1. REMOVAL AND INSTALLATION OF THE TIRE PRESSURE WARNING VALVE AND TRANSMITTER When installing a tire, make sure that the tire pressure warning valve and transmitter does not interfere with the tire bead. After completing the operation, remove the valve core to rapidly release the air in the tire and check that the warning light comes on. If the warning light does not come on, the system may be defective. If there is an air leakage, tighten the nut to a force of 4.0 N*m (41 kgf*cm, 35 in.*lbf) and push the valve core 2 or 3 times to remove any dirt attached to the valve core. If air continues to leak, replace the grommet, the washer and the nut. When installing the tire pressure warning valve and transmitter, check whether the rim, grommet, washer and nut are clean. Use a manufacturer specified cap. When putting air into the tire, first install the tire pressure valve straight onto the stem of the tire pressure warning valve and transmitter.
2. TIRE AND WHEEL REPLACEMENT OR TIRE ROTATION If replacing a tire, be sure to check the grommet of the tire valve for damage. If necessary, replace the grommet, the washer and the nut. If tires and wheels are replaced, be sure to register the transmitter ID (See «REGISTRATION»(ref-235571-S01517126292006062400000) ).

Scheme 35

1. DIAGNOSIS OF TIRE VIBRATION Inspection procedure
2. DIAGNOSIS OF IRREGULAR TIRE WEAR Inspection procedure

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. INSPECT TIRES Check the tires for wear and proper inflation pressure. Cold tire inflation pressure INFLATION PRESSURE Tire Size Specified Value kPa (kgf/cm 2, psi) Front Rear 205/55R16 89W 240 (2.4, 35) 260 (2.6, 38) 225/45R17 91V 225/45R17 90W (1) 240 (2.4, 35) - 245/45R17 95W (2) - 260 (2.6, 38) 225/45R17 95V (1) 240 (2.4, 35) - 245/45R17 95V (2) - 260 (2.6, 38) 225/40R18 88Y (1) 240 (2.4, 35) - 255/40R 18 95Y (2) - 260 (2.6, 38) (1) Only for front tires (2) Only for rear tires Using a dial indicator, check the runout of tires. Tire runout: 1.0 mm (0.039 in.) or less
2. ROTATE TIRES HINT: If the rotating direction of the tires is specified, rotate the tires (Scheme 38) 2WD models with 17-inch tires or 18-inch tires cannot be rotated.
3. INSPECT WHEEL BALANCE Check and adjust the off-the-car balance. If necessary, check and adjust the on-the-car balance. Imbalance after adjustment: 8.0 g (0.018 lb.) or less. HINT: In the case of 16-inch wheels, balance weight should be installed by tapping. NOTE: Remove dirt, oil and water from the surface where the balance weight is to be adhered with a cleaning detergent. Do not touch the sticking surface of the tape. Adhere the sticking type balance weight to the flat position (Scheme 40) Push the balance weight securely with a finger to adhere it to the position. Do not reuse a balance weight. Please use the LEXUS genuine sticking type balance weight.
4. INSPECT FRONT AXLE DEVIATION AND BACKLASH HINT: (See «ON-VEHICLE INSPECTION»(ref-235570-S13335859882006062400000) FOR FRONT AXLE, «ON-VEHICLE INSPECTION»(ref-235570-S30452480222006062400000) FOR REAR AXLE)
5. INSPECT REAR AXLE DEVIATION AND BACKLASH HINT: (See «ON-VEHICLE INSPECTION»(ref-235570-S13335859882006062400000) FOR FRONT AXLE, «ON-VEHICLE INSPECTION»(ref-235570-S30452480222006062400000) FOR REAR AXLE)

Scheme 41

Scheme 42

1. TIRE PRESSURE WARNING SYSTEM PRECAUTION When the tire pressure warning light comes on, immediately check the pressure of the tire and adjust it to the specified value. (The tire pressure warning light will come on if there is an open in the tire pressure warning light circuit.) NOTE: Check the spare tire as well since this system monitors pressure of 4 tires. AIR PRESSURE REFERENCE Tire Size Specified Value kPa (kgf/cm 2 , psi) Front Rear 205/55R16 89W 240 (2.4, 35) 260 (2.6, 38) 225/45R17 91V 225/45R17 90W (1) 240 (2.4, 35) - 245/45R17 95W (2) - 260 (2.6, 38) 225/45R17 95V (1) 240 (2.4, 35) - 245/45R17 95V (2) - 260 (2.6, 38) 225/40R18 88Y (1) 240 (2.4, 35) - 255/40R18 95Y (2) - 260 (2.6, 38) (1) Only for front tire (2) Only for rear tires When the tire pressure warning light blinks, there is a malfunction in the system. Check for DTCs. Changing the tire pressure warning select switch between "MAIN" and "2nd" allows registration of 2 transmitter ID set. Check the tire pressure warning select switch to see whether the tire is registered in "MAIN" or "2nd". If the vehicle is driven without selecting switch state correctly, the tire pressure warning ECU and receiver determines the system is malfunctioning and causes the tire pressure warning light to blink. It is necessary to register the transmitter ID in the tire pressure warning ECU and receiver after replacing the tire pressure warning valve and transmitter and/or tire pressure warning ECU and receiver (See «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-235571-S02578917792006062400000) ). When replacing the tire pressure warning ECU and receiver; Using the DATA LIST, read the transmitter IDs registered in the ECU and make a note of them before removing the tire pressure warning ECU and receiver. Register the transmitter IDs after installing a new tire pressure warning ECU and receiver. Tire and wheel replacement or tire rotation; After tires or wheels are replaced with new tire pressure warning valve and transmitter, it is necessary to register the transmitter IDs. After the set of the tires and wheels are replaced, be sure to select the tire pressure warning select switch. It is not necessary to register the transmitter IDs after tire rotation is performed. After dropping the tire pressure warning valve and transmitter into the tire, disengage the bead from the wheel. NOTE: Be careful not to damage the tire pressure monitor valve because of interference between the sensor and tire bead. The initialization is necessary to reset the warning threshold in accordance with variant tire pressure settings due to tire types. Precautions about the tire pressure; The tire pressures decrease naturally. In winter, as the tire pressure may decrease depending on the ambient temperature (The tire pressure decreases about 10 kPa (0.2 kgf/cm 2 , 1.45 psi) with the ambient temperature will be 10°C (°F) down.). The tire pressures warning will be indicated easily, if the tire pressures are not adjusted when the ambient temperature is down. Therefore, increase the tire pressure above the specified value. When replacing the tire pressure warning valve and transmitter; Take a note of the 7 digit number (transmitter ID) written on the tire pressure warning valve and transmitter when replacing it. Register the transmitter IDs in the tire pressure warning ECU and receiver after replacing the tire pressure warning valve and transmitter and installing the tires and wheels on the vehicle. NOTE: The transmitter ID is written on the tire pressure warning valve and transmitter. The ID will be unable to be read after installing the tire pressure warning valve and transmitter on the tire and wheel. Therefore, take a note of the transmitter ID before installing the tire pressure warning valve and transmitter.
2. IN CASE OF TIRE AND WHEEL REPLACEMENT When tires and wheels are replaced, always ensure to register the transmitter ID correctly.
3. IN CASE OF TIRE ROTATION, REPLACEMENT OF TIRE PRESSURE WARNING ECU AND RECEIVER, TIRE PRESSURE WARNING VALVE AND TRANSMITTER, OR TIRE(S) WITH DIFFERENT TIRE PRESSURE Initialize the tire pressure warning system after any of the following is performed: Replacing the tire pressure warning ECU and receiver or the tire pressure warning valve and transmitter Replacing tire(s) with different tire pressure HINT: The tire pressure warning system will not operate properly if it is not initialized (See «INITIALIZATION»(ref-235571-S20591791182006062400000) ).
4. FAIL-SAFE FUNCTION When a malfunction occurs in the tire pressure warning system, the tire pressure warning light blinks and informs the driver of the system failure. The result of this diagnosis is stored in the tire pressure warning ECU and receiver.

Scheme 43

Scheme 44

Scheme 45

1. DESCRIPTION OF SYSTEM A tire pressure warning valve and transmitter is equipped with a tire pressure sensor and a transmitter and is installed in a tire wheel assembly. The sensor measures the tire pressure. The measured value and transmitter ID are transmitted to the tire pressure warning ECU and receiver on the body as radio waves. If the transmitter ID has already been registered, the ECU compares the measured air pressure value with the standard value. When the value is less than the standard value registered in the tire pressure warning ECU and receiver, the warning light on the combination meter comes on. For the differences in the air pressure settings by the type of tires, or the differences in pressure between the front and rear tires, a tire pressure warning reset switch has been newly adopted. TPWS transmitters with different bending angles at the tire pressure warning valve and transmitter have been provided for aluminum wheels. (They are not interchangeable with other wheels.)
2. WHEN TIRE PRESSURE WARNING LIGHT IS LIT When the tire pressure warning light does not go off, or when it comes on during driving, check tire pressure. If the tire pressure warning light comes on within several hours after adjusting the tire pressure, the tire may have a slow air leak. If the tire pressure warning light comes on even after adjusting the tire pressure, selection of the tire pressure warning switch "MAIN" / "2nd" may be incorrect. Under the following conditions, the system may not function properly: Areas, facilities or devices that use similar radio frequencies are located in the vicinity of the vehicle. Devices using similar radio frequencies are used in the vehicle. Large amounts snow or ice are stuck to the vehicle, especially on the wheels and around the wheel houses. The battery of the transmitter is depleted. Tires and wheels without tire pressure warning valves and transmitters are used. Snow tires and tire chains are used. The registered set of the tires and wheels does not correspond to the selection of the tire pressure warning select switch. If wheels other than the specified ones are used, the system may not function properly because different radio waves are transmitted from the tire pressure warning valve and transmitter. Depending on the tire type, the tire pressure warning valve and transmitter may not function properly even though the specified wheels are used. The system may not function properly unless it is initialized with the tire pressures at the specified values. The average useful life of the grommet of the tire pressure warning valve and transmitter is approximately 5 years, at which time it must be replaced. Re-tighten the valve nut if air is leaking from, although it is less than 5 years old and there is no problem with grommets. After removing and installing the ECU or a sensor, output a diagnosis code and check that it is a normal code.
3. FUNCTION OF COMPONENTS COMPONENTS FUNCTIONS Components Function Tire pressure warning valve and transmitter Combined as a single unit with a disc wheel air valve, this component measures tire pressure and temperature and transmits an ID number for measurement value and identification. Built-in the battery. Tire pressure warning antenna Receives and transmits a necessary signal from the transmitter to the tire pressure warning ECU and receiver. Tire pressure warning ECU and receiver Receives a signal from the receiver and identifies it as the vehicle's own signal. If the measurement value is equal to or lower than the specified value, this component transmits a signal so that the air pressure warning light on the combination meter comes on. Tire pressure warning light Located in the combination meter, it informs the driver of a decrease in the tire air pressure and a system failure. Satellite switch The satellite switches include tire pressure warning reset switch and select switch functions. Initialization can be performed by selecting the tire pressure warning reset switch mode on the multi-display and operating the satellite switches. Also, tires can be selected by selecting the tire select switch mode and operating the satellite switches. Tire pressure warning reset switch (satellite switch) Enters the initialization mode for tire or wheel replacement, or tire pressure warning ECU and receiver replacement. HINT: The satellite switch include tire pressure warning reset switch function. Tire pressure warning select switch (satellite switch) When 2 sets of ID are registered in the tire pressure warning ECU and receiver, either of the sets can be selected by changing the switch between "MAIN" and "2nd". HINT: The satellite switch include tire select switch function.
4. TIRE PRESSURE WARNING RESET SWITCH (SATELLITE SWITCH) By operating the tire pressure warning reset switch, the tire pressure warning ECU and receiver can be set to issue a warning at an inflation pressure that corresponds to the type of tires. Therefore, the dealer must set the warning threshold to the proper value in order to comply with the local regulations. Operate the tire pressure warning reset switch only after the inflation pressures of 4 tires have been adjusted on the vehicle. To initialize the system, press and hold the tire pressure warning reset switch for 3 seconds or longer with the engine switch on. After the system has been initialized, the warning light blinks 3 times (1 second on, 1 second off). During initialization, the tire pressure warning valve and transmitter measures the inflation pressure of the tires, and registers the signals that are transmitted into the tire pressure warning ECU and receiver at a frequency of one per minute. The initialization process is completed when the signals from the 4 tires have been received. Initialization is usually completed in 2 or 3 minutes.
5. TIRE PRESSURE WARNING SELECT SWITCH (SATELLITE SWITCH) This switch is installed at the base of the instrument panel on the driver seat side. The control ECU can be used to register two sets of transmitter IDs, and can select one or the other using the tire pressure warning select switch. Consequently, there is no need to log the ID again each time a tire is changed. Make sure ID registration is performed by your car dealer.

INITIALIZATION

1. INITIALIZATION NOTE: Perform initialization after the transmitter ID registration is completed. Initialization is necessary after replacing either the ECU, tires with different tire pressure or tire pressure warning valve and transmitter, or when a new vehicle is delivered. Perform the tire pressure adjustment after the vehicle has sufficiently cooled down. If the vehicle is not sufficiently cooled down, increase the air pressure by 20 to 30 kPa in addition to the specified value. Set the air pressure of 4 wheels, to the specified value. TIRE PRESSURE REFERENCE Tire Size Specified Value kPa (kgf/cm 2 , psi) Front Rear 205/55R16 89W 240 (2.4, 35) 260 (2.6, 38) 225/45R17 91V 225/45R17 90W (1) 240 (2.4, 35) - 245/45R17 95W (2) - 260 (2.6, 38) 225/45R17 95V (1) 240 (2.4, 35) - 245/45R17 95V (2) - 260 (2.6, 38) 225/40R18 88Y (1) 240 (2.4, 35) - 255/40R18 95Y (2) - 260 (2.6, 38) (1) Only for front tire (2) Only for rear tires Keep the tire pressure warning reset switch (satellite switch) pressed for 3 seconds or more with the engine switch on (IG). HINT: The initialization is completed when the tire pressure warning ECU has received signals from all of the wheels. Check that the low tire pressure warning light blinks 3 times (1 second ON, 1 second OFF). If the engine is on, "PRESSURE INITIAL" will be displayed on the multi-information display. NOTE: Initialization is usually completed in 2 or 3 minutes. When the initialization is completed incorrectly, DTC C2177/77 is memorized after driving the vehicle about 20 minutes or more. The initialization can be terminated by making a short circuit between terminals TC and CG of the DLC3 connector. Confirm that initialization is completed using the intelligent tester. Check that the pressure of each tire is displayed in INIT THRESHOLD 1 to 4. Initialization is completed.

Scheme 46

Scheme 47

Scheme 48

Scheme 49

1. ENTER TEST MODE HINT: Operation of the low tire pressure warning reset switch (satellite switch) can be checked in TEST MODE. During TEST MODE, the system is not initialized by pressing the tire pressure warning reset switch (satellite switch). The circuit of the tire pressure warning reset switch (satellite switch) can be inspected during this mode. Make sure that the engine switch is off. Connect the intelligent tester to the DLC3. Turn the engine switch on (IG). Select TEST MODE on the intelligent tester. Perform the tire pressure warning reset switch (satellite switch) test. Press the tire pressure warning reset switch (satellite switch). Check the low tire pressure warning light. SIGNAL CONDITION Test Signal Normal Condition Tire Pressure Warning Reset Switch Switch ON: Low tire pressure warning light comes on Switch OFF: Low tire pressure warning light blinks
2. PERFORM SIGNAL CHECK HINT: When entering the signal check mode, the tire pressure warning ECU and receiver sets all the signal check DTCs first. After completing signal check for each inspection item, the DTCs that are determined to be normal by the tire pressure warning ECU and receiver will be cleared. The DTCs for other inspection items may not be cleared when only a certain signal is inspected. When the tester returns to the normal mode from the signal check mode, all the signal check DTCs will be cleared. Make sure that the engine switch is off. Connect the intelligent tester to the DLC3. Turn the engine switch on (IG). Select the SIGNAL CHECK on intelligent tester. Drive the vehicle at 12 mph (40 km/h) or more for 30 seconds or more. Remove the valve core and rapidly reduce the pressure (above 40 kPa (0.4 kgf/cm 2 , 5.8 psi)/30 sec.). HINT: The transmitter ID can be transmitted by rapidly reducing the tire pressure. Check that the tire pressure warning system test mode DTCs are cleared. SIGNAL CONDITION SIGNAL CHECK DTC Test Signal Signal Check DTC Clear Condition C2181 to C2184 Transmitter Data Receive data from the transmitter which has an ID registered in the tire pressure warning ECU and receiver C2191 Vehicle Speed Signal Vehicle speed of 12 mph (20 km/h) or more is detected for 3 seconds or more C2192/92 Tire Pressure Warning Select Switch Change the mode by pressing the tire pressure warning select switch in the following order: MAIN --> 2nd --> MAIN C2195/95 Open in tire pressure warning antenna (multi-receiver type) Voltage of front-right antenna and/or rear-left antenna terminal is below regulation value. Result HINT: After the signal check is completed, check for a DTC and signal check DTC to confirm the system status. SIGNAL CONDITION Condition Procedure SIGNAL CHECK DTC is output Repair the faulty part and enter SIGNAL CHECK again SIGNAL CHECK DTCs are cleared No problem End of SIGNAL CHECK After completing the test mode (SIGNAL CHECK), turn the engine switch off and disconnect the tester. DTC of SIGNAL CHECK (TEST DIAGNOSIS) function: If a trouble code is displayed during the test mode DTC check, check the circuit indicated by the code. For details of each code, refer to the relevant reference listed under respective "DTC No." in «DTC INDEX»(ref-235571-S39507661972006062400000) .

DTC INDEX

TERMINALS OF ECU

HINT

Inspect the connectors from the back side while the connectors are connected.

Scheme 50

TERMINALS CONDITION AND REFERENCE VALUE

Scheme 51

Scheme 52

Scheme 53

1. CHECK BATTERY VOLTAGE Battery voltage: 11 to 14 V If the voltage is below 11 V, recharge the battery before proceeding.
2. CHECK DLC3 The vehicle's tire pressure warning ECU and receiver uses ISO 9141-2 for communication. The terminal arrangement of DLC3 complies with SAE J1962 and matches the ISO 9141-2 format. Verify the conditions listed in «TERMINAL NO AND CONDITION TABLE»(ref-235571-S01522924272006062400000) : TERMINAL NO. AND CONDITION TABLE Terminal No. Disc. Connection / Voltage or Resistance Condition 7 SIL Bus + Line / Pulse generation During transmission 4 CG Chassis Ground to Body Ground / 1 ohms or less Always 16 BAT Battery Positive to Body Ground / 10 to 14 V Always HINT: If the intelligent tester display shows a communication error message when the cable of the intelligent tester is connected to the DLC3, the engine switch is turned on and the tester is in operation, there is a problem on the vehicle side or tester side. If communication is normal when the tester is connected to another vehicle, inspect the DLC3 on the original vehicle. If communication is still not possible when the tester is connected to another vehicle, the problem may be in the tester itself. Consult the Service Department listed in the tester operator's manual.
3. DIAGNOSIS SYSTEM Warning light and indicator When there is a problem with the tire pressure warning system, the "CHECK SYSTEM" displayed on the multi-display and the tire pressure warning light blinks at 0.5 second intervals. NOTE: When the malfunction has been corrected, the tire pressure warning light does not come on and the "CHECK SYSTEM" does not display. DTCs (Normal mode) DTCs are memorized in the tire pressure warning ECU and receiver and can be read by using the intelligent tester (See «PROBLEM SYMPTOMS TABLE»(ref-235571-S26696990082006062400000) ). Test mode By switching from the normal mode to the test mode (input signal check), you can inspect the tire pressure warning ECU and receiver, each tire pressure warning valve and transmitter and vehicle speed sensor (See «DTC C2171/71 TRANSMITTER ID NOT REGISTERED IN MAIN MODE: DTC C2172/72 TRANSMITTER ID NOT REGISTERED IN 2ND MODE»(ref-235571-S23564098542006062400000) ).
4. CHECK WARNING LIGHT Turn the engine switch on (IG). Check that the low tire pressure warning light comes on for 3 seconds. If the warning light did not light for 3 seconds, proceed to the troubleshooting for the tire pressure warning light circuit. TROUBLE AREA Trouble Area See Procedure Tire pressure warning light circuit «Tire Pressure Warning Light Circuit»(ref-235571-S18000754562006062400000)
5. LOW TIRE PRESSURE WARNING LIGHT AND INDICATOR TABLE HINT: The «WARNING LIGHT CONDITION TABLE»(ref-235571-S02202365722006062400000) indicates the state of the low tire pressure warning light and indicator after the engine switch is turned on (IG).

WARNING LIGHT CONDITION TABLE

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. DTC CHECK (USING SST CHECK WIRE) Check DTCs. Using SST, connect terminals TC and CG of the DLC3. SST 09843-18040 Turn the engine switch on (IG). Read and record any DTCs indicated by the tire pressure warning light on the combination meter. Refer to the illustration on the left as an examples of the normal system code and codes 13 and 43. HINT: If the tire pressure warning light does not indicate any DTCs or the normal system code, inspect the tire pressure warning light circuit or TC and CG terminal circuit. TROUBLE AREA REFERENCE Trouble Area See Procedure Tire pressure warning light circuit «Tire Pressure Warning Light Circuit»(ref-235571-S18000754562006062400000) TC and CG terminal circuit «TC and CG Terminal Circuit»(ref-235571-S33538881552006062400000) If 2 or more malfunctions are indicated at the same time, the lowest numbered DTC is displayed first. Refer to the «DIAGNOSTIC TROUBLE CODE TABLE»(ref-235571-S26245846312006062400000) for DTC information. After completing the check, turn the engine switch off and remove the SST from the DLC3. SST 09843-18040
2. DTC CHECK (USING INTELLIGENT TESTER) Check DTCs. Connect the intelligent tester to the DLC3. Turn the engine switch on (IG). Read the DTCs following the prompts on the tester screen. HINT: Refer to the intelligent tester operator's manual for further details.
3. DTC CLEAR HINT: After repairing the malfunctions, clear the DTCs. Connect the intelligent tester to the DLC3. Turn the engine switch on (IG). Clear the DTCs following the prompts on the tester screen. HINT: Refer to the intelligent tester operator's manual for further details.

DISPOSAL

HINT

The tire pressure warning valve and transmitter is powered by a lithium battery. When disposing of the tire pressure warning valve and transmitter, remove the battery and dispose of it correctly.

Scheme 60

1. DISPOSE OF TIRE PRESSURE WARNING VALVE AND TRANSMITTER Using a screwdriver, pry off the back cover. The battery and base board covered with silicone resin are exposed. While taking out the battery, disconnect the 2 terminals that connect the battery and the base board.

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

1. REMOVE FRONT WHEEL RH
2. REMOVE FRONT FENDER LINER RH
3. REMOVE TIRE PRESSURE ANTENNA FRONT RH Disconnect the connector. Remove the nut and the front right tire pressure warning antenna assembly.
4. REMOVE REAR WHEEL LH
5. REMOVE REAR SEAT CUSHION ASSEMBLY (See «REMOVAL»(ref-235576-S10366850202006062400000) )
6. REMOVE REAR SEATBACK ASSEMBLY (See Step 4 in «REMOVAL»(ref-235576-S10366850202006062400000) )
7. REMOVE REAR FENDER LINER LH
8. REMOVE TIRE PRESSURE ANTENNA REAR LH Disconnect the connector. Remove the 2 nuts and the rear left tire pressure warning antenna assembly.

Scheme 66

Scheme 67

Scheme 68

1. INSTALL TIRE PRESSURE ANTENNA FRONT RH Install the front right tire pressure monitor antenna assembly with the nut. Torque: 7.5 N*m (77 kgf*cm, 66 in.*lbf) Connect the connector.
2. INSTALL FRONT FENDER LINER RH
3. INSTALL FRONT TIRE (RH) Torque: 103 N*m (1,050 kgf*cm, 911 in.*lbf)
4. INSTALL TIRE PRESSURE ANTENNA REAR LH Install the rear left tire pressure monitor antenna assembly with the 2 nuts. Torque: 7.5 N*m (77 kgf*cm, 66 in.*lbf) Connect the connector.
5. INSTALL REAR FENDER LINER LH
6. INSTALL REAR TIRE (LH) Torque: 103 N*m (1,050 kgf*cm, 911 in.*lbf)
7. INSTALL REAR SEATBACK ASSEMBLY
8. INSTALL REAR SEAT CUSHION ASSEMBLY
9. REGISTRATION OF TRANSMITTER ID HINT: (See «REGISTRATION»(ref-235571-S01517126292006062400000) ) SST 09843-18040
10. INSPECT TIRE PRESSURE WARNING SYSTEM HINT: (See «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-235571-S02578917792006062400000) )

Scheme 69

Scheme 70
