| A/C Compressor-To-Cylinder Block |
| Bolt & Nut | 38 (52) |
| Stud Bolt | 19 (26) |
| Camshaft Bearing Cap-To-Cylinder Head Fastener (1) | 14 (20) |
| Camshaft Timing Pulley-To-Camshaft Fastener | 61 (80) |
| Center Exhaust Pipe-To-Tailpipe Fastener | 32 (43) |
| Connecting Rod Cap-To-Connecting Rod Fastener |
| Step 1 | 22 (30) |
| Step 2 | (2) |
| Crankshaft Pulley-To-Crankshaft Fastener | 243 (330) |
| Cylinder Head-To-Cylinder Head Fastener (3) |
| Step 1 | 26 (35) |
| Step 2 | (2) |
| Step 3 | (2) |
| Drive Belt Tensioner-To-Cylinder Head Fastener | 15 (21) |
| Drive Belt Tensioner Absorber-To-Drive Belt Tensioner Arm Fastener | 14 (20) |
| Drive Belt Tensioner Absorber-To-Drive Belt Tensioner Bracket Fastener | 14 (20) |
| Drive Belt Tensioner Arm-To-Drive Belt Tensioner Fastener | 15 (21) |
| Drive Belt Tensioner Bracket-To-Oil Pump Fastener | 21 (28) |
| Drive Plate-To-Crankshaft Fastener (4) | 61 (83) |
| Drive Plate-To-Torque Converter Clutch Fastener | 35 (48) |
| ECT Sensor-To-Cylinder Head Fastener | 14 (20) |
| Engine Hanger-To-Cylinder Head Fastener | 30 (40) |
| Engine Hanger-To-Cylinder Head Fastener | 30 (40) |
| Engine Mounting Bracket-To-Cylinder Block Fastener | 44 (59) |
| Engine Rear Mounting Member-To-Body Fastener | 19 (26) |
| Engine Rear Mounting Member-To-Transmission Fastener | 10 (13) |
| Exhaust Manifold-To-Cylinder Head Fastener | 30 (40) |
| Front Exhaust Pipe-To-Center Exhaust Pipe Fastener | 32 (43) |
| Front Exhaust Pipe-To-Exhaust Manifold Fastener | 32 (43) |
| Front Suspension Member Brace-To-Body Fastener (5) | 43 (58) |
| Front Suspension Member Brace-To-Front Suspension Member Fastener (5) | 88 (119) |
| Fuel Inlet Hose-To-Fuel Pipe Support Fastener | 22 (29) |
| Fuel Inlet Pipe-To-Cylinder Block Fastener | 22 (29) |
| Generator-To-Cylinder Block Fastener | 30 (40) |
| Generator-To-Water Pump Fastener | 30 (40) |
| Idler Pulley-To-Oil Pump Fastener | 26 (35) |
| Intake Manifold-To-Cylinder Head Fastener | 21 (28) |
| Lower Arm-To-Steering Knuckle Fastener | 181 (245) |
| Main Bearing Cap-To-Cylinder Block Fastener (6) |
| Step 1 | 33 (45) |
| Step 2 | (2) |
| Manifold Stay-To-Cylinder Block Fastener | 30 (40) |
| Manifold Stay-To-Intake Manifold Fastener | 30 (40) |
| No. 1 Oil Pan-To-Transmission Fastener | 27 (37) |
| No. 1 Oil Pipe-To-Cylinder Block Fastener | 41 (55) |
| No. 1 Oil Pipe-To-No. 3 Camshaft Bearing Cap Fastener | 41 (55) |
| No. 2 Water Bypass Pipe-To-Cylinder Block Fastener | 15 (21) |
| No. 2 Water Bypass Pipe-To-Water Pump Fastener | 15 (21) |
| Oil Filter Bracket-To-Cylinder Block Fastener | 66 (90) |
| PS Pump Front Bracket-To-Cylinder Block Fastener | 38 (52) |
| PS Pump Front Bracket-To-PS Vane Pump Fastener | 43 (58) |
| PS Pump Rear Stay-To-Manifold Stay Fastener | 29 (39) |
| PS Pump Rear Stay-To-Power Steering Pump Bracket Fastener | 29 (39) |
| PS Vane Pump-To-A/C Compressor Fastener | 43 (58) |
| PS Vane Pump-To-Cylinder Block Fastener | 43 (58) |
| Rear Support Member-To-Body Fastener | 19 (26) |
| Shock Absorber-To-Steering Knuckle Fastener | 47 (64) |
| Sliding Yoke-To-Steering Intermediate Shaft Fastener | 26 (35) |
| Stabilizer Bar-To-Body |
| Bolt | 13 (18) |
| Nut | 30 (49) |
| Starter-To-Transmission Fastener | 27 (37) |
| Straight Screw Plug-To-Camshaft Timing Pulley Fastener | 11 (15) |
| Suspension Member-To-Body Fastener | 52 (70) |
| Tailpipe Bracket-To-Body Fastener | 10 (13) |
| Timing Belt Tensioner-To-Oil Pump Fastener | 20 (27) |
| Torque Converter Clutch-To-Drive Plate Fastener | 35 (48) |
| Transmission-To-Cylinder Block Fastener | 53 (72) |
| Transmission Control Rod-To-Shift Lever Fastener | 10 (13) |
| Transmission Control Rod-To-Transmission Fastener | 10 (13) |
| Vacuum Control Valve Set-To-Intake Manifold Fastener | 15 (21) |
| Vane Pump Assembly Bolts (7) |
| Bolt A | 43 (58) |
| Bolt B | 38 (52) |
| Water Outlet-To-Cylinder Head Fastener | 21 (28) |
| INCH Lbs. (N.m) |
| Cylinder Head Cover-To-Cylinder Head Fastener | 80 (9) |
| High-Tension Cord-To-Cylinder Head Cover Fastener | 71 (8) |
| No. 1 Timing Belt Cover-To-Oil Pump Fastener | 71 (8) |
| No. 2 Timing Belt Cover-To-Cylinder Head Fastener | 71 (8) |
| No. 3 Camshaft Bearing Cap-To-Cylinder Head Hexagon Bolt | 44 (5) |
| No. 3 Timing Belt Cover-To-Cylinder Head Fastener | 71 (8) |
| No. 4 Timing Belt Cover-To-Cylinder Head Fastener | 71 (8) |
| Rear Oil Seal Retainer-To-Cylinder Block Fastener | 53 (6) |
| Timing Belt Plate-To-Oil Pump Fastener | 71 (8) |
| (1) Tighten bolt following specified sequence. (Scheme 1) (2) Tighten bolt 90 degrees. (3) Tighten bolt following specified sequence. (Scheme 2) (4) Tighten bolt following specified sequence. (Scheme 3) (5) Identify bolt position and length before tightening. (Scheme 4) (6) Tighten bolt following specified sequence. (Scheme 5) (7) Identify bolt length before tightening. (Scheme 6) |
