HOW TO PROCEED WITH TROUBLESHOOTING

HINT

*: Use Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS NEXT: Go to next step
3. CONNECT TECHSTREAM TO THE DLC3* HINT: If the display indicates a communication fault in the tester, inspect the DLC3. NEXT: Go to next step
4. CHECK DTC AND FREEZE FRAME DATA* HINT: Record or print DTCs and freeze frame data, if necessary. NEXT: Go to next step
5. CLEAR DTC AND FREEZE FRAME DATA* NEXT: Go to next step
6. CONDUCT VISUAL INSPECTION NEXT: Go to next step
7. SET CHECK MODE DIAGNOSIS* NEXT: Go to next step
8. CONFIRM PROBLEM SYMPTOMS HINT: If the engine does not start, perform steps 10 and 12 first. Result Result Proceed to Malfunction does not occur A Malfunction occurs B B --> GO TO STEP 10 A: Go to next step
9. SIMULATE SYMPTOMS NEXT: Go to next step
10. CHECK DTC* Result Result Proceed to Malfunction code A No code B B --> GO TO STEP 12 A: Go to next step
11. REFER TO «DIAGNOSTIC TROUBLE CODE CHART»(ref-387359-S23628788162011022400000) NEXT --> GO TO STEP 14
12. CONDUCT BASIC INSPECTION Result Result Proceed to Malfunctioning parts not confirmed A Malfunctioning parts confirmed B B --> GO TO STEP 17 A: Go to next step
13. REFER TO «PROBLEM SYMPTOMS TABLE»(ref-387359-S01947944302011022400000) Result Result Proceed to Malfunctioning circuit confirmed A Malfunctioning parts confirmed B B --> GO TO STEP 17 A: Go to next step
14. CHECK ECM POWER SOURCE CIRCUIT NEXT: Go to next step
15. CONDUCT CIRCUIT INSPECTION Result Result Proceed to Malfunction not confirmed A Malfunction confirmed B B --> GO TO STEP 18 A: Go to next step
16. CHECK FOR INTERMITTENT PROBLEMS NEXT --> GO TO STEP 18
17. CONDUCT PARTS INSPECTION NEXT: Go to next step
18. IDENTIFY PROBLEM NEXT: Go to next step
19. ADJUST AND/OR REPAIR NEXT: Go to next step
20. CONDUCT CONFIRMATION TEST NEXT --> END

BASIC INSPECTION

When the malfunction is not confirmed by the DTC check, troubleshooting should be carried out in all circuits considered to be possible causes of the problem. In many cases, by carrying out the basic engine check shown in the following flowchart, the location of the problem can be found quickly and efficiently. Therefore, using this check is essential when troubleshooting the engine.

1. CHECK BATTERY VOLTAGE NOTE: Carry out this check with the engine stopped and the engine switch off. Result Result Proceed to 11 V or more OK Below 11 V NG NG --> CHARGE OR REPLACE BATTERY OK: Go to next step
2. CHECK WHETHER ENGINE CRANKS NG --> PROCEED TO «PROBLEM SYMPTOMS TABLE»(ref-387359-S01947944302011022400000) OK: Go to next step
3. CHECK WHETHER ENGINE STARTS NG --> GO TO STEP 6 OK: Go to next step
4. CHECK AIR FILTER Visually check that the air filter is not excessively contaminated with dirt or oil. NG --> REPLACE AIR FILTER OK: Go to next step
5. CHECK IDLING SPEED NG --> TROUBLESHOOT IDLING SPEED AND PROCEED TO NEXT STEP OK: Go to next step
6. CHECK FUEL PRESSURE NG --> TROUBLESHOOT FUEL PRESSURE AND PROCEED TO NEXT STEP OK: Go to next step
7. CHECK FOR SPARK NG --> TROUBLESHOOT SPARK AND PROCEED TO NEXT STEP OK --> PROCEED TO «PROBLEM SYMPTOMS TABLE»(ref-387359-S01947944302011022400000)

PROBLEM SYMPTOMS TABLE

HINT

Use the table below to help determine the cause of the problem. The potential cases of the symptoms are listed in order of probability in the "Suspected area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.

SFI SYSTEM

Scheme 1

HINT

The standard normal voltage between each pair of the ECM terminals is shown in the table below. The appropriate conditions for checking each pair of the terminals are also indicated. The result of checks should be compared with the standard normal voltage for that pair of terminals, displayed in the Specified Condition column. The illustration above can be used as a reference to identify the ECM terminal locations.

HINT

*: The ECM terminal voltage is constant regardless of the output voltage from the sensor.

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. WAVEFORM 1 CAMSHAFT TIMING OIL CONTROL VALVE (OCV): ECM Terminal Name Between OC1+ and OC1- or OC2+ and OC2- Between OE1+ and OE1- or OE2+ and OE2- Tester Range 5 V/DIV, 1 ms./DIV Condition Idling HINT: The wavelength becomes shorter as the engine rpm increases.
2. WAVEFORM 2 HEATED OXYGEN SENSOR: ECM Terminal Name Between OX1B and O1B- or OX2B and O2B- Tester Range 0.2 V/DIV, 200 ms./DIV Condition Maintain engine speed at 2500 rpm for 2 minutes after warning up sensor HINT: In Data List, item O2S B1 S2 shows the ECM input values from the heated oxygen sensor.
3. WAVEFORM 3 INJECTOR NO. 1 (TO NO. 6) INJECTION SIGNAL: ECM Terminal Name Between #10 (to #60) and E1 Tester Range 2 V/DIV, 20 ms./DIV Condition Idling HINT: The wavelength becomes shorter as the engine rpm increases.
4. WAVEFORM 4 KNOCK SENSOR: ECM Terminal Name Between KNK1 and EKNK Between KNK2 and EKNK2 Tester Range 0.01 to 10 V/DIV, 0.01 to 10 ms./DIV Condition Maintain engine speed at 4000 rpm after warning up HINT: The wavelength becomes shorter as the engine rpm increases. The waveforms and amplitudes displayed differ slightly depending on the vehicle.
5. WAVEFORM 5 CRANKSHAFT POSITION SENSOR AND VVT SENSOR FOR INTAKE CAMSHAFT: ECM Terminal Name Between NE+ and NE- Between VV1+ and VV1- or VV2+ and VV2- Tester Range 5 V/DIV, 20 ms./DIV Condition Idling HINT: The wavelength becomes shorter as the engine rpm increases.
6. WAVEFORM 6 CRANKSHAFT POSITION SENSOR AND VVT SENSOR FOR EXHAUST CAMSHAFT: ECM Terminal Name Between NE+ and NE- Between EV1+ and EV1- or EV2+ and EV2- Tester Range 5 V/DIV, 20 ms./DIV Condition Idling HINT: The wavelength becomes shorter as the engine rpm increases.
7. WAVEFORM 7 IGNITER IGT SIGNAL (FROM ECM TO IGNITER) AND IGNITER IGF SIGNAL (FROM IGNITER TO ECM): ECM Terminal Name Between IGT (1 to 6) and E1 Between IGF1 and E1 or IGF2 and E1 Tester Range 2 V/DIV, 20 ms./DIV Condition Idling HINT: The wavelength becomes shorter as the engine rpm increases.
8. WAVEFORM 8 EVAP VSV: ECM Terminal Name Between PRG and E1 Tester Range 5 V/DIV, 50 ms./DIV Condition Idling HINT: If the waveform is not similar to the illustration, check the waveform again after idling for 10 minutes or more.
9. WAVEFORM 9 VEHICLE SPEED SIGNAL: ECM Terminal Name Between SPD and E1 Tester Range 5 V/DIV, 20 ms./DIV Condition Driving at 12 mph (20 km/h) HINT: The wavelength becomes shorter as the vehicle speed increases.
10. WAVEFORM 10 THROTTLE ACTUATOR POSITIVE TERMINAL: ECM Terminal Name Between M+ and ME01 Tester Range 5 V/DIV, 1 ms./DIV Condition Idling with warm engine HINT: The duty ratio varies depending on the throttle actuator operation.
11. WAVEFORM 11 THROTTLE ACTUATOR NEGATIVE TERMINAL: ECM Terminal Name Between M- and ME01 Tester Range 5 V/DIV, 1 ms./DIV Condition Idling with warm engine HINT: The duty ratio varies depending on the throttle actuator operation.
12. WAVEFORM 12 ENGINE SPEED SIGNAL: ECM Terminal Name Between TACH and E1 Tester Range 5 V/DIV, 10 ms./DIV Condition Idling HINT: The wavelength becomes shorter as the engine rpm increases.
13. WAVEFORM 13 INJECTOR NO. 1 (TO NO. 6) INJECTION SIGNAL AND INJECTION CONFIRMATION SIGNAL: ECM Terminal Name Between INJF and E1 Tester Range 2 V/DIV, 20 ms./DIV Condition Idling HINT: The wavelength becomes shorter as the engine rpm increases.
14. WAVEFORM 14 HIGH PRESSURE SIDE FUEL PUMP (SPILL VALVE): ECM Terminal Name CH1: Between FPD and E1 CH2: Between FPF1 and E1 Tester Range 2 V/DIV, 5 ms./DIV Condition Idling
15. WAVEFORM 15 DC MOTOR FOR SCV POSITIVE TERMINAL: ECM Terminal Name Between IA1+ and E01 Tester Range 5 V/DIV, 1 ms./DIV Condition Idling
16. WAVEFORM 16 DC MOTOR FOR SCV NEGATIVE TERMINAL: ECM Terminal Name Between IA1- and E01 Tester Range 5 V/DIV, 1 ms./DIV Condition Idling
17. WAVEFORM 17 CAN COMMUNICATION SIGNAL: ECM Terminal Name Between CANH and E1 Tester Range 1 V/DIV, 10 μs/DIV Condition Engine switch on (IG) HINT: The waveform varies depending on the CAN communication signal.
18. WAVEFORM 18 CAN COMMUNICATION SIGNAL: ECM Terminal Name Between CANL and E1 Tester Range 1 V/DIV, 10 μs/DIV Condition Engine switch on (IG) HINT: The waveform varies depending on the CAN communication signal.

Scheme 20

Scheme 21

1. DESCRIPTION When troubleshooting OBD II (On-Board Diagnostics) vehicles, Techstream (complying with SAE J1987) must be connected to the DLC3 (Data Link Connector 3) of the vehicle. Various data in the vehicle's ECM (Engine Control Module) can be then read. OBD ll regulations require that the vehicle's on-board computer illuminates the MIL (Malfunction Indicator Lamp) on the instrument panel when the computer detects a malfunction in: The emission control systems components. The power train control components (which affect vehicle emissions). The computer itself. In addition, the applicable DTCs (Diagnostic Trouble Codes) prescribed by SAE J2012 are recorded on 3 consecutive trips, the MIL turns off automatically but the DTCs remain recorded in the ECM memory. To check the DTCs, connect Techstream to the DLC3. The tester displays DTCs, freeze frame data, and a variety of the engine data. The DTCs and freeze frame data can be erased with the tester. In order to enhance OBD function on vehicles and develop the Off-Board diagnosis system, CAN communication is introduced in this system (CAN: Controller Area Network). It minimizes a gap between technician skills and vehicle technology. CAN is a network, which uses a pair of data transmission lines, spanning multiple computers and sensors. It allows a high speed communication between the systems and simplification of the wire harness connection.
2. NORMAL MODE AND CHECK MODE The diagnosis system operates in normal mode during normal vehicle use. In normal mode, 2 trip detection logic is used to ensure accurate detection of malfunctions. Check mode is also available as an option for technicians. In check mode, 1 trip detection logic is used for simulating malfunction symptoms and increasing the system's ability to detect malfunctions, including intermittent problems (Techstream only).
3. 2 TRIP DETECTION LOGIC When a malfunction is first detected, the malfunction is temporarily stored in the ECM memory (1st trip). If the same malfunction is detected during the next subsequent drive cycle, the MIL is illuminate (2nd trip).
4. FREEZE FRAME DATA The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was running or stopped, whether the engine was warmed up or not, whether the air fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction.
5. DLC3 (Data link Connector 3) The vehicle's ECM uses the ISO 15765-4 for communication protocol. The terminal arrangement of the DLC3 complies with SAE J1962 and matches the ISO 15765-4 format. Symbols Terminal No. Names Reference terminal Results Condition SIL 7 Bus "+" line 5 - Signal ground Pulse generation During transmission CG 4 Chassis ground Body ground 1 ohms or less Always SG 5 Signal ground Body ground 1 ohms or less Always BAT 16 Battery ground Body ground 9 to 14 V Always CANH 6 CAN "High" line CANL 54 to 69 ohms Engine switch off CANH 6 CAN "High" line Battery positive 1 Mohms or higher Engine switch off CANH 6 CAN "High" line CG 1 kohms or higher Engine switch off CANL 14 CAN "Low" line Battery positive 1 Mohms or higher Engine switch off CANL 14 CAN "Low" line CG 1 kohms or higher Engine switch off HINT: The DLC3 is the interface prepared for reading various data from the vehicle's ECM. After connecting the cable of Techstream, turn the engine switch on (IG) and turn the tester on. If a communication failure message is displayed on the tester screen (on the tester: UNABLE TO CONNECT TO VEHICLE), a problem exists in either the vehicle or tester. In order to identify the location of the problem, connect the tester to another vehicle. If communication is normal: Inspect the DLC3 on the original vehicle. If communication is still not possible: The problem is probably in the tester itself. Consult the Service Department listed in the instruction manual.
6. BATTERY VOLTAGE Standard Voltage 11 to 14 V If voltage is below 11 V, replace or recharge the battery before proceeding.
7. MIL (Malfunction Indicator Lamp) The MIL is illuminated when the engine switch is first turned on (the engine is not running). The MIL should turn OFF when the engine is started. If the MIL remains illuminated, the diagnosis system has detected a malfunction or abnormality in the system. HINT: If the MIL is not illuminated when the engine switch is first turned on, check the MIL circuit. Refer to «MIL Circuit»(ref-387361-S12226687202011022400000).
8. ALL READINESS HINT: With All Readiness you can check whether or not the DTC judgment has been completed by using Techstream. You should check All Readiness after simulating malfunction symptoms or for validation after finishing repairs. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn Techstream ON. Clear the DTCs. Perform the DTC judgment driving pattern to run the DTC judgment. Select the following menu items: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTCs to be confirmed. Check the DTC judgment result. TECHSTREAM: Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System normal INCOMPLETE DTC judgment not completed You should perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit

DTC CHECK / CLEAR

Note. When the diagnosis system is changed from the normal mode to check mode or vice versa, all DTCs and freeze frame data recorded in normal mode are erased. Before changing modes, always check and make a note of DTCs and freeze frame data.

HINT

1. DTCs which are stored in the ECM can be displayed on Techstream. Techstream can display the current and pending DTCs.
2. Same DTCs are not set if the ECM does not detect the same malfunction again during a second consecutive driving cycle. However, such malfunctions, detected on only one occasion, are stored as pending DTCs.

1. CHECK DTC (Using Techstream) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following menu items: Powertrain / Engine and ECT / Trouble Codes. Check the DTC(s) and freeze frame data, and then write them down. Check the details of the DTC(s). Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-387359-S23628788162011022400000).
2. CLEAR DTC (Using Techstream) Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following menu items: Powertrain / Engine and ECT / Trouble Codes. Erase the DTCs.
3. CLEAR DTC (Without using Techstream) Perform either one of the following operations: Disconnect the negative battery cable for more than 1 minute. Remove the EFI and ETCS fuses from the engine room J/B and R/B No. 2 located inside the engine compartment for more than 1 minute.

Scheme 22

1. DESCRIPTION The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was running or stopped, whether the engine was warmed up or not, whether the air fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction. HINT: If it is impossible to replicate the problem even though a DTC is detected, confirm the freeze frame data. The ECM records engine conditions in the from of freeze frame data every 0.5 seconds. Using Techstream, five separate sets of freeze frame data, including the data values at the time when the DTC was set, can be checked. 3 data set before the DTC was set. 1 data set when the DTC was set. 1 data set after the DTC was set. These data sets can be used to simulate the condition of the vehicle around the time of the occurrence of the malfunction. The data may assist in identifying of the cause of the malfunction, and in judging whether it was temporary or not.
2. LIST OF FREEZE FRAME DATA LABEL (Techstream Display) Measure Item Diagnostic Note Trouble Code Freeze DTC - Vehicle Speed Vehicle speed Speed indicated on speedometer Engine Speed Engine speed - Calculate Load Calculate load Calculated load by ECM Vehicle Load Vehicle load - MAF Mass air flow volume If value approximately 0.0 g/s: Mass air flow meter power source circuit open or shorted VG circuit open or shorted If value 160.0 g/s or more: E2G circuit open Atmosphere Pressure Atmospheric pressure - Coolant Temp Engine coolant temperature If value -40°C (-40°F), sensor circuit open If value 140°C (284°F), sensor circuit shorted Intake Air Intake air temperature If value -40°C (-40°F), sensor circuit open If value 140°C (284°F), sensor circuit shorted Ambient Temperature Ambient temperature - Engine Run Time Accumulated engine running time - Initial Engine Coolant Temp Initial engine coolant temperature - Initial Intake Air Temp Initial intake air temperature - Battery Voltage Battery voltage - Accel Sens. No. 1 Volt % Absolute Accelerator Pedal Position (APP) No. 1 - Accel Sens. No. 2 Volt % Absolute APP No. 2 - Throttle Sensor Volt % Throttle position Read value with engine switch on (IG) (Do not start engine) Throttle Sensor #2 Volt % Throttle sensor positioning #2 - Throttle Sensor Position Throttle sensor positioning Read value with engine switch on (IG) (Do not start engine) Throttle Motor DUTY Throttle motor - Fuel Press Fuel Pressure - Injection Volume (Cylinder 1) Injection volume - Fuel Pump Speed Control Fuel pump speed control status - Fuel Pump/Speed Status Fuel pump/speed status - Vacuum Pump Vacuum pump ON: Operating Combustion Status (D4) Combustion status (D4) - Fuel Pressure Target Value Target fuel pressure - Fuel Pump Duty (D4) Fuel pump duty (D4) - High Pressure FP Duty High pressure fuel pump duty - HP FP Discharge Rate High pressure fuel pump discharge rate (for bank1) - SCV Status (D4) SCV status (D4) - SCV Angle (D4) SCV angle (D4) - SCV Angle Sensor (D4) SCV angle sensor (D4) - Injection Timing (D4) Injection timing (D4) - Injection Time (D4) Injection timing (D4) - EVAP (Purge) VSV EVAP purge VSV duty ratio - Evap Purge Flow Purge flow - Purge Density Learn Value Learning value of purge density - EVAP System Vent Valve EVAP system vent valve ON: Closed EVAP Purge VSV EVAP Purge VSV - Target Air-Fuel Ratio Target air-fuel ratio - AF Lambda B1S1 Fuel trim at A/F sensor - AF Lambda B2S1 Fuel trim at A/F sensor - AFS Voltage B1S1 A/F sensor output voltage Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensor AFS Voltage B2S1 A/F sensor output voltage Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensor AFS Current B1S1 A/F sensor output current Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output current of sensor AFS Current B2S1 A/F sensor output current Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output current of sensor O2S B1S2 Heated oxygen sensor output Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensor O2S B2S2 Heated oxygen sensor output Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensor O2S Impedance B1S2 Heated oxygen sensor impedance (Bank 1) for North America O2S Impedance B2S2 Heated oxygen sensor impedance (Bank 2) for North America Short FT #1 Short-term fuel trim Short-term fuel compensation used to maintain air fuel ratio at stoichiometric air-fuel ratio Long FT #1 Long-term fuel trim Overall fuel compensation carried out in long-term to compensate a continual deviation of short-term fuel trim from central value Total FT #1 Total fuel trim - Short FT #2 Short-term fuel trim Short-term fuel compensation used to maintain air fuel ratio at stoichiometric air-fuel ratio Long FT #2 Long-term fuel trim Overall fuel compensation carried out in long-term to compensate a continual deviation of short-term fuel trim from central value Total FT #2 Total fuel trim - Fuel System Status #1 Fuel system status (Bank 1) OL (Open Loop): Has not yet satisfied conditions to go closed loop CL (Closed Loop): Using air fuel ratio sensor as feedback for fuel control OL DRIVE: Open loop due to driving conditions (fuel enrichment) OL FAULT: Open loop due to detected system fault CL FAULT: Closed loop but air fuel ratio sensor, which used for fuel control malfunctioning Fuel System Status #2 Fuel system status (Bank 2) OL (Open Loop): Has not yet satisfied conditions to go closed loop CL (Closed Loop): Using air fuel ratio sensor as feedback for fuel control OL DRIVE: Open loop due to driving conditions (fuel enrichment) OL FAULT: Open loop due to detected system fault CL FAULT: Closed loop but air fuel ratio sensor, which used for fuel control malfunctioning IGN Advance Ignition advance - Knock Feedback Value Feedback value of knocking - Knock Correct Learn Value Correction learning value of knocking - ACIS VSV ACIS VSV - VVT Control Status #1 VVT control status (bank 1) - VVT Control Status #2 VVT control status (bank 2) - VVT Aim Angle #1 VVT aim angle (bank 1) - VVT Change Angle #1 VVT change angle (bank 1) - VVT OCV Duty #1 VVT OCV operation duty (bank 1) - VVT Aim Angle #2 VVT aim angle (bank 2) - VVT Change Angle #2 VVT change angle (bank 2) - VVT OCV Duty #2 VVT OCV operation duty (bank 2) - VVT Ex Hold Lrn Val #1 VVT exhaust hold duty ratio learning value (bank 1) - VVT Ex Chg Angle #1 VV exhaust change angle (bank 1) - VVT Ex OCV Duty #1 VVT exhaust OCV duty (bank 1) - VVT Ex Hold Lrn Val #2 VVT exhaust hold duty ration learning value (bank 2) - VVT Ex Chg Angle #2 VVT exhaust change angle (bank 2) - VVT Ex OCV Duty #2 VVT exhaust OCV duty (bank 2) - Catalyst Temp B1S1 Catalyst temperature - Catalyst Temp B2S1 Catalyst temperature - Catalyst Temp B1S2 Catalyst temperature - Catalyst Temp B2S2 Catalyst temperature - Starter Signal Starter signal - Starter Control Starter control - Power Steering Signal Record Power Steering Signal - Starter Relay Starter relay - Power Steer. Sig. Record Power Steering Signal (history) Signal status usually ON until engine switch is turned off ACC Relay ACC relay - Neutral Position SW Signal Neutral position switch signal - Clutch Switch Clutch switch status - Stop Light Switch Stop light switch - A/C Signal A/C signal - Closed Throttle Position SW Closed throttle position switch - Fuel Cut Condition Fuel cut condition ON or OFF - Immobilizer Communication Immobilizer communication ON or OFF OFF: Communication malfunctioning, or engine immobilizer system set Electrical Load Signal Electrical load signal - Engine Oil Pressure SW Engine oil pressure switch signal Always ON while engine is running Time after DTC Cleared Cumulative time after DTC cleared - Distance from DTC Cleared Accumulated distance after DTC cleared - Warm-up Cycle Cleared DTC Warm-up cycle after DTC cleared - TC and TE1 TC and TE1 terminals of DLC3 - Ignition Trig. Count Ignition - Cylinder #1 Misfire Count Cylinder #1 misfire rate Displayed only while idling Cylinder #2 Misfire Count Cylinder #2 misfire rate Displayed only while idling Cylinder #3 Misfire Count Cylinder #3 misfire rate Displayed only while idling Cylinder #4 Misfire Count Cylinder #4 misfire rate Displayed only while idling Cylinder #5 Misfire Count Cylinder #5 misfire rate Displayed only while idling Cylinder #6 Misfire Count Cylinder #6 misfire rate Displayed only while idling All Cylinders Misfire Count All cylinder misfire rate Displayed only while idling Misfire RPM Misfire RPM - Misfire Load Misfired load - Misfire Margin Misfire monitoring - Catalyst OT MF F/C Catalyst Over Tmp Misfire prevention F/C - Cat OT MF F/C History Catalyst Over Tmp Misfire prevention F/C history - Cat OT MF F/C Cylinder #1 Catalyst Over Tmp Misfire prevention #1 - Cat OT MF F/C Cylinder #2 Catalyst Over Tmp Misfire prevention #2 - Cat OT MF F/C Cylinder #3 Catalyst Over Tmp Misfire prevention #3 - Cat OT MF F/C Cylinder #4 Catalyst Over Tmp Misfire prevention #4 - Cat OT MF F/C Cylinder #5 Catalyst Over Tmp Misfire prevention #5 - Cat OT MF F/C Cylinder #6 Catalyst Over Tmp Misfire prevention #6 - Swirl C.V. Duty Ratio SCV duty ratio - A/C Magnetic Clutch Relay A/C magnetic clutch relay - Electric Fan Motor Electric fan motor - Idle Fuel Cut Idle fuel cut ON: when throttle valve fully closed and engine speed over 1500 rpm FC TAU FC TAU Fuel cut being performed under very light load to prevent engine combustion from becoming incomplete Engine Speed of Cyl #1 Engine rpm during No. 1 cylinder fuel cut Output only when Control the Cylinder #1 Fuel Cut is performed using Active Test Engine Speed of Cyl #2 Engine rpm during No. 2 cylinder fuel cut Output only when Control the Cylinder #2 Fuel Cut is performed using Active Test Engine Speed of Cyl #3 Engine rpm during No. 3 cylinder fuel cut Output only when Control the Cylinder #3 Fuel Cut is performed using Active Test Engine Speed of Cyl #4 Engine rpm during No. 4 cylinder fuel cut Output only when Control the Cylinder #4 Fuel Cut is performed using Active Test Engine Speed of Cyl #5 Engine rpm during No. 5 cylinder fuel cut Output only when Control the Cylinder #5 Fuel Cut is performed using Active Test Engine Speed of Cyl #6 Engine rpm during No. 6 cylinder fuel cut Output only when Control the Cylinder #6 Fuel Cut is performed using Active Test Av Engine Speed of All Cyl Engine rpm during No. 1 to No. 6 cylinder fuel cut Output only when Active Test is performed Received MIL from ECT MIL status from ECT - Shift Position Sig from ECT Shift position signal from ECT - A/T Oil Temp from ECT ATF temperature from ECT - SPD (NO) Output shaft speed - SPD (NT) Input shaft speed - ECT Lock Up ECT lock up status

DATA LIST / ACTIVE TEST

1. DATA LIST HINT: By reading the Data List displayed on Techstream, you can check values, including those of the switches, sensors, and actuators, without removing any parts. Reading the Data List as the first step of troubleshooting is one method of shortening diagnostic time. NOTE: In the table below, the values listed under Normal Condition are reference only. Do not depend solely on these values when determining whether or not a part is faulty. Warm up the engine. Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following menus: Powertrain / Engine and ECT / Data List. Check the values by referring to the table below. Tester Display Measurement Item/Range Normal Condition (*1) Diagnostic Note Vehicle Speed Vehicle speed: Min.: 0 km/h, Max.: 255 Km/h Actual vehicle speed Speed indicated on speedometer Engine Speed Engine speed: Min.: 0 rpm, Max.: 16383.75 rpm: A/T: 650 to 750 rpm: Idling M/T: 700 to 800 rpm: Idling - Calculate Load Calculated load by ECM: Min.: 0%, Max.: 100% A/T: 10.5 to 16.5%: Idling 12.0 to 18.0%: Running without load (2500 rpm) M/T: 10.0 to 16.0%: Idling 10.0 to 16.0%: Running without load (2500 rpm) - Vehicle Load Vehicle load: Min.: 0%, Max.: 25700% Actual vehicle load - MAF Air flow rate from MAF meter: Min.: 0 gm/sec, Max.: 655.35 gm/sec A/T: 1.9 to 2.9 gm/sec: Idling 7.7 to 11.3 gm/sec: 2500 rpm M/T: 1.9 to 2.9 gm/sec: Idling 6.5 to 10.1 gm/sec: 2500 rpm If value approximately 0.0 gm/sec: Mass air flow meter power source circuit open VG circuit open or short If value 160.0 gm/sec or more: E2G circuit open Atmosphere Pressure Atmospheric pressure: Min.: 0 kPa, Max.: 255 kPa Equivalent to atmospheric pressure (absolute pressure) - Coolant Temp Engine coolant temperature: Min.: -40°C (-40 °F), Max.: 140°C (284 °F) 80 to 105°C (176 to 221°F): After warming up If value -40°C (-40°F): sensor circuit open If value 140°C (284°F): sensor circuit shorted Intake Air Intake air temperature: Min.: -40°C (-40°F), Max.: 140°C (284°F) Equivalent to ambient air temperature If value -40°C (-40°F): sensor circuit open If value 140°C (284°F): sensor circuit shorted Ambient Temperature Ambient temperature: Min.: -40°C (-40 °F), Max.: 215°C (419 °F) Actual atmospheric temperature - Engine Run Time Engine run time: Min.: 0 second, Max.: 65535 seconds Time after engine start - Initial Engine Coolant Temp Initial engine coolant temperature: Min.: -40°C (-40°F), Max.: 120°C (248 °F) Close to ambient air temperature Service data Initial Intake Air Temp Initial intake air temperature: Min.: -40°C (-40°F), Max.: 120°C (248 °F) Close to ambient air temperature Service data Battery Voltage Battery voltage: Min.: 0 V, Max.: 65.535 V 9 to 14 V: Idling - Accel Sens. No. 1 Volt % Absolute Accelerator Pedal Position (APP) No. 1: Min.: 0%, Max.: 100% 10 to 25%: Accelerator pedal released 60 to 90%: Accelerator pedal fully depressed - Accel Sens. No. 2 Volt % Absolute APP No. 2: Min.: 0%, Max.: 100% 20 to 45%: Accelerator pedal released 80 to 100%: Accelerator pedal fully depressed - Accel Sensor Out No. 1 APP sensor No. 1 voltage: Min.: 0 V, Max.: 4.98 V - ETCS Freeze data Accel Sensor Out No. 2 APP sensor No. 2 voltage: Min.: 0 V, Max.: 4.98 V - ETCS Freeze data Accel Sensor Out No. 1 APP sensor No. 1 voltage: Min.: 0 V, Max.: 5 V 0.5 to 1.1 V: Accelerator pedal released 2.6 to 4.5 V: Accelerator pedal fully depressed - Accel Sensor Out No. 2 APP sensor No. 2 voltage: Min.: 0 V, Max.: 5 V 1.2 to 2.0 V: Accelerator pedal released 3.4 to 5.0 V: Accelerator pedal fully depressed - Accelerator Idle Position Whether or not accelerator pedal position sensor detecting idle: ON or OFF ON: Idling - Accel Fully Close #1 (AD) Accelerator fully closed value No. 1 (AD): Min.: 0 V, Max.: 4.9804 V - ETCS service data Accel Fully Close Learn #1 Accelerator fully closed learning value No. 1: Min.: 0 V, Max.: 124.512 deg - ETCS service data Accel Fully Close Learn #2 Accelerator fully closed learning value No. 2: Min.: 0 V, Max.: 124.512 deg - ETCS service data Throttle Sensor Volt % Throttle position: Min.: 0%, Max.: 100% 10 to 24%: Idling Calculated value based on VTA1 Throttle Sensor #2 Volt % Throttle sensor positioning #2: Min.: 0%, Max.: 100% - Calculated value based on VTA2 ST1 Brake pedal signal: ON or OFF ON: Brake pedal released - System Guard System guard: ON or OFF - ETCS service data Open Side Malfunction Open side malfunction: ON or OFF - ETCS service data Throttle Idle Position Whether or not throttle position sensor detecting idle: ON or OFF ON: Idling - Throttle Require Position Throttle requirement position: Min.: 0 V, Max.: 5 V 0.5 to 1.0 V: Idling - Throttle Sensor Position Throttle requirement positioning: Min.: 0%, Max.: 100% 10 to 24%: Idling Calculated value based on VTA1 Throttle Position No. 1 Throttle position sensor No. 1 output voltage: Min.: 0 V, Max.: 4.98 V - ETCS Freeze data Throttle Position No. 2 Throttle position sensor No. 2 output voltage: Min.: 0 V, Max.: 4.98 V - ETCS Freeze data Throttle Position No. 1 Throttle position No. 1: Min.: 0 V, Max.: 5 V 0.5 to 1.2 V: Throttle fully closed 3.2 to 4.8 V: Throttle fully open - Throttle Position No. 2 Throttle position No. 2: Min.: 0 V, Max.: 5 V 2.1 to 3.1 V: Throttle fully closed 3.2 to 4.8 V: Throttle fully open - Throttle Position Command Throttle position command value: Min.: 0 V, Max.: 4.9804 V 0.5 to 4.8 V ETCS service data Throttle Sens Open Pos #1 Throttle sensor opener position No. 1: Min.: 0 V, Max.: 4.9804 V 0.6 to 0.9 V ETCS service data Throttle Sens Open Pos #2 Throttle sensor opener position No. 2: Min.: 0 V, Max.: 4.9804 V 2.2 to 2.6 V ETCS service data Throttle Sens Open #1 (AD) Throttle sensor opener position No. 1 (AD): Min.: 0 V, Max.: 4.9804 V 0.6 to 0.9 V ETCS service data Throttle Motor Whether or not throttle actuator control permitted: ON or OFF ON: Idling Read value with engine switch on (IG) (Do not start engine) Throttle Motor Current Throttle actuator current: Min.: 0 A, Max.: 20 A 0 to 3.0 A: Idling - Throttle Motor DUTY Throttle actuator: Min.: 0%, Max.: 100% 0.5 to 40%: Idling - Throttle Motor Current Throttle current: Min.: 0 A, Max.: 19.92 A 0 to 3.0 A: Idling - Throttle Motor Open Duty Throttle actuator opening duty ratio: Min.: 0%, Max.: 100% 0 to 40%: Idling ETCS service data Throttle Motor Close Duty Throttle actuator closed duty ratio: Min.: 0%, Max.: 100% 0 to 40%: Idling ETCS service data Throttle Motor Duty (Open) Throttle actuator duty ratio (open): Min.: 0%, Max.: 100% 0 to 40%: Idling ETCS service data Throttle Motor Duty (Close) Throttle actuator duty ratio (close): Min.: 0%, Max.: 100% 0 to 40%: Idling ETCS service data Throttle Fully Close Learn Throttle valve fully closed (learned value): Min.: 0 V, Max.: 5 V 0.4 to 0.8 V - ETCS Actuator Power Whether or not electric throttle control system power input: ON or OFF ON: Idling - +BM Voltage +BM voltage: Min.: 0, Max.: 19.921 10 to 15 V: Idling ETCS service data Actuator Power Supply Actuator power supply ON or OFF ON: Idling ETCS service data Clutch Current Clutch current: Min.: 0 A, Max.: 2.49 A - - Fail Safe Drive Whether or not fail safe function executed: ON or OFF ON: ETCS has failed - Fail Safe Drive (Main CPU) Whether or not fail safe function executed: ON or OFF ON: ETCS has failed - Fuel Press Fuel pressure: Min.: 0 kPa Max.: 655350 kPa 3 to 5 MPa: Idling 7 to 9 MPa: 2000 rpm - Injection Volum (Cylinder 1) Injection volume (Cylinder 1): Min.: 0 ml, Max.: 2.047 ml 0.05 to 0.15 ml/idling Quantity of fuel injection volume for 10 times Fuel Pump Speed Control Fuel pump speed control status: ON or OFF Idling: ON Active test Fuel Pump/Speed Status Fuel pump/status: ON or OFF ON: Cranking Active Test support data Vacuum Pump Key-off EVAP system leak detection pump status: ON or OFF - Active Test support data Combustion Status (D4) Combustion status FC, Stoich 1, Stoich 2 Stoich 1 - Fuel Pressure Target Value Target fuel pressure Min.: 0 mm3, Max.: 512 mm3 AT: 3 to 5 MPa: Idling MT: 2.5 to 4.5 MPa: Idling - Fuel Pump Duty (D4) Fuel pump duty Min.: 0, Max.: 100% 0 to 40%: Idling - High Pres FP Duty Duty by the high pressure fuel pump Min.: 0%, Max.: 100% 0 to 40% - HP FP Discharge Rate Fuel volume required by the high- pressure fuel pump Min.: 0 mm3, Max.: 512 mm3 - - SCV Status (D4) SCV status Min.: 0, Max.: 1 1: Idling - SCV Angle (D4) SCV angle Min.: -17.25 deg, Max.: 107.75 deg 0 deg: Idling - SCV Angle Sensor (D4) SCV angle sensor Min.: 0, Max.: 20 V 0.6 V: Idling - Injection Timing (D4) Injection timing Min.: -210 CA, Max.: 480 CA 300°CA: Idling - Injection Time (D4) Injection time (Cylinder 1) Min.: 0 ms, Max.: 32.64 ms 0.7 to 1.6 ms: Idling - EVAP (Purge) VSV EVAP (Purge) VSV control duty: Min.: 0%, Max.: 100% 10 to 50%: Idling Order signal from ECM Evap Purge Flow Purge flow: Min.: 0%, Max.: 102.4% 0 to 10%: Idling Service data Purge Density Learn Value Learning value of purge density: Min.: -50, Max.: 350 -40 to 10: Idling Service data Vapor Pressure Pump Vapor pressure: Min.: -4.125 kPa, Max.: 2.125 kPa 0 kPa: Fuel tank cap removed Pressure inside fuel tank monitored by vapor pressure sensor Vapor pressure (calculated) Vapor pressure (calculated): Min.: -5.632 kPa, Max.: 715.264 kPa 0 kPa: Fuel tank cap removed Pressure inside fuel tank monitored by vapor pressure sensor EVAP System Vent Valve Key-off EVAP system vent valve status: ON or OFF - Active Test support data EVAP Purge VSV VSV status for EVAP control: ON or OFF - - Target Air-Fuel Ratio Target air-fuel ratio: Min.: 0, Max.: 1.999 0.8 to 1.2: Idling - AF Lambda B1S1 Short-term fuel trim associated with bank 1 sensor 1: Min.: 0, Max.: 1.999 Value less than 1 (0.000 to 0.999) = Rich Stoichiometric air-fuel ratio = 1 Value greater than 1 (1.001 to 1.999) = Lean - AF Lambda B2S1 Short-term fuel trim associated with bank 2 sensor 1: Min.: 0, Max.: 1.999 Value less than 1 (0.000 to 0.999) = Rich Stoichiometric air-fuel ratio = 1 Value greater than 1 (1.001 to 1.999) = Lean - AFS Voltage B1S1 A/F sensor output voltage for bank 1 sensor 1: Min.: 0 V, Max.: 7.999 V 2.8 to 3.8 V: Idling Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensor AFS Voltage B2S1 A/F sensor output voltage for bank 2 sensor 1: Min.: 0 V, Max.: 7.999 V 2.8 to 3.8 V: Idling Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensor AFS Current B1S1 A/F sensor current for bank 1 sensor 1: Min.: -128 mA, Max.: 127.99 mA - - AFS Current B2S1 A/F sensor current for bank 2 sensor 1: Min.: -128 mA, Max.: 127.99 mA - - O2S B1S2 Heated oxygen sensor output voltage for bank 1 sensor 2: Min.: 0 V, Max.: 1.275 V 0.1 to 0.9 V: Driving at 44 mph (70 km/h) Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensor O2S B2S2 Heated oxygen sensor output voltage for bank 2 sensor 2: Min.: 0 V, Max.: 1.275 V 0.1 to 0.9 V: Driving at 44 mph (70 km/h) Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensor O2S Impedance B1S2*3 Sub heated oxygen sensor impedance (bank 1 sensor 2): Min.: 0 ohms, Max.: 21247.68 ohms - - O2S Impedance B2S2*3 Sub heated oxygen sensor impedance (bank 2 sensor 2): Min.: 0 ohms, Max.: 21247.68 ohms - - Short FT #1 Short-term fuel trim of bank 1: Min.: -100%, Max.: 99.2% - 20 to 20% Short-term fuel compensation used to maintain air-fuel ratio at stoichiometric air-fuel ratio Long FT #1 Long-term fuel trim of bank 1: Min.: -100%, Max.: 99.2% - 30 to 30% Overall fuel compensation carried out in long-term to compensate continual deviation of short-term fuel trim from central value Total FT #1 Total fuel trim of bank 1 Average value for fuel trim system of bank 1: Min.: -0.5, Max.: 0.496 - 0.28 to 0.2: Idling - Short FT #2 Short-term fuel trim of bank 2: Min.: -100%, Max.: 99.2% - 20 to 20% Short-term fuel compensation used to maintain air-fuel ratio at stoichiometric air-fuel ratio Long FT #2 Long-term fuel trim of bank 2: Min.: -100%, Max.: 99.2% - 30 to 30% Overall fuel compensation carried out in long-term to compensate continual deviation of short-term fuel trim from central value Total FT #2 Total fuel trim of bank 1 Average value for fuel trim system of bank 2: Min.: -0.5, Max.: 0.496 - 0.28 to 0.2: Idling - Fuel System Status #1 Fuel system status (Bank 1): OL or CL or OLDRIVE or OLFAULT or CLFAULT CL: Idling after warming up OL (Open Loop): Has not yet satisfied conditions to go closed loop CL (Closed Loop): Using air fuel ratio sensor as feedback for fuel control OLDRIVE: Open loop due to driving conditions (fuel enrichment) OLFAULT: Open loop due to detected system fault CLFAULT: Closed loop but air fuel ratio sensor, which used for fuel control malfunctioning Fuel System Status #2 Fuel system status (Bank 2): OL or CL or OLDRIVE or OLFAULT or CLFAULT CL: Idling after warming up OL (Open Loop): Has not yet satisfied conditions to go closed loop CL (Closed Loop): Using air fuel ratio sensor as feedback for fuel control OLDRIVE: Open loop due to driving conditions (fuel enrichment) OLFAULT: Open loop due to detected system fault CLFAULT: Closed loop but air fuel ratio sensor, which used for fuel control malfunctioning IGN Advance Ignition timing advance for No. 1 cylinder: Min.: -64 deg., Max.: 63.5 deg. BTDC 5 to 22°: Idling - Knock Feedback Value Feedback value of knocking: Min.: -64°CA, Max.: 1984°CA -28 to 0°CA: Driving at 44 mph (70 km/h) Service data Knock Correct Learn Value Correction learning value of knocking: Min.: -64°CA, Max.: 1984°CA 4 to 28°CA: Driving at 44 mph (70 km/h) Service data ACIS VSV ACIS VSV: ON or OFF - Active Test support data VVT Control Status #1 VVT control (bank 1) status: ON or OFF - - VVT Control Status #2 VVT control (bank 2) status: ON or OFF - - VVT Aim Angle #1*2 VVT aim angle (bank 1): Min.: 0%, Max.: 100% 0%: Idling VVT duty signal value during intrusive operation VVT Change Angle #1*2 VVT change angle (bank 1): Min.: 0°FR, Max.: 60°FR 0°FR: Idling Displacement angle during intrusive operation VVT OCV Duty #1*2 VVT OCV operation duty: Min.: 0%, Max.: 100% 10 to 40%: Idling Requested duty value for intrusive operation VVT Aim Angle #2*2 VVT aim angle (bank 2): Min.: 0%, Max.: 100% 0%: Idling VVT duty signal value during intrusive operation VVT Change Angle #2*2 VVT change angle (bank 2): Min.: 0°FR, Max.: 60°FR 0°FR: Idling Displacement angle during intrusive operation VVT OCV Duty #2*2 VVT OCV (bank 2) operation duty: Min.: 0%, Max.: 100% 10 to 40%: Idling Requested duty value for intrusive operation VVT Ex Hold Lrn Val #1*2 VVT exhaust hold duty ratio learning value (bank 1): Min.: 0%, Max.: 100% 40 to 65%: Idling - VVT Ex Chg Angle #1*2 VVT exhaust change angle (bank 1) Min.: 0°FR, Max.: 60°FR 0°FR: Idling - VVT Ex OCV Duty #1*2 VVT exhaust OCV duty (bank 1) Min.: 0%, Max.: 100% 0%: Idling - VVT Ex Hold Lrn Val #2*2 VVT exhaust hold duty ratio learning value (bank 2): Min.: 0%, Max.: 100% 40 to 65%: Idling - VVT Ex Chg Angle #2*2 VVT exhaust change angle (bank 2) Min.: 0°FR, Max.: 60°FR 0°FR: Idling - VVT Ex OCV Duty #2*2 VVT exhaust OCV duty (bank 1): Min.: 0%, Max.: 100% 0%: Idling - Catalyst Temp B1S1 Catalyst temperature (bank 1, sensor 1): Min.: -40°C (-40°F), Max.: 6513.5°C (11755°F) - - Catalyst Temp B2S1 Catalyst temperature (bank 2, sensor 1): Min.: -40°C (-40°F), Max.: 6513.5°C (117550°F) - - Catalyst Temp B1S2 Catalyst temperature (bank 1, sensor 2): Min.: -40°C (-40°F), Max.: 6513.5°C (11755°F) - - Catalyst Temp B2S2 Catalyst temperature (bank 2, sensor 2): Min.: -40°C (-40°F), Max.: 6513.5°C (11755°F) - - Starter Signal Starter signal: ON or OFF ON: Cranking - Starter Control Starter switch status ON or OFF ON: Cranking - Power Steering Signal Record Power steering signal ON or OFF ON: Power steering operation - Starter Relay Starter relay ON or OFF ON: Cranking - Power Steer. Sig. Record Power steering signal ON or OFF ON: When steering wheel first turned after engine switch turned to ON - ACC Relay ACC relay ON or OFF ON: Cranking - Neutral Position SW Signal PNP switch status ON or OFF ON: P or N position - Clutch Switch Clutch switch status: ON or OFF ON: Clutch pedal depressed - Stop Light Switch Stop light switch: ON or OFF ON: Brake pedal depressed - A/C Signal A/C signal: ON or OFF ON: A/C ON - Closed Throttle Position SW Closed throttle position switch: ON or OFF ON: Throttle fully closed OFF: Throttle open - Fuel Cut Condition Fuel cut condition: ON or OFF ON: Any fuel cut operation executed - Immobilizer Communication Immobilizer communication: ON or OFF - OFF: Communication malfunctioning, or engine immobilizer system set ON: Communication Normal Electrical Load Signal Electrical load signal: ON or OFF ON: Headlights or defogger turned ON - Engine Oil Pressure SW Engine oil pressure switch signal ON or OFF ON: Oil pressure warning light turn ON - Check Mode Check mode: 0: OFF, 1: ON ON: Check mode ON Refer to «CHECK MODE PROCEDURE»(ref-387359-S23762167392011022400000) SPD Test Result Check mode result for speed signal: Compl or Incmpl - - Misfire Test Result Check mode result for misfire monitor: Compl or Incmpl - - OXS1 Test Result Check mode result for HO2 sensor (bank 1): Compl or Incmpl - - OXS2 Test Result Check mode result for HO2 sensor (bank 2): Compl or Incmpl - - A/F Test Results #2 Check mode result for air-fuel ratio sensor (bank 2): Compl or Incmpl - - A/F Test Results #1 Check mode result for air-fuel ratio sensor (bank 1): Compl or Incmpl - - Complete Parts Monitor Comprehensive component monitor Not Avl or Avail - Comprehensive Component Monitor Fuel System Monitor Fuel system monitor Not Avl or Avail - Fuel System Monitor Misfire Monitor Misfire monitor Not Avl or Avail - Misfire Monitor EGR/VVT Monitor EGR/VVT monitor Compl or Incmpl - - EGR/VVT Monitor EGR/VVT monitor Not Avl or Avail - - O2S (A/FS) Heater Monitor O2S (A/FS) heater monitor: Not Avl or Avail - - O2S (A/FS) Heater Monitor O2S (A/FS) heater monitor: Compl or Incmpl - - O2S (A/FS) Monitor O2S (A/FS) monitor: Not Avl or Avail - - O2S (A/FS) Monitor O2S (A/FS) monitor: Compl or Incmpl - - EVAP Monitor EVAP monitor: Not Avl or Avail - - EVAP Monitor EVAP monitor: Compl or Incmpl - - Catalyst Monitor Catalyst monitor: Not Avl or Avail - - Catalyst Monitor Catalyst monitor: Compl or Incmpl - - Component Monitor ENA*3 Comprehensive component monitor: Unable or Enable - - Component Monitor CMPL*3 Comprehensive component monitor: Compl or Incmpl - - Fuel System Monitor ENA*3 Fuel system monitor: Unable or Enable - - Fuel System Monitor CMPL*3 Fuel system monitor: Compl or Incmpl - - Misfire Monitor ENA*3 Misfire monitor: Unable or Enable - - Misfire Monitor CMPL*3 Misfire monitor: Compl or Incmpl - - EGR/VVT Monitor ENA*3 EGR/VVT monitor: Unable or Enable - - EGR/VVT Monitor CMPL*3 EGR/VVT monitor: Compl or Incmpl - - Heater Monitor ENA*3 O2S (A/FS) heater monitor: Unable or Enable - - Heater Monitor CMPL*3 O2S (A/FS) heater monitor: Compl or Incmpl - - O2S (A/FS) Monitor ENA*3 O2S (A/FS) monitor: Unable or Enable - - O2S (A/FS) Monitor CMPL*3 O2S (A/FS) monitor: Compl or Incmpl - - A/C Monitor ENA*3 A/C monitor: Unable or Enable - - A/C Monitor CMPL*3 A/C monitor: Compl or Incmpl - - 2nd Air Monitor ENA*3 2nd air monitor: Unable or Enable - - 2nd Air Monitor CMPL*3 2nd air monitor: Compl or Incmpl - - EVAP Monitor ENA*3 EVAP monitor: Unable or Enable - - EVAP Monitor CMPL*3 EVAP monitor: Compl or Incmpl - - Heated Cat Monitor ENA*3 Heated Cat monitor: Unable or Enable - - Heated Cat Monitor CMPL*3 Heated Cat monitor: Compl or Incmpl - - Catalyst Monitor ENA*3 Catalyst monitor: Unable or Enable - - Catalyst Monitor CMPL*3 Catalyst monitor: Compl or Incmpl - - # Codes (Include History) #Codes: Min.: 0, Max.: 255 - Number of detected DTCs MIL MIL status: ON or OFF ON: MIL ON - MIL ON Run Distance MIL ON Run Distance: Min.: 0 mile (0 km) Max.: 40959 mile (65535 km) Distance after DTC detected - Running Time from MIL ON Running time from MIL ON: Min.: 0 minute, Max.: 65535 minutes Equivalent to running time after MIL ON - Time after DTC Cleared Time after DTC cleared: Min.: 0 minute, Max.: 65535 minutes Equivalent to time after DTCs erased - Distance from DTC Cleared Distance after DTC cleared: Min.: 0 km, Max.: 65535 km Equivalent to drive distance after DTCs erased - Warm-up Cycle Cleared DTC Warm-up cycle after DTC cleared: Min.: 0, Max.: 255 - Number of warm-up cycles after DTC cleared OBD Requirements OBD requirement OBD2 - Number of Emission DTC Emission related DTCs - Number of emission related DTCs TC and TE1 TC and TE1 terminals of DLC3: ON or OFF - Active Test support data Ignition Trig. Count Ignition counter: Min.: 0, Max.: 800 0 to 800 - Cylinder #1 Misfire Count Misfire ratio of cylinder 1: Min.: 0, Max.: 255 0 This item displayed only during idling Cylinder #2 Misfire Count Misfire ratio of cylinder 2: Min.: 0, Max.: 255 0 This item displayed only during idling Cylinder #3 Misfire Count Misfire ratio of cylinder 3: Min.: 0, Max.: 255 0 This item displayed only during idling Cylinder #4 Misfire Count Misfire ratio of cylinder 4: Min.: 0, Max.: 255 0 This item displayed only during idling Cylinder #5 Misfire Count Misfire ratio of cylinder 5: Min.: 0, Max.: 255 0 This item displayed only during idling Cylinder #6 Misfire Count Misfire ratio of cylinder 6: Min.: 0, Max.: 255 0 This item displayed only during idling All Cylinders Misfire Count All cylinders misfire rate: Min.: 0, Max.: 255 0 to 35 - Misfire RPM Engine RPM for first misfire range: Min.: 0 rpm, Max.: 6375 rpm 0 rpm: Misfire 0 - Misfire Load Engine load for first misfire range: Min.: 0 g/rev, Max.: 3.98 g/rev 0 g/rev: Misfire 0 - Misfire Margin Misfire monitoring: Min.: -100%, Max.: 99.22% - 100 to 99.22% Misfire detection margin Catalyst OT MF F/C Catalyst overheat misfire prevention fuel cut availability: Not Avl or Avail Avail: Catalyst OT MF F/C available Not Avl: Catalyst OT MF F/C not available Service data Cat OT MF F/C History Catalyst overheat misfire prevention fuel cut history: ON or OFF ON: Fuel cut operation history exists Service data Cat OT MF F/C Cylinder #1 Display of fuel cut operation in No. 1 (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder #2 Display of fuel cut operation in No. 2 (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder #3 Display of fuel cut operation in No. 3 (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder #4 Display of fuel cut operation in No. 4 (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder #5 Display of fuel cut operation in No. 5 (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder #6 Display of fuel cut operation in No. 6 (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Swirl C.V Duty Ratio SCV duty ratio: Min.: -100%, Max.: 155% 0%: Idling - A/C Magnetic Clutch Relay A/C magnetic clutch relay status ON or OFF - Active Test support data Electric Fan Motor Electric fan motor: ON or OFF ON: Electric fan motor operating - Idle Fuel Cut Fuel cut idle: ON or OFF ON: Fuel cut operating Idle Fuel Cut = "ON" when throttle valve fully closed and engine speed over 2800 rpm FC TAU Fuel cut TAU (Fuel cut during very light load): ON or OFF ON: Fuel cut operating Fuel cut being performed under very light load to prevent engine combustion from becoming incomplete Model Code Model code - Identifies model code: GSE2## Engine Type Engine type - Identifies engine type: 4GR-FSE Cylinder Number Number of cylinders: Min.: 0, Max.: 255 - Identifies number of cylinders: 6 Transmission Type Transmission type - Identifying transmission type: 6AT/MT Destination Destination - Identifying destination: A (America) Model Year Model year: Min.: 1900, Max.: 2155 - Identifying model year: 200# MY System Identification System identification - Identifying engine system: GASLINE (gasoline engine) Engine Speed of Cyl #1 Engine RPM for cylinder 1: Min.: 0 rpm, Max.: 51199 rpm - Output only when check the Cylinder Compression is performed using Active Test Engine Speed of Cyl #2 Engine RPM for cylinder 2: Min.: 0 rpm, Max.: 51199 rpm - Output only when check the Cylinder Compression is performed using Active Test Engine Speed of Cyl #3 Engine RPM for cylinder 3: Min.: 0 rpm, Max.: 51199 rpm - Output only when check the Cylinder Compression is performed using Active Test Engine Speed of Cyl #4 Engine RPM for cylinder 4: Min.: 0 rpm, Max.: 51199 rpm - Output only when check the Cylinder Compression is performed using Active Test Engine Speed of Cyl #5 Engine RPM for cylinder 5: Min.: 0 rpm, Max.: 51199 rpm - Output only when check the Cylinder Compression is performed using Active Test Engine Speed of Cyl #6 Engine RPM for cylinder 6: Min.: 0 rpm, Max.: 51199 rpm - Output only when check the Cylinder Compression is performed using Active Test Av Engine Speed of All Cyl Engine RPM for all cylinders: Min.: 0 rpm, Max.: 51199 rpm - Output only when check the Cylinder Compression is performed using Active Test Received MIL from ECT Received MIL from ECT: ON or OFF MIL illuminate instruction ON signal from ECT: ON - Shift Position Sig from ECT Received shift position signal from ECT: 1st, 2nd, 3rd, 4th, 5th, or 6th Actual shift position - A/T Oil Temp from ECT Received ATF temperature sensor value form ECT: Min.: -40°C (-40°F), Max.: 215°C (419°F) After stall test: Approx. 80°C (176°F) Equal to ambient temperature when cold soak If the value is -40°C (-40°F) or 215°C (419°F), ATF temperature sensor circuit opened or shorted SPD (NO) Output shaft speed: Min.: 0 rpm, Max.: 12750 rpm Vehicle stopped: 0 rpm - SPD (NT) Input shaft speed: Min.: 0 rpm, Max.: 12750 rpm Lock-up is ON (after warming up engine): Input turbine speed (NT) is equal to engine speed Lock-up is OFF (idling with shift lever in N): Input turbine speed (NT) is nearly equal to engine speed - ECT Lock Up Lock Up Status/ ON or OFF Lock-up is Operating: ON Not operating: OFF - HINT: *1: If no idling conditions are specified, the transmission gear selector lever should be in the N or P position, and the A/C switch and all accessory switches should be OFF. *2: Data List values are only displayed when performing the following Active Test: VVT B1, VVT B2, VVT EX B1 and VVT EX B2. For other Active Test, the Data List value will be 0. *3: Except KOREA
2. ACTIVE TEST HINT: Performing an Active Test enables components including the relays, VSV (Vacuum Switching Valve) and actuators, to be operated without removing any parts. An Active Test can be performed with Techstream. Performing an Active Test as the first step of troubleshooting is one method of shortening diagnostic time. Data List can be displayed during Active Test. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following menus: Powertrain / Engine and ECT / Active Test. Perform an Active Test by referring to the below. Tester Display Test Part Control Range Diagnostic Note Control the Injection Volume Change injection volume Between -12.5 and 24.8% All injectors tested at the same time Perform test at less than 3000 rpm Injection volume can be changed in 1% graduations within control range Control the Injection Volume for A/F Sensor Change injection volume Lower by 12.5% or increase by 24.8% Perform test at less than 3000 rpm Control the Injection Volume for A/F Sensor enables checking and graphing of A/F (Air Fuel Ratio) sensor and Heated Oxygen (HO2) sensor voltage outputs Activate the Fuel Pump Speed Control Fuel pump speed control ON (low speed) / OFF (high speed) Test possible when following conditions met: Engine switch on (IG) Engine is stopped Activate the VSV for Intake Control ACIS VSV ON/OFF - Activate the VSV for Evap Control Activate EVAP VSV control ON/OFF - Control the A/C Magnet Clutch Control the A/C magnet clutch ON/OFF - Control the Fuel Pump / Speed Activate fuel pump (C/OPN Relay) ON/OFF - Connect the TC and TE1 Turn on and off TC and TE1 connection ON/OFF ON: TC and TE1 connected OFF: TC and TE1 disconnected Control the Idle Fuel Cut Prohibit Prohibit idling fuel cut control ON/OFF - Prohibit the Catalyst OT Misfire prevent F/C Prohibit catalyst overheat malfunction prevention fuel cut operation during misfire ON: Fuel cut is prohibited Confirm that the vehicle is stopped and engine is 3000 rpm or less. Control the Electric Cooling Fan Control Electric Cooling Fan ON/OFF Test possible when following conditions met: Engine switch on (IG) Engine is stopped Activate the Starter Relay Starter ON/OFF - Activate the ACC Cut Relay Active ACC cut relay ON/OFF Test possible when following conditions met: Engine switch on (IG) Engine is stopped Control the ETCS Open/Close Slow Speed Throttle actuator ON: Throttle valve opens/closes slowly Test possible when following conditions met: Engine switch on (IG) Engine is stopped Fully depressing accelerator pedal (APP: 58 degrees or more) Control the ETCS Open/Close Fast Speed Throttle actuator ON: Throttle valve opens/closes fast Same as above Control the VVT Linear (Bank 1) Control VVT (bank 1) -128 to 127% This valve added to present OCV control duty 100%: Maximum advance -100%: Maximum retard Engine stall or rough idle when VVT actuator operated by 100%. Test possible during idle. Control the VVT System (Bank 1) Turn on and off OCV (Oil Control Valve) ON/OFF Engine stalls or idles roughly when OCV turned ON Normal engine running or idling when OCV OFF Control the VVT Linear (Bank 2) Control VVT (bank 2) Between -128 and 127% Same as above Control the VVT System (Bank 2) Turn on and off OCV (Oil Control Valve) ON/OFF Engine stalls or idles roughly when OCV turned ON Normal engine running or idling when OCV OFF Control the VVT Exhaust Linear (Bank 1) Control VVT (bank 1) -128 to 127% This valve added to present OCV control duty 100%: Maximum advance -100%: Maximum retard - Control the VVT Exhaust Linear (Bank 2) Control VVT (bank 2) Between -128 and 127% Same as above Control the Injection Timing #1 Control injection timing #1 Between -16 CA and 16 CA Test possible during vehicle stopping and engine idling. Control the Injection Timing #2 Control injection timing #2 Between -16 CA and 16 CA Same as above Control the Injection Timing #3 Control injection timing #3 Between -16 CA and 16 CA Same as above Control the Injection Timing #4 Control injection timing #4 Between -16 CA and 16 CA Same as above Control the Injection Timing #5 Control injection timing #5 Between -16 CA and 16 CA Same as above Control the Injection Timing #6 Control injection timing #6 Between -16 CA and 16 CA Same as above Activate the Vacuum Pump Vacuum pump ON/OFF - Activate the VSV for Vent Valve Vent valve ON/OFF - Control the SCV Duty Ratio Control SCV duty ratio Between -128 and 127% Perform test only for 10 seconds. Control the Target Fuel Pressure Control the target fuel pressure Between -12.5 and 24.8% Test possible during vehicle stopping and engine idling. Control the Cylinder #1 Fuel Cut Cylinder #1 injector fuel cut ON/OFF Test possible during vehicle stopping and engine idling.*2 Control the Cylinder #2 Fuel Cut Cylinder #2 injector fuel cut ON/OFF Control the Cylinder #3 Fuel Cut Cylinder #3 injector fuel cut ON/OFF Control the Cylinder #4 Fuel Cut Cylinder #4 injector fuel cut ON/OFF Control the Cylinder #5 Fuel Cut Cylinder #5 injector fuel cut ON/OFF Control the Cylinder #6 Fuel Cut Cylinder #6 injector fuel cut ON/OFF Control the All Cylinders Fuel Cut All cylinder injector fuel cut ON/OFF Check the Cylinder Compression Check the cylinder compression pressure ON/OFF - *1: Except KOREA NOTE: *1: If the display of the Data List's Catalyst OT MF F/C item is Not Avl, perform this Active Test with the vehicle stopped and the engine idling. If the display of the Data List's Catalyst OT MF F/C item is Avail, perform this Active Test as described below. Stop the engine and turn the engine switch on (IG) to turn Control the Cylinder #1 Fuel Cut (to #6 Fuel Cut) ON. Start the engine. HINT: *2: When performing the Active Test item "Check the Cylinder Compression" and then cranking the engine, the ECM stops the fuel injection and ignition, and measures the engine speed for each cylinder. If one cylinder's speed is higher than the others, that cylinder's compression pressure can be concluded to be lower than the others. Warm up the engine. Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester ON. Select the following menu items: Powertrain / Engine and ECT / Active Test / Check the Cylinder Compression. Select the following monitor items: Compression / Engine Speed of Cyl #1 to #6, Av Engine Speed of All Cyl Press the RIGHT or LEFT button to change the Check the Cylinder Compression to ON. HINT: Fuel injection and ignition for all cylinders are prohibited at this time, and each cylinder's engine speed measurement will enter standby mode. Crank the engine until the monitor item values "Engine speed of Cyl #1 to #6" and "Av Engine Speed of All Cyl" change. Monitor the engine speed (Engine Speed of Cyl #1 to #6, Av Engine Speed of All Cyl) displayed on the tester. HINT: The tester displays the values to be extremely high before cranking the engine. Each cylinder's engine speed is measured while cranking the engine and then the tester displays the actual engine speed values. NOTE: The Active Test item "Check the Cylinder Compression" will automatically turn off 255 seconds after the Active Test is turned on. When the "Check the Cylinder Compression" is OFF and the engine is cranked, the engine will start. If the "Check the Cylinder Compression" test needs to be performed again after each cylinder's engine speed measurement has been performed once, press EXIT to return to the Active Test menu screen. Then perform the Check the Cylinder Compression test again. Use a fully-charged battery.
3. SYSTEM CHECK HINT: Performing a System Check enables the system, which consists of multiple actuators, to be operated without removing any parts. In addition, it can show whether or not any DTCs are set, and can detect potential malfunctions in the system. The System Check can be performed with Techstream. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following menus: Powertrain / Engine and ECT / Utility. Perform the System Check by referring to the below. Tester Display Test Part Control Range Diagnostic Note Evaporative System Check (Automatic Mode) Perform 4 steps in order to operate EVAP key-off monitor automatically 35°C (95°F) or less If no DTCs in PENDING CODE after performing this test, system functioning normally Refer to EVAP system. Refer to «EVAP System»(ref-387361-S07210361482011022400000) Evaporative System Check (Manual Mode) Perform 4 steps in order to operate EVAP key-off monitor manually 35°C (95°F) or less Used to detect malfunctioning parts Refer to EVAP system. Refer to «EVAP System»(ref-387361-S07210361482011022400000)

DIAGNOSTIC TROUBLE CODE CHART

HINT

Parameters listed in the chart may not be exactly the same as your readings due to the type of instrument or other factors.

If a DTC is displayed, check the trouble area for the DTC listed in the table below. For details of each DTC.

*: MIL flashes when a catalyst damaged misfire is detected.
