DESCRIPTION

If the steering lock ECU determines that there is a malfunction inside the ECU, it outputs this DTC. Diagnostic communication between the steering lock ECU and the Techstream is performed via the certification ECU as the steering lock ECU is not connected to BEAN.

PROCEDURE

1. REPLACE STEERING LOCK ACTUATOR ASSEMBLY (STEERING LOCK ECU) HINT: The steering lock ECU and steering lock actuator assembly are supplied as a unit. Replace the steering lock actuator assembly. Refer to «REMOVAL»(/lexus/is-f/i-2007-2014/remont/windows/#window-glass-service-information) . NEXT --> END

The power source control ECU controls the power supply to activate the steering lock motor. This prevents the steering from being locked while the vehicle is moving.

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. INSPECT STEERING LOCK ACTUATOR ASSEMBLY (STEERING LOCK ECU) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition J29-3 (IGE) - J29-1 (GND) Specified condition is checked after performing the following: Turn the engine switch off Turn the engine switch on (ACC or IG) Motor activated: Below 1 V Motor not activated: 10 to 12 V J29-3 (IGE) - J29-1 (GND) Specified condition is checked after performing the following: Move the shift lever to P Turn the engine switch off Open the driver's door Motor activated: Below 1 V Motor not activated: 10 to 12 V HINT: The steering lock ECU and steering lock actuator assembly are supplied as a unit. NG --> See step 2 OK --> See step 4
2. CHECK HARNESS AND CONNECTOR (STEERING LOCK ACTUATOR ASSEMBLY - BODY GROUND) Disconnect the J29 connector from the steering lock actuator assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition J29-1 (GND) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (STEERING LOCK ACTUATOR ASSEMBLY - POWER SOURCE CONTROL ECU) Disconnect the J55 connector from the power source control ECU. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition J29-3 (IGE) - J55-32 (SLR+) Always Below 1 ohms J29-3 (IGE) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE POWER SOURCE CONTROL ECU
4. REPLACE STEERING LOCK ACTUATOR ASSEMBLY (STEERING LOCK ECU). Refer to «DISASSEMBLY»(/lexus/is-f/i-2007-2014/remont/steering-column/#steering-column-service-information)

The steering lock ECU receives power from the IG2 relay. When the voltage value indicated by the IG signal from the certification ECU equals to the voltage that is applied to the steering lock ECU, the steering will be unlocked. The steering lock ECU will not lock the steering when power from the IG2 relay is present. This prevents the steering from being locked while the vehicle is moving.

Scheme 78

Scheme 79

Scheme 80

Scheme 81

1. INSPECT NO. 2 IGNITION RELAY Remove the IG2 relay from the No. 2 engine room junction block and relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Specified Condition 3 - 5 10 kohms or higher 3 - 5 Below 1 ohms (when battery voltage is applied to terminals 1 and 2) NG --> REPLACE NO. 2 IGNITION RELAY OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (STEERING LOCK ACTUATOR ASSEMBLY - BODY GROUND) Disconnect the J29 connector from the steering lock actuator assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition J29-1 (GND) - Body ground Always Below 1 ohms J29-2 (SGND) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (STEERING LOCK ACTUATOR ASSEMBLY - BATTERY) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition J29-6 (IG2) - J29-1 (GND) Engine switch on (IG) 10 to 14 V J29-6 (IG2) - J29-2 (SGND) Engine switch on (IG) 10 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition *J29-6 (IG2) - J29-7 (B) Engine switch off 10 kohms or higher *: This measurement is performed with the engine switch off to check for a battery voltage short in the IG2 circuit. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
4. REPLACE STEERING LOCK ACTUATOR ASSEMBLY (STEERING LOCK ECU). Refer to «DISASSEMBLY»(/lexus/is-f/i-2007-2014/remont/steering-column/#steering-column-service-information)

The steering lock ECU is connected to the power source control ECU and ID CODE BOX. The steering lock ECU cannot activate the motor unless it receives permission signals from both ECUs. (The power source control ECU permits the steering lock ECU to supply power to activate the motor.)

Scheme 82

1. CHECK VEHICLE CONDITION Check the problem symptom of the steering lock system. Result Condition Proceed to Steering lock cannot be released. A Steering cannot be locked. B B --> See step 6 A: Go to next step
2. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Check the steering lock command reception record. Enter the following menus: Body Electrical / Smart Access / Data List. SMART ACCESS Tester Display Measurement Item/Range Normal Condition Lock/Unlock Receive Steering lock command reception record/YES or NO YES: Steering lock/unlock signal received NO: Steering lock/unlock signal not received Check if steering unlock command reception is confirmed. OK "YES" is displayed on the Techstream. NG --> See step 8 OK: Go to next step
3. INSPECT STEERING LOCK ACTUATOR ASSEMBLY (STEERING LOCK ECU) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition J29-3 (IGE) - J29-1 (GND) Turn the engine switch off Turn the engine switch on (ACC or IG) Motor activated: Below 1 V Motor not activated: 10 to 12 V NG --> See step 4 OK --> See step 9
4. CHECK HARNESS AND CONNECTOR (STEERING LOCK ACTUATOR ASSEMBLY - BODY GROUND) Disconnect the J29 connector from the steering lock actuator assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition J29-1 (GND) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (STEERING LOCK ACTUATOR ASSEMBLY - POWER SOURCE CONTROL ECU) Disconnect the J55 connector from the power source control ECU. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition J29-3 (IGE) - J55-32 (SLR+) Always Below 1 ohms J29-3 (IGE) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE POWER SOURCE CONTROL ECU
6. INSPECT STEERING LOCK ACTUATOR ASSEMBLY (STEERING LOCK ECU) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition J29-3 (IGE) - J29-1 (GND) Specified condition is checked after performing the following: Move the shift lever to P Turn the engine switch off Open the driver's door Motor activated: Below 1 V Motor not activated: 10 to 12 V NG --> See step 7 OK --> See step 10
7. CHECK HARNESS AND CONNECTOR (STEERING LOCK ACTUATOR ASSEMBLY - POWER SOURCE CONTROL ECU) Disconnect the J29 connector from the steering lock actuator assembly. Disconnect the J55 connector from the power source control ECU. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition J29-3 (IGE) - J55-32 (SLR+) Always Below 1 ohms J29-3 (IGE) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE POWER SOURCE CONTROL ECU
8. CHECK SMART ACCESS SYSTEM WITH PUSH-BUTTON START (for start). Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(/lexus/is-f/i-2007-2014/remont/starter/#smart-access-system-keyless-start-diagnostics-introduction__how-to-proceed-with-troubleshooting)
9. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(/lexus/is-f/i-2007-2014/remont/steering-column/#steering-lock-diagnostics-introduction__problem-symptoms-table)
10. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(/lexus/is-f/i-2007-2014/remont/steering-column/#steering-lock-diagnostics-introduction__problem-symptoms-table)

The unlock position sensor is one of the components comprising the steering lock actuator. The sensor switch contact closes when the steering lock is released. The steering lock release signal is then sent to the power source control ECU. Upon receiving the signal, the ECU permits engine start. This prevents the engine from being started with the steering locked.

Scheme 83

Scheme 84

Scheme 85

1. INSPECT STEERING LOCK ACTUATOR ASSEMBLY (STEERING LOCK ECU) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition J29-4 (SLP1) - J29-2 (SGND) Turn the engine switch off Turn the engine switch on (ACC or IG) Below 1 V NG --> See step 2 OK --> See step 3
2. CHECK HARNESS AND CONNECTOR (STEERING LOCK ACTUATOR ASSEMBLY - POWER SOURCE CONTROL ECU) Disconnect the J29 connector from the steering lock actuator assembly. Disconnect the J55 connector from the power source control ECU. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition J29-4 (SLP1) - J55-26 (SLP) Always Below 1 ohms J29-4 (SLP1) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
3. REPLACE STEERING LOCK ACTUATOR ASSEMBLY. Refer to «DISASSEMBLY»(/lexus/is-f/i-2007-2014/remont/steering-column/#steering-column-service-information)
4. CHECK SMART ACCESS SYSTEM WITH PUSH-BUTTON START (for start). Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(/lexus/is-f/i-2007-2014/remont/starter/#smart-access-system-keyless-start-diagnostics-introduction__how-to-proceed-with-troubleshooting)

This circuit supplies power source voltage from the battery to terminal B of the steering lock ECU. This is used as power source for the CPU, motor, communication, and peripheral circuits.

Scheme 86

Scheme 87

1. CHECK HARNESS AND CONNECTOR (STEERING LOCK ACTUATOR ASSEMBLY - BODY GROUND) Disconnect the J29 connector from the steering lock actuator assembly. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition J29-1 (GND) - Body ground Always Below 1 ohms J29-2 (SGND) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (STEERING LOCK ACTUATOR ASSEMBLY - BATTERY) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition J29-7 (B) - J29-1 (GND) Always 10 to 14 V J29-7 (B) - J29-2 (SGND) Always 10 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (STEERING LOCK ACTUATOR ASSEMBLY - BATTERY) OK --> See step 3
3. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(/lexus/is-f/i-2007-2014/remont/steering-column/#steering-lock-diagnostics-introduction__problem-symptoms-table)
