Automatic Transaxle (Service Information): Overview Lexus HS I

Automatic Trans 54 illustrations ~3842 words

Scheme 12

Scheme 12: ILLUSTRATION
Scheme 12: ILLUSTRATION

Scheme 13

Scheme 13: ILLUSTRATION
Scheme 13: ILLUSTRATION

Scheme 14

Scheme 14: ILLUSTRATION
Scheme 14: ILLUSTRATION

Scheme 15

Scheme 15: ILLUSTRATION
Scheme 15: ILLUSTRATION

Scheme 16

Scheme 16: ILLUSTRATION
Scheme 16: ILLUSTRATION

Scheme 17

Scheme 17: ILLUSTRATION
Scheme 17: ILLUSTRATION

Scheme 18

Scheme 18: ILLUSTRATION
Scheme 18: ILLUSTRATION

Scheme 19

Scheme 19: ILLUSTRATION
Scheme 19: ILLUSTRATION

Scheme 20

Scheme 20: ILLUSTRATION
Scheme 20: ILLUSTRATION

Scheme 21

Scheme 21: REMOVAL
Scheme 21: REMOVAL

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46
  1. PRECAUTION HINT
  2. PRECAUTION (w/ Navigation System) NOTE: After the power switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  3. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  4. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL - Step 3»(ref-398219-S28362000682011051600000)
  5. REMOVE BATTERY SERVICE HOLE COVER . Refer to «REMOVAL - Step 4»(ref-398232-S04454197092011051600000)
  6. REMOVE SERVICE PLUG GRIP . Refer to «REMOVAL - Step 5»(ref-398232-S04454197092011051600000)
  7. REMOVE HOOD SUB-ASSEMBLY Disconnect the washer hose. Using a screwdriver, remove the 2 stop rings along the groove. HINT: Tape the screwdriver tip before use. TEXT IN ILLUSTRATION *1 Protective Tape Release the 2 ball joints and separate the 2 hood support assemblies from the hood sub-assembly. Remove the 4 bolts and hood sub-assembly.
  8. ALIGN FRONT WHEELS FACING STRAIGHT AHEAD
  9. REMOVE FRONT WHEELS
  10. REMOVE REAR ENGINE UNDER COVER LH
  11. REMOVE REAR ENGINE UNDER COVER RH
  12. REMOVE ENGINE UNDER COVER
  13. REMOVE NO. 1 ENGINE UNDER COVER
  14. REMOVE NO. 2 ENGINE UNDER COVER
  15. DRAIN COOLANT (for Engine) . Refer to «REPLACEMENT - Step 2»(ref-398217-S29765876382011051600000)
  16. DRAIN COOLANT (for Inverter) . Refer to «REPLACEMENT - Step 2»(ref-398232-S31936804272011051600000)
  17. DRAIN HYBRID TRANSAXLE FLUID See step 1
  18. REMOVE FRONT WIPER ARM HEAD CAP . Refer to «REMOVAL - Step 1»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
  19. REMOVE FRONT WIPER ARM AND BLADE ASSEMBLY LH . Refer to «REMOVAL - Step 2»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
  20. REMOVE FRONT WIPER ARM AND BLADE ASSEMBLY RH . Refer to «REMOVAL - Step 3»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
  21. REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 4»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
  22. REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY . Refer to «REMOVAL - Step 5»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
  23. REMOVE WATER GUARD PLATE RH . Refer to «REMOVAL - Step 6»(ref-398212-S03672311542011051600000)
  24. REMOVE NO. 2 HEATER AIR DUCT SPLASH SHIELD SEAL . Refer to «REMOVAL - Step 7»(ref-398212-S03672311542011051600000)
  25. REMOVE COWL BODY MOUNTING REINFORCEMENT RH . Refer to «REMOVAL - Step 8»(ref-398212-S03672311542011051600000)
  26. REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 9»(ref-398212-S03672311542011051600000)
  27. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL - Step 28»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  28. REMOVE NO. 1 ENGINE COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 29»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  29. REMOVE CONNECTOR COVER ASSEMBLY . Refer to «REMOVAL - Step 9»(ref-398232-S32095834502011051600000)
  30. CHECK TERMINAL VOLTAGE . Refer to «REMOVAL - Step 10»(ref-398232-S32095834502011051600000)
  31. TEMPORARILY INSTALL CONNECTOR COVER ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-398232-S32095834502011051600000)
  32. REMOVE NO. 5 INVERTER BRACKET . Refer to «REMOVAL - Step 12»(ref-398232-S32095834502011051600000)
  33. SEPARATE GENERATOR CABLE . Refer to «REMOVAL - Step 13»(ref-398232-S32095834502011051600000)
  34. SEPARATE MOTOR CABLE . Refer to «REMOVAL - Step 14»(ref-398232-S32095834502011051600000)
  35. REMOVE INVERTER RESERVE TANK ASSEMBLY . Refer to «REMOVAL - Step 15»(ref-398232-S32095834502011051600000)
  36. DISCONNECT WATER HOSE . Refer to «REMOVAL - Step 16»(ref-398232-S32095834502011051600000)
  37. REMOVE CONNECTOR COVER ASSEMBLY . Refer to «REMOVAL - Step 17»(ref-398232-S32095834502011051600000)
  38. SEPARATE AIR CONDITIONING HARNESS ASSEMBLY . Refer to «REMOVAL - Step 18»(ref-398232-S32095834502011051600000)
  39. SEPARATE FRAME WIRE . Refer to «REMOVAL - Step 19»(ref-398232-S32095834502011051600000)
  40. TEMPORARILY INSTALL CONNECTOR COVER ASSEMBLY . Refer to «REMOVAL - Step 20»(ref-398232-S32095834502011051600000)
  41. DISCONNECT LOW VOLTAGE CONNECTOR . Refer to «REMOVAL - Step 21»(ref-398232-S32095834502011051600000)
  42. REMOVE INVERTER WITH CONVERTER ASSEMBLY . Refer to «REMOVAL - Step 22»(ref-398232-S32095834502011051600000)
  43. REMOVE AIR CLEANER CAP SUB-ASSEMBLY . Refer to «REMOVAL - Step 44»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  44. REMOVE AIR CLEANER CASE . Refer to «REMOVAL - Step 45»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  45. REMOVE INVERTER BRACKET ASSEMBLY . Refer to «REMOVAL - Step 46»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  46. DISCONNECT NO. 3 RADIATOR HOSE . Refer to «REMOVAL - Step 47»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  47. DISCONNECT NO. 2 RADIATOR HOSE . Refer to «REMOVAL - Step 48»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  48. DISCONNECT NO. 3 INVERTER COOLING HOSE . Refer to «REMOVAL - Step 49»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  49. DISCONNECT NO. 5 INVERTER COOLING HOSE . Refer to «REMOVAL - Step 50»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  50. DISCONNECT OUTLET HEATER WATER HOSE . Refer to «REMOVAL - Step 51»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  51. DISCONNECT INLET HEATER WATER HOSE . Refer to «REMOVAL - Step 52»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  52. DISCONNECT WIRE HARNESS Pull up the lever and disconnect the connector of the hybrid vehicle control ECU. Disconnect the 3 clamps. Disconnect the 2 connectors and 2 clamps from the engine room junction block and disconnect the wire harness. Remove the bolt and disconnect the earth wire. Disconnect the 2 clamps. Disconnect the 4 connectors, 7 clamps and 3 bolts. HINT: When removing clamp A, disengage it from the motor cable. TEXT IN ILLUSTRATION *1 Marking Tape *2 Clamp A *3 Motor Cable Remove the bolt and wire harness bracket. Remove the bolt and heater hose bracket.
  53. DISCONNECT NO. 1 MOTOR COOLING HOSE Disconnect the clamp and No. 1 motor cooling hose. TEXT IN ILLUSTRATION *1 No. 1 Motor Cooling Hose *2 No. 2 Motor Cooling Hose Front Side
  54. DISCONNECT NO. 2 MOTOR COOLING HOSE Disconnect the clamp and No. 2 motor cooling hose.
  55. REMOVE OIL COOLER UNION SUB-ASSEMBLY Remove the bolt and oil cooler tube clamp. Remove the union bolt, gasket and oil cooler union sub-assembly.
  56. REMOVE OIL COOLER INLET TUBE SUB-ASSEMBLY Remove the bolt and oil cooler tube clamp. Using a union nut wrench (17 mm) and a wrench, disconnect the oil cooler inlet tube sub-assembly.
  57. SECURE STEERING WHEEL . Refer to «REMOVAL - Step 2»(/lexus/hs/i-2009-2012/remont/manual-power-steering/#steering-gear-linkage-service-information)
  58. REMOVE COLUMN HOLE COVER SILENCER SHEET . Refer to «REMOVAL - Step 7»(ref-398212-S08004449232011051600000)
  59. SEPARATE NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY . Refer to «REMOVAL - Step 8»(ref-398212-S08004449232011051600000)
  60. SEPARATE NO. 1 STEERING COLUMN HOLE COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 5»(/lexus/hs/i-2009-2012/remont/manual-power-steering/#steering-gear-linkage-service-information)
  61. REMOVE FRONT NO. 3 ENGINE UNDER COVER . Refer to «REMOVAL - Step 3»(/lexus/hs/i-2009-2012/remont/exhaust/#exhaust-service-information)
  62. REMOVE FRONT EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 6»(/lexus/hs/i-2009-2012/remont/exhaust/#exhaust-service-information)
  63. REMOVE FRONT AXLE SHAFT NUT LH . Refer to «REMOVAL - Step 9»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  64. REMOVE FRONT AXLE SHAFT NUT RH HINT: Perform the same procedure as for the LH side.
  65. SEPARATE FRONT SPEED SENSOR LH . Refer to «REMOVAL - Step 3»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  66. SEPARATE FRONT SPEED SENSOR RH HINT: Perform the same procedure as for the LH side.
  67. SEPARATE TIE ROD END SUB-ASSEMBLY LH . Refer to «REMOVAL - Step 14»(/lexus/hs/i-2009-2012/remont/manual-power-steering/#steering-gear-linkage-service-information)
  68. SEPARATE TIE ROD END SUB-ASSEMBLY RH HINT: Perform the same procedure as for the LH side.
  69. SEPARATE FRONT STABILIZER LINK ASSEMBLY LH . Refer to «REMOVAL - Step 8»(ref-398257-S32783650802011051600000)
  70. SEPARATE FRONT STABILIZER LINK ASSEMBLY RH HINT: Perform the same procedure as for the LH side.
  71. SEPARATE FRONT NO. 1 LOWER SUSPENSION ARM SUB-ASSEMBLY LH . Refer to «REMOVAL - Step 13»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  72. SEPARATE FRONT NO. 1 LOWER SUSPENSION ARM SUB-ASSEMBLY RH HINT: Perform the same procedure as for the LH side.
  73. SEPARATE FRONT DRIVE SHAFT ASSEMBLY LH . Refer to «REMOVAL - Step 15»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  74. SEPARATE FRONT DRIVE SHAFT ASSEMBLY RH HINT: Perform the same procedure as for the LH side.
  75. REMOVE FRONT DRIVE SHAFT ASSEMBLY LH . Refer to «REMOVAL - Step 17»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  76. REMOVE FRONT DRIVE SHAFT ASSEMBLY RH . Refer to «REMOVAL - Step 18»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  77. REMOVE FRONT DRIVE SHAFT LH HOLE SNAP RING . Refer to «REMOVAL - Step 19»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  78. INSTALL ENGINE HANGER Install the 2 engine hangers with the 2 bolts. TEXT IN ILLUSTRATION *1 No. 1 Engine Hanger *2 No. 2 Engine Hanger Torque: 38 N*m (387 kgf*cm, 28 ft.*lbf) Part Name Part No. No. 1 engine hanger 12281-28010 or 12281-0H010 No. 2 engine hanger 12282-28010 or 12282-0H010 Bolt 91552-81020 Attach the sling device to the engine hangers and chain block.
  79. REMOVE REAR SIDE RAIL REINFORCEMENT SUB-ASSEMBLY LH . Refer to «REMOVAL - Step 18»(ref-398257-S39431564992011051600000)
  80. REMOVE REAR SIDE RAIL REINFORCEMENT SUB-ASSEMBLY RH HINT: Perform the same procedure as for the LH side.
  81. REMOVE FRONT SUSPENSION MEMBER REAR BRACE LH . Refer to «REMOVAL - Step 21»(ref-398257-S39431564992011051600000)
  82. REMOVE FRONT SUSPENSION MEMBER REAR BRACE RH HINT: Perform the same procedure as for the LH side.
  83. REMOVE FRONT SUSPENSION CROSSMEMBER SUB-ASSEMBLY . Refer to «REMOVAL - Step 23»(ref-398257-S39431564992011051600000)
  84. REMOVE FRONT CROSSMEMBER SUB-ASSEMBLY Remove the 2 bolts and separate the front engine mounting insulator from the front cross member sub-assembly. Remove the 4 bolts and front cross member sub-assembly.
  85. REMOVE FRONT ENGINE MOUNTING INSULATOR . Refer to «REMOVAL - Step 86»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  86. REMOVE REAR NO. 1 ENGINE MOUNTING INSULATOR . Refer to «REMOVAL - Step 87»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  87. SUPPORT HYBRID VEHICLE TRANSAXLE ASSEMBLY Support the hybrid vehicle transaxle assembly with a transmission jack.
  88. REMOVE ENGINE MOUNTING BRACKET LH Remove the bolt and nut, and separate the engine mounting insulator LH. Remove the 4 bolts and engine mounting bracket LH.
  89. REMOVE HYBRID VEHICLE TRANSAXLE ASSEMBLY Remove the 9 bolts and hybrid vehicle transaxle assembly. NOTE: To avoid damage to the knock pins, do not pry the connecting portion of the hybrid transaxle and the engine.
  90. REMOVE FRONT ENGINE MOUNTING BRACKET Remove the 3 bolts and front engine mounting bracket.
  91. REMOVE REAR ENGINE MOUNTING BRACKET Remove the 4 bolts and rear engine mounting bracket.
  92. REMOVE AUTOMATIC TRANSMISSION CASE COVER Disconnect the 2 clamps. Remove the 2 bolts, clip and automatic transmission case cover. Remove the automatic transmission case cover.
  93. REMOVE MOTOR CABLE BRACKET Disconnect the 2 clamps. Remove the 2 bolts and motor cable bracket.

Scheme 47

Scheme 47: INSTALLATION
Scheme 47: INSTALLATION

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58
  1. INSTALL MOTOR CABLE BRACKET Install the motor cable bracket with the 2 bolts. Torque: 8.0 N*m (81 kgf*cm, 71 in.*lbf) Connect the 2 clamps.
  2. INSTALL AUTOMATIC TRANSMISSION CASE COVER Install the automatic transmission case cover. Install the automatic transmission case cover with the 2 bolts and new clip. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf) Connect the 2 clamps.
  3. INSTALL REAR ENGINE MOUNTING BRACKET Install the rear engine mounting bracket with the 4 bolts in several steps. Torque: 45 N*m (459 kgf*cm, 33 ft.*lbf) NOTE: Temporarily tighten bolt A, and then fully tighten the 4 bolts in the order of B, C, D and A.
  4. INSTALL FRONT ENGINE MOUNTING BRACKET Install the front engine mounting bracket with the 3 bolts in several steps. Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf) NOTE: Temporarily tighten bolt A, and then fully tighten the 3 bolts in the order of B, C and A.
  5. SUPPORT HYBRID VEHICLE TRANSAXLE ASSEMBLY Support the hybrid vehicle transaxle assembly with a transmission jack.
  6. INSTALL HYBRID VEHICLE TRANSAXLE ASSEMBLY Make sure that the knock pins are installed on the engine. Install the hybrid vehicle transaxle with the 9 bolts shown in the illustration to the engine. Bolt A Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf) Bolt B Torque: 46 N*m (469 kgf*cm, 34 ft.*lbf) Bolt C Torque: 28 N*m (286 kgf*cm, 21 ft.*lbf) Bolt D Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) NOTE: Do not forcibly pry on the hybrid vehicle transaxle assembly. Do not apply grease either to the spline or to the input shaft. TEXT IN ILLUSTRATION *1 Knock Pin HINT: Bolt Installation Direction Diameter Bolt Length A From transaxle to engine 12 mm (0.472 in.) 55 mm (2.17 in.) B From transaxle to engine 10 mm (0.394 in.) 65 mm (2.56 in.) C From engine to transaxle 8 mm (0.325 in.) 38 mm (1.50 in.) D From engine to transaxle 10 mm (0.394 in.) 32 mm (1.26 in.)
  7. INSTALL ENGINE MOUNTING BRACKET LH Install the engine mounting bracket LH with the 4 bolts. Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf) NOTE: Temporarily tighten bolt A, and then fully tighten the 4 bolts in the order of D, B, C and A. Install the engine mounting insulator LH with the through bolt and nut. Torque: 56 N*m (571 kgf*cm, 41 ft.*lbf) NOTE: When installing the engine mounting insulator, tighten the nut while holding the bolt.
  8. INSTALL REAR NO. 1 ENGINE MOUNTING INSULATOR . Refer to «INSTALLATION - Step 10»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  9. TEMPORARILY TIGHTEN FRONT ENGINE MOUNTING INSULATOR . Refer to «INSTALLATION - Step 11»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  10. INSTALL FRONT CROSSMEMBER SUB-ASSEMBLY Install the front crossmember sub-assembly with the 4 bolts. Torque: 96 N*m (979 kgf*cm, 71 ft.*lbf) Install the front engine mounting insulator to the front crossmember with the 2 bolts. Torque: 95 N*m (969 kgf*cm, 70 ft.*lbf) Tighten the front engine mounting insulator with the bolt and nut. Torque: 145 N*m (1479 kgf*cm, 107 ft.*lbf)
  11. INSTALL FRONT SUSPENSION CROSSMEMBER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 14»(ref-398257-S33610908832011051600000)
  12. INSTALL FRONT SUSPENSION MEMBER REAR BRACE LH . Refer to «INSTALLATION - Step 15»(ref-398257-S33610908832011051600000)
  13. INSTALL FRONT SUSPENSION MEMBER REAR BRACE RH HINT: Perform the same procedure as for the LH side.
  14. INSTALL REAR SIDE RAIL REINFORCEMENT SUB-ASSEMBLY LH . Refer to «INSTALLATION - Step 17»(ref-398257-S33610908832011051600000)
  15. INSTALL REAR SIDE RAIL REINFORCEMENT SUB-ASSEMBLY RH HINT: Perform the same procedure as for the LH side.
  16. REMOVE ENGINE HANGER Remove the 2 bolts and 2 engine hangers. TEXT IN ILLUSTRATION *1 No. 1 Engine Hanger *2 No. 2 Engine Hanger
  17. INSTALL FRONT DRIVE SHAFT LH HOLE SNAP RING . Refer to «INSTALLATION - Step 1»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  18. INSTALL FRONT DRIVE SHAFT ASSEMBLY LH . Refer to «INSTALLATION - Step 2»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  19. INSTALL FRONT DRIVE SHAFT ASSEMBLY RH . Refer to «INSTALLATION - Step 3»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  20. INSTALL FRONT NO. 1 LOWER SUSPENSION ARM SUB-ASSEMBLY LH . Refer to «INSTALLATION - Step 6»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  21. INSTALL FRONT NO. 1 LOWER SUSPENSION ARM SUB-ASSEMBLY RH HINT: Perform the same procedure as for the LH side.
  22. INSTALL FRONT STABILIZER LINK ASSEMBLY LH . Refer to «INSTALLATION - Step 14»(ref-398257-S36721921462011051600000)
  23. INSTALL FRONT STABILIZER LINK ASSEMBLY RH HINT: Perform the same procedure as for the LH side.
  24. CONNECT TIE ROD END SUB-ASSEMBLY LH . Refer to «INSTALLATION - Step 13»(/lexus/hs/i-2009-2012/remont/manual-power-steering/#steering-gear-linkage-service-information)
  25. CONNECT TIE ROD END SUB-ASSEMBLY RH HINT: Perform the same procedure as for the LH side.
  26. INSTALL FRONT SPEED SENSOR LH . Refer to «INSTALLATION - Step 10»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  27. INSTALL FRONT SPEED SENSOR RH HINT: Perform the same procedure as for the LH side.
  28. INSTALL FRONT AXLE SHAFT NUT LH . Refer to «INSTALLATION - Step 14»(/lexus/hs/i-2009-2012/remont/axle-shafts/#drive-shaft-service-information)
  29. INSTALL FRONT AXLE SHAFT NUT RH HINT: Perform the same procedure as for the LH side.
  30. INSTALL FRONT EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 6»(/lexus/hs/i-2009-2012/remont/exhaust/#exhaust-service-information)
  31. INSTALL FRONT NO. 3 ENGINE UNDER COVER . Refer to «INSTALLATION - Step 5»(/lexus/hs/i-2009-2012/remont/exhaust/#exhaust-service-information)
  32. INSTALL NO. 1 STEERING COLUMN HOLE COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 17»(/lexus/hs/i-2009-2012/remont/manual-power-steering/#steering-gear-linkage-service-information)
  33. CONNECT NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY . Refer to «INSTALLATION - Step 4»(ref-398212-S01418807202011051600000)
  34. INSTALL COLUMN HOLE COVER SILENCER SHEET . Refer to «INSTALLATION - Step 5»(ref-398212-S01418807202011051600000)
  35. INSTALL OIL COOLER INLET TUBE SUB-ASSEMBLY Temporarily install a new oil cooler inlet tube sub-assembly to the oil cooler tube union. TEXT IN ILLUSTRATION *1 Oil Cooler Tube Union *2 Oil Cooler Inlet Tube Sub-assembly *3 Oil Cooler Tube Clamp Install the oil cooler tube clamp with the bolt. Torque: 8.2 N*m (84 kgf*cm, 73 in.*lbf) Using a union nut wrench (17 mm), tighten the oil cooler inlet tube sub-assembly while holding the oil cooler union with a wrench. Torque: 34 N*m (347 kgf*cm, 25 ft.*lbf)
  36. INSTALL OIL COOLER UNION SUB-ASSEMBLY Temporarily install the oil cooler union sub-assembly and oil cooler tube clamp with the bolt. Install a new gasket to the oil cooler union sub-assembly. Tighten the union bolt with the oil cooler union sub-assembly stopper pressed against the rib. Torque: 35 N*m (357 kgf*cm, 26 ft.*lbf) TEXT IN ILLUSTRATION *1 Rib *2 Stopper Tighten the oil cooler tube clamp bolt. Torque: 8.2 N*m (84 kgf*cm, 73 in.*lbf)
  37. CONNECT NO. 1 MOTOR COOLING HOSE Connect the No. 1 motor cooling hose with the clamp.
  38. CONNECT NO. 2 MOTOR COOLING HOSE Connect the No. 2 motor cooling hose with the clamp.
  39. INSTALL WIRE HARNESS Install the heater hose bracket with the bolt. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf) Install the wire harness bracket with the bolt. Torque: 19 N*m (194 kgf*cm, 14 ft.*lbf) Connect the wire harness with the 4 connectors, 7 clamps and 3 bolts. Bolt A Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Bolt B Torque: 8.4 N*m (86 kgf*cm, 74 in.*lbf) HINT: When installing clamp A, be sure to align it with the space between the 2 pieces of marking tape on the motor cable. TEXT IN ILLUSTRATION *1 Marking Tape *2 Clamp A *3 Motor Cable Connect the wire harness with the 2 clamps. Connect the earth wire with the bolt. Torque: 8.4 N*m (86 kgf*cm, 74 in.*lbf) Connect the wire harness to the engine room junction block with the 2 clamps. Connect the 2 connectors to the engine room junction block. Connect the wire harness with the 3 clamps. Connect the connector to the hybrid vehicle control ECU with the lock lever.
  40. CONNECT INLET HEATER WATER HOSE . Refer to «INSTALLATION - Step 41»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  41. CONNECT OUTLET HEATER WATER HOSE . Refer to «INSTALLATION - Step 42»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  42. CONNECT NO. 3 INVERTER COOLING HOSE . Refer to «INSTALLATION - Step 43»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  43. CONNECT NO. 5 INVERTER COOLING HOSE . Refer to «INSTALLATION - Step 44»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  44. CONNECT NO. 2 RADIATOR HOSE . Refer to «INSTALLATION - Step 45»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  45. CONNECT NO. 3 RADIATOR HOSE . Refer to «INSTALLATION - Step 46»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  46. INSTALL INVERTER BRACKET ASSEMBLY . Refer to «INSTALLATION - Step 47»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  47. INSTALL AIR CLEANER CASE . Refer to «INSTALLATION - Step 48»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  48. INSTALL AIR CLEANER CAP SUB-ASSEMBLY . Refer to «INSTALLATION - Step 49»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  49. INSTALL INVERTER WITH CONVERTER ASSEMBLY . Refer to «INSTALLATION - Step 2»(ref-398232-S08189663512011051600000)
  50. CONNECT LOW VOLTAGE CONNECTOR . Refer to «INSTALLATION - Step 3»(ref-398232-S08189663512011051600000)
  51. REMOVE CONNECTOR COVER ASSEMBLY . Refer to «REMOVAL - Step 17»(ref-398232-S32095834502011051600000)
  52. CONNECT FRAME WIRE . Refer to «INSTALLATION - Step 5»(ref-398232-S08189663512011051600000)
  53. CONNECT AIR CONDITIONING HARNESS ASSEMBLY . Refer to «INSTALLATION - Step 6»(ref-398232-S08189663512011051600000)
  54. INSTALL CONNECTOR COVER ASSEMBLY . Refer to «INSTALLATION - Step 7»(ref-398232-S08189663512011051600000)
  55. CONNECT WATER HOSE . Refer to «INSTALLATION - Step 8»(ref-398232-S08189663512011051600000)
  56. INSTALL INVERTER RESERVE TANK ASSEMBLY . Refer to «INSTALLATION - Step 9»(ref-398232-S08189663512011051600000)
  57. CONNECT MOTOR CABLE . Refer to «INSTALLATION - Step 10»(ref-398232-S08189663512011051600000)
  58. CONNECT GENERATOR CABLE . Refer to «INSTALLATION - Step 11»(ref-398232-S08189663512011051600000)
  59. INSTALL NO. 5 INVERTER BRACKET . Refer to «INSTALLATION - Step 12»(ref-398232-S08189663512011051600000)
  60. INSTALL SERVICE PLUG GRIP . Refer to «INSTALLATION - Step 1»(ref-398232-S39550488562011051600000)
  61. INSTALL BATTERY SERVICE HOLE COVER . Refer to «INSTALLATION - Step 2»(ref-398232-S39550488562011051600000)
  62. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL . Refer to «INSTALLATION - Step 2»(ref-398219-S33566720602011051600000)
  63. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 3»(ref-398219-S33566720602011051600000)
  64. ADD HYBRID TRANSAXLE FLUID See step 2
  65. ADD COOLANT (for Inverter) . Refer to «REPLACEMENT - Step 3»(ref-398232-S31936804272011051600000)
  66. ADD COOLANT (for Engine) . Refer to «REPLACEMENT - Step 3»(ref-398217-S29765876382011051600000)
  67. INSPECT AND ADJUST HYBRID TRANSAXLE FLUID See step 3
  68. INSPECT FOR COOLANT LEAK (for Inverter) . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-398232-S24475875012011051600000)
  69. INSPECT FOR COOLANT LEAK (for Engine) . Refer to «ON-VEHICLE INSPECTION - Step 1»(/lexus/hs/i-2009-2012/remont/cooling-system-mechanical/#cooling-inspection)
  70. INSPECT FOR EXHAUST GAS LEAK
  71. INSTALL NO. 2 ENGINE UNDER COVER
  72. INSTALL NO. 1 ENGINE UNDER COVER
  73. INSTALL ENGINE UNDER COVER
  74. INSTALL REAR ENGINE UNDER COVER LH
  75. INSTALL REAR ENGINE UNDER COVER RH
  76. INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 22»(ref-398212-S16707862502011051600000)
  77. INSTALL COWL BODY MOUNTING REINFORCEMENT RH . Refer to «INSTALLATION - Step 23»(ref-398212-S16707862502011051600000)
  78. INSTALL NO. 2 HEATER AIR DUCT SPLASH SHIELD SEAL . Refer to «INSTALLATION - Step 24»(ref-398212-S16707862502011051600000)
  79. INSTALL WATER GUARD PLATE RH . Refer to «INSTALLATION - Step 25»(ref-398212-S16707862502011051600000)
  80. INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY . Refer to «INSTALLATION - Step 3»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
  81. INSTALL COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 4»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
  82. INSTALL FRONT WIPER ARM AND BLADE ASSEMBLY RH . Refer to «INSTALLATION - Step 5»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
  83. INSTALL FRONT WIPER ARM AND BLADE ASSEMBLY LH . Refer to «INSTALLATION - Step 6»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
  84. INSTALL FRONT WIPER ARM HEAD CAP . Refer to «INSTALLATION - Step 7»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
  85. INSTALL FRONT WHEELS . Refer to «INSTALLATION - Step 90»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  86. INSTALL HOOD SUB-ASSEMBLY Install the hood sub-assembly with the 4 bolts. Torque: 13 N*m (133 kgf*cm, 10 ft.*lbf) TEXT IN ILLUSTRATION *1 Stop Ring Install the 2 stop rings to the hood support assemblies. Install the 2 hood support assemblies. Check that the 2 hood support assemblies is engaged in the 2 ball joints and it cannot be pulled out. Connect the washer hose.
  87. INSPECT AND ADJUST HOOD SUB-ASSEMBLY HINT
  88. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT HINT
  89. INSTALL NO. 1 ENGINE COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 95»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  90. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION - Step 96»(/lexus/hs/i-2009-2012/remont/mechanical/#engine-mechanical-service-information)
  91. INSPECT ABS SPEED SENSOR SIGNAL HINT: Refer to «TEST MODE PROCEDURE»(ref-398097-S15603599552011051600000) .

Scheme 59

Scheme 59: REPLACEMENT
Scheme 59: REPLACEMENT

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61
  1. DRAIN HYBRID TRANSAXLE FLUID Using a 10 mm hexagon socket wrench, remove the filler plug and gasket. TEXT IN ILLUSTRATION *1 Filler Plug *2 Drain Plug Using a 10 mm hexagon socket wrench, remove the drain plug and gasket. Using a 10 mm hexagon socket wrench, install the drain plug with a new gasket. Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf)
  2. ADD HYBRID TRANSAXLE FLUID Add transaxle fluid until the fluid level reaches the bottom lip of the filler plug opening. NOTE: Keep the transaxle fluid temperature at 5°C (41°F) or higher. Stop the vehicle on a flat road. Recheck the transaxle fluid level after driving when exchanging transaxle fluid. Insufficient or excessive amounts of transaxle fluid may be the cause of some trouble. Reference 4.2 liters (4.4 US qts, 3.7 lmp.qts) Using a 10 mm hexagon socket wrench, temporarily tighten the filler plug with gasket.
  3. INSPECT AND ADJUST HYBRID TRANSAXLE FLUID Put the engine in inspection mode. Refer to «INSPECTION MODE PROCEDURE»(ref-398089-S21258796492011051600000) . After waiting for 1 minute or more, stop the engine. Using a 10 mm hexagon socket wrench, remove the filler plug and gasket. Add transaxle fluid. Check that the fluid level is between 0 to 5 mm (0 to 0.197 in.) from the bottom lip of the transaxle filler plug opening. NOTE: Keep the transaxle fluid temperature at 5°C (41°F) or higher. Stop the vehicle on a flat road. Recheck the transaxle fluid level after driving when exchanging transaxle fluid. Insufficient or excessive amounts of transaxle fluid may be the cause of some trouble. Check for leaks if the quantity of transaxle fluid is low. Using a 10 mm hexagon socket wrench, install the filler plug with a new gasket. Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf)

Scheme 62

Scheme 62: ILLUSTRATION
Scheme 62: ILLUSTRATION

Scheme 63

Scheme 63: REMOVAL
Scheme 63: REMOVAL

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65
  1. DRAIN HYBRID TRANSAXLE FLUID See step 1
  2. REMOVE COOL AIR INTAKE DUCT SEAL . Refer to «REMOVAL - Step 1»(ref-398259-S08115739352011051600000)
  3. REMOVE HOOD CENTER CUSHION . Refer to «REMOVAL - Step 2»(ref-398259-S08115739352011051600000)
  4. REMOVE FRONT BUMPER ASSEMBLY . Refer to «REMOVAL - Step 3»(ref-398259-S08115739352011051600000)
  5. REMOVE INTAKE AIR RESONATOR Disconnect the No. 2 air cleaner inlet from the No. 1 air cleaner inlet. Remove the nut, 3 bolts and intake air resonator.
  6. REMOVE OIL WITH MOTOR PUMP ASSEMBLY Disconnect the No. 1 motor cooling hose, No. 2 motor cooling hose, connector and 2 clamps. Remove the 2 bolts and oil with motor pump assembly.

More articles — Automatic Transaxle (Service Information)
