR-Door Motor) Enter the following menus: Body Electrical / RR-Door Motor / Data List. Read the Data List according to the display on the Techstream. RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note RR Door P/W Up SW Rear RH side power window manual up switch signal / ON or OFF ON: Rear RH door power window manual up switch operated OFF: Rear RH door power window manual up switch not operated - RR Door P/W Down SW Rear RH side power window manual down switch signal / ON or OFF ON: Rear RH door power window manual down switch operated OFF: Rear RH door power window manual down switch not operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 5 OK: Go to next step
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear RH Side) Replace the power window regulator motor assembly (for rear RH side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000) . NEXT: Go to next step
CHECK MANUAL UP / DOWN FUNCTION Check that the rear RH side door power window moves when the manual up/down function of the power window regulator assembly (for rear RH side) is operated. Refer to «OPERATION CHECK»(ref-387457-S01402700302011022400000) . OK Rear RH side manual up/down function is normal. NG --> See step 10 OK --> END (POWER WINDOW REGULATOR MOTOR ASSEMBLY IS DEFECTIVE)
INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear RH Side) Remove the power window regulator switch assembly (for rear RH side). Refer to «REMOVAL»(ref-387465-S03559737962011022400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 2 (U) - 5 (E) Auto up or up position Below 1 ohms 10 (D) - 5 (E) Auto down or down position Below 1 ohms NG --> See step 9 OK: Go to next step
CHECK HARNESS AND CONNECTOR (REAR RH SIDE SWITCH - REAR RH SIDE MOTOR AND BODY GROUND) Disconnect the power window regulator motor assembly (for rear RH side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition N9-2 (U) - N10-10 (UP1) Always Below 1 ohms N9-10 (D) - N10-7 (DWN1) Always Below 1 ohms N9-5 (E) - Body ground Always Below 1 ohms N9-2 (U) - Body ground Always 10 kohms or higher N9-10 (D) - Body ground Always 10 kohms or higher N10-10 (UP1) - Body ground Always 10 kohms or higher N10-7 (DWN1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
CHECK HARNESS AND CONNECTOR (REGULATOR MOTOR - BATTERY AND BODY GROUND) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition N10-2 (B) - Body ground Always 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition N10-1 (E) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear RH side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000)
REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear RH side). Refer to «REMOVAL»(ref-387465-S03559737962011022400000)
REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY. Refer to «DISASSEMBLY - Step 2»(ref-387450-S00524585432011022400000)

Note. When the power window regulator motor assembly (for driver side) is reinstalled or replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the multiplex network master switch assembly and holding it at the auto up position. Open the power window by fully pushing down the multiplex network master switch assembly. When the ECU determines that the power window regulator motor assembly (for driver side) has a malfunction, DTC B2311 is set.

Scheme 118

Scheme 118: PROCEDURE

Scheme 119

CHECK DTC OUTPUT Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-387457-S11667955312011022400000) . Recheck for DTCs. Result Result Proceed to No DTCs output A DTC B2311 is output B DTC B2312 is output C DTC B2313 is output D D --> See step 9 C --> See step 8 B --> See step 7 A: Go to next step
READ VALUE USING TECHSTREAM (P-Door Motor) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / P-Door Motor / Data List. Read the Data List according to the display on the Techstream. P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note P Door P/W Auto SW Front passenger side power window auto switch signal / ON or OFF ON: Front passenger door power window auto switch operated OFF: Front passenger door power window auto switch not operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 3 OK --> See step 5
CHECK HARNESS AND CONNECTOR (POWER WINDOW SWITCH - REGULATOR MOTOR) Disconnect the power window regulator switch assembly (for front passenger side) connector. Disconnect the power window regulator motor assembly (for front passenger side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition L17-4 (A) - L15-4 (AUTO) Always Below 1 ohms L17-4 (A) - Body ground Always 10 kohms or higher L15-4 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Front Passenger Side) Remove the power window regulator switch assembly (for front passenger side). Refer to «REMOVAL»(ref-387465-S06239671762011022400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 4 (A) - 5 (E) Auto up or auto down position Below 1 ohms NG --> See step 6 OK --> See step 5
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Front Passenger Side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000)
REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Front Passenger Side). Refer to «REMOVAL»(ref-387465-S06239671762011022400000)
GO TO DTC (B2311). Refer to «DTC B2311: Power Window Motor Malfunction»(ref-387476-S06272341832011022400000)
GO TO DTC (B2312). Refer to «DTC B2312: Power Window Switch Malfunction»(ref-387476-S20743779892011022400000)
GO TO DTC (B2313). Refer to «DTC B2313: Glass Position Initialization Incomplete»(ref-387476-S30985322432011022400000)

Scheme 120

Scheme 120: PROCEDURE

Scheme 121

CHECK DTC OUTPUT Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-387457-S11667955312011022400000) . Recheck for DTCs. Result Result Proceed to No DTCs output A DTC B2311 is output B DTC B2312 is output C DTC B2313 is output D D --> See step 9 C --> See step 8 B --> See step 7 A: Go to next step
READ VALUE USING TECHSTREAM (RL-Door Motor) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / RL-Door Motor / Data List. Read the Data List according to the display on the Techstream. RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note RL Door P/W Auto SW Rear LH side power window auto switch signal / ON or OFF ON: Rear LH power window auto switch operated OFF: Rear LH power window auto switch not operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 3 OK --> See step 5
CHECK HARNESS AND CONNECTOR (REAR LH SIDE SWITCH - REAR LH SIDE MOTOR) Disconnect the power window regulator switch assembly (for rear LH side) connector. Disconnect the power window regulator motor assembly (for rear LH side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition O9-4 (A) - O10-4 (AUTO) Always Below 1 ohms O9-4 (A) - Body ground Always 10 kohms or higher O10-4 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear LH Side) Remove the power window regulator switch assembly (for rear LH side). Refer to «REMOVAL»(ref-387465-S03559737962011022400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 4 (A) - 5 (E) Auto up or auto down position Below 1 ohms NG --> See step 6 OK --> See step 5
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear LH Side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000)
REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear LH Side). Refer to «REMOVAL»(ref-387465-S03559737962011022400000)
GO TO DTC (B2311). Refer to «DTC B2311: Power Window Motor Malfunction»(ref-387476-S06272341832011022400000)
GO TO DTC (B2312). Refer to «DTC B2312: Power Window Switch Malfunction»(ref-387476-S20743779892011022400000)
GO TO DTC (B2313). Refer to «DTC B2313: Glass Position Initialization Incomplete»(ref-387476-S30985322432011022400000)

Scheme 122

Scheme 122: PROCEDURE

Scheme 123

CHECK DTC OUTPUT Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-387457-S11667955312011022400000) . Recheck for DTCs. Result Result Proceed to No DTCs output A DTC B2311 is output B DTC B2312 is output C DTC B2313 is output D D --> See step 9 C --> See step 8 B --> See step 7 A: Go to next step
READ VALUE USING TECHSTREAM (RR-Door Motor) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / RR-Door Motor / Data List. Read the Data List according to the display on the Techstream. RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note RR Door P/W Auto SW Rear RH side power window auto switch signal / ON or OFF ON: Rear RH power window auto switch operated OFF: Rear RH power window auto switch not operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 3 OK --> See step 5
CHECK HARNESS OR CONNECTOR (REAR RH SIDE SWITCH - REAR RH SIDE MOTOR) Disconnect the power window regulator switch assembly (for rear RH side) connector. Disconnect the power window regulator motor assembly (for rear RH side) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition N9-4 (A) - N10-4 (AUTO) Always Below 1 ohms N9-4 (A) - Body ground Always 10 kohms or higher N10-4 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear RH Side) Remove the power window regulator switch assembly (for rear RH side). Refer to «REMOVAL»(ref-387465-S03559737962011022400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 4 (A) - 5 (E) Auto up or auto down position Below 1 ohms NG --> See step 6 OK --> See step 5
REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear RH Side). Refer to «REMOVAL»(ref-387465-S10157975862011022400000)
REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear RH Side). Refer to «REMOVAL»(ref-387465-S03559737962011022400000)
GO TO DTC (B2311). Refer to «DTC B2311: Power Window Motor Malfunction»(ref-387476-S06272341832011022400000)
GO TO DTC (B2312). Refer to «DTC B2312: Power Window Switch Malfunction»(ref-387476-S20743779892011022400000)
GO TO DTC (B2313). Refer to «DTC B2313: Glass Position Initialization Incomplete»(ref-387476-S30985322432011022400000)
