DESCRIPTION
The power window regulator motor is operated by the multiplex network master switch assembly or power window regulator switch assembly. The power window regulator motor assembly has motor, regulator and ECU functions.
This DTC is output when the power window regulator motor assembly has a malfunction, or the ECU built into the regulator motor assembly determines that the fully closed window position has deviated approximately 20 mm (0.787 in.) or more from the normal position.
HINT
DTC B2311 can be stored in each power window regulator motor assembly (power window ECU).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2311 | Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal position | Battery disconnected when power switch on (IG) Power window regulator motor assembly (for driver side) Incorrect installation of power window components Overheated power window regulator motor assembly |
D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER SIDE))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2311 | Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal position | Battery disconnected when power switch on (IG) Power window regulator motor assembly (for front passenger side) Incorrect installation of power window components Overheated power window regulator motor assembly |
P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER SIDE))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2311 | Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal position | Battery disconnected when power switch on (IG) Power window regulator motor assembly (for rear LH side) Incorrect installation of power window components Overheated power window regulator motor assembly |
RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2311 | Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal position | Battery disconnected when power switch on (IG) Power window regulator motor assembly (for rear RH side) Incorrect installation of power window components Overheated power window regulator motor assembly |
RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH SIDE))
The power window regulator motor assembly is operated by the multiplex network master switch assembly or power window regulator switch assembly. The power window regulator motor assembly has motor, regulator and ECU functions.
This DTC is output when the ECU built into the regulator motor and master switch determines that the multiplex network master switch assembly or power window regulator switch assembly is stuck.
HINT
DTC B2312 can be stored in the multiplex network master switch assembly and in each power window regulator motor assembly (power window ECU).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2312 | Multiplex network master switch assembly stuck Multiplex network master switch assembly held in same position for more than 20 seconds Door control switch (multiplex network master switch assembly) operated for 20 seconds or more | Multiplex network master switch assembly |
MASTER SWITCH (MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY)
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2312 | Multiplex network master switch assembly stuck Multiplex network master switch assembly held in same position for more than 20 seconds | Multiplex network master switch assembly Power window regulator motor assembly (for driver side) Wire harness or connector |
D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER SIDE))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2312 | Power window regulator switch assembly (for front passenger side) stuck Power window regulator switch assembly (for front passenger side) held in same position for more than 20 seconds | Power window regulator switch assembly (for front passenger side) Power window regulator motor assembly (for front passenger side) Wire harness or connector |
P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER SIDE))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2312 | Power window regulator switch assembly (for rear LH side) stuck Power window regulator switch assembly held in same position for more than 20 seconds | Power window regulator switch assembly (for rear LH side) Power window regulator motor assembly (for rear LH side) Wire harness or connector |
RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2312 | Power window regulator switch assembly (for rear RH side) stuck Power window regulator switch assembly held in same position for more than 20 seconds | Power window regulator switch assembly (for rear RH side) Power window regulator motor assembly (for rear RH side) Wire harness or connector |
RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH SIDE))
Scheme 116
Scheme 117
Scheme 118
Scheme 119
- for Driver Side
- for Front Passenger Side
- for Rear LH Side
- for Rear RH Side
The power window regulator motor assembly is operated by the multiplex network master switch or power window regulator switch assembly. The power window regulator motor assembly has motor, regulator and ECU functions.
When the ECU determines that the power window regulator motor assembly has not been initialized, DTC B2313 is set.
HINT
DTC B2313 can be stored in each power window regulator motor assembly (power window ECU).
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2313 | Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctions | Power window regulator motor assembly (for driver side) not initialized Power window regulator motor assembly (for driver side) |
D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER SIDE))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2313 | Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctions | Power window regulator motor assembly (for front passenger side) not initialized Power window regulator motor assembly (for front passenger side) |
P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER SIDE))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2313 | Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctions | Power window regulator motor assembly (for rear LH side) not initialized Power window regulator motor assembly (for rear LH side) |
RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2313 | Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctions | Power window regulator motor assembly (for rear RH side) not initialized Power window regulator motor assembly (for rear RH side) |
RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH SIDE))
When the power switch is on (IG), the multiplex network master switch assembly sends remote up and down signals to each power window regulator motor assembly via the LIN communication line.
Scheme 120
When the hybrid vehicle control system is running or the power switch is on (IG), the power window regulator motor assembly (for driver side) is operated by the multiplex network master switch assembly. The power window regulator motor assembly (for driver side) has motor, regulator and ECU functions.
HINT
If the pulse sensor built into the power window regulator motor assembly (for driver side) malfunctions, the power window control system enters fail-safe mode. The remote up and down and auto up and down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the multiplex network master switch assembly at the auto up position, and opened manually by pushing down the multiplex network master switch assembly.
Scheme 121
When the hybrid vehicle control system is running or the power switch is on (IG), the power window regulator motor assembly (for front passenger side) is operated by the power window regulator switch assembly (for front passenger side). The power window regulator motor assembly (for front passenger side) has motor, regulator, and ECU functions.
HINT
If the pulse sensor built into the power window regulator motor assembly (for front passenger side) malfunctions, the power window control system enters fail-safe mode. The remote up and down and auto up and down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the power window regulator switch assembly (for front passenger side) at the auto up position, and opened manually by pushing down the power window regulator switch assembly (for front passenger side).
Scheme 122
When the hybrid vehicle control system is running or the power switch is on (IG), the power window regulator motor assembly (for rear LH side) is operated by the power window regulator switch assembly (for rear LH side). The power window regulator motor has motor, regulator, and ECU functions.
HINT
If the pulse sensor built into the power window regulator motor assembly (for rear LH side) malfunctions, the power window control system enters fail-safe mode. The remote up and down and auto up and down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the power window regulator switch assembly (for rear LH side) at the auto up position, and opened manually by pushing down the power window regulator switch assembly (for rear LH side).
Scheme 123
When the hybrid vehicle control system is running or the power switch is on (IG), the power window regulator motor assembly (for rear RH side) is operated by the power window regulator switch assembly (for rear RH side). The power window regulator motor assembly (for rear RH side) has motor, regulator, and ECU functions.
HINT
If the pulse sensor built into the power window regulator motor (for rear RH side) malfunctions, the power window control system enters fail-safe mode. The remote up and down and auto up and down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the power window regulator switch assembly (for rear RH side) at the auto up position, and opened manually by pushing down the power window regulator switch assembly (for rear RH side).
Scheme 124
If the manual up and down functions operate normally but the auto up and down functions do not, then the fail-safe mode may be functioning.
If the power window initialization. Refer to INITIALIZATION has not been performed, the auto up and down functions will not operate.
Scheme 125
If the manual up and down functions operate normally but the auto up and down functions do not, the fail-safe mode may be functioning.
If power window initialization. Refer to INITIALIZATION has not been performed, the auto up and down functions will not operate.
Scheme 126
If the manual up and down functions operate normally but the auto up and down functions do not, the fail-safe mode may be functioning.
If power window initialization. Refer to INITIALIZATION has not been performed, the auto up and down functions will not operate.
Scheme 127
If the manual up and down functions operate normally but the auto up and down functions do not, the fail-safe mode may be functioning.
If power window initialization. Refer to INITIALIZATION has not been performed, the auto up and down functions will not operate.
Scheme 128
- When a key switch is pushed: 1) the door control receiver assembly receives the key signal; 2) the door control receiver assembly sends a signal to the certification ECU (smart key ECU assembly); 3) the main body ECU (multiplex network body ECU) sends the operation permission signal to the power window regulator motor assembly; and 4) the power window regulator motor assemblies are activated.
- When the driver door key cylinder (key linked switch) is turned: 1) the door lock motor receives the signal; 2) the main body ECU (multiplex network body ECU) sends the signal to the power window regulator motor assembly; and 3) the power window regulator motor assemblies are activated.
- When the front doors are closed, each power window regulator motor assembly can control its power window operation for approximately 43 seconds after the power switch is turned from on (IG) to off by receiving operation permission signals from the main body ECU (multiplex network body ECU).
- However, when approximately 43 seconds have elapsed, or the driver side door or front passenger side door is opened within approximately 43 seconds of the power switch being turned off, the power window regulator motor assembly stops operating.
- During an auto operation, when 43 seconds have passed and key-off operation is prohibited, the window operation stops immediately.
If a door glass or a power window regulator motor assembly does not operate smoothly, the jam protection function may be triggered automatically, resulting in the auto up function being unable to fully close the window.
HINT
This symptom may occur for any of the windows.
This symptom may occur for any of the windows.
The jam protection function operates within a specified range during the manual up or auto up operation.
