Engine Control (Sfi) System (Dtcs P0010 - P0368): Other

MONITOR STRATEGY

Related DTCs	P0010: VVT OCV (bank 1) open/short P0020: VVT OCV (bank 2) open/short
Required sensors / components (Main)	VVT OCV (Variable Valve Timing oil control valve)
Required sensors / components (Sub)
Frequency of operation	Continuous
Duration	1 second
MIL operation	Immediately
Sequence of operation	None

TYPICAL ENABLING CONDITIONS

Monitor runs whenever following DTCs are not present	None
All of the following conditions are met
Starter	OFF
Engine switch	On (IG)
Time after engine switch off to on (IG)	0.5 seconds or more

TYPICAL MALFUNCTION THRESHOLDS

One of the following conditions is met	A, B or C
A. All of the following conditions are met	A, b and c
A. Battery voltage	11 V or more, and less than 13 V
B. Target duty ratio	Less than 70%
C. Output signal duty ratio	100% or more
B. All of the following conditions are met	D, e and f
D. Battery voltage	13 V or more
E. Target duty ratio	Less than 80%
F. Output signal duty ratio	100% or more
C. Both of the following conditions are met	G and h
G. Current cut status	Not cut
H. Output signal duty ratio	3% or less

COMPONENT OPERATING RANGE

OCV current

3 to 100%

Scheme 283

Scheme 283: WIRING DIAGRAM

Related DTCs	P0011: Advanced camshaft timing (bank 1) P0012: Retard camshaft timing (bank 1) P0021: Advanced camshaft timing (bank 2) P0022: Retard camshaft timing (bank 2)
Required sensors / components (Main)	VVT OCV and VVT Actuator
Required sensors / components (Sub)	Crankshaft position sensor, camshaft position sensor and Engine coolant temperature sensor
Frequency of operation	Once per drive cycle
Duration	Within 10 seconds
MIL operation	Advanced camshaft timing (bank 1): Immediately Advanced camshaft timing (bank 2): Immediately Retard camshaft timing (bank 1): 2 driving cycle Retard camshaft timing (bank 2): 2 driving cycle
Sequence of operation	None

Monitor runs whenever following DTCs are not present	P0010, P0020 (OCV bank 1, 2) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0100, P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor)
Battery voltage	11 V or more
Engine RPM	500 to 4000 RPM
ECT	75 to 100°C (167 to 212°F)

All of the following conditions are met
Deviation of actual valve timing and target valve timing	More than 5°CA (Crankshaft angle)
Valve timing	No change at advanced valve timing

ADVANCED CAMSHAFT TIMING

All of the following conditions are met
Deviation of actual valve timing and target valve timing	More than 5°CA (Crankshaft angle)
Valve timing	No change at retarded valve timing

RETARD CAMSHAFT TIMING

Related DTCs	P0013: VVT OCV (bank 1) open/short P0023: VVT OCV (bank 2) open/short
Required sensors / components (Main)	VVT OCV (Variable Valve Timing oil control valve)
Required sensors / components (Sub)
Frequency of operation	Continuous
Duration	1 second
MIL operation	Immediately
Sequence of operation	None

Monitor runs whenever following DTCs are not present	None
All of the following conditions are met
Starter	OFF
Engine switch	On (IG)
Time after engine switch off to on (IG)	0.5 seconds or more

One of the following conditions is met	A, B or C
A. All of the following conditions are met	A, b and c
A. Battery voltage	11 V or more, and less than 13 V
B. Target duty ratio	Less than 70%
C. Output signal duty ratio	100% or more
B. All of the following conditions are met	D, e and f
D. Battery voltage	13 V or more
E. Target duty ratio	Less than 80%
F. Output signal duty ratio	100% or more
C. All of the following conditions are met	G and h
G. Current cut status	Not cut
H. Output signal duty ratio	3% or less

OCV current

3 to 100%

Scheme 284

Scheme 284: WIRING DIAGRAM

Related DTCs	P0014: Advanced camshaft timing (bank 1) P0015: Retarded camshaft timing (bank 1) P0024: Advanced camshaft timing (bank 2) P0025: Retarded camshaft timing (bank 2)
Required sensors / components (Main)	VVT OCV and VVT Actuator
Required sensors / components (Sub)	Crankshaft position sensor, Camshaft position sensor and Engine coolant temperature sensor
Frequency of operation	Once per driving cycle
Duration	Within 10 seconds
MIL operation	Advanced camshaft timing (bank 1): 2 driving cycles Advanced camshaft timing (bank 2): 2 driving cycles Retarded camshaft timing (bank 1): Immediately Retarded camshaft timing (bank 2): Immediately
Sequence of operation	None

Monitor runs whenever following DTCs are not present	P0013, P0023 (Exhaust OCV bank 1, 2) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0100, P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor)
Battery voltage	11 V or more
Engine RPM	500 to 4000 RPM
ECT	75 to 100°C (167 to 212°F)

Valve timing	No change
Valve timing	Advance position

ADVANCED CAMSHAFT TIMING

Valve timing	No change
Valve timing	Retard position

RETARDED CAMSHAFT TIMING

Related DTCs	P0016: Camshaft timing misalignment at idle (intake camshaft bank 1) P0018: Camshaft timing misalignment at idle (intake camshaft bank 2)
Required sensors/components (Main)	VVT actuator
Required sensors/components (Sub)	VVT sensor, Crankshaft position sensor
Frequency of operation	Once per drive cycle
Duration	Within 1 minute
MIL operation	2 driving cycles
Sequence of operation	None

Monitor runs whenever following DTCs are not present	P0010, P0020 (OCV bank 1, 2) P0100, P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor)
Engine RPM	500 to 1000 RPM

One of the following conditions is met
VVT learning value at maximum retarded valve timing (bank 1)	Less than 18.5°CA (crankshaft angle)
VVT learning value at maximum retarded valve timing (bank 2)	Less than 18.5°CA (crankshaft angle)
VVT learning value at maximum retarded valve timing (bank 1)	More than 43.5°CA (crankshaft angle)
VVT learning value at maximum retarded valve timing (bank 2)	More than 43.5°CA (crankshaft angle)

Scheme 285

Scheme 285: WIRING DIAGRAM

Related DTCs	P0017: Camshaft timing misalignment at idle (exhaust camshaft bank 1) P0019: Camshaft timing misalignment at idle (exhaust camshaft bank 2)
Required Sensors / Components (Main)	VVT actuator
Required Sensors / Components (Related)	VVT sensor, Crankshaft position sensor
Frequency of Operation	Once per driving cycle
Duration	Within 1 minute
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTCs are not present	P0013, P0023 (Exhaust OCV bank 1, 2) P0100, P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor)
VVT feedback mode	Executing
VVT	Maximum advanced position
Engine RPM	500 to 1000 RPM

One of the following conditions is met	Condition 1 or 2
1. VVT learning value	Less than 77°CA
2. VVT learning value	More than 102°CA

PROCEDURE

CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0017 AND P0019) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the tester on. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. Result Display (DTC Output) Proceed to P0017 or P0019 A P0017 or P0019 and other DTCs B HINT: If any DTCs other than P0017 or P0019 are output, troubleshoot those DTCs first. B --> GO TO DTC CHART A: Go to next step
PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE OIL CONTROL VALVE FOR EXHAUST CAMSHAFT) Connect Techstream to the DLC3. Start the engine and turn the tester on. Warm up the engine. Select the following menu items: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Check the engine speed while operating the oil control valve using the tester. OK Tester Operation Specified Condition OCV OFF (-128%) Normal engine idle speed OCV ON (127%) Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 4 OK: Go to next step
CHECK WHETHER DTC OUTPUT RECURS (DTC P0017 OR P0019) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the tester on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-387359-S19593904092011022400000) . Start the engine and warm it up. Switch the check mode using the tester. Refer to «CHECK MODE PROCEDURE»(ref-387359-S23762167392011022400000) . Drive the vehicle for more than 10 minutes. Read the DTCs using the tester. OK No DTC output. NG --> See step 4 OK --> END
CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMP TEETH ON TIMING CHAIN) Remove the cylinder head covers RH and LH. Turn the crankshaft to align the matchmarks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the matchmarks of the camshaft pulley and camshaft bearing cap align. Turn the crankshaft clockwise by 360° if the matchmarks do not align. Check if they align once again. OK The matchmarks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. Reinstall the cylinder head cover RH and LH. NG --> ADJUST VALVE TIMING OK: Go to next step
INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Remove the exhaust camshaft timing oil control valve. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Apply the positive battery voltage to terminal 1 and the negative battery voltage to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the camshaft timing oil control valve. NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY OK: Go to next step
CHECK OIL CONTROL VALVE FILTER AND PIPE Remove the oil pipe No. 1 or No. 2. Remove the oil control valve filter. Check that the filter and pipe are not clogged. OK The filter and pipe are not clogged. Reinstall the oil pipe No. 1 or No. 2. NG --> REPLACE OIL CONTROL VALVE FILTER OR PIPE OK: Go to next step
REPLACE CAMSHAFT TIMING GEAR ASSEMBLY NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the tester on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-387359-S19593904092011022400000) . Start the engine and warm it up. Switch the check mode using the tester. Refer to «CHECK MODE PROCEDURE»(ref-387359-S23762167392011022400000) . Drive the vehicle for more than 10 minutes. Confirm that no DTC is set using the tester. OK No DTC output. HINT: DTC P0017 or P0019 is output when foreign objects in engine oil are caught in some parts of the system. These codes will stay registered even if the system returns to normal after a short time. These foreign objects are then captured by the oil filter, thus eliminating the source of the problem. NG --> REPLACE ECM OK --> END

Related DTCs	P0031: A/F sensor heater (bank 1) open/short (Low electrical current) P0032: A/F sensor heater (bank 1) open/short (High electrical current) P0051: A/F sensor heater (bank 2) open/short (Low electrical current) P0052: A/F sensor heater (bank 2) open/short (High electrical current)
Required sensors / components (Main)	A/F sensor heater (bank 1 and 2)
Required sensors / components (Sub)
Frequency of operation	Continuous
Duration	10 seconds
MIL operation	Immediately
Sequence of operation	None

Monitor runs whenever following DTCs are not present

None

ALL

Time after engine start	10 seconds or more
Heater ON duty ratio	50 % or more
Battery voltage	10.5 V or more

P0031 AND P0051

Time after engine start

10 seconds or more

P0032 AND P0052

A/F sensor heater current

Less than 0.8 A

P0031 AND P0051

Hybrid IC high current limiter port

Fail

P0032 AND P0052

A/F sensor heater resistance

1.8 to 3.4 ohms at 20°C (68°F)

Scheme 286

Scheme 286: WIRING DIAGRAM

Related DTCs	P0037: Heated oxygen sensor heater (bank 1 sensor 2) open/short (Low electrical current) P0038: Heated oxygen sensor heater (bank 1 sensor 2) open/short (High electrical current) P0057: Heated oxygen sensor heater (bank 2 sensor 2) open/short (Low electrical current) P0058: Heated oxygen sensor heater (bank 2 sensor 2) open/short (High electrical current) P0141: Heated oxygen sensor heater performance (bank 1 sensor 2) P0161: Heated oxygen sensor heater performance (bank 2 sensor 2)
Required sensors / components (Main)	Heated oxygen sensor heater (bank 1 sensor 2) Heated oxygen sensor heater (bank 2 sensor 2)
Required sensors / components (Sub)
Frequency of operation	Continuous: P0037, P0038, P0057 and P0058 Once per driving cycle: P0141 and P0161
Duration	0.5 seconds: P0037 and P0057 1 second: P0038 and P0058 10 seconds: P0141 and P0161
MIL operation	Immediately: P0037, P0038, P0057 and P0058 2 driving cycles: P0141 and P0161
Sequence of operation	None

Monitor runs whenever following DTCs are not present

None

ALL

Battery voltage

10.5 V or more, and less than 20 V

P0037 AND P0057

Battery voltage	10.5 V or more
Engine	Running
Starter	OFF

P0038 AND P0058 (CASE 1)

Battery voltage

10.5 V or more, and less than 20 V

P0038 AND P0058 (CASE 2)

Monitor runs whenever following DTCs not present	None
Either of the following conditions is met	Condition A or B
A. All of the following conditions are met	Conditions 1, 2, 3, 4 and 5
1. Battery voltage	10.5 V or more
2. Fuel cut	OFF
3. Time after fuel cut ON to OFF	30 seconds or more
4. Accumulated heater ON time	100 seconds or more
5. Learned heater OFF current operation	Completed
B. Duration that rear heated oxygen sensor impedance is less than 15 kohms	2 seconds or more

P0141 AND P0161 (HEATER PERFORMANCE MONITOR CHECK)

Heater current

Less than 0.3 A

P0037 AND P0057

One of the following conditions is met	Condition A or B
A. Learned heater OFF current	More than 2 A
B. Heater current	2 A or more

P0038 AND P0058

Accumulated heater resistance

Varies with sensor element temperature (Example: More than 23 ohm)

P0141 AND P0161 (HEATER PERFORMANCE MONITOR CHECK)

Heated oxygen (HO2) sensor heater current

0.3 A or more, or less than 2 A (when engine idles, HO2 sensor warmed up and battery voltage 11 to 14 V)

MONITOR RESULT

Refer to CHECKING MONITOR STATUS. Refer to «CHECKING MONITOR STATUS»(ref-387359-S40101581502011022400000) .

Related DTCs	P0087: Fuel pressure sensor too low
Required sensors / components (Main)	Fuel pressure sensor
Required sensors / components (Sub)
Frequency of operation	Continuous
Duration	About 10 seconds
MIL operation	Immediately
Sequence of operation	None

Monitor runs whenever following DTCs are not present	None
Time after engine start	0.2 seconds or more
Time after fuel cut finished	3 seconds or more
Target fuel pressure	Small change

Either of the following conditions A or B is met
A. Both of the following conditions are met	1 and 2
1. Difference in fuel pressure between actual and target	Less than -5 Mpa (-51.0 kgf/cm 2 , -725 psi)
2. Difference in high pressure fuel pump duty between actual and target	More than 40%
B. Both of the following conditions 3 and 4 are met	3 and 4
3. Difference in fuel pressure between actual and target	Less than -3 Mpa (-30.6 kgf/cm 2 , -435 psi)
4. Difference in high pressure fuel pump duty between actual and target	More than 40%

Related DTCs	P0088: Fuel pressure sensor too high
Required sensors / components (Main)	Fuel pressure sensor
Required sensors / components (Sub)
Frequency of operation	Continuous
Duration	About 10 seconds
MIL operation	Immediately
Sequence of operation	None

Monitor runs whenever following DTCs are not present	None
Time after engine start	0.2 seconds or more
Time after fuel cut finished	3 seconds or more
Target fuel pressure	Small change

1. Difference in fuel pressure between actual and target	More than 3 Mpa (30.6 kgf/cm 2 , 435 psi)
2. Difference in high pressure fuel pump duty between actual and target	More than 40%

CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0088) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the tester on. Clear DTCs. Start the engine. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using Techstream. Result Display (DTC output) Proceed to P0088 A P0088 and other DTCs B HINT: If any codes other than P0088 are output, perform troubleshooting for those DTCs first. B --> GO TO DTC CHART A: Go to next step
CHECK FUEL PRESSURE SENSOR Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the tester on. Start the engine. Turn the tester on. Enter the following menus: Powertrain / Engine and ECT / Data List / Fuel Press. Check that the fuel pressure fluctuates when the engine is raced. OK Fuel pressure fluctuates. NG --> REPLACE FUEL PRESSURE SENSOR OK: Go to next step
REPLACE FUEL PUMP FOR HIGH PRESSURE Replace the fuel pump for high pressure. Refer to «COMPONENTS»(ref-387358-S25093440482011022400000) . NEXT: Go to next step
CHECK IF DTC OUTPUT REOCCURS (SEE IF DTC P088 IS OUTPUT AGAIN) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the tester on. Clear DTCs. Start the engine. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using Techstream. Result Display (DTC output) Proceed to P0088 A No output B B --> END A --> REPLACE ECM

Related DTCs	P0100: Mass air flow meter range check (Chattering) P0102: Mass air flow meter range check (Low voltage) P0103: Mass air flow meter range check (High voltage)
Required Sensors/Components (Main)	MAF meter
Required Sensors/Components (Sub)	Crankshaft position sensor
Frequency of Operation	Continuous
Duration	3 seconds
MIL Operation	Immediately: Engine speed less than 4000 RPM 2 driving cycles: Engine speed 4000 RPM or more
Sequence of Operation	None

Monitor runs whenever following DTCs are not present

None

Mass air flow meter voltage

Less than 0.2 V, or more than 4.9 V

P0100

Mass air flow meter voltage

Less than 0.2 V

P0102

Mass air flow meter voltage

More than 4.9 V

P0103

Mass air flow meter voltage

Between 0.2 V and 4.9 V

Scheme 287

Scheme 287: WIRING DIAGRAM

Related DTCs	P0101: Mass air flow meter rationality
Required Sensors/Components (Main)	Mass air flow meter
Required Sensors/Components (Related)	Crankshaft Position (CKP) sensor, Engine Coolant Temperature (ECT) sensor and Throttle Position (TP) sensor
Frequency of Operation	Continuous
Duration	20 seconds or more
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTCs not present	None
Throttle position (TP sensor voltage)	0.24 V or more
Engine	Running
Battery voltage	10.5 V or more
Engine coolant temperature	70°C (158°F) or more
IAT sensor circuit (P0110, P0112 and P0113)	OK
ECT sensor circuit (P0115, P0117 and P0118)	OK
CKP sensor circuit (P0335)	OK
TP sensor circuit (P0120, P0121, P0122, P0123, P0220, P0222, P0223 and P2135)	OK
Canister pressure sensor circuit (P0450, P0452 and P0453)	OK
EVAP leak detection pump (P2401 and P2402)	OK
EVAP vent valve (P2419 and P2420)	OK

Both of following conditions 1 and 2 met
1. Averaged engine load value ratio	Less than 0.85%, or more than 1.3% (varies with estimated engine load)
2. Averaged air fuel ratio	Less than -20%, or more than 20%

CONFIRMATION DRIVING PATTERN

HINT

Performing this confirmation pattern will activate the mass air flow performance monitor.

Scheme 288

Scheme 288: CONFIRMATION DRIVING PATTERN

Connect Techstream to the DLC3.
Turn the engine switch On (IG).
Turn the tester ON.
Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-387359-S19593904092011022400000) .
Start the engine, and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher.
Drive the vehicle at approximately 62 mph (100 km/h) for 20 seconds or more.
Select the following menu items: Powertrain / Engine and ECT / Trouble Codes / Pending and check if any DTCs (any pending DTCs) are set.

CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect Techstream to the DLC3. Turn the engine switch On (IG). Turn the tester ON. Select the following menu items: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. Result Display (DTC Output) Proceed to P0101 A P0101 and other DTCs B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> GO TO DTC CHART A: Go to next step
CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage. OK No leakage from air induction system. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
CHECK PCV HOSE CONNECTIONS OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK --> REPLACE MASS AIR FLOW METER

Scheme 289

Scheme 289: DESCRIPTION

The Intake Air Temperature (IAT) sensor, mounted on the Mass Air Flow (MAF) meter, monitors the IAT. The IAT sensor has a built in thermistor with a resistance that varies according to the temperature of the intake air. When the IAT is low, the resistance of the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes (Scheme 289)
The IAT sensor is powered by a 5 V supply from the THA terminal of the ECM, via resistor R.
Resistor R and the IAT sensor are connected in series. When the resistance value of the IAT sensor changes, according to changes in the IAT, the voltage at terminal THA also varies. Based on this signal, the ECM increases the fuel injection volume when the engine is cold to improve driveability. HINT: When any of DTCs P0110, P0112 and P0113 are set, the ECM enters fail-safe mode. During fail-safe mode, the IAT is estimated to be 20°C (68°F) by the ECM. Fail-safe mode continues until a pass condition is detected.

DTC No.	Proceed to	DTC Detection Condition	Trouble Area
P0110	Step 1	Open or short in Intake Air Temperature (IAT) sensor circuit for 0.5 seconds (1 trip detection logic)	Open or short in IAT sensor circuit IAT sensor (built into MAF meter) ECM
P0112	Step 4	Short in Intake Air Temperature (IAT) sensor circuit for 0.5 seconds (1 trip detection logic)	Short in IAT sensor circuit IAT sensor (built into MAF meter) ECM
P0113	Step 2	Open in Intake Air Temperature (IAT) sensor circuit for 0.5 seconds (1 trip detection logic)	Open in IAT sensor circuit IAT sensor (built into MAF meter) ECM

HINT

When any of these DTCs are set, check the IAT by entering the following menus on Techstream: Powertrain / Engine and ECT / Data List / All Data / Intake Air.

Temperature Displayed	Malfunction
40°C (-40°F)	Open circuit
140°C (284°F)	Short circuit

Related DTCs	P0110: Intake air temperature sensor open/short (Chattering) P0112: Intake air temperature sensor short (Low electrical voltage) P0113: Intake air temperature sensor open (High electrical voltage)
Required Sensors/Components (Main)	Intake Air Temperature (IAT) sensor
Required Sensors/Components (Sub)
Frequency of Operation	Continuous
Duration	0.5 seconds
MIL Operation	Immediately
Sequence of Operation	None

Monitor runs whenever following DTCs are not present

None

Intake air temperature sensor voltage

Less than 0.18 V, or more than 4.91 V

P0110

Intake air temperature sensor voltage

Less than 0.18 V

P0112

Intake air temperature sensor voltage

More than 4.91 V

P0113

Intake air temperature sensor resistance

0.18 to 4.91 V

Scheme 290

Scheme 290: WIRING DIAGRAM

Related DTCs	P0111: Intake air temperature sensor rationality (After engine stop) P0111: Intake air temperature sensor rationality (After cold engine start)
Required Sensors/Components (Main)	Intake Air Temperature (IAT) sensor
Required Sensors/Components (Sub)	Engine coolant temperature sensor and MAF meter
Frequency of Operation	Once per driving cycle
Duration	10 seconds or more
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTCs are not present

None

ALL

Time after engine start	10 seconds or more
Battery voltage	10.5 V or more
ECT sensor circuit (P0115, P0116 and P0117)	OK
ECT change since engine stopped	Less than 180°C (324°F)
ECT before engine stop	70°C (158°F) or more
Time that MAF is low before engine stop	Less than 70 minutes
Accumulated MAF amount before engine stop	Manual transmission: 2261 g or more Automatic transmission: 3039 g or more
Key-off duration	30 minutes

AFTER ENGINE STOP

Key-off duration	5 hours or more
Time after engine start	10 seconds or more
ECT sensor circuit (P0115, P0116 and P0117)	OK
ECT	70°C (158°F) or more
Accumulated MAF amount	Manual transmission: 2261 g or more Automatic transmission: 3039 g or more
One of the following conditions 1 or 2 is met
1. Duration while engine load is low	120 seconds or more
2. Duration while engine load is high	10 seconds or more

AFTER COLD ENGINE START

IAT change

Less than 1°C (1.8°F)

AFTER ENGINE STOP

IAT change

Less than 1°C (1.8°F)

AFTER COLD ENGINE START

CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. Result Display (DTC Output) Proceed to P0111 and other DTCs A P0111 B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> REPLACE MASS AIR FLOW METER A --> GO TO DTC CHART

Related DTCs	P0115: Engine coolant temperature sensor open/short (Chattering) P0117: Engine coolant temperature sensor short (Low electrical voltage) P0118: Engine coolant temperature sensor open (High electrical voltage)
Required Sensors/Components (Main)	Engine coolant temperature sensor
Required Sensors/Components (Related)
Frequency of Operation	Continuous
Duration	0.5 seconds
MIL Operation	Immediately
Sequence of Operation	None

Monitor runs whenever following DTCs are not present

None

Engine coolant temperature sensor voltage

Less than 0.14 V, or more than 4.91 V

P0115

Engine coolant temperature sensor voltage

Less than 0.14 V

P0117

Engine coolant temperature sensor voltage

More than 4.91 V

P0118

Engine coolant temperature sensor voltage

0.14 to 4.91 V

Scheme 291

Scheme 291: WIRING DIAGRAM

Related DTCs	P0116: Engine coolant temperature sensor rationality (ECT sensor cold start monitor) P0116: Engine coolant temperature sensor rationality (ECT sensor soak monitor)
Required Sensors/Components (Main)	Engine coolant temperature (ECT) sensor
Required Sensors/Components (Sub)	Intake air temperature sensor and MAF meter
Frequency of Operation	Once per driving cycle
Duration	10 seconds
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTCs are not present

None

ALL

Battery voltage	10.5 V or more
Time after engine start	1 second or more
ECT at engine start	Less than 60°C (140°F)
IAT sensor circuit (P0110, P0112 and P0113)	OK
Soak time	0 second or more
Accumulated MAF	Manual transmission: 1441.99 g or more Automatic transmission: 930.97 g or more
Engine	Running
Fuel cut	OFF
Difference between ECT at engine start and IAT	Less than 40°C (72°F)

ECT SENSOR COLD START MONITOR

Battery voltage	10.5 V or more
Engine	Running
Soak time	5 hours
ECT at engine start	60°C (140°F) or more
Accumulated MAF	Manual transmission: 2652.82 g or more Automatic transmission: 1910.19 g or more

ECT SENSOR SOAK MONITOR

ECT sensor value change

Less than 5°C (9°F)

ECT SENSOR COLD START MONITOR

Difference between current ECT sensor value and pervious ECT sensor value when engine stopped

Less than 5°C (9°F)

ECT SENSOR SOAK MONITOR

CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0116) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTC. Result Display (DTC output) Proceed to P0116 A P0116 and other DTCs B B --> GO TO DTC CHART A: Go to next step
INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-387331-S42293293712011022400000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-387331-S01663711062011022400000) . NG --> REPLACE THERMOSTAT OK --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR

Related DTCs	P011B: Engine Coolant Temperature (ECT) / Intake Air Temperature (IAT) sensor correlation
Required Sensors / Components (Main)	ECT / IAT sensor
Required Sensors / Components (Related)
Frequency of Operation	Once per driving cycle
Duration	7 hours or more
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTCs are not present	None
All of following conditions met	Conditions 1 and 2
1. All of following conditions met	Conditions (a), (b), (c) and (d)
(a) After engine switch ON and engine not running time	Less than 20 seconds
(b) Soak Time	7 hours or more
(c) Battery voltage	10.5 V or more
(d) Time after engine start	26 seconds or more
2. Either of the following conditions are met	Condition (d) and (e)
(d) Minimum IAT after engine start	10°C (14°F) or more
(e) ECT before engine start	10°C (14°F) or more

Deviated ECT and IAT

Less than -20°C (-36°F) or more than 20°C (36°F)

CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Select the following menu items: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. Result Result Proceed to P011B A P011B and other DTCs B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
READ VALUE USING TECHSTREAM (INTAKE AIR TEMPERATURE) Leave the vehicle for 7 hours or more. HINT: It is necessary leave the vehicle for 7 hours or more to allow conditions similar to the DTC detection conditions. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Select the following menu items: Powertrain / Engine and ECT / All Data / Intake Air. Read the value displayed on the tester. OK Difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the vehicle's outside temperature gauge (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent temperature swings from being displayed on its display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
READ VALUE USING TECHSTREAM (COOLANT TEMPERATURE) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Select the following menu items: Powertrain / Engine and ECT / All Data / Coolant Temp. Read the value displayed on the tester. OK The difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check that there are heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-387359-S23628788162011022400000)
REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-387363-S01991594592011022400000)
REPLACE ECM. Refer to «REMOVAL»(ref-387363-S31270846412011022400000)
REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-387363-S36167779392011022400000)

Related DTCs	P0120: Throttle position sensor 1 range check (Chattering) P0122: Throttle position sensor 1 range check (Low voltage) P0123: Throttle position sensor 1 range check (High voltage) P0220: Throttle position sensor 2 range check (Chattering) P0222: Throttle position sensor 2 range check (Low voltage) P0223: Throttle position sensor 2 range check (High voltage) P2135: Throttle position sensor range check (Correlation)
Required Sensors/Components (Main)	Throttle position sensor
Required Sensors/Components (Related)
Frequency of Operation	Continuous
Duration	2 seconds: P0120, P0122, P0123, P0220, P0222 and P0223 0.5 seconds: P2135
MIL Operation	Immediately
Sequence of Operation	None

Monitor runs whenever following DTCs are not present

None

VTA1 voltage

0.2 V or less, or 4.535 V or more

P0120

VTA1 voltage

0.2 V or less

P0122

VTA1 voltage

4.535 V or more

P0123

Either of the following conditions is met	(a) or (b)
(a) VTA2 voltage	1.75 V or less
(b) VTA2 voltage when VTA1 0.2 to 2.02 V	4.8 V or more

P0220

VTA2 voltage

1.75 V or less

P0222

VTA2 voltage when VTA1 0.2 to 2.02 V

4.8 V or more

P0223

Either of the following conditions A or B is met
Condition A
Difference between VTA1 and VTA2 voltages	0.02 V or less
Condition B
VTA1 voltage	0.2 V or less
VTA2 voltage	1.75 V or less

P2135

VTA1 voltage	More than 0.2 V, and less than 4.535 V
VTA2 voltage	More than 1.75 V, and less than 4.8 V

FAIL-SAFE

When any of these DTCs, as well as other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions, are set, the ECM enters fail-safe mode. During the ECM cuts the current to the throttle actuator off, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Scheme 292

Scheme 292: WIRING DIAGRAM

Related DTCs	P0121: TP sensor rationality
Required Sensors/Components (Main)	TP sensor
Required Sensors/Components (Sub)
Frequency of Operation	Continuous
Duration	Within 2 seconds
MIL Operation	Immediately
Sequence of Operation	None

Monitor runs whenever following DTCs are not present	None
Either of the following conditions A or B is met
A. Engine switch	On (IG)
B. Electric throttle motor power	ON
TP sensor malfunction (P0120, P0122, P0123, P0220, P0222, P0223, P2135)	Not detected

Either of the following conditions is set
Difference of TP sensor voltage between VTA1 and VTA2 x 0.8	Higher than 1.6 V
Difference of TP sensor voltage between VTA1 and VTA2 x 0.8	Lower than 0.8 V

When this DTC, as well as other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions, is set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator off, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the engine switch is then turned off.

CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0121) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTC. Result Display (DTC output) Proceed to P0121 A P0121 and other DTCs B B --> GO TO DTC CHART A --> REPLACE THROTTLE BODY

Related DTCs	P0125: Insufficient engine coolant temperature for closed-loop fuel control
Required Sensors/Components (Main)	Thermostat, cooling system
Required Sensors/Components (Related)	Engine coolant temperature sensor and mass air flow meter
Frequency of Operation	Once per driving cycle
Duration	102 seconds: Engine coolant temperature at engine start -8.33°C (17°F) or more 183 seconds: Engine coolant temperature at engine start -19.44 to -8.33°C (-3 to 17°F) 1200 seconds: Engine coolant temperature at engine start less than -19.44°C (-3°F)
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTCs are not present	None
Thermostat fail (P0128)	Not detected
IAT sensor circuit fail (P0110, P0112 and P0113)	Not detected
ECT sensor circuit fail (P0115, P0117 and P0118)	Not detected
MAF sensor circuit fail (P0100, P0101, P0102 and P0103)	Not detected

Time until actual engine coolant temperature reaches closed-loop fuel control enabling temperature

102 seconds or more: Engine coolant temperature at engine start -8.33°C (17°F) or more 183 seconds or more: Engine coolant temperature at engine start -19.44 to -8.33°C (-3 to 17°F) 1200 seconds or more: Engine coolant temperature at engine start less than -19.44°C (-3°F)

CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. Result Display (DTC Output) Proceed to P0125 A P0125 and other DTCs B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> GO TO DTC CHART A: Go to next step
INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-387331-S42293293712011022400000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-387331-S01663711062011022400000) . NG --> REPLACE THERMOSTAT OK: Go to next step
CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR

Related DTCs	P0128: Coolant Thermostat
Required Sensors/Components (Main)	Thermostat
Required Sensors/Components (Related)	Engine Coolant Temperature (ECT) sensor, Intake Air Temperature (IAT) sensor, Vehicle speed sensor
Frequency of Operation	Once per driving cycle
Duration	600 seconds
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor will run whenever this DTC is not present	P0010, P0020 (OCV bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust OCV bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052 (A/F sensor heater) P0100, P0102, P0103 (MAF meter) P0110, P0112, P0113 (IAT sensor) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (CKP sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor) P2195, P2196, P2197, P2198 (A/F sensor - rationality) P2237, P2240 (A/F sensor - open) P2238, P2241, P2252, P2255 (A/F sensor - low impedance) P2239, P2242, P2253, P2256 (A/F sensor - high impedance) P2A00, P2A03 (A/F sensor - slow response)
Battery voltage	11 V or more
Either of the following conditions 1 or 2 is met
1. All of the following conditions are met	(a), (b) and (c)
(a) ECT at engine start - IAT at engine start	15 to 7°C (-27 to 12.6°F)
(b) ECT at engine start	10 to 56°C (14 to 133°F)
(c) IAT at engine start	10 to 56°C (14 to 133°F)
2. All of the following conditions are met	(d), (e) and (f)
(d) ECT at engine start - IAT at engine start	More than 7°C (12.6°F)
(e) ECT at engine start	56°C (133°F) or less
(f) IAT at engine start	10°C (14°F) or more
Accumulated time that vehicle speed is 80 mph (128 km/h) or more	Less than 20 seconds

Duration that both of the following conditions 1 and 2 are met	5 seconds or more
1. Estimated	75°C (167°F) or more
2. ECT sensor output	Below 75°C (167°F)

CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0128) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTC. Result Display (DTC Output) Proceed to P0128 A P0128 and other DTCs B HINT: If any DTC other than P0128 are output, troubleshoot those DTCs first. B --> GO TO DTC CHART A: Go to next step
CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-387331-S42293293712011022400000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-387331-S01663711062011022400000) . NG --> REPLACE THERMOSTAT OK --> REPLACE ECM

Related DTCs	P0136: Heated oxygen sensor output voltage (Output voltage) (bank 1) P0136: Heated oxygen sensor impedance (Low) (bank 1) P0137: Heated oxygen sensor output voltage (Low voltage) (bank 1) P0137: Heated oxygen sensor impedance (High) (bank 1) P0138: Heated oxygen sensor output voltage (High voltage) (bank 1) P0138: Heated oxygen sensor output voltage (Extremely high) (bank 1) P0139: Heated oxygen sensor output voltage during fuel cut (bank 1) P0156: Heated oxygen sensor output voltage (Output voltage) (bank 2) P0156: Heated oxygen sensor impedance (Low) (bank 2) P0157: Heated oxygen sensor output voltage (Low voltage) (bank 2) P0157: Heated oxygen sensor impedance (High) (bank 2) P0158: Heated oxygen sensor output voltage (High voltage) (bank 2) P0158: Heated oxygen sensor output voltage (Extremely high) (bank 2) P0159: Heated oxygen sensor output voltage during fuel cut (bank 2)
Required Sensors/Components (Main)	Heated oxygen sensor (sensor 2)
Required Sensors/Components (Related)	Crankshaft position sensor Engine coolant temperature sensor Mass air flow meter Throttle position sensor
Frequency of Operation	Once per driving cycle: Active air fuel ratio control detection, Heated oxygen sensor abnormal voltage during fuel cut Continuous: Other
Duration	20 seconds: Heated oxygen sensor output (Output voltage, High voltage, Low voltage) 30 seconds: Heated oxygen sensor impedance (Low) 90 seconds: Heated oxygen sensor impedance (High) 10 seconds: Heated oxygen sensor voltage (Extremely high) 7 seconds: Heated oxygen sensor voltage during fuel cut
MIL Operation	2 driving cycles
Sequence of Operation	None

All

Monitor runs whenever following DTCs not present

P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052 (A/F sensor heater) P0037, P0038, P0057, P0058 (HO2 sensor heater) P0100, P0102, P0103 (MAF meter) P0110, P0112, P0113 (IAT sensor) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P0125 (Insufficient ECT for closed loop) P0128 (Thermostat) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (CKP sensor) P0450, P0451, P0452, P0453 (EVAP system) P0500 (Vehicle speed sensor) P2195, P2196, P2197, P2198 (A/F sensor - rationality) P2237, P2240 (A/F sensor - open) P2238, P2241, P2252, P2255 (A/F sensor - low impedance) P2239, P2242, P2253, P2256 (A/F sensor - high impedance) P2A00, P2A03 (A/F sensor - slow response)

Active air fuel ratio control	Performing
Active air fuel ratio control is performed when all of the following conditions are met
Battery voltage	11 V or more
Engine coolant temperature	75°C (167°F) or more
Idling	OFF
Engine RPM	Less than 4000 RPM
Air fuel ratio sensor status	Activated
Fuel system status	Closed loop
Fuel cut	OFF
Engine load	10 to 75%
Shift position	4th or more

HEATED OXYGEN SENSOR OUTPUT VOLTAGE (OUTPUT VOLTAGE, HIGH VOLTAGE AND LOW VOLTAGE)

Battery voltage	11 V or more
Estimated heated oxygen sensor temperature	Less than 700°C (1292°F)
ECM monitor	Completed
DTC P0606	Not set

HEATED OXYGEN SENSOR IMPEDANCE (LOW)

Battery voltage	11 V or more
Estimated heated oxygen sensor temperature	450°C (842°F) or higher
DTC P0606	Not set

HEATED OXYGEN SENSOR IMPEDANCE (HIGH)

Battery voltage	11 V or more
Time after engine start	2 seconds or more

HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)

Engine coolant temperature	75°C (167°F) or more
Catalyst temperature	400°C (752°F) or more
Fuel cut	Executing

HEATED OXYGEN SENSOR VOLTAGE DURING FUEL CUT

Either of the following conditions is met	1 or 2
1. All of the following conditions (a), (b) and (c) are met
(a) Commanded air fuel ratio	14.2 or less
(b) Rear heated oxygen sensor voltage	0.21 to 0.59 V
(c) Oxygen storage capacity of catalyst	1.6 g or more
2. All of the following conditions (d), (e) and (f) are met
(d) Commanded air fuel ratio	15 or more
(e) Rear heated oxygen sensor voltage	0.21 to 0.59 V
(f) Oxygen storage capacity of catalyst	1.6 g or more

HEATED OXYGEN SENSOR OUTPUT VOLTAGE (OUTPUT VOLTAGE)

All of the following conditions (a), (b) and (c) are met
(a) Commanded air fuel ratio	14.2 or less
(b) Rear heated oxygen sensor voltage	Less than 0.21 V
(c) Oxygen storage capacity of catalyst	1.6 g or more

HEATED OXYGEN SENSOR OUTPUT VOLTAGE (LOW OUTPUT VOLTAGE)

All of the following conditions (a), (b) and (c) are met
(a) Commanded air fuel ratio	15 or more
(b) Rear heated oxygen sensor voltage	More than 0.59 V
(c) Oxygen storage capacity of catalyst	1.6 g or more

HEATED OXYGEN SENSOR OUTPUT VOLTAGE (HIGH OUTPUT VOLTAGE)

Duration of following condition	30 seconds or more
Heated oxygen sensor impedance	Less than 5 ohms

HEATED OXYGEN SENSOR IMPEDANCE (LOW)

Duration of following condition	90 seconds or more
Heated oxygen sensor impedance	15 kohms or more

HEATED OXYGEN SENSOR IMPEDANCE (HIGH)

Duration of following condition	10 seconds or more
Heated oxygen sensor voltage	1.2 V or higher

HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)

One of the following conditions is met	(a) or (b)
(a) Duration until rear oxygen sensor voltage drops to 0.2 V during fuel cut	7 seconds or more
(b) Duration that rear oxygen sensor voltage drops from 0.35 V to 0.2 V during fuel cut	1 second or more

HEATED OXYGEN SENSOR VOLTAGE DURING FUEL-CUT

Duration of following condition	30 seconds or more
Heated oxygen sensor voltage	Varies between 0.1 V and 0.9 V

Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .

Scheme 293

Scheme 293: WIRING DIAGRAM

HINT

This confirmation driving pattern is used in the "PERFORM CONFIRMATION DRIVING PATTERN" procedure of the following diagnostic troubleshooting procedure.
Performing this confirmation driving pattern will activate the heated oxygen sensor monitor (The catalyst monitor is performed simultaneously). This is very useful for verifying the completion of a repair.

Scheme 294

Connect Techstream to the DLC3.
Turn the engine switch on (IG).
Warm-up the engine until the engine coolant temperature reaches 75°C (167°F) or more [A].
Drive the vehicle at between 38 mph and 75 mph (60 km/h and 120 km/h) for at least 10 minutes [B].
Drive the vehicle 38 mph (60 km/h) or more and decelerate the vehicle for 10 seconds or more. Perform this 3 times [C].
Turn the tester on.
Select the following menu items: Powertrain / Engine and ECT / Utility / All Readiness.
Input DTCs: P0136, P0137, P0138, P0139, P0156, P0157, P0158 and P0159. Check the DTC MONITOR is NORMAL. If DTC MONITOR is INCOMPLETE, perform the drive pattern adding the vehicle speed and using the second gear to decelerate the vehicle.

Related DTCs	P0171: Fuel trim Lean (bank 1) P0172: Fuel trim Rich (bank 1) P0174: Fuel trim Lean (bank 2) P0175: Fuel trim Rich (bank 2)
Required Sensors/Components (Main)	Fuel system
Required Sensors/Components (Sub)	A/F sensor, Mass air flow meter, Crankshaft position sensor
Frequency of Operation	Continuous
Duration	Within 10 seconds
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTCs are not present	P0010, P0020 (OCV bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust OCV bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052 (A/F sensor heater) P0100, P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor)
Fuel system status	Closed loop
Battery voltage	11 V or more
Either of the following conditions 1 or 2 is met
1. Engine RPM	Less than 1100 RPM
2. Engine load	13.3% or more
Catalyst monitor	Not executed

EVAP purge-cut	Executing
Either of the following conditions 1 or 2 is met
1. Average between short-term fuel trim and long-term fuel trim	35 % or more (varies with ECT)
2. Average between short-term fuel trim and long-term fuel trim	35 % or less (varies with ECT)

FUEL-TRIM

Related DTCs	P0190: Fuel rail pressure sensor range check (Chattering) P0192: Fuel rail pressure sensor range check (Low voltage) P0193: Fuel rail pressure sensor range check (High voltage)
Required Sensors/Components (Main)	Fuel Rail Pressure Sensor
Required Sensors/Components (Sub)
Frequency of Operation	Continuous
Duration	5 seconds
MIL Operation	Immediately
Sequence of Operation	None

Monitor runs whenever following DTCs are not present	None
Time after engine start	5 seconds or more

Fuel rail pressure sensor voltage

Less than 0.25 V, or more than 4.5 V

P0190

Fuel rail pressure sensor voltage

Less than 0.25 V

P0192

Fuel rail pressure sensor voltage

More than 4.5 V

P0193

Fuel rail pressure sensor voltage

0.25 to 4.5 V

Scheme 295

Scheme 295: WIRING DIAGRAM

Related DTCs	P0200: Injector circuit open (All) P0201: Injector circuit open (Cylinder 1) P0202: Injector circuit open (Cylinder 2) P0203: Injector circuit open (Cylinder 3) P0204: Injector circuit open (Cylinder 4) P0205: Injector circuit open (Cylinder 5) P0206: Injector circuit open (Cylinder 6)
Required Sensors/Components (Main)	Injector
Required Sensors/Components (Sub)
Frequency of Operation	Continuous
Duration	10 seconds
MIL Operation	Immediately
Sequence of Operation	None

Monitor runs whenever following DTCs are not present	None
Time after engine switch off to on (IG)	1 second or more
Engine speed	4000 RPM or less
Battery voltage	10.5 V or more

Either of the following conditions A or B is met
A. No confirmed injection signal input in one of cylinders	20 times or more
B. No confirmed injection signal input in all cylinders	10 revolution or more

Scheme 296

Scheme 296: WIRING DIAGRAM

Scheme 297

Related DTCs	P0300: Multiple cylinder misfire P0301: Cylinder 1 misfire P0302: Cylinder 2 misfire P0303: Cylinder 3 misfire P0304: Cylinder 4 misfire P0305: Cylinder 5 misfire P0306: Cylinder 6 misfire
Required Sensors/Components (Main)	Injector, Ignition coil and spark plug
Required Sensors/Components (Related)	Crankshaft position, Camshaft position Engine coolant temperature and intake air temperature sensors and Mass air flow meter
Frequency of Operation	Continuous
Duration	1000 to 4000 crankshaft revolutions: Emission related misfire 200 to 600 crankshaft revolutions: Catalyst damaged misfire
MIL Operation	2 driving cycles: (MIL illuminates when misfire detected) MIL flashes immediately: When catalyst damaged misfire occur
Sequence of Operation	None

Monitor runs whenever following DTCs not present	P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0100, P0102, P0103 (MAF meter) P0110, P0112, P0113 (IAT sensor) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P0125 (Insufficient ECT for closed loop) P0327, P0328, P0332, P0333 (Knock sensor) P0335 (CKP sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0500 (Vehicle speed sensor)
Battery voltage	8 V or more
VVT system	Not operated by scan tool
Engine RPM	400 to 6550 RPM
Either of the following conditions (a) or (b) is met
(a) Engine coolant temperature at engine start	More than -7°C (19°F)
(b) Engine coolant temperature	More than 20°C (68°F)
Fuel cut	OFF

MISFIRE

First 1000 revolutions after engine start, or Check Mode	Crankshaft 1000 revolutions
Except above	Crankshaft 1000 revolutions x 4

MONITOR PERIOD OF EMISSION-RELATED-MISFIRE

All of the following conditions 1, 2 and 3 are met	Crankshaft 200 revolutions
1. Driving cycles	1st
2. Check mode	OFF
3. Engine RPM	Less than 2500 RPM
Except above (MIL blinks immediately)	Crankshaft 200 revolutions x 3

MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)

Misfire rate

1.4% or more

MONITOR PERIOD OF EMISSION-RELATED-MISFIRE

Number of misfire per 200 revolutions	66 or more (varies with intake air amount and RPM)
Paired cylinder misfire (MIL blinks immediately)	Detected

MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)

Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .

Connect Techstream to the DLC3.
Turn the engine switch on (IG).
Turn the tester on.
Record the DTC(s) and freeze frame data.
Using the tester, switch the ECM from normal mode to check mode. Refer to «CHECK MODE PROCEDURE»(ref-387359-S23762167392011022400000) .
Read the misfire counts of each cylinder (Cylinder #1 Misfire Count to Cylinder #6 Misfire Count) with the engine in an idling condition. If any misfire count is displayed, skip the following confirmation driving pattern.
Drive the vehicle several times with the conditions, such as engine RPM and engine load, shown in, Misfire RPM and Misfire Load in the Data List. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below, using the Misfire RPM and Misfire Load in the Data List. Engine RPM Duration Idling 3.5 minutes or more 1000 3 minutes or more 2000 1.5 minutes or more 3000 1 minute or more
Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the engine switch off until the stored DTC(s) and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTC(s), freeze frame data and other data will be erased.
Record the DTC(s), freeze frame data and misfire counts.
Turn the engine switch off and wait for at least 5 seconds.

Related DTCs	P0327: Knock sensor (Bank 1) open/short (Low voltage) P0328: Knock sensor (Bank 1) open/short (High voltage) P0332: Knock sensor (Bank 2) open/short (Low voltage) P0333: Knock sensor (Bank 2) open/short (High voltage)
Required Sensors/Components (Main)	Knock sensor (Bank 1 and 2)
Required Sensors/Components (Sub)
Frequency of Operation	Continuous
Duration	1 second
MIL Operation	Immediately
Sequence of Operation	None

Monitor runs whenever following DTCs are not present	None
Time after engine start	5 seconds or more
Battery voltage	10.5 V or more
Engine switch	On (IG)
Starter	OFF

Knock sensor voltage

Less than 0.5 V

KNOCK SENSOR RANGE CHECK (LOW VOLTAGE) P0327 AND P0332

Knock sensor voltage

More than 4.5 V

KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE) P0328 AND P0333

Scheme 298

Scheme 298: WIRING DIAGRAM

Related DTCs	P0335: Crankshaft position sensor verify pulse input P0335: Crankshaft position sensor range check/rationality
Required Sensors/Components (Main)	Crankshaft Position (CKP) sensor
Required Sensors/Components (Sub)	VVT sensor
Frequency of Operation	Continuous
Duration	Within 5 seconds or 3 times
MIL Operation	Immediately
Sequence of Operation	None

Monitor runs whenever following DTCs are not present

None

ALL

Starter	OFF
Engine speed	600 RPM or more
Time after starter from ON to OFF	3 seconds or more

CASE 1 (VERIFY PULSE INPUT)

Time after starter OFF to ON	0.3 seconds or more
Number of VVT sensor signal pulse	6 times
Battery voltage	7 V or more
Engine switch	On (IG)

CASE 2 (RANGE CHECK / RATIONALITY)

Starter

CASE 3 (RANGE CHECK / RATIONALITY)

Engine speed signal

No signal

CASE 1 (VERIFY PULSE INPUT)

Number of CKP sensor signal pulse

44 times or less, or 58 times or more

CASE 2 (RANGE CHECK / RATIONALITY)

Engine speed signal

No signal

CASE 3 (RANGE CHECK / RATIONALITY)

CKP sensor

CKP sensor output voltage fluctuates while crankshaft revolving 34 CKP sensor signals per crankshaft revolution

Related DTCs	P0340: VVT sensor (Bank 1) range check / rationality P0340: Camshaft position/Crankshaft position misalignment (Bank 1) P0340: VVT sensor (Bank 1) range check (chattering) P0342: VVT sensor (Bank 1) range check (low voltage) P0343: VVT sensor (Bank 1) range check (high voltage) P0345: VVT sensor (Bank 2) range check / rationality P0345: VVT sensor (Bank 2) range check (chattering) P0347: VVT sensor (Bank 2) range check (low voltage) P0348: VVT sensor (Bank 2) range check (high voltage)
Required Sensors/Components (Main)	VVT position sensor (Bank 1 and 2)
Required Sensors/Components (Sub)	Crankshaft position sensor
Frequency of Operation	Continuous
Duration	5 seconds
MIL Operation	2 driving cycles: P0340 (cranking) Immediately: Others
Sequence of Operation	None

Monitor runs whenever following DTCs are not present

None

ALL

Engine speed	600 RPM or more
Starter	OFF

P0340 (ENGINE RUNNING)

Engine speed	600 RPM or more
Battery voltage	8 V or more
Starter	OFF
Engine switch	On (IG)

P0345 (ENGINE RUNNING)

Starter	ON
Minimum battery voltage	Less than 11 V

P0340 (CRANKING)

Starter	OFF
Time after engine switch off to on (IG)	2 seconds or more

P0340, P0342, P0343 (CHATTERING, LOW VOLTAGE, HIGH VOLTAGE)

Starter	OFF
Time after engine switch off to on	2 seconds or more
Battery Voltage	8 V or more

P0345, P0347, P0348 (CHATTERING, LOW VOLTAGE, HIGH VOLTAGE)

Camshaft position and crankshaft position phase	Misaligned
VVT sensor signal	No signal

P0340 (ENGINE RUNNING)

Camshaft position signal

No signal

P0340 (CRANKING)

VVT sensor voltage

Less than 0.3 V, or more than 4.7 V

P0340 (CHATTERING)

VVT sensor voltage

Less than 0.3 V

P0342 (LOW VOLTAGE)

VVT sensor voltage

More than 4.7 V

P0343 (HIGH VOLTAGE)

VVT sensor signal

No signal

P0345 (ENGINE RUNNING, CRANKING)

VVT sensor voltage

Less than 0.3 V, or more than 4.7 V

P0345 (CHATTERING)

VVT sensor voltage

Less than 0.3 V

P0347 (LOW VOLTAGE)

VVT sensor voltage

More than 4.7 V

P0348 (HIGH VOLTAGE)

VVT sensor voltage

0.3 to 4.7 V

Related DTCs	P0351: Igniter (cylinder 1) malfunction P0352: Igniter (cylinder 2) malfunction P0353: Igniter (cylinder 3) malfunction P0354: Igniter (cylinder 4) malfunction P0355: Igniter (cylinder 5) malfunction P0356: Igniter (cylinder 6) malfunction
Required Sensors/Components (Main)	Igniter (Cylinder 1 to 6)
Required Sensors/Components (Sub)	Crankshaft position sensor
Frequency of Operation	Continuous
Duration	More than 0.256 seconds and 4 sparks
MIL Operation	Immediately
Sequence of Operation	None

Monitor runs whenever following DTCs are not present	None
Either of the following conditions 1 or 2 is met
1. Both of the following conditions (a) and (b) are met
(a) Engine RPM	500 RPM or less
(b) Battery voltage	6 V or more
2. All of the following conditions(c), (d) and (e) are met
(c) Engine RPM	More than 500 RPM
(d) Battery voltage	10 V or more
(e) Number or sparks after CPU is reset	5 sparks or more

Ignition signal fail counter

More than 2 times

IGF signal

Igniter transmits IGF signal when it receives IGT signal from ECM

Scheme 299

Scheme 299: WIRING DIAGRAM

Scheme 300

Related DTCs	P0365: VVT sensor (Bank 1) range check / rationality P0365: VVT sensor (Bank 1) range check (chattering) P0367: VVT sensor (Bank 1) range check (low voltage) P0368: VVT sensor (Bank 1) range check (high voltage) P0390: VVT sensor (Bank 2) range check / rationality P0390: VVT sensor (Bank 2) range check (chattering) P0392: VVT sensor (Bank 2) range check (low voltage) P0393: VVT sensor (Bank 2) range check (high voltage)
Required Sensors/Components (Main)	VVT position sensor (Bank 1 and 2)
Required Sensors/Components (Sub)	Crankshaft position sensor
Frequency of Operation	Continuous
Duration	5 seconds
MIL Operation	Immediately
Sequence of Operation	None

Monitor runs whenever following DTCs are not present

None

ALL

Starter	OFF
Engine switch	On (IG)
Time after engine switch off to on (IG)	2 seconds or more
Battery voltage	8 V or more

CHATTERING, LOW VOLTAGE, HIGH VOLTAGE

Engine speed	600 RPM or more
Battery voltage	8 V or more
Starter	OFF
Engine switch	On (IG)

P0365, P0390 (ENGINE RUNNING)

Exhaust camshaft position sensor voltage

Less than 0.3 V, or more than 4.7 V

P0365, P0390 (CHATTERING)

Exhaust camshaft position sensor voltage

Less than 0.3 V

P0367, P0392 (LOW VOLTAGE)

Exhaust camshaft position sensor voltage

More than 4.7 V

P0368, P0393 (HIGH VOLTAGE)

Exhaust camshaft position signal

No signal

P0365, P0390 (ENGINE RUNNING)

VVT sensor voltage

0.3 to 4.7 V

Engine Control (Sfi) System (Dtcs P0010 - P0368): Other Lexus IS II facelift

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

TYPICAL MALFUNCTION THRESHOLDS

COMPONENT OPERATING RANGE

Scheme 283

Scheme 284

Scheme 285

PROCEDURE

Scheme 286

MONITOR RESULT

Scheme 287

CONFIRMATION DRIVING PATTERN

Scheme 288

Scheme 289

Scheme 290

Scheme 291

FAIL-SAFE

Scheme 292

Scheme 293

Scheme 294

Scheme 295

Scheme 296

Scheme 297

Scheme 298

Scheme 299

Scheme 300

More articles — Engine Control (Sfi) System (Dtcs P0010 - P0368)

Login / Signup

Enter the code

You have successfully logged in!
