Cooling (service Information) Lexus IS F I

Cooling Fan 62 illustrations ~3629 words

Scheme 1

Scheme 1: REPLACEMENT
Scheme 1: REPLACEMENT

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4
  1. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL - Step 3»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  2. REMOVE ENGINE UNDER COVER
  3. DRAIN ENGINE COOLANT Loosen the radiator drain cock plug. WARNING: Do not loosen the radiator drain cock plug while the engine and radiator are still hot. Pressurized, hot engine coolant and steam may be released and cause serious burns. HINT: Collect the coolant in a container and dispose of it according to local regulations. Remove the radiator reservoir cap, and using a 6 mm socket hexagon wrench, remove the vent plug. Drain coolant. Loosen the 2 cylinder block drain cock plugs.
  4. ADD ENGINE COOLANT NOTE: Before adding coolant, turn the A/C switch OFF. Total capacity 11.9 liters (12.6 US qts, 10.5 Imp. qts) Tighten the radiator drain cock plug by hand. Tighten the 2 cylinder block drain cock plugs. Torque: 13 N*m (133 kgf*cm, 10 ft.*lbf) Add TOYOTA Super Long Life Coolant (SLLC) into the radiator reservoir. Capacity Approximately 5.0 liters (5.3 US qts, 4.4 Imp. qts) HINT: LEXUS vehicles are filled with TOYOTA SLLC at the factory. In order to avoid damage to the engine cooling system and other technical problems, only use TOYOTA SLLC or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, non-borate coolant with long-life hybrid organic acid technology (coolant with long-life hybrid organic acid technology consists of a combination of low phosphates and organic acids). Contact any authorized LEXUS dealer or repairer or another duly qualified and equipped professional for further details. Thermostat opening timing can be confirmed by squeezing the inlet radiator hose and sensing vibrations when the coolant starts to flow inside the hose. Further add coolant into the reservoir until it reaches the FULL line. Squeeze the No. 1 and No. 2 radiator hoses several times, and then check the coolant level. If the coolant level is low, add coolant. Using a 6 mm socket hexagon wrench, install the vent plug. Torque: 1.5 N*m (15 kgf*cm, 13 in.*lbf) Bleed air from the cooling system. NOTE: Before starting the engine, turn the A/C switch off. While idling the engine for approximately 10 minutes, make sure that the coolant remains at the FULL line by adding coolant as necessary. After idling the engine for 10 minutes, add coolant to the level shown in the illustration. Capacity Approximately 2.5 to 3.5 liters (2.6 to 3.7 US qts, 2.2 to 3.1 Imp.qts) Close the radiator reservoir cap, and run the engine at 1500 to 2000 rpm for 5 minutes. HINT: Thermostat opening timing can be confirmed by squeezing the No. 1 radiator hose and sensing vibrations when the SLLC starts to flow inside the hose. WARNING: When squeezing the radiator hose: Wear protective gloves. Be careful as the radiator hose is hot. Keep your hands away from the radiator fan. Stop the engine and wait until the coolant cools down to ambient temperature. WARNING: Do not remove the radiator reservoir cap while the engine and radiator are still hot. Pressurized, hot coolant and steam may be released and cause serious burns. Check the coolant level. If the coolant level is below the FULL line, add coolant until it reaches the FULL line.
  5. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(/lexus/is-f/i-2007-2014/remont/cooling-system-mechanical/#cooling-inspection)
  6. INSTALL ENGINE UNDER COVER
  7. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION - Step 94»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)

Scheme 5

Scheme 5: ILLUSTRATION
Scheme 5: ILLUSTRATION

Scheme 6

Scheme 6: ILLUSTRATION
Scheme 6: ILLUSTRATION

Scheme 7

Scheme 7: ON-VEHICLE INSPECTION
Scheme 7: ON-VEHICLE INSPECTION

Scheme 8

Scheme 8
Scheme 8
  1. INSPECT WATER PUMP Visually check the air hole and drain hole for coolant leakage. If leakage is found, replace the water pump. Turn the pulley and check that the water pump bearing moves smoothly and quietly. If necessary, replace the water pump.

Scheme 9

Scheme 9: REMOVAL
Scheme 9: REMOVAL

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. REMOVE ENGINE UNDER COVER
  2. DRAIN ENGINE COOLANT See step 3
  3. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 2»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  4. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL - Step 3»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  5. REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 20»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  6. REMOVE ENGINE ROOM SIDE COVER RH . Refer to «REMOVAL - Step 4»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  7. REMOVE AIR CLEANER CAP SUB-ASSEMBLY . Refer to «REMOVAL - Step 4»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
  8. REMOVE RADIATOR RESERVE TANK ASSEMBLY See step 19
  9. REMOVE V-RIBBED BELT . Refer to «REMOVAL - Step 4»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  10. DISCONNECT NO. 2 RADIATOR HOSE Disconnect the No. 2 radiator hose from the water inlet housing.
  11. DISCONNECT NO. 5 WATER BY-PASS HOSE Disconnect the No. 5 water by-pass hose from the water inlet housing.
  12. DISCONNECT WATER INLET HOSE Disconnect the water inlet hose from the water inlet housing.
  13. DISCONNECT NO. 3 WATER BY-PASS HOSE Disconnect the No. 3 water by-pass hose from the water inlet housing.
  14. REMOVE WATER INLET HOUSING Remove the 3 bolts, water inlet housing and gasket.
  15. REMOVE WATER PUMP PULLEY Using a screwdriver or an equivalent, hold the water pump pulley. HINT: Tape the screwdriver tip before use to avoid damage. Remove the 4 bolts and water pump pulley.
  16. REMOVE WATER PUMP Remove the 9 bolts, water pump and gasket.

Scheme 16

Scheme 16: INSTALLATION
Scheme 16: INSTALLATION

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. INSTALL WATER PUMP Install the water pump and a new gasket with the 9 bolts as shown in the illustration. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) for bolt A Torque: 23 N*m (235 kgf*cm, 17 ft.*lbf) for bolt B Torque: 47 N*m (479 kgf*cm, 35 ft.*lbf) for bolt C
  2. INSTALL WATER PUMP PULLEY Temporarily install the pulley with the 4 bolts. Using a screwdriver or an equivalent, hold the pulley and tighten the 4 bolts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) HINT: Tape the screwdriver tip before use to avoid damage.
  3. INSTALL WATER INLET HOUSING Install a new gasket to the water pump. Install the water inlet housing with the 3 bolts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
  4. CONNECT NO. 3 WATER BY-PASS HOSE Connect the No. 3 water by-pass hose to the water inlet housing. HINT: The direction of the hose clamp is indicated in the illustration.
  5. CONNECT WATER INLET HOSE Connect the water inlet hose to the water inlet housing. HINT: The direction of the hose clamp is indicated in the illustration.
  6. CONNECT NO. 5 WATER BY-PASS HOSE Connect the No. 5 water by-pass hose to the water inlet housing. HINT: The direction of the hose clamp is indicated in the illustration.
  7. CONNECT NO. 2 RADIATOR HOSE Connect the No. 2 radiator hose to the water inlet housing.
  8. INSTALL V-RIBBED BELT . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  9. INSTALL RADIATOR RESERVE TANK ASSEMBLY See step 10
  10. INSTALL AIR CLEANER CAP SUB-ASSEMBLY . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
  11. ADD ENGINE COOLANT See step 4
  12. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(/lexus/is-f/i-2007-2014/remont/cooling-system-mechanical/#cooling-inspection)
  13. INSTALL ENGINE ROOM SIDE COVER RH . Refer to «INSTALLATION - Step 92»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  14. INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 91»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  15. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION - Step 94»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  16. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 95»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  17. INSTALL ENGINE UNDER COVER

Scheme 21

Scheme 21: ILLUSTRATION
Scheme 21: ILLUSTRATION

Scheme 22

Scheme 22: ILLUSTRATION
Scheme 22: ILLUSTRATION

Scheme 23

Scheme 23: REMOVAL
Scheme 23: REMOVAL
  1. REMOVE ENGINE UNDER COVER
  2. DRAIN ENGINE COOLANT See step 3
  3. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL - Step 3»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  4. REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 20»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  5. DISCONNECT NO. 2 RADIATOR HOSE See step 10
  6. REMOVE WATER INLET SUB-ASSEMBLY WITH THERMOSTAT Remove the 3 nuts, water inlet sub-assembly with thermostat and gasket.

Scheme 24

Scheme 24: INSPECTION
Scheme 24: INSPECTION

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26
  1. INSPECT WATER INLET SUB-ASSEMBLY WITH THERMOSTAT HINT: The water inlet sub-assembly with thermostat is stamped with the valve opening temperature. Immerse the water inlet sub-assembly with thermostat in water and gradually heat the water. Check the valve opening temperature. Standard valve opening temperature 80 to 84°C (176 to 183°F) If the valve opening temperature is not within the specified range, replace the water inlet sub-assembly with thermostat. Check the valve lift. Standard valve lift 10.0 mm (0.394 in.) or more at 95°C (203°F) If the valve lift is not as specified, replace the water inlet sub-assembly with thermostat. Check that the valve closes when the water inlet sub-assembly with thermostat is at a low temperature (below 77°C (171°F)). If it does not close as specified, replace the water inlet sub-assembly with thermostat.

INSTALLATION

  1. INSTALL WATER INLET SUB-ASSEMBLY WITH THERMOSTAT Install a new gasket and the water inlet sub-assembly with thermostat with the 3 nuts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
  2. CONNECT NO. 2 RADIATOR HOSE See step 7
  3. ADD ENGINE COOLANT See step 4
  4. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(/lexus/is-f/i-2007-2014/remont/cooling-system-mechanical/#cooling-inspection)
  5. INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 91»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  6. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION - Step 94»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  7. INSTALL ENGINE UNDER COVER

Scheme 27

Scheme 27: ILLUSTRATION
Scheme 27: ILLUSTRATION

Scheme 28

Scheme 28: ON-VEHICLE INSPECTION
Scheme 28: ON-VEHICLE INSPECTION
  1. INSPECT COOLING FAN MOTOR Disconnect the cooling fan motor connector. Check that the motor turns smoothly when the battery is connected to the fan motor connector. Measure the current according to the value(s) in the table below. Standard Current Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) at 12 V 18.0 to 22.0 A If the result is not as specified, replace the cooling fan motor.
  2. INSPECT NO. 2 COOLING FAN MOTOR Disconnect the No. 2 cooling fan motor connector. Check that the motor turns smoothly when the battery is connected to the fan motor connector. Measure the current according to the value(s) in the table below. Standard Current Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) at 12 V 18.0 to 22.0 A If the result is not as specified, replace the No. 2 cooling fan motor.

Scheme 29

Scheme 29: REMOVAL
Scheme 29: REMOVAL

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33
  1. REMOVE RADIATOR ASSEMBLY HINT
  2. DISCONNECT COOLING FAN MOTOR CONNECTORS Disconnect the 2 cooling fan motor connectors from the 2 cooling fan ECUs. Disconnect the 2 clamps.
  3. REMOVE FAN Remove the nut and fan.
  4. REMOVE NO. 2 FAN Remove the nut and No. 2 fan.
  5. REMOVE COOLING FAN MOTOR Remove the 3 screws and the cooling fan motor.
  6. REMOVE NO. 2 COOLING FAN MOTOR Remove the 3 screws and the No. 2 cooling fan motor.
  1. INSTALL NO. 2 COOLING FAN MOTOR Install the No. 2 cooling fan motor with the 3 screws. Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)
  2. INSTALL COOLING FAN MOTOR Install the cooling fan motor with the 3 screws. Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)
  3. INSTALL NO. 2 FAN Install the No. 2 fan with the nut. Torque: 6.3 N*m (64 kgf*cm, 56 in.*lbf)
  4. INSTALL FAN Install the fan with the nut. Torque: 6.3 N*m (64 kgf*cm, 56 in.*lbf)
  5. CONNECT COOLING FAN MOTOR CONNECTORS Connect the cooling fan motor connectors to the 2 cooling fan ECUs. Install the 2 clamps.
  6. INSTALL RADIATOR ASSEMBLY HINT

Scheme 34

Scheme 34: ON-VEHICLE INSPECTION
Scheme 34: ON-VEHICLE INSPECTION
  1. CHECK COOLING FAN ECU Put the vehicle in the following conditions: The engine switch is off. The coolant temperature is less than 92°C (198°F). The battery voltage is between 11 and 14 V. The A/C switch is off. Connect the 400 A probe of an ammeter to terminals M+ of the cooling fan motors. Turn the engine switch on (IG) and wait for approximately 10 seconds. Check that the fans stop. Start the engine. Check that the fans stop with the engine idling. HINT: Make sure that the radiator coolant temperature is less than 92°C (198°F). Turn the A/C switch off. Check that the fans operate when the A/C switch is turned ON (MAX COOL). Measure the current according to the value(s) in the table below. Standard Current Item Specified Condition Cooling fan motor 2 to 22 A No. 2 cooling fan motor 2 to 22 A HINT: The coolant temperature is less than 92°C (198°F). Check that the fans operate when the engine coolant temperature sensor connector is disconnected. Measure the current according to the value(s) in the table below. Standard Current Item Specified Condition Cooling fan motor 2 to 22 A No. 2 cooling fan motor 2 to 22 A After the engine is warmed up, check that the fans operate as shown in the illustration below. HINT: The coolant temperature at which the fans start operating is approximately 94°C (201°F). This system can also be checked using the Techstream. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.

Scheme 35

Scheme 35: ILLUSTRATION
Scheme 35: ILLUSTRATION

Scheme 36

Scheme 36: ILLUSTRATION
Scheme 36: ILLUSTRATION

Scheme 37

Scheme 37: ILLUSTRATION
Scheme 37: ILLUSTRATION

Scheme 38

Scheme 38: ILLUSTRATION
Scheme 38: ILLUSTRATION

Scheme 39

Scheme 39: ON-VEHICLE INSPECTION
Scheme 39: ON-VEHICLE INSPECTION

Scheme 40

Scheme 40
Scheme 40
  1. CHECK RADIATOR CAP SUB-ASSEMBLY Measure the valve opening pressure. If there are water stains or foreign matter on O-ring 1, clean it with water and finger scouring. Check that O-ring 1 is not deformed, cracked or swollen. Apply engine coolant to O-ring 1 and rubber packing 2 before using a radiator cap tester. When using the cap tester, tilt it more than 30°. Pump the cap tester several times, and check the maximum pressure*. Pump speed 1 pump per second *: Even if the cap cannot maintain the maximum pressure, it is not a defect. Judgment Criterion Item Specified Condition Standard value (for brand-new cap) 93 to 123 kPa (1.0 to 1.2 kgf/cm 2 , 13.5 to 17 psi) Minimum standard value (for used cap) 79 kPa (0.8 kgf/cm 2 , 11.4 psi) If the maximum pressure is less than the minimum standard value, replace the radiator reservoir cap sub-assembly.
  2. CHECK FINS FOR BLOCKAGE Check that the radiator and condenser are not blocked with leaves, dirt, or insects. Clean the hose connections. If the fins are blocked, wash them with water or a steam cleaner. NOTE: If the distance between the steam cleaner and core is too close, the fins may be damaged. Keep the following injection distance. Standard Injection Distance Injection Distance Injection Pressure 300 mm (11.8 in.) 2942 to 4903 kPa (30 to 50 kgf/cm 2 , 427 to 711 psi) 500 mm (19.7 in.) 4903 to 7845 kPa (50 to 80 kgf/cm 2 , 711 to 1138 psi) If the fins are bent, straighten them with a screwdriver or pliers. Never apply water directly into the electric components. Dry the fins with compressed air.

Scheme 41

Scheme 41: REMOVAL
Scheme 41: REMOVAL

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57
  1. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL - Step 3»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  2. REMOVE ENGINE ROOM SIDE COVER LH . Refer to «REMOVAL - Step 4»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  3. REMOVE ENGINE ROOM SIDE COVER RH . Refer to «REMOVAL - Step 5»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  4. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 2»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  5. REMOVE NO. 1 AIR CLEANER INLET . Refer to «REMOVAL - Step 20»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  6. REMOVE AIR CLEANER CAP SUB-ASSEMBLY . Refer to «REMOVAL - Step 4»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
  7. REMOVE ENGINE UNDER COVER
  8. REMOVE NO. 2 ENGINE UNDER COVER
  9. DRAIN AUTOMATIC TRANSMISSION FLUID . Refer to «REMOVAL - Step 3»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
  10. DRAIN ENGINE COOLANT See step 3
  11. REMOVE RADIATOR GRILLE PROTECTOR . Refer to «REMOVAL - Step 2»(/lexus/is-f/i-2007-2014/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  12. REMOVE FRONT BUMPER ASSEMBLY . Refer to «REMOVAL - Step 3»(/lexus/is-f/i-2007-2014/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  13. REMOVE FRONT BUMPER ENERGY ABSORBER . Refer to «DISASSEMBLY - Step 22»(/lexus/is-f/i-2007-2014/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  14. REMOVE RADIATOR SUPPORT OPENING COVER . Refer to «REMOVAL - Step 11»(/lexus/is-f/i-2007-2014/remont/automatic-hvac-system/#air-conditioning-service-information)
  15. REMOVE MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) . Refer to «REMOVAL - Step 4»(/lexus/is-f/i-2007-2014/remont/cruise-control-systems/#cruise-control-service-information)
  16. REMOVE HOOD LOCK CONTROL CABLE COVER . Refer to «REMOVAL - Step 8»(/lexus/is-f/i-2007-2014/remont/exterior-body-panels/#door-service-information)
  17. REMOVE HOOD LOCK NUT CAP . Refer to «REMOVAL - Step 9»(/lexus/is-f/i-2007-2014/remont/exterior-body-panels/#door-service-information)
  18. DISCONNECT HOOD LOCK ASSEMBLY . Refer to «REMOVAL - Step 10»(/lexus/is-f/i-2007-2014/remont/exterior-body-panels/#door-service-information)
  19. REMOVE RADIATOR RESERVE TANK ASSEMBLY Disconnect 2 reserve tank hoses, then remove the 2 bolts and radiator reserve tank assembly.
  20. REMOVE ENGINE ROOM ECU OUTLET DUCT Remove the engine room ECU outlet duct from the engine room ECU box.
  21. REMOVE UPPER RADIATOR SUPPORT Disconnect the smog ventilation sensor connector. Disconnect the 2 horn connectors. Separate the 5 clamps and the wire harness from the upper radiator support. Separate the 2 clamps and the wire harness from the upper radiator support. Separate the 3 clamps and the wire harness from the fan shroud. Disconnect the 2 cooling fan ECU connectors. Remove the 5 bolts and the upper radiator support.
  22. DISCONNECT NO. 1 RADIATOR HOSE Disconnect the No. 1 radiator hose from the radiator assembly.
  23. DISCONNECT NO. 2 RADIATOR HOSE Disconnect the No. 2 radiator hose from the radiator assembly.
  24. DISCONNECT OIL COOLER HOSE Disconnect the 2 oil cooler hoses from the radiator assembly. Disconnect the 2 bolts and oil cooler pipe from the radiator assembly.
  25. SEPARATE COOLER CONDENSER ASSEMBLY Remove the 4 bolts and separate the cooler condenser assembly from the radiator assembly.
  26. REMOVE RADIATOR ASSEMBLY Remove the radiator assembly from the vehicle together with the cooling fan assembly. NOTE: Make sure that the cooler condenser assembly and radiator assembly do not come into contact with each other. Remove the 2 bolts. Release the claw and lift the fan assembly from the radiator assembly.
  27. REMOVE RADIATOR SUPPORT CUSHION Remove the 2 radiator support cushions.
  28. REMOVE LOWER RADIATOR SUPPORT Remove the 2 lower radiator supports.

Scheme 58

Scheme 58: INSTALLATION
Scheme 58: INSTALLATION

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61
  1. INSTALL LOWER RADIATOR SUPPORT Install the 2 lower radiator supports to the radiator assembly.
  2. INSTALL RADIATOR SUPPORT CUSHION Install the 2 radiator support cushions to the radiator assembly.
  3. INSTALL RADIATOR ASSEMBLY Install the fan assembly to the radiator with the 2 guides at the bottom and claw on the top. Install the 2 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) Install the radiator assembly to the vehicle together with the cooling fan assembly. NOTE: Make sure that the cooler condenser assembly and radiator assembly do not come into contact with each other.
  4. INSTALL COOLER CONDENSER ASSEMBLY Install the cooler condenser assembly with the 4 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf)
  5. CONNECT OIL COOLER HOSE Install the oil cooler pipe with the 2 bolts. Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf) Connect the 2 oil cooler hoses to the radiator assembly.
  6. CONNECT NO. 2 RADIATOR HOSE Connect the No. 2 radiator hose to the radiator assembly.
  7. CONNECT NO. 1 RADIATOR HOSE Connect the No. 1 radiator hose to the radiator assembly.
  8. INSTALL UPPER RADIATOR SUPPORT Install the 5 bolts and the upper radiator support. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Connect the 2 cooling fan ECM connectors. Install the 3 clamps and the wire harness to the fan shroud. Install the 2 clamps and the wire harness to the upper radiator support. Install the 5 clamps and the wire harness to the upper radiator support. Connect the 2 horn connectors. Connect the smog ventilation sensor connector.
  9. INSTALL ENGINE ROOM ECU OUTLET DUCT Install the engine room ECU outlet duct to the engine room ECU box.
  10. INSTALL RADIATOR RESERVE TANK ASSEMBLY Install the radiator reserve tank assembly with the 2 bolts and 2 reserve tank hoses. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf)
  11. INSTALL HOOD LOCK ASSEMBLY . Refer to «INSTALLATION - Step 7»(/lexus/is-f/i-2007-2014/remont/exterior-body-panels/#door-service-information)
  12. INSTALL HOOD LOCK NUT CAP . Refer to «INSTALLATION - Step 8»(/lexus/is-f/i-2007-2014/remont/exterior-body-panels/#door-service-information)
  13. INSTALL HOOD LOCK CONTROL CABLE COVER . Refer to «INSTALLATION - Step 9»(/lexus/is-f/i-2007-2014/remont/exterior-body-panels/#door-service-information)
  14. INSTALL MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/cruise-control-systems/#cruise-control-service-information)
  15. INSTALL AIR CLEANER CAP SUB-ASSEMBLY . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
  16. INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 91»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  17. INSTALL RADIATOR SUPPORT OPENING COVER . Refer to «INSTALLATION - Step 11»(/lexus/is-f/i-2007-2014/remont/automatic-hvac-system/#air-conditioning-service-information)
  18. INSTALL FRONT BUMPER ENERGY ABSORBER . Refer to «REASSEMBLY - Step 2»(/lexus/is-f/i-2007-2014/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  19. INSTALL FRONT BUMPER ASSEMBLY . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  20. INSTALL RADIATOR GRILLE PROTECTOR . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/exteriorinterior-trim/#exterior-panels-trim-service-information)
  21. ADD AUTOMATIC TRANSMISSION FLUID
  22. ADD ENGINE COOLANT See step 4
  23. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(/lexus/is-f/i-2007-2014/remont/cooling-system-mechanical/#cooling-inspection)
  24. INSTALL ENGINE UNDER COVER
  25. INSTALL NO. 2 ENGINE UNDER COVER
  26. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 95»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  27. INSTALL ENGINE ROOM SIDE COVER LH . Refer to «INSTALLATION - Step 93»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  28. INSTALL ENGINE ROOM SIDE COVER RH . Refer to «INSTALLATION - Step 92»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  29. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION - Step 94»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information)
  30. ADJUST MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) . Refer to «ADJUSTMENT - Step 1»(/lexus/is-f/i-2007-2014/remont/cruise-control-systems/#cruise-control-service-information)
  31. ADD WINDSHIELD WASHER FLUID (w/ Headlight Cleaner System) . Refer to «INSTALLATION - Step 3»(/lexus/is-f/i-2007-2014/remont/wiperwasher-systems/#wiper-washer-service-information)
  32. VEHICLE PREPARATION FOR FOG LIGHT AIMING . Refer to «ADJUSTMENT - Step 1»(/lexus/is-f/i-2007-2014/remont/exterior-lights/#lighting-exterior-service-information)
  33. PREPARATION FOR FOG LIGHT AIMING . Refer to «ADJUSTMENT - Step 2»(/lexus/is-f/i-2007-2014/remont/exterior-lights/#lighting-exterior-service-information)
  34. INSPECT FOG LIGHT AIMING . Refer to «ADJUSTMENT - Step 3»(/lexus/is-f/i-2007-2014/remont/exterior-lights/#lighting-exterior-service-information)
  35. ADJUST FOG LIGHT AIMING . Refer to «ADJUSTMENT - Step 4»(/lexus/is-f/i-2007-2014/remont/exterior-lights/#lighting-exterior-service-information)

Scheme 62

Scheme 62: ON-VEHICLE INSPECTION
Scheme 62: ON-VEHICLE INSPECTION
  1. INSPECT FAN NO. 1 RELAY Remove the relay from the engine room No. 1 relay block. Measure the resistance of the relay. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Normal 10 kohms or higher 3 - 5 Battery voltage applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the relay. Install the relay to the engine room No. 1 relay block.
  2. INSPECT FAN NO. 2 RELAY Remove the relay from the engine room No. 1 relay block. Measure the resistance of the relay. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Normal 10 kohms or higher 3 - 5 Battery voltage applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the relay. Install the relay to the engine room No. 1 relay block.

More articles — Engine
