INSTALLATION

  1. INSTALL OIL WITH MOTOR PUMP ASSEMBLY Install the oil with motor pump assembly with the 2 bolts. Torque: 16 N*m (163 kgf*cm, 12 ft.*lbf) Connect the connector, 2 clamps, No. 1 motor cooling hose and No. 2 motor cooling hose.
  2. INSTALL INTAKE AIR RESONATOR Install the intake air resonator with the 3 bolts and nut. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf) Connect the No. 2 air cleaner inlet to the No. 1 air cleaner inlet.
  3. INSTALL FRONT BUMPER ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-398259-S22402231542011051600000)
  4. INSTALL HOOD CENTER CUSHION . Refer to «INSTALLATION - Step 2»(ref-398259-S22402231542011051600000)
  5. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION - Step 3»(ref-398259-S22402231542011051600000)
  6. ADD HYBRID TRANSAXLE FLUID See step 2
  7. INSPECT AND ADJUST HYBRID TRANSAXLE FLUID See step 3
  8. ADD WASHER FLUID (w/ Headlight Cleaner System) . Refer to «INSTALLATION - Step 2»(ref-398237-S13510395882011051600000)
  9. ADJUST FOG LIGHT AIMING . Refer to «INSTALLATION - Step 5»(ref-398259-S22402231542011051600000)

Scheme 66

Scheme 66: ILLUSTRATION
Scheme 66: ILLUSTRATION

Scheme 67

Scheme 67: ILLUSTRATION
Scheme 67: ILLUSTRATION

REPLACEMENT

HINT

  1. Use the same procedure for the RH side and LH side.
  2. The procedure listed below is for the LH side.

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71
  1. REMOVE FRONT WHEELS
  2. REMOVE REAR ENGINE UNDER COVER LH
  3. DRAIN HYBRID TRANSAXLE FLUID See step 1
  4. SEPARATE FRONT SPEED SENSOR . Refer to «REMOVAL - Step 3»(ref-398256-S30923904202011051600000)
  5. SEPARATE FRONT FLEXIBLE HOSE . Refer to «REMOVAL - Step 5»(ref-398256-S30923904202011051600000)
  6. SEPARATE TIE ROD END SUB-ASSEMBLY . Refer to «REMOVAL - Step 14»(ref-398255-S11225442242011051600000)
  7. REMOVE FRONT AXLE SHAFT NUT . Refer to «REMOVAL - Step 9»(ref-398256-S30923904202011051600000)
  8. SEPARATE FRONT STABILIZER LINK ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-398256-S30923904202011051600000)
  9. SEPARATE FRONT NO. 1 LOWER SUSPENSION ARM SUB-ASSEMBLY . Refer to «REMOVAL - Step 13»(ref-398256-S30923904202011051600000)
  10. SEPARATE FRONT DRIVE SHAFT ASSEMBLY . Refer to «REMOVAL - Step 15»(ref-398256-S30923904202011051600000)
  11. REMOVE FRONT DRIVE SHAFT ASSEMBLY LH . Refer to «REMOVAL - Step 17»(ref-398256-S30923904202011051600000)
  12. REMOVE FRONT DRIVE SHAFT ASSEMBLY RH . Refer to «REMOVAL - Step 18»(ref-398256-S30923904202011051600000)
  13. REMOVE FRONT DRIVE SHAFT LH HOLE SNAP RING . Refer to «REMOVAL - Step 19»(ref-398256-S30923904202011051600000)
  14. REMOVE HYBRID VEHICLE TRANSAXLE ASSEMBLY TYPE T OIL SEAL Remove the left side oil seal. Using SST, remove the oil seal. SST: 09514-35011 TEXT IN ILLUSTRATION *a Hold *b Turn Remove the right side oil seal. Using SST, remove the oil seal. SST: 09612-30012 TEXT IN ILLUSTRATION *a Hold *b Turn
  15. INSTALL HYBRID VEHICLE TRANSAXLE ASSEMBLY TYPE T OIL SEAL Install a new left side oil seal. Using SST and a hammer, tap in a new oil seal. SST: 09223-15020 SST: 09950-70010 09951-07200 Oil seal driven in depth -0.5 to 0.5 mm (-0.0197 to 0.0197 in.) Coat the lip of the oil seal with MP grease. Install a new right side oil seal. Using SST and a hammer, tap in a new oil seal. SST: 09223-00010 Oil seal driven in depth -0.5 to 0.5 mm (-0.0197 to 0.0197 in.) Coat the lip of the oil seal with MP grease.
  16. INSTALL FRONT DRIVE SHAFT LH HOLE SNAP RING . Refer to «INSTALLATION - Step 1»(ref-398256-S13345297362011051600000)
  17. INSTALL FRONT DRIVE SHAFT ASSEMBLY LH . Refer to «INSTALLATION - Step 2»(ref-398256-S13345297362011051600000)
  18. INSTALL FRONT DRIVE SHAFT ASSEMBLY RH . Refer to «INSTALLATION - Step 3»(ref-398256-S13345297362011051600000)
  19. INSTALL FRONT STABILIZER LINK ASSEMBLY . Refer to «INSTALLATION - Step 4»(ref-398256-S13345297362011051600000)
  20. INSTALL FRONT NO. 1 LOWER SUSPENSION ARM SUB-ASSEMBLY . Refer to «INSTALLATION - Step 6»(ref-398256-S13345297362011051600000)
  21. INSTALL TIE ROD END SUB-ASSEMBLY . Refer to «INSTALLATION - Step 13»(ref-398255-S38291903472011051600000)
  22. INSTALL FRONT SPEED SENSOR . Refer to «INSTALLATION - Step 10»(ref-398256-S13345297362011051600000)
  23. INSTALL FRONT FLEXIBLE HOSE . Refer to «INSTALLATION - Step 12»(ref-398256-S13345297362011051600000)
  24. INSTALL FRONT AXLE SHAFT NUT . Refer to «INSTALLATION - Step 14»(ref-398256-S13345297362011051600000)
  25. ADD HYBRID TRANSAXLE FLUID See step 2
  26. INSPECT AND ADJUST HYBRID TRANSAXLE FLUID See step 3
  27. INSTALL FRONT WHEELS . Refer to «INSTALLATION - Step 18»(ref-398256-S13345297362011051600000)
  28. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT HINT
  29. INSTALL REAR ENGINE UNDER COVER LH
  30. INSPECT ABS SPEED SENSOR SIGNAL HINT

Scheme 72

Scheme 72: ILLUSTRATION
Scheme 72: ILLUSTRATION

Scheme 73

Scheme 73: REPLACEMENT
Scheme 73: REPLACEMENT

Scheme 74

Scheme 74
Scheme 74
  1. REMOVE HYBRID VEHICLE TRANSAXLE ASSEMBLY HINT
  2. REMOVE INPUT SHAFT OIL SEAL Using a screwdriver with the tip taped, remove the oil seal. TEXT IN ILLUSTRATION *a Protective Tape
  3. INSTALL INPUT SHAFT OIL SEAL Coat a lip of a new oil seal with MP grease. Using SST and a hammer, tap in the oil seal. SST: 09388-40010 Oil seal driven in depth 1.0 to 1.8 mm (0.0394 to 0.0709 in.) NOTE: Ensure that no foreign matter adheres to the oil seal lip. Ensure that the oil seal is not at an angle.
  4. INSTALL HYBRID VEHICLE TRANSAXLE ASSEMBLY HINT

Scheme 75

Scheme 75: ILLUSTRATION
Scheme 75: ILLUSTRATION

Scheme 76

Scheme 76: ILLUSTRATION
Scheme 76: ILLUSTRATION

Scheme 77

Scheme 77: ILLUSTRATION
Scheme 77: ILLUSTRATION

Scheme 78

Scheme 78: ILLUSTRATION
Scheme 78: ILLUSTRATION

REMOVAL

Note. If the shift lock control unit assembly is to be replaced with a new one, it is necessary to clear the learned shift sensor voltage value by disconnecting and reconnecting the cable of the negative (-) battery terminal. Refer to PRECAUTION .

Scheme 79

Scheme 79: REMOVAL
Scheme 79: REMOVAL

Scheme 80

Scheme 80
Scheme 80
  1. PRECAUTION (w/ Navigation System) NOTE: After the power switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL - Step 3»(ref-398219-S28362000682011051600000)
  4. REMOVE INSTRUMENT PANEL FINISH PANEL END LH . Refer to «REMOVAL - Step 7»(ref-398252-S24838975742011051600000)
  5. REMOVE INSTRUMENT PANEL FINISH PANEL END RH . Refer to «REMOVAL - Step 8»(ref-398252-S24838975742011051600000)
  6. REMOVE INSTRUMENT CLUSTER FINISH PANEL GARNISH ASSEMBLY (w/o Navigation System) . Refer to «REMOVAL - Step 9»(ref-398252-S24838975742011051600000)
  7. REMOVE REMOTE TOUCH ASSEMBLY (w/ Navigation System) . Refer to «REMOVAL - Step 10»(ref-398252-S24838975742011051600000)
  8. REMOVE CENTER INSTRUMENT PANEL REGISTER ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-398252-S24838975742011051600000)
  9. REMOVE INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY . Refer to «REMOVAL - Step 9»(ref-398277-S40680051002011051600000)
  10. REMOVE FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure as for the LH side. Refer to «REMOVAL - Step 1»(ref-398252-S41672440622011051600000) .
  11. REMOVE FRONT DOOR OPENING TRIM COVER RH HINT: Use the same procedure as for the LH side. Refer to «REMOVAL - Step 2»(ref-398252-S41672440622011051600000) .
  12. REMOVE COWL SIDE TRIM BOARD RH HINT: Use the same procedure as for the LH side. Refer to «REMOVAL - Step 3»(ref-398252-S41672440622011051600000) .
  13. REMOVE INSTRUMENT SIDE PANEL RH . Refer to «REMOVAL - Step 34»(ref-398252-S24838975742011051600000)
  14. REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 35»(ref-398252-S24838975742011051600000)
  15. REMOVE FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY . Refer to «REMOVAL - Step 9»(ref-398090-S05229630012011051600000)
  16. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY . Refer to «REMOVAL - Step 37»(ref-398252-S24838975742011051600000)
  17. REMOVE FRONT CONSOLE BOX COVER . Refer to «REMOVAL - Step 1»(ref-398252-S00212974612011051600000)
  18. REMOVE FRONT CONSOLE UPPER PANEL GARNISH (w/o Seat Heater System) . Refer to «REMOVAL - Step 2»(ref-398252-S00212974612011051600000)
  19. REMOVE FRONT CONSOLE UPPER PANEL GARNISH (w/ Seat Heater System) . Refer to «REMOVAL - Step 3»(ref-398252-S00212974612011051600000)
  20. REMOVE REAR CONSOLE PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 4»(ref-398252-S00212974612011051600000)
  21. REMOVE CONSOLE BOX CARPET . Refer to «REMOVAL - Step 6»(ref-398252-S00212974612011051600000)
  22. REMOVE REAR CONSOLE BOX SUB-ASSEMBLY . Refer to «REMOVAL - Step 7»(ref-398252-S00212974612011051600000)
  23. REMOVE CONSOLE BOX LH . Refer to «REMOVAL - Step 51»(ref-398252-S24838975742011051600000)
  24. REMOVE CONSOLE BOX RH . Refer to «REMOVAL - Step 52»(ref-398252-S24838975742011051600000)
  25. REMOVE CONSOLE BOX . Refer to «REMOVAL - Step 53»(ref-398252-S24838975742011051600000)
  26. REMOVE TRANSMISSION INSTRUMENT PANEL SHIFT ASSEMBLY Remove the 3 nuts and separate the transmission instrument panel shift assembly. Disconnect the 3 connectors to remove the transmission instrument panel shift assembly.
  1. INSTALL TRANSMISSION INSTRUMENT PANEL SHIFT ASSEMBLY Connect the 3 connectors to the transmission instrument panel shift assembly. Install the transmission instrument panel shift assembly with the 3 nuts. Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf)
  2. INSTALL CONSOLE BOX . Refer to «INSTALLATION - Step 6»(ref-398252-S05152107252011051600000)
  3. INSTALL CONSOLE BOX RH . Refer to «INSTALLATION - Step 7»(ref-398252-S05152107252011051600000)
  4. INSTALL CONSOLE BOX LH . Refer to «INSTALLATION - Step 8»(ref-398252-S05152107252011051600000)
  5. INSTALL REAR CONSOLE BOX SUB-ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-398252-S21631923852011051600000)
  6. INSTALL CONSOLE BOX CARPET . Refer to «INSTALLATION - Step 2»(ref-398252-S21631923852011051600000)
  7. INSTALL REAR CONSOLE PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 4»(ref-398252-S21631923852011051600000)
  8. INSTALL FRONT CONSOLE UPPER PANEL GARNISH (w/o Seat Heater System) . Refer to «INSTALLATION - Step 5»(ref-398252-S21631923852011051600000)
  9. INSTALL FRONT CONSOLE UPPER PANEL GARNISH (w/ Seat Heater System) . Refer to «INSTALLATION - Step 6»(ref-398252-S21631923852011051600000)
  10. INSTALL FRONT CONSOLE BOX COVER . Refer to «INSTALLATION - Step 7»(ref-398252-S21631923852011051600000)
  11. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY . Refer to «INSTALLATION - Step 22»(ref-398252-S05152107252011051600000)
  12. INSTALL FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-398090-S14725239612011051600000)
  13. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 24»(ref-398252-S05152107252011051600000)
  14. INSTALL INSTRUMENT SIDE PANEL RH . Refer to «INSTALLATION - Step 25»(ref-398252-S05152107252011051600000)
  15. INSTALL COWL SIDE TRIM BOARD RH HINT: Use the same procedure as for the LH side. Refer to «INSTALLATION - Step 39»(ref-398252-S34916510952011051600000) .
  16. INSTALL FRONT DOOR OPENING TRIM COVER RH HINT: Use the same procedure as for the LH side. Refer to «INSTALLATION - Step 40»(ref-398252-S34916510952011051600000) .
  17. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure as for the LH side. Refer to «INSTALLATION - Step 41»(ref-398252-S34916510952011051600000) .
  18. INSTALL INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY . Refer to «INSTALLATION - Step 5»(ref-398277-S29468340142011051600000)
  19. INSTALL CENTER INSTRUMENT PANEL REGISTER ASSEMBLY . Refer to «INSTALLATION - Step 48»(ref-398252-S05152107252011051600000)
  20. INSTALL INSTRUMENT CLUSTER FINISH PANEL GARNISH ASSEMBLY (w/o Navigation System) . Refer to «INSTALLATION - Step 49»(ref-398252-S05152107252011051600000)
  21. INSTALL REMOTE TOUCH ASSEMBLY (w/ Navigation System) . Refer to «INSTALLATION - Step 50»(ref-398252-S05152107252011051600000)
  22. INSTALL INSTRUMENT PANEL FINISH PANEL END RH . Refer to «INSTALLATION - Step 51»(ref-398252-S05152107252011051600000)
  23. INSTALL INSTRUMENT PANEL FINISH PANEL END LH . Refer to «INSTALLATION - Step 52»(ref-398252-S05152107252011051600000)
  24. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL . Refer to «INSTALLATION - Step 2»(ref-398219-S33566720602011051600000)
  25. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 3»(ref-398219-S33566720602011051600000)
  26. INSPECT SHIFT LEVER Turn the power switch on (READY). Check that all available shift positions can be selected moving the shift lever. HINT: After the shift lever is replaced with a new one, perform the above operation. If this operation is not performed, moving the shift lever may not initially select shift positions.
  27. INSPECT SRS WARNING LIGHT Inspect the SRS warning light. Refer to «DIAGNOSIS SYSTEM»(ref-398246-S08284640642011051600000) .

Scheme 81

Scheme 81: ILLUSTRATION
Scheme 81: ILLUSTRATION

Scheme 82

Scheme 82: REMOVAL
Scheme 82: REMOVAL

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84
  1. REMOVE NO. 1 ENGINE UNDER COVER
  2. REMOVE REAR ENGINE UNDER COVER LH
  3. REMOVE AUTOMATIC TRANSMISSION CASE COVER Disconnect the 2 connectors and clamp. Remove the 2 bolts (A) and 2 oil cooler tube clamps. Remove the 2 bolts (B), clip and automatic transmission case cover.
  4. REMOVE SHIFT CONTROL ACTUATOR ASSEMBLY Using pliers or an equivalent tool, turn the shift control actuator bolt covers counterclockwise and remove the 3 shift control actuator bolts and shift control actuator assembly. TEXT IN ILLUSTRATION *1 Shift Control Actuator Bolt *2 Cover *3 Shift Control Actuator Assembly *4 Transaxle Assembly HINT: Use pliers or an equivalent tool to initially rotate the cover, and then proceed to remove the shift control actuator bolt and cover by pulling the cover towards the front of the vehicle by hand while rotating the bolt counterclockwise. This actuator is a precision instrument. Do not strike it with a plastic hammer or equivalent tool during installation. This actuator detects its own position when a battery is reconnected. Thus it does not require initialization.
  5. REMOVE SHIFT CONTROL ACTUATOR SEAL NOTE: It is not always necessary to replace or remove/install the shift control actuator seal at the same time when replacing the shift control actuator assembly. HINT: Remove/install the shift control actuator seal only if oil leaks from the shift control actuator seal or other faults are found when the shift control actuator assembly is removed. Using a screwdriver with the tip taped, remove the shift control actuator seal. NOTE: When removing the shift control actuator seal, be sure not to damage the case or manual shaft with the screwdriver.

Scheme 85

Scheme 85: INSTALLATION
Scheme 85: INSTALLATION

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87
  1. INSTALL SHIFT CONTROL ACTUATOR SEAL NOTE: It is not always necessary to replace or remove/install the shift control actuator seal at the same time when replacing the shift control actuator assembly. HINT: Remove/install the shift control actuator seal only if oil leaks from the shift control actuator seal or other faults are found when the shift control actuator assembly is removed. Using SST and a hammer, tap in a new shift control actuator seal. SST: 09820-00031 Seal installation depth 8.5 to 9.8 mm (0.335 to 0.386 in.) TEXT IN ILLUSTRATION *a Seal installation depth
  2. INSTALL SHIFT CONTROL ACTUATOR ASSEMBLY Install the shift control actuator assembly with 3 new shift control actuator bolts. Torque: 9.5 N*m (97 kgf*cm, 84 in.*lbf) Install 3 new shift control actuator bolt caps to the shift control actuator bolts. NOTE: Push in each shift control actuator cap firmly until the claw of the shift control actuator bolt cap engages with the control actuator bolt.
  3. INSTALL AUTOMATIC TRANSMISSION CASE COVER Install the automatic transmission case cover with the 2 bolts (B) and new clip. Torque: 12 N*m (120 kgf*cm, 9 ft.*lbf) Install the 2 oil cooler tube clamps with the 2 bolts (A). Torque: 8.2 N*m (84 kgf*cm, 73 in.*lbf) Connect the 2 connectors and clamp.
  4. INSTALL REAR ENGINE UNDER COVER LH
  5. INSTALL NO. 1 ENGINE UNDER COVER

Scheme 88

Scheme 88: ILLUSTRATION
Scheme 88: ILLUSTRATION

Scheme 89

Scheme 89: REMOVAL
Scheme 89: REMOVAL
  1. PRECAUTION (w/ Navigation System) NOTE: After the power switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL - Step 3»(ref-398219-S28362000682011051600000)
  4. REMOVE FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure as for the LH side. Refer to «REMOVAL - Step 1»(ref-398252-S41672440622011051600000) .
  5. REMOVE FRONT DOOR OPENING TRIM COVER RH HINT: Use the same procedure as for the LH side. Refer to «REMOVAL - Step 2»(ref-398252-S41672440622011051600000) .
  6. REMOVE COWL SIDE TRIM BOARD RH HINT: Use the same procedure as for the LH side. Refer to «REMOVAL - Step 3»(ref-398252-S41672440622011051600000) .
  7. REMOVE INSTRUMENT SIDE PANEL RH . Refer to «REMOVAL - Step 34»(ref-398252-S24838975742011051600000)
  8. REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 35»(ref-398252-S24838975742011051600000)
  9. REMOVE FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY . Refer to «REMOVAL - Step 9»(ref-398090-S05229630012011051600000)
  10. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY . Refer to «REMOVAL - Step 37»(ref-398252-S24838975742011051600000)
  11. REMOVE ECU INTEGRATION BOX . Refer to «REMOVAL - Step 11»(ref-398241-S23670282752011051600000)
  12. REMOVE TRANSMISSION CONTROL ECU ASSEMBLY Disengage the 2 claws and remove the transmission control ECU assembly from the ECU integration box. TEXT IN ILLUSTRATION *1 Claw *2 Transmission Control ECU Assembly
  1. INSTALL TRANSMISSION CONTROL ECU ASSEMBLY Engage the 2 claws to install the transmission control ECU assembly to the ECU integration box.
  2. INSTALL ECU INTEGRATION BOX . Refer to «INSTALLATION - Step 2»(ref-398241-S29539901422011051600000)
  3. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY . Refer to «INSTALLATION - Step 22»(ref-398252-S05152107252011051600000)
  4. INSTALL FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-398090-S14725239612011051600000)
  5. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 24»(ref-398252-S05152107252011051600000)
  6. INSTALL INSTRUMENT SIDE PANEL RH . Refer to «INSTALLATION - Step 25»(ref-398252-S05152107252011051600000)
  7. INSTALL COWL SIDE TRIM BOARD RH HINT: Use the same procedure as for the LH side. Refer to «INSTALLATION - Step 39»(ref-398252-S34916510952011051600000) .
  8. INSTALL FRONT DOOR OPENING TRIM COVER RH HINT: Use the same procedure as for the LH side. Refer to «INSTALLATION - Step 40»(ref-398252-S34916510952011051600000) .
  9. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure as for the LH side. Refer to «INSTALLATION - Step 41»(ref-398252-S34916510952011051600000) .
  10. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL . Refer to «INSTALLATION - Step 2»(ref-398219-S33566720602011051600000)
  11. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 3»(ref-398219-S33566720602011051600000)
  12. INSPECT SRS WARNING LIGHT Inspect the SRS warning light. Refer to «DIAGNOSIS SYSTEM»(ref-398246-S08284640642011051600000) .
