Windshield / Windowglass (Service Information): Overview Lexus IS II facelift 2

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. REMOVE POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL except Wood Panel: Using a molding remover, disengage the 4 claws and 2 clips. Disconnect the connector and remove the power window regulator switch assembly with front door armrest base panel. for Wood Panel: Using a molding remover, disengage the 3 claws and 2 clips. Disconnect the connector and remove the power window regulator switch assembly with front door armrest base panel.
2. REMOVE POWER WINDOW REGULATOR SWITCH ASSEMBLY Disengage the 2 claws and remove the power window regulator switch assembly.

Scheme 41

Scheme 42

1. INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY Check the switch function. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 2 (U) - 5 (E) Auto up or up position Below 1 ohms 4 (A) - 5 (E) Auto up or auto down position Below 1 ohms 10 (D) - 5 (E) Auto down or down position Below 1 ohms 2 (U) - 5 (E) Free 10 kohms or higher 4 (A) - 5 (E) Free 10 kohms or higher 10 (D) - 5 (E) Free 10 kohms or higher If the result is not as specified, replace the power window regulator switch assembly (for front passenger side). Check that the LED illuminates. Apply battery voltage to the power window regulator switch assembly and check that the LED illuminates. OK Measurement Condition Specified Condition Battery positive (+) --> 8 (LED) Battery negative (-) --> 5 (E) LED illuminates If the result is not as specified, replace the power window regulator switch assembly (for front passenger side).

Scheme 43

Scheme 44

1. INSTALL POWER WINDOW REGULATOR SWITCH ASSEMBLY Engage the 2 claws and install the power window regulator switch assembly.
2. INSTALL POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL except Wood Panel: Connect the connector. Engage the 4 claws and 2 clips and install the power window regulator switch assembly with front door armrest base panel. for Wood Panel: Connect the connector. Engage the 3 claws and 2 clips and install the power window regulator switch assembly with front door armrest base panel.

Scheme 45

Scheme 46

Scheme 47

1. REMOVE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH REAR DOOR ARMREST BASE PANEL Using a molding remover, disengage the 2 claws and 2 clips. Disconnect the connector and remove the rear power window regulator switch assembly with rear door armrest base panel.
2. REMOVE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY Disengage the 2 claws and remove the rear power window regulator switch assembly.

Scheme 48

Scheme 49

Scheme 50

Scheme 51

1. INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear LH) Check the switch function. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 2 (U) - 5 (E) Auto up or up position Below 1 ohms 4 (A) - 5 (E) Auto up or auto down position Below 1 ohms 10 (D) - 5 (E) Auto down or down position Below 1 ohms 2 (U) - 5 (E) Free 10 kohms or higher 4 (A) - 5 (E) Free 10 kohms or higher 10 (D) - 5 (E) Free 10 kohms or higher If the result is not as specified, replace the rear power window regulator switch assembly (for rear LH side). Check that the LED illuminates. Apply battery voltage to the rear power window regulator switch assembly and check that the LED illuminates. OK Measurement Condition Specified Condition Battery positive (+) --> 8 (LED) Battery negative (-) --> 5 (E) LED illuminates If the result is not as specified, replace the rear power window regulator switch assembly (for rear LH side).
2. INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear RH) Check the switch function. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 2 (U) - 5 (E) Auto up or up position Below 1 ohms 4 (A) - 5 (E) Auto up or auto down position Below 1 ohms 10 (D) - 5 (E) Auto down or down position Below 1 ohms 2 (U) - 5 (E) Free 10 kohms or higher 4 (A) - 5 (E) Free 10 kohms or higher 10 (D) - 5 (E) Free 10 kohms or higher If the result is not as specified, replace the rear power window regulator switch assembly (for rear RH side). Check that the LED illuminates. Apply battery voltage to the rear power window regulator switch assembly and check that the LED illuminates. OK Measurement Condition Specified Condition Battery positive (+) --> 8 (LED) Battery negative (-) --> 5 (E) LED illuminates If the result is not as specified, replace the rear power window regulator switch assembly (for rear RH side).

Scheme 52

1. INSTALL REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY Engage the 2 claws and install the rear power window regulator switch assembly.
2. INSTALL REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH REAR DOOR ARMREST BASE PANEL Connect the connector. Engage the 2 claws and 2 clips and install the rear power window regulator switch assembly with rear door armrest base panel.

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG. Refer to «DISASSEMBLY [08/2012 - ] - Step 1»(ref-606568-S15452695272014032500000)
3. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 2»(ref-606568-S15452695272014032500000)
4. REMOVE COURTESY LIGHT ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 3»(ref-606568-S15452695272014032500000)
5. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 4»(ref-606568-S15452695272014032500000)
6. REMOVE FRONT DOOR INNER GLASS WEATHERSTRIP. Refer to «DISASSEMBLY [08/2012 - ] - Step 6»(ref-606568-S15452695272014032500000)
7. REMOVE FRONT DOOR SERVICE HOLE COVER. Refer to «DISASSEMBLY [08/2012 - ] - Step 14»(ref-606568-S15452695272014032500000)
8. REMOVE FRONT DOOR GLASS SUB-ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 15»(ref-606568-S15452695272014032500000)
9. REMOVE FRONT DOOR WINDOW REGULATOR SUB-ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 16»(ref-606568-S15452695272014032500000)
10. REMOVE FRONT POWER WINDOW REGULATOR MOTOR Using a "torx" socket wrench (T25), remove the 3 screws and the front power window regulator motor.
11. REMOVE REAR DOOR INSIDE HANDLE BEZEL PLUG. Refer to «DISASSEMBLY [08/2012 - ] - Step 1»(ref-606568-S42006757042014032500000)
12. REMOVE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 2»(ref-606568-S42006757042014032500000)
13. REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 3»(ref-606568-S42006757042014032500000)
14. REMOVE REAR DOOR INNER GLASS WEATHERSTRIP. Refer to «DISASSEMBLY [08/2012 - ] - Step 5»(ref-606568-S42006757042014032500000)
15. REMOVE REAR DOOR SERVICE HOLE COVER. Refer to «DISASSEMBLY [08/2012 - ] - Step 11»(ref-606568-S42006757042014032500000)
16. REMOVE REAR DOOR GLASS RUN. Refer to «DISASSEMBLY [08/2012 - ] - Step 15»(ref-606568-S42006757042014032500000)
17. REMOVE REAR DOOR WINDOW DIVISION BAR SUB-ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 16»(ref-606568-S42006757042014032500000)
18. REMOVE REAR DOOR QUARTER WINDOW GLASS. Refer to «DISASSEMBLY [08/2012 - ] - Step 17»(ref-606568-S42006757042014032500000)
19. REMOVE REAR DOOR GLASS SUB-ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 18»(ref-606568-S42006757042014032500000)
20. REMOVE REAR DOOR WINDOW REGULATOR SUB-ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 19»(ref-606568-S42006757042014032500000)
21. REMOVE REAR POWER WINDOW REGULATOR MOTOR Using a "torx" socket wrench (T25), remove the 3 screws and the rear power window regulator motor.

Scheme 59

Scheme 60

Scheme 61

Scheme 62

1. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH FRONT Apply positive (+) battery voltage to connector terminal 2 (B). NOTE: Do not apply positive (+) battery voltage to any terminals other than terminal 2 (B) to avoid damaging the pulse sensor inside the motor. Apply negative (-) battery voltage to connector terminals 1 (E) and 7 (DWN1) or 10 (UP1). Check that the motor gear rotates smoothly as follows: OK Measurement Condition Specified Condition Connect the positive (+) battery cable to terminal 2 (B), and connect the negative (-) battery cable to terminal 1 (E), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (E) connected, connect the negative (-) battery cable to terminal 10 (UP1). Disconnect and reconnect the negative (-) battery cable to terminal 10 (UP1) within 1 second. Motor gear rotates clockwise (Up) Connect the positive (+) battery cable to terminal 2 (B), and connect the negative (-) battery cable to terminal 1 (E), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (E) connected, connect the negative (-) battery cable to terminal 7 (DWN1). Disconnect and reconnect the negative (-) battery cable to terminal 7 (DWN1) within 1 second. Motor gear rotates counterclockwise (Down) If the result is not as specified, replace the power window regulator motor assembly LH front. WARNING: Reset the power window regulator motor (initialize the pulse sensor) after installing the power window regulator motor and regulator assembly onto the door.
2. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH FRONT Apply positive (+) battery voltage to connector terminal 2 (B). NOTE: Do not apply positive (+) battery voltage to any terminals other than terminal 2 (B) to avoid damaging the pulse sensor inside the motor. Apply negative (-) battery voltage to connector terminals 1 (E) and 7 (DWN1) or 10 (UP1). Check that the motor gear rotates smoothly as follows: OK Measurement Condition Specified Condition Connect the positive (+) battery cable to terminal 2 (B), and connect the negative (-) battery cable to terminal 1 (E), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (E) connected, connect the negative (-) battery cable to terminal 10 (UP1). Disconnect and reconnect the negative (-) battery cable to terminal 10 (UP1) within 1 second. Motor gear rotates counterclockwise (Up) Connect the positive (+) battery cable to terminal 2 (B), and connect the negative (-) battery cable to terminal 1 (E), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (E) connected, connect the negative (-) battery cable to terminal 7 (DWN1). Disconnect and reconnect the negative (-) battery cable to terminal 7 (DWN1) within 1 second. Motor gear rotates clockwise (Down) If the result is not as specified, replace the power window regulator motor assembly RH front. WARNING: Reset the power window regulator motor (initialize the pulse sensor) after installing the power window regulator motor and regulator assembly onto the door.
3. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH REAR Apply positive (+) battery voltage to connector terminal 2 (B). NOTE: Do not apply positive (+) battery voltage to any terminals other than terminal 2 (B) to avoid damaging the pulse sensor inside the motor. Apply negative (-) battery voltage to connector terminals 1 (E) and 7 (DWN1) or 10 (UP1). Check that the motor gear rotates smoothly as follows: OK Measurement Condition Specified Condition Connect the positive (+) battery cable to terminal 2 (B), and connect the negative (-) battery cable to terminal 1 (E), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (E) connected, connect the negative (-) battery cable to terminal 10 (UP1). Disconnect and reconnect the negative (-) battery cable to terminal 10 (UP1) within 1 second. Motor gear rotates counterclockwise (Up) Connect the positive (+) battery cable to terminal 2 (B), and connect the negative (-) battery cable to terminal 1 (E), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (E) connected, connect the negative (-) battery cable to terminal 7 (DWN1). Disconnect and reconnect the negative (-) battery cable to terminal 7 (DWN1) within 1 second. Motor gear rotates clockwise (Down) If the result is not as specified, replace the power window regulator motor assembly LH rear. WARNING: Reset the power window regulator motor (initialize the pulse sensor) after installing the power window regulator motor and regulator assembly onto the door.
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH REAR Apply positive (+) battery voltage to connector terminal 2 (B). NOTE: Do not apply positive (+) battery voltage to any terminals other than terminal 2 (B) to avoid damaging the pulse sensor inside the motor. Apply negative (-) battery voltage to connector terminals 1 (E) and 7 (DWN1) or 10 (UP1). Check that the motor gear rotates smoothly as follows: OK Measurement Condition Specified Condition Connect the positive (+) battery cable to terminal 2 (B), and connect the negative (-) battery cable to terminal 1 (E), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (E) connected, connect the negative (-) battery cable to terminal 10 (UP1). Disconnect and reconnect the negative (-) battery cable to terminal 10 (UP1) within 1 second. Motor gear rotates clockwise (Up) Connect the positive (+) battery cable to terminal 2 (B), and connect the negative (-) battery cable to terminal 1 (E), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (E) connected, connect the negative (-) battery cable to terminal 7 (DWN1). Disconnect and reconnect the negative (-) battery cable to terminal 7 (DWN1) within 1 second. Motor gear rotates counterclockwise (Down) If the result is not as specified, replace the power window regulator motor assembly RH rear. WARNING: Reset the power window regulator motor (initialize the pulse sensor) after installing the power window regulator motor and regulator assembly onto the door.

See also:
• REMOVAL [08/2012 - ] - Step 4
• REMOVAL [08/2012 - ] - Step 49
• REMOVAL [08/2012 - ] - Step 26
