PRECAUTION

Note. When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected.

System NameSee procedure
Power Window Control SystemINITIALIZATION

SYSTEM REFERENCE CHART

Scheme 244

Scheme 244: PARTS LOCATION

Scheme 245

Scheme 245

Scheme 246

Scheme 246

Scheme 247

Scheme 247

Scheme 248

Scheme 248: SYSTEM DIAGRAM
SenderReceiverSignalLine
Main Body ECU RH (Cowl Side J/B RH)Front Power Seat Switch LH (Position Control ECU)Wireless door unlock signalBEAN
Main Body ECU RH (Cowl Side J/B RH)Front Power Seat Switch LH (Position Control ECU)Smart door unlock signalBEAN
Main Body ECU RH (Cowl Side J/B RH)Front Power Seat Switch LH (Position Control ECU)Brake indicator ON signalBEAN
Main Body ECU RH (Cowl Side J/B RH)Front Power Seat Switch RH (Position Control ECU)Brake indicator ON signalBEAN
Power Source Control ECUFront Power Seat Switch LH (Position Control ECU)Key code check signalBEAN
Combination Meter ECUFront Power Seat Switch LH (Position Control ECU)Vehicle speed signalBEAN
Combination Meter ECUFront Power Seat Switch RH (Position Control ECU)Vehicle speed signalBEAN
Main Body ECU RH (Cowl Side J/B RH)Front Power Seat Switch LH (Position Control ECU)Key ID signalBEAN
Main Body ECU RH (Cowl Side J/B RH)Front Power Seat Switch LH (Position Control ECU)Driver side door courtesy light switch signalBEAN
Main Body ECU RH (Cowl Side J/B RH)Front Power Seat Switch LH (Position Control ECU)Engine switch on (IG) signalBEAN
Front Power Seat Switch LH (Position Control ECU)Outer Mirror Control ECU LHM1 switch memory command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Outer Mirror Control ECU LHM2 switch memory command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Outer Mirror Control ECU LHM3 switch memory command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Outer Mirror Control ECU LHM1 switch call command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Outer Mirror Control ECU LHM2 switch call command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Outer Mirror Control ECU LHM3 switch call command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Multiplex Tilt & Telescopic ECUM1 switch memory command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Multiplex Tilt & Telescopic ECUM2 switch memory command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Multiplex Tilt & Telescopic ECUM3 switch memory command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Multiplex Tilt & Telescopic ECUM1 switch call command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Multiplex Tilt & Telescopic ECUM2 switch call command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Multiplex Tilt & Telescopic ECUM3 switch call command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Multiplex Tilt & Telescopic ECUTilt & telescopic call permission signalBEAN
Front Power Seat Switch LH (Position Control ECU)Multiplex Tilt & Telescopic ECUTilt & telescopic call prohibit signalBEAN
Multiplex Tilt & Telescopic ECUFront Power Seat Switch LH (Position Control ECU)Tilt & telescopic call start signalBEAN
Multiplex Tilt & Telescopic ECUFront Power Seat Switch LH (Position Control ECU)Tilt & telescopic call completion signalBEAN
Outer Mirror Control ECU LHFront Power Seat Switch LH (Position Control ECU)SET switch ON signalBEAN
Outer Mirror Control ECU LHFront Power Seat Switch LH (Position Control ECU)M1 switch ON signalBEAN
Outer Mirror Control ECU LHFront Power Seat Switch LH (Position Control ECU)M2 switch ON signalBEAN
Outer Mirror Control ECU LHFront Power Seat Switch LH (Position Control ECU)M3 switch ON signalBEAN
ECMFront Power Seat Switch LH (Position Control ECU)Shift position P signalBEAN
Certification ECUFront Power Seat Switch LH (Position Control ECU)Memory call command signalBEAN
Main Body ECU RH (Cowl Side J/B RH)Front Power Seat Switch RH (Position Control ECU)Passenger side door courtesy light switch signalBEAN
Main Body ECU RH (Cowl Side J/B RH)Front Power Seat Switch RH (Position Control ECU)Engine switch on (IG) SignalBEAN
Front Power Seat Switch LH (Position Control ECU)Outer Mirror Control ECU RHM1 switch memory command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Outer Mirror Control ECU RHM2 switch memory command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Outer Mirror Control ECU RHM3 switch memory command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Outer Mirror Control ECU RHM1 switch call command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Outer Mirror Control ECU RHM2 switch call command signalBEAN
Front Power Seat Switch LH (Position Control ECU)Outer Mirror Control ECU RHM3 switch call command signalBEAN
Outer Mirror Control ECU RHFront Power Seat Switch RH (Position Control ECU)SET switch ON signalBEAN
Outer Mirror Control ECU RHFront Power Seat Switch RH (Position Control ECU)M1 switch ON signalBEAN
Outer Mirror Control ECU RHFront Power Seat Switch RH (Position Control ECU)M2 switch ON signalBEAN
Outer Mirror Control ECU RHFront Power Seat Switch RH (Position Control ECU)M3 switch ON signalBEAN
ECMFront Power Seat Switch RH (Position Control ECU)Shift position P signalBEAN

COMMUNICATION TABLE

Note. When disconnecting the negative (-) battery cable, initialize the following systems after the cable is reconnected.

System NameSee procedure
Power Window Control SystemINITIALIZATION

SYSTEM REFERENCE CHART

Scheme 249

Scheme 249: PARTS LOCATION

Scheme 250

Scheme 250: SYSTEM DIAGRAM

CLIMATE CONTROL SYSTEM

SymptomSuspected areaSee reference
Climate control seat system does not operate1. RH-IG fuseTERMINALS OF ECU
2. FR S/HTR RH fuseTERMINALS OF ECU
3. Seat heater switchTERMINALS OF ECU
4. Seat climate blowerTERMINALS OF ECU
5. Seatback blowerTERMINALS OF ECU
6. A/C amplifier assembly

PROBLEM SYMPTOMS CHART

Scheme 251

Scheme 251: TERMINALS OF ECU

Scheme 252

Scheme 252
  1. A/C AMPLIFIER ASSEMBLY Measure the voltage and resistance according to the value(s) in the table below. Voltage TESTER CONDITION SPECIFIED CONDITION CHART Symbols (Terminal No. Wiring Color Terminal Description Condition Specified Condition SW-5 (J59-2) - Body ground LG - Body ground Input climate control signal (Driver side) Always 10 to 14 V SW-4 (J59-3) - Body ground R - Body ground Input climate control signal (Passenger side) Always 10 to 14 V S5-4 (J59-7) - Body ground BR - Body ground GND Engine switch on (IG) 4 to 6 V SG-4 (J59-10) - Body ground GR - Body ground Power supply Always 10 to 14 V Standard TESTER CONDITION SPECIFIED CONDITION CHART Symbols (Terminal No. Wiring Color Terminal Description Condition Specified Condition ROUT (J59-8) - Body ground W - Body ground Output climate control signal (Front RH side) Engine switch on (IG) Pulse generation LOUT (J59-16) - Body ground Y - Body ground Output climate control signal (Front LH side) Engine switch on (IG) Pulse generation Waveform (Reference): Using an oscilloscope: WAVEFORM REFERENCE CHART Item Condition Tool setting 2 V/DIV., 500 ., Vehicle condition Turn the engine switch on (IG)
